- Page 1 ® IS4100 ScanQuest Series Laser Scan Engine Installation and User’s Guide...
- Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.
-
Page 3: Table Of Contents
ABLE OF ONTENTS Introduction Theory of Operation................1 Accessories ...................2 Components of the ScanQuest Engine ..........3 Label Locations ..................4 Maintenance ..................4 Automatic Scan Activation ................5 Applications and Protocols................5 Design Specifications Operational ....................6 Maintenance ..................6 Mechanical ....................7 Electrical ....................7 Environmental..................8 Compliance....................8 IS4125 Depth of Field ................9 IS4125 Object Detection .................10 Design Specifications Specifications for the Supplemental Window ........11... - Page 4 ABLE OF ONTENTS Scan Sense Timing IS4110 Timing Diagram...............23 Regulatory Requirements and Warnings Regulatory Requirements..............24 Europe ....................25 United States ..................26 Canada ....................27 Warnings....................27 Limited Warranty ..................28 Patents ....................29 Index......................30 Customer Support ...................32 Technical Assistance................32 Product Service and Repair..............33...
-
Page 5: Introduction
The manufacturer must submit a Laser Product Report for the FDA in the US or similar forms as required by other countries. Honeywell will assist its customers in complying with the necessary procedures. Theory of Operation An object detection device is located behind the scanner window initiates the scanning process. -
Page 6: Accessories
NTRODUCTION Accessories The following are available: IS4125 Decoded Scan Engine Part Numbers ESCRIPTION ANUFACTURE 19-07092 Flex Ribbon 12 Pos x 70mm Burndy BFC12X70A4 M-07102 Thru Hole 12 Pos ZIF Connector Burndy FLWSLW125-1C7 M-07103 Flex Ribbon 12 Pos x 130mm Burndy BFC12X30A4 IS4110 Non-Decoded Scan Engine Part Numbers ESCRIPTION ANUFACTURE... -
Page 7: Components Of The Scanquest Engine
NTRODUCTION Components of the ScanQuest Scan Engine Figure 1: IS4110 Figure 2: IS4125 Scanner This aperture emits laser light. window: Object When a specified time has elapsed without any scanning, Detection the unit will enter a “standby” mode. To reactivate the Device: unit, present an object in front of the window. -
Page 8: Label Locations
NTRODUCTION Label Locations The serial number label is located on the bottom of the unit. On the top of the unit is the “avoid exposure” and model number label. The following are examples of these labels: Figure 3: Labels Maintenance Smudges and dirt on the unit’s window can interfere with the unit’s performance. -
Page 9: Automatic Scan Activation
UTOMATIC CTIVATION An object detection device is located behind the scanner window initiates the scanning process. In short range mode the signal projects approximately 101.61 mm – 177.84 mm (4" – 7") beyond the output window. In long range mode the signal projects approximately 228.61 mm – 330.21 mm (9" – 13") beyond the output window. -
Page 10: Design Specifications
ESIGN PECIFICATIONS PERATIONAL Light Source: VLD 650 ± 10 nm Designed to be used in CDRH Class II and CDRH/IEC: IEC Class 2 laser products UL recognized component for Canada and Standard: 25 mm to 200 mm (1" to 8") Depth of Field, UPC 100% (0.33 mm (13 mil) bar codes): High Density: 10 mm to 175 mm (0.4"... -
Page 11: Mechanical
ESIGN PECIFICATIONS ECHANICAL 45.7 mm L x 40.6 mm W x 18.5 mm D Dimensions: 1.8" L x 1.6" W x 0.73" D) IS4125 Weight: 53 g. (1.87 oz.) Low profile ZIF 12-pin connector that accepts Termination: a 1 mm x 12 position FFC/FPC cable 45.7 mm L x 40.6 mm W x 14 mm D Dimensions: (1.8"... -
Page 12: Environmental
ESIGN PECIFICATIONS NVIRONMENTAL Operating -20°C to 50°C (-4°F to 122°F) Temperature: Storage -40°C to 70°C (-40°F to 158°F) Temperature: IS4125 Humidity: 5% to 95% relative humidity, non-condensing Vibration: 7G over 10-500 Hz Light Levels: Up to 60,000 Lux (5,574 footcandles) OMPLIANCE Laser Class: Class 2;... -
Page 13: Is4125 Depth Of Field
IS4125 D EPTH OF IELD Minimum Bar Code Element Width Standard High Density 10.4 10.4 Figure 4. Depth of Field Specifications are subject to change without notice. -
Page 14: Is4125 Object Detection
IS4125 O BJECT ETECTION Figure 5. IS4125 Object Detection Field Please note certain ambient light conditions may interfere with the object detection mechanism, resulting in false activation of the engine. To mitigate the problem, please try one of the following suggestions: Avoid mounting the engine directly facing the ambient light source. -
Page 15: Design Specifications
ESIGN PECIFICATIONS Specifications for the Supplemental Window In applications where a secondary window is installed with the IS4125, the following recommendations should be followed in order to achieve the best performance. While these recommendations provide general guidelines for a successful integration and installation, it will take some testing to find exact parameters to optimize scan performance and auto detection in each application. -
Page 16: Default Settings
EFAULT ETTINGS Many functions of the IS4125 decode scan engine can be configured or enabled/disabled. The decode engine is shipped from the factory configured to a set of default conditions. The default parameter of the decode scan engine has an asterisk (*) in the charts on the following pages. If an asterisk is not in the default column then the default setting is OFF or disabled. - Page 17 EFAULT ETTINGS RS232 Light Keyboard Parameter Default RS232 Wedge No Two Second Timeout Razzberry Tone on Timeout No Tone on Timeout Three Beeps on Timeout Beep Before Transmit ...
- Page 18 EFAULT ETTINGS RS232 Light Keyboard Parameter Default RS232 Wedge Prefix ID for UPC/EAN Suffix ID for UPC/EAN Bars High Spaces High Transmit as Scanned ...
- Page 19 EFAULT ETTINGS RS232 Light Keyboard Parameter Default RS232 Wedge Set Minimum Character Length Set Character Lock Length Transmit UPC-A Number Sys ...
- Page 20 EFAULT ETTINGS RS232 Light Keyboard Parameter Default RS232 Wedge Matrix 2 of 5 Check Digit Hong Kong Matrix 2 of 5 ...
- Page 21 EFAULT ETTINGS RS232 Light Keyboard Parameter Default RS232 Wedge Retransmit of Same Code 1st Configurable Prefix ID 2nd Configurable Prefix ID 1st Configurable Suffix ID 2nd Configurable Suffix ID ...
-
Page 22: Scanner Terminations
100 mA of current. A current limiting pull- Beeper - up resistor and Piezo type transducer (QMB- 111PXN or equivalent) is recommended. Input. Do not connect to this pin, Honeywell internal use Reserved Input only. Negative connection for scan mode indicator. -
Page 23: Is4125-38 Connector Pin Assignments
100 mA of current. A current limiting pull- Beeper - up resistor and Piezo type transducer (QMB- 111PXN or equivalent) is recommended. Input. Do not connect to this pin, for Honeywell internal Reserved Input use only. Negative connection for LED. An external pull-up and LED are suggested. -
Page 24: Is4125-41, Is4125-63 & Is4125-76 Connector Pin Assignments
100 mA of current. A current limiting pull-up Beeper - resistor and Piezo type transducer (QMB- 111PXN or equivalent) is recommended. Input. Do not connect to this pin. This pin is for Honeywell Reserved Input internal use only. Negative connection for LED. An external pull-up and LED LED - is suggested. -
Page 25: Is4125-163 Connector Pin Assignments
100 mA of current. A current limiting pull-up Beeper - resistor and Piezo type transducer (QMB- 111PXN or equivalent) is recommended. Input. Do not connect to this pin. This pin is for Honeywell Reserved Input internal use only. Negative connection for LED. An external pull-up and LED LED - are suggested. -
Page 26: Is4110 Connector Pin Assignments
CANNER ERMINATIONS IS4110 Connector Pin Assignments Honeywell provides a low profile ZIF 10-pin connector that accepts an FPC/FFC cable with a 1.0 mm Pitch and a 0.3 mm end thickness. This cable is available from Honeywell in various lengths. Figure 11... -
Page 27: Scan Sense Timing
ENSE IMING IS4110 Timing Diagram The SCAN SENSE pulse occurs once for each flip cycle. A flip cycle represents one scan in each direction (right to left then left to right from the scanner perspective). The HIGH to LOW transition of the SCAN SENSE signal initiates the start of the flip cycle. -
Page 28: Regulatory Requirements And Warnings
EGULATORY EQUIREMENTS AND ARNINGS Regulatory Requirements The IS4100 Series ScanQuest Laser Scan engines are designed to meet the requirements of CDRH Class II and IEC Class 2 laser products. CDRH Class II/IEC Class 2 are defined as follows: Emission Duration: Greater than 0.25 seconds Accessible Emission Limit: Less than 0.001 W (1.0 milliwatts) average... -
Page 29: Europe
EGULATORY EQUIREMENTS AND ARNINGS Europe The CE Mark is required on products with IS4110 and IS4125 Scan Engines if the products are to be imported into European Economc Area (EEA) countries. Use of the CE Mark requires compliance with Directives and standards dependent upon the type of product. -
Page 30: United States
EGULATORY EQUIREMENTS AND ARNINGS United States Laser Safety To assist with the FDA filing requirements (refer to Regulatory Requirements on page 24), Metrologic has registered the scan engine with the FDA as a component. Customers can contact CDRH at the following address: Food and Drug Administration Center for Devices and Radiological Health Light Products Branch (HFX-312) -
Page 31: Canada
EGULATORY EQUIREMENTS AND ARNINGS Canada Laser Safety The Radiation Protection Bureau currently accepts products meeting the FDA standards in Canada. For more information contact: Radiation Protection Bureau 775 Brookfield Road Ottawa, Ontario K1A 1C1 The IS4125 has been tested to meet Class B EMC Standards. The integrator is responsible to maintain proper EMC techniques to maintain this performance level. -
Page 32: Limited Warranty
IMITED ARRANTY Honeywell International Inc. ("HII") warrants its products and optional accessories to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;... -
Page 33: Patents
ATENTS For patent information, please refer to www.honeywellaidc.com/patents. -
Page 34: Index
NDEX Adapter Cable .......2 IEC........6, 7, 8 Applications and Protocols ....5 Indicators LED ....... 2, 18–22 Assignments pin ..........3 Interfaces ......6, 7, 8 Introduction ........1 IR Sensor ........1, 3 Beam Width......6, 7, 8 Beeper....... 12–17, 18–22 Keyboard Wedge .. - Page 35 NDEX System Interfaces ..1, 5, 6, 7, 8 Red LED........2 Regulatory Requirements Canada Laser Safety....27 Termination ........7 Europe Laser Safety....25 Transducer........2 United States Laser Safety..26 TTL ....... 5, 12–17, 21, 22 Repair..........28 Ribbon Cable......2, 3 RMA ..........28 UL .........
-
Page 36: Customer Support
UPPORT Technical Assistance If you need assistance installing or troubleshooting your device, please call your distributor or the nearest technical support office: North America/Canada Telephone: (800) 782-4263 E-mail: hsmnasupport@honeywell.com Latin America Telephone: (803) 835-8000 Telephone: (800) 782-4263 E-mail: hsmlasupport@honeywell.com Brazil... -
Page 37: Product Service And Repair
USTOMER UPPORT Product Service and Repair Honeywell International Inc. provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product. - Page 40 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com 00-02257 Rev E May 2010...
