Vermont Castings Defiant 0019 Installation Instructions

Hide thumbs

Preparation
1. Remove all accessories from inside the stove; lift off
the griddle, load door and front doors.
Defiants and Vigilants shipped from the factory have a
wooden wedge inside the stove to hold the damper
closed during shipment. Leave this wedge in place
Bottom Heat Shield
until after the legs are installed.
2. With assistance, remove the stove from the pallet
Installation Instructions
and place it close to its installed location. If your
stove has a porcelain enamel finish, use a piece of
For the Defiant* (Models
cardboard or a drop cloth to cushion the ash lip and
top plate.
0019/0027**), Vigilant*,
3. If the stove is already installed, disconnect the chim-
ney connector.
Resolute, Intrepid and
4. Tilt the stove into a secure reclining position. It will
require at least two people to tilt the stove and a
Intrepid II
third to steady it from the front.
For the Defiant, Vigilant and Resolute, tilt the stove
Please read these instructions completely before
forward over the ash lip until the top plate rests on
you begin the installation.
the floor.
*NOTE: Defiant and Vigilant Owners - These instruc-
For the Intrepid and Intrepid II, tilt the stove back to rest
tions are for stoves purchased after March 1, 1980.
on the pallet or wooden blocks.
Contact your Vermont Castings' Authorized Dealer to
One-half inch screws were installed in the leg bolt holes
obtain the correct instructions and hardware for stoves
to stabilize the stove during shipment. Remove and
purchased before March 1, 1980.
discard them. The appropriate leg bolts are packed
Bottom heat shields must be used unless the stove is
with the stove legs.
to be situated on a completely noncombustible hearth,
Attach the Legs
such as unpainted concrete over earth.
Attach the legs to the stove loosely using one washer
Clean all heat shields as needed (or at least annually)
per leg. They will be tightened firmly later in the instal-
so they will continue to reflect heat adequately. In ad-
lation.
dition, check all leg bolts annually to be sure they are
secure. For complete information on floor protection,
For all stoves except the Vigilant, use the silver-colored
refer to the installation section of your Owner's Manual.
3/8" x 1" leg bolts. For Vigilants, use the silver-colored
Tool needed: Open end wrench, 9/16"
3/8" x 1¹⁄₄" bolts.
Materials Provided:
Standard Legs
All Stoves: Bottom heat shield (1), C-brackets (4), 1/4-
20 x 1/2" wing screws (4)
Short Legs
Defiant / Vigilant: Bottom heat shields (2), C-brackets
(4), 1/4-20 x 2" threaded studs (4), 3/8" spacers (4), hex
nuts (4), wing nuts (4)
Resolute / Intrepid / Intrepid II: Bottom heat shields
Handle Holder
(1), C-brackets (4), 1/4-20 x 1/2" wing screws (4)
Bottom Heat Shield
**Not applicable to Defiant Model 1910, which has glass pan-
C-bracket
els in its front doors. Defiant Models 0019 and 0027 do not
have glass panels.
ST514
Wing Screw
Fig. 1 Rotate the two fornt C-brackets so that they slide over
the leg bolts between the washer (or handle holder) and the
legs.
2005095 8/08 Rev. 13
ST514
Bottom heat shield
& clips
11/00
