2 Operation

2.1 Operating the door phone

2.1.1 Robin SV with piëzo button(s)
Press the bell-sign on the Robin SV to dial the predefined destination. The intercom will play a
ringing sound and the predefined phone set will be called.

2.1.2 Robin SV with Keypad

The Robin SV with Keypad has 16 keys.
 Keys 1, 2, 3, 4, 5, 6, 7, 8, 9 and 0: use these keys to enter the desired preset, followed by
the green call button
 Green call button: start calling the just entered preset
 Red disconnect button: disconnect the call
 The 'i'-key: call a preconfigured preset, for example the reception desk
 The 'C'-key: clear the input
 The '*'- and '#'-key: used for entering a PIN code
The Robin SV provides a phone book where the Administrator configures "presets". A preset is in
fact an "alias" and refers for instance to: an apartment number, a tenant, or a department within a
large corporation. For each preset defined in the Robin SVs phonebook you can assign up to three
phone numbers, an e-mail address (optional for Picture to e-mail) and a PIN code (optional) that
will activate the built-in door-opener relay. By dialing the preset number on the intercom it will
start calling phone number one. If the first number is engaged or not answering it will continue
wit the second number. If the second number is engaged or not answering it will continue wit the
third number. It also features a 'i-button' on the Keypad. This button can be programmed to dial a
predefined preset, for instance the reception or building manager.
Other Keypad specific settings can be changed in the menu -Telephony-Call settings-General-.

2.2 Answering

You answer a call initiated by the Robin SV by answering the phone that is being called. In case
you use a H.264 compatible videophone or softphone, live video is displayed on the screen of the
receiving telephone set.

2.3 Controlling the built-in door opener

The built-in door opener is controlled with predefined keys on the phone set that answers the call.
When you activate the door opener, the attached door, fence or barrier will open.
