Instruction Manual

Current Probe

SS-560/570

Table of Contents

Summary of Contents for Iwatsu SS-560

Page 1 Instruction Manual Current Probe SS-560/570...
Page 3: Table Of Contents
1.1 Current Probe ···········································11 1.2 Features ··················································11 1.3 Names of Parts ·········································12 1.4 Part Functions ··········································12 2 Specifications ·······················································15 2.1 Instrument Specifications (SS-560) ···············15 2.2 Certification Standards (SS-560) ··················16 2.3 Instrument Specifications (SS-570) ···············18 2.4 Certification Standards (SS-570) ··················19 3 Measurement Procedure ········································21 3.1 Notes on Use ···········································21...
Page 4 Memo...
Page 5: Preface
Preface ◇ Thank you for purchasing the Current Probe SS-560/570. We hope that you will enjoy it for years to come. ◇ Please read this manual carefully before attempting to use the instrument. Store the manual in a safe place so it can be referred to when necessary.
Page 6 ◇ Unauthorized reproduction of the contents of this manual is strictly prohibited. ◇ If you have any questions about this instrument, contact IWATSU or our sales distributors. Revision history ◇ April 2021: 1st edition...
Page 7 Continued use under these circumstances may result in electric shock or fire. Contact IWATSU or our sales distributors for repair. Do not attempt to repair this instrument yourself. • Turn off the power to the insulated target conductor to be...
Page 8 • When handling power cables and sensor cables: This may result in fire, electric shock or equipment damage. If the power cord is damaged, contact IWATSU or our sales distributors for repair. Do not attempt to fabricate power cord and sensor cable.
Page 9 • Do not use this instrument when it has failed. Using a failed main unit or, cable or AC adaptor may be a cause of an electric shock or fire. In the event of a failure, contact Iwatsu office or our sales distributors for repair.
Page 10 The dirt causes electric shock, a fire or damage. • This instrument SS-560 and SS-570 might not be able to be used at the same time because there are restrictions on power consumption in the probe power on the oscilloscope side according to the measured current.
Page 11 Read this page to ensure proper safety. (to be continued) CAUTION • Do not supply current that exceeds the maximum continuous input range. The values are derived from the rise in temperature caused when the unit heats up during measurement. Do not input the current that exceeds this.
Page 12 Read this page to ensure proper safety. (to be continued) CAUTION • When removing the connector from the power supply receptacle, first unlock the connector, grasp the connector and pull to remove. Failure to remove the connector in this manner may damage the terminator.
Page 13: Checking Packed Materials
If you do not have a proper packing or shock-absorbing material for transportation, contact IWATSU or our sales distributors. If transportation is to be handled by a forwarding agent, display "Contains a precision machine" on each side of the packing box.
Page 14: Components
Repair and sending instrument to be repaired If a failure occurs, send the instrument to IWATSU or our sales distributors. When sending an instrument to be repaired, clearly write the...
Page 15: Overview
1.2 Features • Highly accurate current detection • Easy current measurement • Broadband frequency bandwidth SS-560 : DC to 10 MHz SS-570 : DC to 2 MHz • Large diameter allows high-current measurements.
Page 16: Names Of Parts
1 Overview 1.3 Names of Parts • External view 1.4 Part Functions 1. Clamp This clamps around the insulated target conductor to be measured. 2. Slider This slider opens the clamp. Always use it to open and close the clamp. 3.
Page 17 1 Overview 6. Demagnetizing switch (DEMAG) This can demagnetize the core if it has been magnetized by switching the power on and off, or by an excessive input. Always carry out demagnetizing before measurement. Moreover, the demagnetizing process takes about 3 second. During demagnetizing, a demagnetizing waveform is output.
Page 18 1 Overview Memo...
Page 19: Specifications
2 Specifications 2 Specifications 2.1 Instrument Specifications (SS-560) The following values indicate unit performance 30 minutes after the power has been turned on in an ambient environment of 23°C ± 3°C and below the moisture of 80 %RH (no dew condensation).
Page 20: Certification Standards (Ss-560)
Sensor part: 176(W) X 69(H) X 27(D) mm (±2 mm) External dimensions Terminator part: 27(W) X 55(H) X 18(D) mm (±2 mm) Weight 500 g ±20 g Hard case (1), Instruction manual (1), Accessories Sheet for China RoHS (1), Cable tie (1) 2.2 Certification Standards (SS-560) Safety EN61010-2-032 EN61326-1...
Page 21 2 Specifications Fig.1 Frequency characteristics (SS-560, Typical characteristics) Fig.2 Derating according to frequency (SS-560) Fig.3 Input impedance (SS-560, Typical characteristics)
Page 22: Instrument Specifications (Ss-570)
2 Specifications 2.3 Instrument Specifications (SS-570) The following values indicate unit performance 30 minutes after the power has been turned on in an ambient environment of 23°C ± 3°C and below the moisture of 80 %RH (no dew condensation). DC to 2 MHz (-3 dB) Bandwidth (Typical characteristics shown in Fig.4) Rise time...
Page 23: Certification Standards (Ss-570)
2 Specifications Diameter of measurable φ20 mm or less conductors Sensor cable: 2.0 m ±0.1 m Cable or cord lengths Power cord: 1.0 m ±0.1 m Sensor part: 176(W) X 69(H) X 27(D) mm (±2 mm) External dimensions Terminator part: 27(W) X 55(H) X 18(D) mm (±2 mm) Weight 500 g ±20 g Hard case (1), Instruction manual (1),...
Page 24 2 Specifications Fig.4 Frequency characteristics (SS-570, Typical characteristics) Fig.5 Derating according to frequency (SS-570) Fig.6 Input impedance (SS-570, Typical characteristics)
Page 25: Measurement Procedure
Appendix 3 Measurement Procedure 3.1 Notes on Use To avoid short circuits and potentially life-threatening hazards, follow these precautions. • Be sure to use this instrument on an insulated circuit. Moreover, do not use it for the bare conductor. • Be careful to avoid damaging the insulation surface of the insulated target conductor to be measured.
Page 26: Preparations For Measurement
Appendix 3.2 Preparations for Measurement (1) Have this instrument, the power supply (PS-52 etc.) and oscilloscope or recorder for waveform measurement ready. Before turning on the power, make sure that the voltage of the power supply being used matches the supply voltage indicated on the rear panel of the PS-52 or PS-54.
Page 27: Demagnetizing And Zero Adjustment
Appendix 3.3 Demagnetizing and Zero Adjustment (1) With the waveform measurement instrument input at ground, adjust the trace to the zero position. (2) Set the input coupling of the waveform measurement instrument to Connect the output connector of this instrument to the input connector of the waveform measurement instrument.
Page 28: Measurement Procedure
Appendix (4) Before clamping an insulated target conductor to be measured, confirm that the clamp can be securely closed: press the slider until UNLOCK is no longer displayed, and hold it until LOCK appears. (5) Press the demagnetizing switch (DEMAG) on the terminator. (6) Turn the zero adjustment dial on the terminator to adjust the trace to the zero position.
Page 29 • The current consumption of this instrument depends on the current value to be measured. Confirm that the total current consumption of this instrument does not exceed the current of 600 mA. See Figure 7 (for SS-560) or Figure 8 (for SS-570). Fig.7 Current consumption* vs.
Page 30 Appendix • The maximum continuous input range is based on heat that is internally generated during measurement. Never input current in excess of this level. Exceeding the rated level may result in damage to this instrument. • The maximum continuous input range varies according to the frequency of the current to be measured.
Page 31 (1) 700 Apeak, for non-continuous input (1) indicates an upper waveform response limit of 300 Apeak (for SS-560) / 700 Apeak (for SS-570). Use the sensor at RMS current input levels that are within the maximum continuous input range. (2) indicates the upper response limit for a single input pulse.
Page 32 Appendix • The output of this instrument is terminated internally. Use a waveform measurement instrument with an input impedance of at least 1 MΩ. • Immediately after powering on, this instrument may be subject to an appreciable offset drift due to the effect of self-heating. To counteract this, allow the instrument to warm up for about 30 minutes before carrying out measurement.
Page 33 Appendix • When power is turned on, a demagnetizing waveform is initially applied to the output: this is not a fault. • Accurate measurement may be impossible in locations subject to strong external magnetic fields, such as transformers and high current conductors, or in locations subject to strong external electric fields, such as radio transmission equipment.
Page 34: Appendix
Digital oscilloscope ViewGoII series that can attach DS-579, and power connector conversion cable are used together, and it is possible to use them slimly and compactly. If you have any questions about this instrument, contact IWATSU or our sales distributors.
Page 35 MEMO...
Page 36 Contact Us Overseas Sales Sect., Sales Dept. No.2 Address : 1-7-41 Kugayama, Suginami-ku, Tokyo 168-8501, Japan Phone : +81 3 5370 5483 Facsimile : +81 3 5370 5492 Web Site : http://www.iti.iwatsu.co.jp /index_e.html E-mail : info-tme@iwatsu.co.jp...
