- Page 1 12th, Mar. 2021 Ver.1 GPD Premium-1 Engineering team “SPK611/8500E2” HDMI 8K Upgrade Kit for AVC-X8500HBKE2/SPE2 Upgrade Operation Manual Revision History Ver. No. Issue date Notes Ver.1 12/Apr./2021 Issue (Service Info No. DZ22-001) 1 / 25...
-
Page 2: Table Of Contents
Contents I. Preparation ............................4 I-1. Send the product over to a service agent ................... 4 I-2. Contents of the upgrade kit box ......................5 II. Upgrade procedure ..........................6 II-1. Remove the external parts....................... 6 II-2. Remove the HDMI PCB ........................7 II-3. - Page 3 III-2. Basic information about the upgrade kit ..................21 III-3. Specification changes after the upgrade ..................22 III-4. Specification changes of the FL display after the upgrade ............... 24 III-5. Other notes ..........................25 3 / 25...
-
Page 4: Preparation
I. Preparation I-1. Send the product over to a service agent Instruct your dealer to follow the packing procedure in this step (I-1) properly to protect the product and the parts of the upgrade kit during shipment. The dealer collects customer unit and ships it in the new box together with the Upgrade Kit Box to the service agent. -
Page 5: I-2. Contents Of The Upgrade Kit Box
I-2. Contents of the upgrade kit box 1) For inside of product HDMI 8K PCB (Upgraded PCB) PCB BRACKET and SCREW CORD HOLDER and SCREW 2) For REAR PANEL HDMI 8K LABEL “A” LABEL 3) For DOOR CAUTION LABEL (DOOR) DOOR CUSHION ASSY 4) ACCESSORIES QUICK START GUIDE... -
Page 6: Upgrade Procedure
II. Upgrade procedure II-1. Remove the external parts Remove the top cover. (Note: The removed screws are reused in step II-7-4)) Remove the side covers (left and right). (Note: The removed screws are reused in step II-7-1), 2) and SIDE COVER (L) SIDE COVER (R) 6 / 25... -
Page 7: Ii-2. Remove The Hdmi Pcb
II-2. Remove the HDMI PCB Remove the HDMI connector fixing screw on the rear. (Note: The removed screws are reused in step II-4-3)) 2) Remove the two PCB fixing screws. (Note: The removed screws are reused in step II-4-4)) (Front view) HDMI PCB Remove all the connections to the HDMI PCB (connectors, HDMI cable, PCB connections, and antenna cables). - Page 8 Cut and remove the three clamp bands that are securing the HDMI cable. (Top view) (Side view) Remove the HDMI PCB. 8 / 25...
-
Page 9: Ii-3. Attach The Hdmi 8K Label And A Label To The Rear Panel
II-3. Attach the HDMI 8K label and A label to the rear panel HDMI 8K LABEL “A” LABEL Note: ・ Before attaching the HDMI 8K label, remove the stickers on the HDMI 8K label that are covering the screw holes. 9 / 25... -
Page 10: Ii-4. Install The Hdmi 8K Pcb Of The Upgrade Kit
II-4. Install the HDMI 8K PCB of the upgrade kit Use the supplied screw to attach the PCB bracket. PCB BRACKET SCREW (Supplied) Screw hole for attaching the PCB bracket. Attach the HDMI 8K PCB included in the upgrade kit. HDMI 8K PCB Use the 10 screws removed in step II-2-1) to fix the HDMI connector. - Page 11 Use the two screws removed in step II-2-2) to attach the HDMI 8K PCB. (Top view) (Front view) Reconnect all the connections related to the HDMI 8K PCB. 11 / 25...
-
Page 12: Ii-5. Tidy Up The Wires
II-5. Tidy up the wires Tidy up the cables of the HDMI 8K PCB. 1)-1. Place the excess N6010 cable length between the DAC PCB and the AUDIO / VIDEO PCB. HDMI 8K PCB N6010 N6011 1)-2. Place the excess N6011 cable length between the HDMI 8K PCB and the DAC DAC PCB PCB. - Page 13 Tidy up the HDMI cable. 3)-1. Route the HDMI cable between the PCB and the bracket. 3)-2. Secure the HDMI cable with the cord holder to a position so that the HDMI cable will not hit the top cover. 3)-3. Place the HDMI cable inside the chassis.
-
Page 14: Ii-6. Update The Firmware
II-6. Update the firmware For details on how to update the firmware, refer to the service manual of the base model. 1) Update to the latest firmware. 2) Check the displayed version of the current firmware. 3) Check the input/output operation for each of the following connectors. ・... -
Page 15: Ii-7. Attach The External Parts
II-7. Attach the external parts How to identify the left and right side covers Hole < Front side of SIDE COVER (L) (inside) There is a circular hole on the front side Front side of product > SIDE COVER (R) (inside) There is a circular hole on the front side Use the screws removed in step II-1-2) to secure the upper front of the side covers (left and right). - Page 16 Use the 10 screws removed in step II-1-2) to attach the side covers (left and right). SIDE COVER (L) SIDE COVER (R) Note: ・ The length of the screws for the side cover and for For SIDE COVER For TOP COVER the top cover are different.
-
Page 17: Ii-8. Attach The Label And Door Cushion
II-8. Attach the label and door cushion CAUTION LABEL(DOOR) Attach the Caution label (door) to the inside of the door. If the same label is already attached, the new label does not need to be attached. DOOR CUSHION ASSY Place the door cushion on the inside of the door and then close the door. -
Page 18: Ii-9. Pack The Product
II-9. Pack the product Reuse the packing materials (carton case, spacers, pad, cushions, and cabinet sheet) the dealer used to ship the product. Wrap the product with the cabinet sheet. CABINET SHEET FRONT PANEL Set two spacers (front and rear), the pad, and the bottom cushions (front and rear) in the carton case. ・... - Page 19 Place the product in the correct orientation. FRONT side of product Place the top cushions (FRONT and REAR) in the correct orientation. “TOP”, “REAR” indication FRONT side of product “TOP”, “ “, “FRONT” indication Place the accessories (Quick Start Guide / Pop Label(A) / Pop Label(B)) in the box.
-
Page 20: Upgrade Information
III. Upgrade information III-1. Information customers should know prior to the upgrade Once the upgrade is performed, the following settings will reset to factory default settings. The backup memory such as volume level will be erased as well. It is necessary to setup the product once again when the product is returned. - Page 21 III-2. Basic information about the upgrade kit Upgrade Kit KIT No. (Name) SPK611/8500E2 Version Europe Base Model AVC-X8500HBKE2 AVC-X8500HSPE2 Service policy ・ Upgrade service period: The period ends at the same time as the EOL of the model AVC-X8500HA. ・ Warranty period: The warranty period of the product is the same as before the upgrade.
- Page 22 III-3. Specification changes after the upgrade 1) New functions for HDMI ・ One HDMI input connector (HDMI IN 7) and two HDMI output connectors (HDMI OUT MONITOR 1 and 2) support 8K 60/50 Hz and 4K 120/100 Hz pass-through. Note: The HDMI Input 7 can not be selected for ZONE 2. ・...
- Page 23 3) Owner’s Manual The new model name is displayed on the cover of the Owner’s Manual. Denon AVC-X8500HA 23 / 25...
- Page 24 III-4. Specification changes of the FL display after the upgrade When the power is turned ON after the upgrade, the display specifications of the FL display are changed as shown in the following figure. Before Upgrade After Upgrade AVC-X8500HA 24 / 25...
- Page 25 Other notes III-5. 1) Similar to the PCBs for regular service, the upgraded PCBs also have no serial number information. Because of that, the upgraded PCBs are not supported by the serial number display mode of the service mode. 2) Because the network module that has the MAC address information is included in the upgrade PCB, the MAC address is changed after the upgrade.
