5.2.1.2 Telephony / Phonebook

Multiple telephone numbers can be entered in the phone book. These can be used as input
elsewhere, for example when setting up 'Schedules'.
A 'Profile' can be associated with each 'Phonebook entry'. A 'Profile' is a set of audio and video
settings. This allows definition of individual settings for each specified telephone number.
When using a Robin SV Keypad, an extra menu will be visible, called 'Preset'. Within the 'Preset'
menu you can create a list with presets. Every preset can contain up to three phone numbers, for
instance a fixed phone, a mobile phone and an extra phone. As soon as a preset is chosen using
the Keypad, the intercom will first try to connect to the first number. If the first number is engaged
or not answering it will continue wit the second number. If the second number is engaged or not
answering it will continue wit the third number. Each preset can also contain an e-mail address and
a PIN code. The e-mail address can be used for sending an e-mail containing a photo of the person
using the intercom. The PIN code (6 digits long) can be used to open the door.
Phonebook:
The green '+' creates a new line.
The '>>' behind a line opens the details for this line.
The red X behind a line deletes the line from the list.
 Description
 Number
 Profile
 Allow register
gf22
The name that is associated with this number
The value entered for the telephone number (see
comment)
If required, you can select a 'Profile' for this number
Select this option if the Robin SV has to support a
'Peer to Peer' connection with a phone set (*)
