JVC GGT0356-001A-H Instructions

WIDE LCD PANEL TV INSTRUCTIONS
LT-32A1
© 2010 Victor Company of Japan, Limited
Safety Precautions
Thank you for buying this JVC LCD panel television.
To make sure you understand how to use your new TV, please read this manual thoroughly before you begin.
• Follow this manual regarding setup! • Never insert the power cord by wet hand!
- Connect only to a 110-240 V, 50/60Hz AC outlet. - It may cause a fatal electric shock.
• Make enough room for inserting and removing the power • Keep the TV set away from direct sunlight!
plug! - TV set can be damaged.
• Place the TV as close to the outlet as possible! • Place the TV set in a neat and dry place. Do not place the
product close to source of steam, heat, moisture or oil.
- The main power supply for this TV is controlled by inserting or removing
the power plug. Because it may cause a fire hazard or electric shock hazard!
• Never cut or damage the power cord! • Don't touch an external metal part of the TV set!
- If the AC plug is not the right shape, or the power cord is not long
- It may cause an electrocuted.
enough, use an appropriate plug adapter or extension cable. (Consult • For keep a distance from potential ignition
your retailer)
sources to the components or part in side TV
• Unplug the power cord when going out!
set, customer should install TV set with a stand
- The power buttons on the remote control and the TV unit cannot
within ± 10 perpendicularly degree.
completely turn off the TV. (Make appropriate arrangements for
• Never dismantle the rear panel!
bedridden people.)
- It may cause an electric shock.
• Do not allow the TV to fall!
• Never obstruct the ventilation holes!
- Do not rest your elbows on, or allow children to hang from the TV.
- It may cause overheating or a fire.
- There is a risk that the TV will fall and cause injuries.
• Handle LCD panel with care!
- Make use of the hole on the back of the stand to prevent
- Use a soft, dry cloth when cleaning.
the TV from falling easily.
• If the TV is damaged or behaving strangely, stop • Never try repair the TV yourself!
- If the problem cannot be solved in "Troubleshooting" unplug the power
using it at once!
cord and contact your retailer.
- Unplug the power cord and contact your retailer.
• If a television is not positioned in a sufficiently stable
• Never place anything on the TV!
location, it can be potentially hazardous due to falling. Many
- Placing liquid, naked flames, cloths, paper, etc. on the TV may cause a
injuries, particularly to children, can be avoided by taking
fire.
• Never expose to rain or moisture! simple precautions such as:
- To prevent fire or electric shock, never allow - Using cabinets or stands recommended by the manufacturer of the
television.
liquids to enter the unit.
• Never insert objects into the cabinet - Only using furniture that can safely support the television.
- Ensuring the television is not overhanging the edge of the supporting
openings!
furniture.
- It may cause a fatal electric shock.
- Not placing the television on tall furniture (for example, cupboards or
- Take care when children are near.
bookcases) without anchoring both the furniture and the television to a
• Hold the TV so as not to scratch the
suitable support.
screen!
- Not standing the television on cloth or other materials placed between
- Do not touch the screen when carrying the TV.
the television and supporting furniture.
• Do not carry the TV on your own!
- Educating children about the dangers of climbing on furniture to reach
- In order to prevent accidents, ensure that the TV
the television or its controls.
is carried by two or more people.
• To prevent accidents, firmly attach the TV stands to the TV
shelf before using microphone.
• For more details on installation, usage and safety ➔ Consult
• Make sure that the subwoofer is in good condition before
your retailer.
installing it on the TV.
- If the subwoofer has leakage current, it may damage the TV or cause
electric shock.
Care when setting
Power requirements • If the microphone is installed,
■
200 mm
• Connect the power cord should be lock it's cable follow
only to a 110-240V, 50/60Hz picture.
AC outlet.
Installation requirements
■
• To avoid overheating,
ensure the unit has ample
150 mm 50 mm 150 mm 50 mm
room.
* Please see how to set up the TV and connection in GGT0356-001A-H.
ENGLISH
Remote control buttons and functions
20
12
Clear SD
2 3
1
15
CHANNEL
ZOOM
4
19 5 6
ECO 5
7 8 9
6
+
RETURN KARAOKE
18 0
7
1
TV/VIDEO MENU
17 8
GGT0364-001A-H 9
OK
0710GLT-NF-MT
DISPLAY BACK 10
16
Zoom : Change the aspect ratio
11
CH VOL
15 12
MODE
13
14
RM-C2022
LCD
Hyper Scan :
Return Plus : Return to the frequently viewed channel.
10 10
Return : Return to the previously viewed channel.
Plane Favorite channel setting.
1. Register the favorite channel
Set 1-4 ?
Press and hold
Programmed! will be displayed.
• Insert the batteries
Use two "AAA/R03" dry cell batteries.
Insert the batteries from the · end,
making sure the · and ª polarities
are correct.
WARNING:
To prevent the spread of fire, keep candles or other open flames away from
this product at all times.
Initial Settings
1
Turn on the TV.
ME NU
• To prevent the TV from falling thread the
belt through the hole on the back of the
JVC logo appears
stand and secure it to the TV rack.
• Show only when powering on for the first time.
Hole for belt
• The power on the unit can also be used.
• The select the new Country Area after Initial Setting has completed.
Belt
(not provided) (While the cursor is pointing to Picture menu
1
Screw (not provided) and hold for 3 seconds.)
1
Adjust Volume
1 Power On / Off # Volume control / Turn off muting
[ For button side front will be displayed on-screen menu
VOLUME VOLUME 2 Color buttons
• When press and hold the button for 3 seconds,
3 Turn on "Clear SD"
on-screen menu will be displayed.
4 Turn on "Zoom"
• To exit, press and hold the button again for
5 Turn on "Eco Mode"
3 seconds. ]
CHANNEL
6 Turn on "Karaoke"
$ Function for viewing Teletext
7 Favourite channel setting
% To Teletext
8 Display on-screen menu
& Change channel / Page / Hyper Scan
9 Operate the menu
( Channel information
! To previous screen
) Switch between TV / Video input
" Turn on "Sound Meister"
~ Return Plus / Return function
+ Change channel / page
Microphone
, Turn the volume off / on
V-Scroll
• When 720p or 1080i or 1080p signal
1. Select is received, "Full" and "Slim" can be
Picture selected.
Zoom 16:9 Zoom
OK
• In PC mode, "Regular" and "Full" can
Auto Panoramic
Regular 2. Set
be selected.
Panoramic
14:9 Zoom
Move the picture with 3 or 4
16:9 Zoom
16:9 Zoom Subtitle
while this bar is displayed.
Full
CH
Press and hold . PR changes without changing the picture screen.
Once you release the button, the picture of the selected PR will appear.
RETURN+
Return Plus Programmed by select the frequently viewed channel then press and hold .
RETURN+
Return Plus Canceled by press and hold .
2. Recall the favorite channel
Press number Press number
Favourite 1-4 ?
button (1-4 only) button (1-4 only)
Press
• If the favorite channel has not been registered then " No memory " will
be displayed.
"AAA/R03"
WARNING:
Batteries
If this symbol is shown,
Batteries shall not be exposed
it is only valid in the
to excessive heat such as direct
European Union.
sunshine, fire or the like.
2 3
Select a language. Select Country Area.
Set Up 1. Select Set Up
> Language > Country Area
English ไทย Area - 1
Tiếng Việt OK Area - 2
Português
Français Melayu 2. Set
Українська Pусский
Castellano
Area-1 : Asia, Middle East, Europe, Oceania, Africa
Area-2 : South America, Philippines
Initial Settings (continued)
If you select Country Area to "Area-1"
4
Select the teletext language group.
1. Select
Set Up
> Teletext Language
OK
Group-1
Group-2
Group-3
Group-4
Group-5
5
Automatically register channels (Auto Program).
Set Up
OK
> Auto Program
CH 40
5%
6 Check what was registered.
OK
Set Up
> Edit
PR ID CH / CC
01 – – – – – – CH 02
02 – – – – – – CH 03
03 B B C A B C CH 47 • If you want to edit channel, follow Edit
04 A B C D E F CH 76
05 – – – – – – CH 12 function in Set Up menu.
06 – – – – – – CH 09
07 – – – – – – CH 05
08 – – – – – – CH 02
09 – – – – – – CH 15
10 – – – – – – CH 28
Using the TV's Menu ---> Area - 1
Display MENU.
Picture Mode Soft
Backlight
Contrast
Brightness
Sharpness
Colour
Tint
White Balance Warm
Features
or Exit from Menu. Confirm after setting.
OK
• Please see "Menu operation guide" at the bottom of menu on-screen.
Picture Mode Select the picture as you like. (Standard / Soft / Bright)
Backlight Darker <--> Brighter
Contrast Lower <--> Higher
Brightness Darker <--> Brighter
Sharpness Softer <--> Sharper
Colour Lighter <--> Deeper
Tint Reddish <--> Greenish *Only NTSC
White Balance Select the white balance of the picture. (Cool / Mid / Warm)
Features Finer picture adjustment
Clear SD For clearly picture (Off / Mode-1 / Mode-2)
Digital VNR Reduces the amount of noise in original
picture. (Off / On)
Colour Management For natural - looking pictures. (Off / On)
Picture Management Fix bright / dark pictures. (Off / On)
Dynamic Backlight Reduces the brightness of the backlight
when the screen is dark. (Off / On)
Colour System Select an appropriate colour system.
(Auto / PAL / SECAM / NTSC 3.58 / NTSC
4.43 / PAL-M / PAL-N)
Zoom Change the aspect ratio.
(Auto / Regular / Panoramic /14:9 Zoom /
16:9 Zoom / 16:9 Zoom Subtitle / Full)
Stereo / I II
Select the stereo, mono or bilingual language.
■
(I / II / O / m / Mono)
Sound Meister Set sound theme to match your listening source.
(Off / Dynamic / Pure / Living)
Bass Compensates low frequencies to widen the
frequency band. (Weaker <--> Stronger)
Treble Compensates high frequencies to widen the
frequency band. (Weaker <--> Stronger)
Surround Expands the stereo sound naturally.
(Narrower <--> Wider)
1. Select
Balance Left Stronger <--> Right Stronger
Voice Enhancer Uses sound enhancement technology. (Off / On)
OK Al Volume Prevent sudden increase or decrease of sound. (Off / On)
Subwoofer Out Chooses to connect subwoofer. (Off / On)
2. Set
Subwoofer Level Adjusts sound level of your subwoofer.
(Lower <--> Louder)
• When Subwoofer Out set to On, you can adjust
Subwoofer Level.
Karaoke You can enjoy to reduce the vocals for your own karaoke.
Karaoke Chooses to reduce the vocals.
(Off / Mode-1 / Mode-2)
Main Volume Adjusts volume level. (Lower <--> Louder)
Microphone Volume Adjusts volume level of microphone.
(Lower <--> Louder)
2
If you select Country Area to "Area-2"
4
Select Air or Cable.
1. Select
Set Up
> Auto Program
OK
Air
Cable
2. Set
5
Searching for the channels (Auto Program)
Set Up
>> Auto Program
CH 40
5%
6 Check what was registered.
OK
Set Up
> Channel Summary
CH / CC ID Skip
CH 02 – – – – – –
CH 03 – – – – – –
• If you want to set undesired channels
CH 04 B B C A B C
CH 05 A B C D E F
to be skipped, follow Channel Summary
CH 06 – – – – – –
CH 07 – – – – – –
CH 08 – – – – – – Yes function in Set Up menu.
CH 09 – – – – – – Yes
CH 10 – – – – – –
CH 11 – – – – – –
2 / 3 Select Main menu.
(Picture / Sound / Features / Set Up)
5 / ∞ Select sub menu.
2 / 3 Change setting.
When 3 is shown.
3 Display function setting.
5 / ∞ Select function.
2 / 3 Change setting.
On Timer Turns on the TV from standby mode.
PR Select a channel. (01 - 99)
On Timer Set a time. (00:00 - 12:00)
Sleep Timer Turns off the TV to standby mode. (Off / 10 / 20 / ...120)
Channel Guard Stop children from watching specific channels.
Blue Back Display a blue screen and mute the sound when the
signal is weak or absent. (Off / On)
Child Lock Disables the side control buttons of the TV. (Off / On)
Auto Shutoff Set the power to turn off if no TV signal (RF) is
received and no operation is performed for about 15
minutes. (Off / On)
Favourite Setting Delete the favorite channel that you registered by (Blue)
.
Power Lamp Sets power lamp lighting while the TV is on. (Off / On)
Eco Mode Adjust picture contrast to match your room brightness.
(Off / Eco-1 / Eco-2 / Max-Eco)
Auto Program Automatically registers channels.
Edit / Manual Move Move a channel position by 2 and Adjust
by 3 / 4.
ID (Red)
Edit a channel name by .
Insert (Green)
Insert a channel by .
Select a CH/CC by 3 / 4.
Enter number by 0-9 buttons.
Delete (Yellow)
Delete a channel by .
Manual (Blue)
Register a new channel by .
(Red) (Green)
Beginning channel search by and .
(Yellow) (Blue)
Channel fine tunning by and .
If the picture or sound is unnatural by
for select a system.
Language Select your desired on screen display language.
Video-2 Setting Switch between video and component signal.
(Video / Component)
Rocket Start TV can turn on quickly. (Off / On)
• When Rocket Start is On, power consumption at
standby mode will more than normal standby mode.
Teletext Select Teletext language group.
Language (Group-1 / Group-2 / Group-3 / Group-4 / Group-5)
HDMI Setting Setting for HDMI input. (Size / Audio)
PC Setting Setting for PC input. (Auto / PC Position / Phase / Pixel)
(continued)
3
