Summary of Contents for MB QUART SS100.4
- Page 2 Basic D-Class mono amplifier application Features and Specifications...11 Setting Up Systems After Installation For Best Performance...12 Troubleshooting and Diagnostics...13 Product Warranty...14 The contents of this manual may not be reproduced or copied with out the written consent of MAXXSONICS USA, Inc. PAGE...
-
Page 3: General Installation Procedure
GENERAL INSTALLATION PROCEDURE System Design The success of any car stereo system relies on several factors, such as the system design, execution of the installation, and system setup. Please remember that any system is only as good as its weakest link. Please remember that higher power systems are not necessarily useful purely for high sound pressure levels, but also to establish a headroom capability, to reproduce musical peaks cleanly without distortion. -
Page 4: Amplifier Feature Descriptions
-In the LPF position, the HIGH PASS filter acts as a subsonic filter. -When the LPF mode is selected, a 0 to +12dB, at 45Hz, BASS -EQ is also switched in. SS75.4 / SS100.4 4-CHANNEL AMPLIFIERS CHANNEL 3 / 4 LEVEL BASS EQ HPF... - Page 5 AMPLIFIER FEATURE DESCRIPTIONS SUPER SPORT AMPLIFIERS: LINE INPUT: Accepts unbalanced RCA inputs from 0.2 volts to 9 volts. LINE OUTPUT: The unbalanced RCA outputs are set the same as the CROSSOVER switch on he top mount control. BALANCED INPUT: Accepts balanced line inputs from 0.4 volts to 12 volts for the optional MMBLD-1 balanced line driver.
- Page 6 SS75.2 / SS125.2 / 2 CHANNEL AMPLIFIER APPLICATIONS FULL RANGE STEREO This is the most basic application for the SUPER SPORT Series 2 channel amplifiers. 1. Interconnect cable checklist: Connect the LINE INPUTS to the Radio/CD with good quality RCA cables. 2.
- Page 7 SS75.2 / SS125.2 2-CHANNEL AMPLIFIER APPLICATIONS Stereo high pass with mono low-pass in a 2 way active, or bi-amplified system In this application we will use a 2 channel amplifier for the high frequencies, and a second one for the low frequencies, or mono sub bass. Please consult the speaker specifications to determine maximum amplifier power requirements.
- Page 8 SS75.4 / SS125.4 / 4 CHANNEL AMPLIFIER APPLICATIONS 4 CHANNEL FULL RANGE SYSTEM Here we show how to use the 4 channel amplifiers as straight forward discrete 4 channel full range units. Interconnect cable checklist: - Connect the four inputs of the amplifier to a Radio/CD with quality RCA cables. Switch setting checklist: - 1/2CH X-OVER: FULL - 3/4CH X-OVER: FULL...
- Page 9 SS75.4 / SS125.4 / 4 CHANNEL AMPLIFIER APPLICATIONS 2 way active, or bi-amplified system with mono bass This application shows how easily a 2 way active system can be implemented using a 4 channel amplifier. Channels 1 and 2 will be used for highs, and channels 3 and 4 for mono bass.
- Page 10 SS500.1 / SS7500.1 / MONO AMPLIFIER APPLICATIONS Basic application These sub bass amplifiers can be used in any of the bi-amplification systems described in this manual, replacing the 2 channel amplifiers as per the illustrations. Interconnect cable checklist: Connect the inputs to a suitable source, e.g. a head unit with good quality RCA cables.
- Page 11 SS1000.1D / SS1500.1D / MONO AMPLIFIER APPLICATIONS Basic application These sub bass amplifiers can be used in any of the bi-amplification systems described in this manual, replacing the 2 channel amplifiers as per the illustrations. Interconnect cable checklist: Connect the inputs to a suitable source, e.g. a head unit with good quality RCA cables.
- Page 12 SS1900.1D MONO AMPLIFIER APPLICATIONS BASIC APPLICATION The 1 channel mono amplifiers are capable of 4, 2 & 1 Ohms loads and can be used in any of the “bi-amplifier” systems described in the full range amplifier directions. SINGLE AMP INSTALLATION PROCEDURE: 1.
-
Page 14: Setting Up Systems After Installation For Best Performance
SETTING UP SYSTEMS AFTER INSTALLATION FOR BEST PERFORMANCE SS75.2 / SS125.2 / SS75.4 / SS125.4 General: At this point you are ready to get more specific on the settings for your amplifier. High Pass: -When in Hi Pass operation, this setting acts as a low frequency cut off for your system reproduction. The point that you set it at cuts off any frequencies from reproduction beyond this point. - Page 15 TROUBLESHOOTING A SYSTEM The key to finding the problem in a misbehaving sound system is to isolate parts of that system in a logical fashion to track down the fault. Description of the PROTECT system built into all Autotek amplifiers The diagnostic system will shut down the amplifier, until reset by turning the head unit off, and back on.
- Page 16 As the manufacturer of Maxxsonics, Autotek, Crunch, MB Quart and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
