- Page 1 User’ s Guide Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info OMB-DAQBOARD-500 Series 16-Bit, 200-KHz PCI Data Acquisition Boards OMB-1138-0901 324545A-01...
- Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
- Page 3 Warnings, Cautions, Notes, and Tips Refer all service to qualified personnel. This symbol warns of possible personal injury or equipment damage under noted conditions. Follow all safety standards of professional practice and the recommendations in this manual. Using this equipment in ways other than described in this manual can present serious safety hazards or cause equipment damage.
- Page 4 PDF documents. Note that hardcopy versions of the manuals can be ordered from the factory. CAUTION ® PDF versions of user manuals will automatically Start [Desktop “Start” pull-down menu] ⇒ Programs ⇒ Omega DaqX Software ® is included on your CD. The Reader provides...
-
Page 5: Table Of Contents
Table of Contents OMB-DAQBOARD-500 Series, Installation Guide 1 – Introduction Basic Information …… 1-1 Block Diagram …… 1-2 Board Features …… 1-3 2 – Connections and Pinouts Overview …… 2-1 68-Pin SCSI Type III Connector …… 2-2 Signal Definitions …… 2-3 TB-100 Terminal Connector Option ……... - Page 6 This product requires one of the following Operating Systems: Windows 2000 Windows XP...
-
Page 7: Installation Guide
OMB-DAQBOARD-500 Series This guide tells how to complete the following steps for a successful installation. Step 1 – Install Software …… page 2 Step 2 – Install Boards in Available PCI Bus-Slots …… page 3 Step 3 – Configure Boards ….. page 5 Step 4 –... - Page 8 Reference Notes: Each DaqBoard/500 Series plugs into a PCI bus-slot. Consult your PC owner’s manual as needed. Reference Note: Adobe PDF versions of user manuals will automatically install onto your hard drive as a part of product support. The default location is in the Programs group, which can be accessed from the Windows Desktop.
- Page 9 – Install Boards in available PCI Bus-slots Step 2 IMPORTANT: Software must be installed before installing hardware. Turn off power to, and UNPLUG the host PC and externally connected equipment prior to removing the PC’s cover and installing the DaqBoard. Electric shock or damage to equipment can result even under low-voltage conditions.
- Page 10 7. Refer to the figure at the right. Align the groove in the DaqBoard’s PCI edge-connector with the ridge of the desired PCI slot, and with the PC’s corresponding rear- panel slot. 8. Push the board firmly into the PCI slot. The board will snap into position.
- Page 11 – Configure Boards Step 3 DaqBoard/500 Series Boards have no jumpers or switches to set. Configuration is performed entirely through software. Refer to the following figure and steps to complete the configuration. The numbers in the figure correspond to the numbered steps. 1.
-
Page 12: Test Hardware
Using “Add Device” This method is for users who have accessed the Daq Configuration control panel applet, but have no DaqBoard/500 Series device icon. 1. After accessing the Daq Configuration control panel applet, click on the <Add Device> button (see figure, right). The Select Device Type window will appear. -
Page 13: Introduction
Introduction The DaqBoard/500 and DaqBoard/505 have 16 single-ended or 8 differential analog inputs multiplexed to a 16-bit A/D converter with maximum throughput of 200 kHz, programmable gains of 1, 2, 4 or 8, one counter input channel, two timer output channels, and 24 lines of digital I/O. In addition, DaqBoard/500 includes two clocked DACs. -
Page 14: Block Diagram
Block Diagram DaqBoard/500 Series Block Diagram Introduction DaqBoard/500 Series User’s Manual 947294... -
Page 15: Board Features
Board Features Analog I/O DaqBoard/500 Series boards support 16 single-ended or 8 differential analog inputs multiplexed to a 16-bit A/D converter. The input multiplexer is supported by a 176 element channel gain RAM which allows the board to select gain on a per channel basis and to access channels in any order. The 16-bit A/D has a maximum throughput of 200 kHz. - Page 16 Introduction DaqBoard/500 Series User’s Manual 947294...
-
Page 17: Connections And Pinouts
Connections and Pinouts Overview …… 2-1 68-Pin SCSI Type III Connector …… 2-2 Signal Definitions …… 2-3 TB-100 Terminal Connector Option …… 2-6 External Connections …… 2-7 Always turn the computer power OFF and unplug it before connecting or discon- necting a screw terminal panel or a cable to the PCI card. - Page 18 68-Pin SCSI Type III Pinout Standard 68-Pin SCSCI Type III, Socket (Female) Connector with Orb Signal Description / Comments DACLKIN/ External DAC Clock In or Counter 1. Rising or Falling CNTR1 See Pin 39 [Note Edge Sensitive. ADCLKIN External ADC Clock In See Pin 5 [Note 3] ADTRGOUT/...
-
Page 19: Signal Definitions
SCSI III Pinout Notes (Apply to the preceding table.) Note 1: AOUT 1 (DAC1) applies to DaqBoard/500 only. The clock source of the secondary DAC1 channel may be software command, DAC1 Pacer clock, or Channel 0 clock source. Likewise, the return line (ARET 1) only applies to the DaqBoard/500. - Page 20 Clocks, Triggers, Counters, and Timers ADCLKIN – Uses pin #2 or pin #5. ADCLKIN is the ADC External Pacer Clock Input. This input recognizes TTL level signals and is edge sensitive. The active edge is selectable as either rising or falling. The ADCLKIN signal connection can be made at either pin #2 or pin #5, but NOT both at the same time.
- Page 21 DACLKIN/CNTR1 – Uses pin # 1 or pin # 39 for one of the following two functions. DACLKIN is the External DAC Pacer clock input. This input recognizes TTL level signals and is edge sensitive. The active edge is selectable as either rising or falling. CNTR1 is the general purpose Counter 1 clock input.
-
Page 22: Tb-100 Terminal Connector Option
TB-100 Terminal Connector Option The TB-100 Terminal Connector option can be used to connect all signal I/O lines that are associated with a DaqBoard/500 or /505. TB-100 can connect to either board’s 68- pin SCSI III connector via a 3 ft., 68-conductor cable (CA-55 or the shielded CA-56); or via a 6 ft. -
Page 23: External Connections
TB-100 Notes (Apply to the preceding table.) Note 1: Digital Common Pins on the SCSI III connector are: 35, 36, and 40. Note 2: Analog Common Pins on the SCSI III connector are: 24, 27, 29, 32, 59, 64, and 67. Note 3: References are not provided for DaqBoard/500 Series devices. - Page 24 Signal Types Floating Sources A Floating Source is a signal that has no connection to the building's power ground. Examples of Floating Sources are thermocouples, batteries and battery powered devices, and signals from optically isolated devices. When connecting Floating Sources to a data acquisition board, the ground reference of the signal must be tied to the analog ground (AGND) in order to establish a common reference point.
- Page 25 Differential (DIFF) In installations where each Ground Referenced Source signal has a local ground [signals located remote from one another] the Differential configuration must be used. Since the Differential configuration only responds to the difference in a signal between its high and low voltages, any Common Mode Voltage will be cancelled out. In addition, Differential configuration provides the best performance of the two configurations in an electrically noisy environment.
- Page 26 Differential for Floating Signal Sources Floating Signal Sources are typically wired to a data acquisition board in Single-Ended configuration. However, when the Floating Source signal leads pass through an electrically noisy environment, Differential configuration will give the best performance. When wiring Floating Signal sources in Differential configuration, a resistor can be connected from the low side of the sources to analog ground (AGND).
-
Page 27: Configuration
Configuration Configuration through Software DaqBoard/500 Series boards have no hardware jumpers or switches. All data-acquisition settings such as analog input, data collection rates, input voltage range, and operating modes are configured through application software. A DaqView software driver provides an application level software interface to Windows NT, 2000, and XP. -
Page 28: Dac Ranges
DAC Ranges The output range of the DaqBoard/500 DACs [DAC0 and DAC1] can be independently set to either ±10 V, or 0 to 10 V. The following table indicates the maximum resolution for each range. Note that resolution is not accuracy. Resolution defines the minimum definable voltage increment. -
Page 29: Software And Board Operation
Software and Board Operation Overview …… 4-1 Out-of-the-Box Drivers for Third-party, Icon-driven Software …… 4-2 DaqCOM Driver …… 4-2 Theory of Operation …… 4-3 Overview DaqBoard/500 Series boards have several software options. Three types of software are available: Out-of the-box graphical programs, e.g., DaqView, ViewXL, and post acquisition data analysis programs such as eZ-PostView, eZ-TimeView, and eZ-FrequencyView. -
Page 30: Drivers For Third-Party, Icon Driven Software
Reference Notes: The software documents: DaqView, ViewXL, and Post Acquisition Data Analysis User’s Guide, are available in PDF version. During software installation, Adobe install onto your hard drive as a part of product support. The default location is in the Programs group, which can be accessed from the Windows Desktop. -
Page 31: Theory Of Operation
Theory of Operation Process Definitions In order to best understand how to operate the various board functions, it is important to first understand the language that will be used to describe the board processes. The following is a list of pertinent terms and definitions used in this document. - Page 32 ADC and DAC Trigger This is the signal or impetus that initiates or terminates an Acquisition. Essentially the Trigger Starts or Stops the ADC or DAC PACER Clock. ADC Channel Configuration RAM Configuration lookup table. The length of this table can be anywhere from 1 element to 176 elements. When an ACQUISITION is in process, the board will sequentially go through this list to determine the channel and gain setting for the next conversion.
- Page 33 Starting (Triggering) an ADC Acquisition There are several methods that can be used to initiate an acquisition, all of these are achieved by triggering or gating the ADC clock as mentioned previously. Note that a trigger is an edge active event and a gate is a level controlled enable.
- Page 34 Stopping an ADC Acquisition (CLOCK) Typical ways of halting an acquisition involve use of one of the following: Software External Gate (ADTRGIN) External Trigger (ADTRGIN) ADC Software The acquisition can be stopped by software control. ADC External Gate An ADC clock may also be “switched off” with the external trig/gate input (ADTRGIN). Refer to the section entitled ADC External Gate (on page 4-5 ) for additional information about this mode.
- Page 35 Clocking the DAC The DaqBoard/500 includes two DAC channels. The clock source of the primary DAC0 channel may be any of the following: DAC0 Pacer Clock External Event (DACLKIN). The clock source for the secondary DAC1 channel is limited to the following sources: DAC1 Pacer Clock Channel 0 Clock Source.
- Page 36 Software and Board Operation DaqBoard/500 Series 988994...
-
Page 37: Ce-Compliance
CE-Compliance Overview ……5-1 CE Standards and Directives …… 5-1 Safety Conditions ……5-2 Emissions/Immunity Conditions ……5-2 Overview CE standards were developed by the European Union (EU) dating from 1985 and include specifications both for safety and for EMI emissions and immunity. Now, all affected products sold in EU countries must meet such standards. -
Page 38: Safety Conditions
For clarification, terms used in some Declarations of Conformity include: • pollution degree: any addition of foreign matter, solid, liquid or gaseous (ionized gases) that may produce a reduction of dielectric strength or surface resistivity. Pollution Degree I has no influence on safety and implies: the equipment is at operating temperature with non-condensing humidity conditions;... -
Page 39: Specifications
Specifications A digital calibration method is used for both analog-to-digital and digital-to-analog conversions. Please contact the factory should you believe your board to be in need of calibration. General Function: High speed, 16 channel multiplexed 16 Bit Analog-to-Digital converter (ADC) with programmable gain, and 24 digital I/O lines for PC compatibles. - Page 40 Signal to Noise and Distortion: S/(N+D) 73 dB min. @ gain = 1 Total Harmonic Distortion: 80 dB (typical) @ gain = 1, measured to 5th harmonic Full Power Bandwidth: 1 MHz Input Impedance Shunt Res. to Ground: 10 M ohm Shunt Capacitance: 28 pf...
- Page 41 Analog Outputs DaqBoard/500 Only Channels Resolution: Output Voltage Ranges: Settling time to 0.006% of FSR: Differential Linearity: Accuracy: Data Storage: Clock/Update Sources: Max update rate/channel Waveform Triggering: Output Current: Digital Inputs / Outputs Channels Ports I/O Direction Select: Input Level: High Level Input Voltage: Low Level Input Voltage: High Level Output...
- Page 42 Counter – 1 Counter designated as CNTR1 Channels Pin Connections: SCSI-68 TB-100 (Option) Input Delay: Max. Count Max. Input Frequency: Input Levels: High Level Input Voltage: Low Level Input Voltage: Timers (Frequency Pulse Generators) – Channels Pin Connections: TMR0 SCSI-68 TB-100 (Option) TMR1 SCSI-68...
- Page 43 Glossary Acquisition A collection of scans acquired at a specified rate as controlled by the sequencer. Analog A signal of varying voltage or current that communicates data. Analog-to-Digital A circuit or device that converts analog values into digital values, such as binary bits, for use in Converter (ADC) digital computer processing.
- Page 44 Differential mode Differential mode voltage refers to a voltage difference between two signals that are referenced voltage to a common point. Example: Signal 1 is +5 VDC referenced to common. Signal 2 is +6 VDC referenced to common. If the +5 VDC signal is used as the reference, the differential mode voltage is +1 VDC (+ 6 VDC - +5 VDC = +1 VDC).
- Page 45 Notes:...
- Page 46 Notes:...
- Page 47 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
