Intrepid
II Wood Burning Stove
®
Installation and Operating Manual
Model 1990CE
SAFETY NOTICE: IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, OPERATED AND MAIN-
TAINED, A HOUSE FIRE MAY RESULT.
TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. FAILURE TO
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN
DEATH. CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
Do Not Discard This Manual: Retain for Future Use
For use in Europe
0966
Intrepid Cover
11/00
30003840 08/17 Rev. 15

Advertisement

loading

Related Manuals for Vermont Castings Intrepid II

Summary of Contents for Vermont Castings Intrepid II

  • Page 1 Intrepid II Wood Burning Stove ® Installation and Operating Manual Model 1990CE For use in Europe SAFETY NOTICE: IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, OPERATED AND MAIN- 0966 TAINED, A HOUSE FIRE MAY RESULT. Intrepid Cover TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. FAILURE TO 11/00 FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.

  • Page 2: Table Of Contents

    Congratulations on your choice of a Vermont Castings Intrepid II. With this purchase, you made a commitment to make the hearth a place of warmth, beauty and comfort in your home. At Vermont Castings Group, we share that joy and ap- preciation of the hearth, and we show it in all our cast iron stoves and fireplaces.

  • Page 3: Specifications

    460 mm (18") 540 mm (21¹⁄₄") 610 mm 640 mm (24") (25¹⁄₄") 520 mm (20¹⁄₂") Top exit flue collar height 180 mm (7¹⁄₈") 545 mm (21¹⁄₂") 350 mm (13³⁄₄") Fig. 1 Intrepid II 1990CE dimensions. 3840 30003840 Intrepid EU specifications 7/06...

  • Page 4: Installation

    An outside air supply is not affected by pressure variations from combustible material to meet all clearance within the house, and improved stove performance often requirements. results. An Outside Air Adaptor Kit for the Intrepid II is avail- • able from your local Vermont Castings dealer. The floor protector is large enough and is constructed properly to meet all requirements.
  • Page 5 The whole connector should be exposed and accessible Chimney Size for inspection and cleaning. An Intrepid II is approved for venting into a masonry chimney In horizontal runs of single-wall chimney connector without with a maximum flue size of 200 x 200 mm (8" x 8"), and protective shields, maintain a clearance of at least 660 mm into a round flue size of 150 mm (6").
  • Page 6 Beginning at the flue collar of the stove, assemble the chimney connector. Insert the first crimped end into the For masonry chimneys, both freestanding and fireplace stove’s flue collar, and keep chimneys may be used for installation of your Intrepid II. each crimped end pointing Freestanding Chimney Installations toward the stove. Using the holes in the flue collar If the chimney connector must pass through a combustible as guides, drill 3 mm (1/8")
  • Page 7 Fireplace Chimney Installations - If your fireplace height is at least 635 mm (25"), you may Above a Fireplace install an Intrepid II with standard legs through the fireplace opening using a “positive connection” kit available from The Intrepid II may be connected to a chimney above a your local dealer. These positive connection kits ensure a fireplace opening also. In such installations, the stove is tight fit between the stove flue collar and the chimney flue. positioned on the hearth in front of the fireplace and the (Fig.
  • Page 8 Your local dealer or your local building inspector can provide details for other approved methods of passing a chimney connector through a combustible wall in your area. DO NOT CONNECT AN INTREPID II TO ANY AIR DIS- TRIBUTION DUCT OR SYSTEM. Hearths...

  • Page 9: Clearances

    Intrepid II Wood Burning Stove ® Costructional Hearth Dimensions as below At least 150 mm or to a suitable heat resistant wall Appliance Appliance Doors Doors Hearth Surface Free of Com- At least bustible Material 150 mm Perimeter should be Perimeter should be clearly marked e.g.
  • Page 10 Intrepid II Wood Burning Stove ® Minimum distance from stove to movable combustible materials (e.g. furniture, drying clothes, etc.) 760 mm (30"). Connecting Flue Pipe - Clearances Single wall connecting fluepipes can reach extremely high temperatures; therefore, clearances from the connecting fluepipe (chimney connector) must comply with the require- ments of Part J of Building Regulations 2000 (Combus- tion Appliances and Fuel Storage Systems).

  • Page 11: Assembly

    Intrepid II Wood Burning Stove ® Assembly Clean the Griddle Before Use At the factory the griddle is coated with vegetable oil to prevent rusting while the stove is in transit and storage. ⁄ " Remove the oil with a dry rag or paper towel before you use the stove.

  • Page 12: Operation

    You can set the lever anywhere in between the left and right extremes. (Fig. 19) The Intrepid II features an automatic thermostat to ensure an even heat output at any setting you select. The thermostat senses the heating and cooling of the stove surface and adjusts the air shutter accordingly.
