6 Trace measurement

To evaluate the trace capability, FME made various measurements using different options.
The test configuration and the results can be found in this chapter.

6.1 System configuration

Multi v5.0.5
STP Green Hills Probe v3.3 , Firmware built Apr 10 2008
Trace clock 82.69 Mhz
(JTAG) clock 5 Mhz

6.2 Test program

int main (void)
{
/* temporary storage */
int i;
volatile unsigned long * ulpRegWrite1;
volatile unsigned long * ulpRegWrite2;
volatile unsigned long ulReg;
printf("Trace Measurement running!\n");
/* read and write DDR-RAM */
ulpRegWrite1 = 0x47000000UL;
for( i = 0x46000000; i < 0x46001000; i+=4)
{
ulReg = *(volatile unsigned long*)i;
*ulpRegWrite1 = ulReg;
ulpRegWrite1++;
}
/* read and write SRAM */
ulpRegWrite1 = 0x01000000UL;
ulpRegWrite2 = 0x01008000UL;
i = 0;
for( ulpRegWrite1 = 0x01000000UL; ulpRegWrite1 < 0x01008000UL;
ulpRegWrite1++,ulpRegWrite2++ )
{
*ulpRegWrite1 = i++;
*ulpRegWrite2 = *ulpRegWrite1;
}
return 0;
}
