Kidde Smoke + Carbon Monoxide Alarm
with Indoor Air Quality Monitor
User Guide
Combination Photoelectric Smoke
& Carbon Monoxide Alarm
with Voice, Hardwire Interconnect,
Indoor Air Quality Monitoring (IAQ),
and Wi-Fi Compatibility
Model P4010ACSCOAQ-WF
wi-Fi CoMPATIBIlITY:
This model requires a home Wi-Fi router
and internet to connect to a mobile device.
( Requires 802.11b/g/n (2.4GHz) Wi-Fi )
noTe: wi-Fi features do not function without AC power.
KIdde wi-Fi AlArM
120V HArdwIre
10-YeAr BATTerY BACKUP
(AC Power reQUIred)
HArdwIre InTerConneCT
wi-Fi CoMPATIBle
VoICe AlArM
Indoor AIr QUAlITY
1
Advertisement
Table of Contents
Related Manuals for Kidde P4010ACSCOAQ-WF
Summary of Contents for Kidde P4010ACSCOAQ-WF
- Page 1 Kidde Smoke + Carbon Monoxide Alarm with Indoor Air Quality Monitor User Guide Combination Photoelectric Smoke & Carbon Monoxide Alarm with Voice, Hardwire Interconnect, Indoor Air Quality Monitoring (IAQ), and Wi-Fi Compatibility Model P4010ACSCOAQ-WF wi-Fi CoMPATIBIlITY: This model requires a home Wi-Fi router and internet to connect to a mobile device.
- Page 2 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke + Carbon Monoxide Alarm with Indoor Air Quality Monitor.”...
-
Page 3: Table Of Contents
. 11 8. Locations To Avoid . . 14 9. Wiring Instructions and Mounting Bracket Installation . 15 10 Kidde App Instructions . . 19 11. Installation, Activation, and Wi-Fi Enrollment . . 20 11.1 Setting Up Wi-Fi Enrollment . -
Page 4: Smoke Alarm: What To Do When The Alarm Sounds
1. Smoke Alarm: What To Do When the Alarm Sounds The smoke alarm pattern is three long beeps with voice “Fire!,” a 1.5 second pause, and three long beeps repeating. The red LED blinks in time with the alarm pattern. The smoke alarm takes precedence when both smoke and carbon monoxide are present. -
Page 5: Carbon Monoxide Alarm: What To Do When The Alarm Sounds
2. Carbon Monoxide Alarm: What To Do When the Alarm Sounds The carbon monoxide (CO) alarm pattern is four quick beeps with voice “Warning! Carbon Monoxide” repeating every 5 seconds. The red LED blinks in time with the alarm pattern. On DC power only, after 4 mins, the alarm pattern and voice will only occur every 60 sec. -
Page 6: Other Alarm Visual And Audible Indicators
3. Other Alarm Visual and Audible Indicators Operational Mode Visual Indications Audible Indications Action/Note: Normal (standby) AC power: Green LED on continuously during light conditions, or blink every 60 sec during dark conditions. DC power: Green LED blink approx every 60 sec. Test (button press when no •... -
Page 7: Troubleshooting Guide
If you are experiencing a problem with your alarm, or a fault, and are unsure of the next action, please contact product support at 1-877-542-5471 before discharging the battery. You may also write us at: Kidde, 1016 Corporate Park Drive, Mebane, NC 27302, or visit our internet address at www.kidde.com. -
Page 8: Introduction, Product Features & Specifications
5. Introduction, Product Features and Specifications Introduction This alarm detects products of combustion using photoelectric technology and carbon monoxide using an electrochemi- cal cell. The device also monitors the indoor air quality of the residence. Many times throughout this User Guide, we will refer to Carbon Monoxide as “CO.”... -
Page 9: Limitations Of Smoke And Carbon Monoxide Alarms
6. Limitations of Smoke and Carbon Monoxide Alarms wArnInG: PleASe reAd CAreFUllY And THoroUGHlY • Life safety from fire in residential occupancies is based primarily on early notification to occupants of the need to escape, followed by the appropriate egress actions by those occupants. •... - Page 10 wArnInG: PleASe reAd CAreFUllY And THoroUGHlY • IMPORTANT: This alarm is designed to detect carbon monoxide gas from ANY source of combustion. It is NOT designed to detect any other gas. CAUTIon: This alarm will only indicate the presence of carbon monoxide gas at the sensor. Carbon monoxide gas may be present in other areas.
-
Page 11: Recommended Locations For Smoke And Carbon Monoxide Alarms
7. Recommended Locations For Smoke And Carbon Monoxide Alarms • Locate smoke alarms in all sleeping areas. Try to monitor the exit path as the bedrooms are usually farthest from the exit. If more than one sleeping area exists, locate additional alarms in each sleeping area. •... - Page 12 Note: measurements shown are to the closest edge NFPA 72 states: “Smoke alarms in rooms with ceiling slopes greater than 1 ft in 8 ft (0.3m in 2.4 m) of the alarm. horizontally shall be located on the high side of the room.” NFPA 72 states: “A row of detectors shall be ot within 6 feet of appliances spaced and located within 3 ft (0.9m) of the peak of the ceiling measured horizontally.”...
- Page 13 • For mobile home installation, select locations carefully to avoid thermal barriers that may form at the ceiling. For more details, see MOBILE HOME INSTALLATION section. • When mounting the alarm on the wall, use an inside wall with the top edge of the alarm at a maximum of 12” (30.5 cm) below the ceiling.
-
Page 14: Locations To Avoid
8. Locations to Avoid (See Figures 7-A, 7-B, & 7-C for recommended locations) • In the garage. Products of combustion are present when you start your automobile. • Normal cooking may cause nuisance alarms. If a kitchen alarm is desired, it should have an alarm silence feature or be a photoelectric type. -
Page 15: Wiring Instructions And Mounting Bracket Installation
1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “ Smoke + Carbon Monoxide Alarm with Indoor Air Quality Monitor.”... - Page 16 • A maximum of 24 Kidde Safety devices may be interconnected in a multiple station arrangement. The intercon- nect system should not exceed the NFPA interconnect limit of 12 smoke alarms and/or 18 alarms total (smoke, CO, Smoke/ CO Combination, heat, etc.). With 18 alarms interconnected, it is still possible to interconnect up to a total of 6 remote signaling devices and / or relay modules.
- Page 17 Kidde App, do not connect your Wi-Fi unit to the AC quick connect harness or mounting bracket yet. See Remove Section 10 for instructions on downloading the Kidde App. If you are not using the Wi-Fi function, then proceed with the following Install three steps.
- Page 18 ONLY transmit smoke and CO alarm signals from these alarms to your mobile device (after the wi-Fi alarm is registered with the Kidde app). Other status notifications from non Wi-Fi alarms, such as low battery, end of unit life, or a fault condition, will NOT be transmitted to your mobile device through the Wi-Fi alarm.
- Page 19 For best Wi-Fi enrollment results, follow these steps: 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke + Carbon Monoxide Alarm with Indoor Air Quality Monitor.”...
-
Page 20: Installation, Activation, And Wi-Fi Enrollment
For best Wi-Fi enrollment results, follow these steps: 1. Scan QR code shown in STEP 1 on the front of the Quick Start Guide. Install the Kidde app. 2. Open the Kidde app. Create and login to your account. Tap “Add a device.” Select “Smoke + Carbon Monoxide Alarm with Indoor Air Quality Monitor.”... -
Page 21: Adding Another Device To An Existing Wi-Fi Alarm Network
B. Open the Kidde App and follow instructions on the App to finish Wi-Fi enrollment. noTe: If no further steps are taken within 15 minutes of initial power up, a voice prompt, “Not Connect- ed” will be heard once, and the Wi-Fi function will turn off. The unit will then perform as a standard hardwired alarm. -
Page 22: Resetting A Device's Wireless Settings
Your WiFi alarm is compatible with Amazon Alexa and Google Assistant. Follow instructions in the Kidde app help section to link your WiFi alarm to Amazon Alexa and/or Google Assistant.* * AMAZON and ALEXA are trademarks of Amazon Technologies, Inc. or its affiliates. -
Page 23: Operation And Testing
When conditions in the residence move outside of the limits shown in the table, an alert is sent to your mobile device. You can also check the status of your indoor air quality using the Kidde app, after your alarm is registered with the app. -
Page 24: Recognizing Nuisance Alarms
erratic or low volume sound, the unit must be replaced. See Permanently Disable Alarm / Discharge Battery section to determine how to prepare the unit for shipment or disposal. noTe: If you push the test button on your alarm, the app will send you a text message. However, if you conduct a remote test using the app, you will not receive a text message. -
Page 25: Battery Backup
close to a cooking appliance. Large quantities of combustible particles are generated from spills or when broiling. Using the fan on a range hood which vents to the outside (non-recirculating type) will also help prevent nuisance alarms from occurring by removing these combustible products from the kitchen. Carbon Monoxide (Co) nuisance RESET: Pushing the button during CO alarm allows the unit to reset calculations and double check for the presence of CO. -
Page 26: Permanently Disable Alarm / Discharge Battery
15. Permanently Disable Alarm / Discharge Battery wArnInG: FAIlUre To dISCHArGe AlArM BATTerY AS InSTrUCTed PrIor To dISPoSAl MAY CreATe PoTenTIAl For lITHIUM BATTerY relATed FIre or HAzArd. wArnInG: dISCHArGInG THe AlArM BATTerY IS PerMAnenT. • Once the alarm battery has been discharged, it cannot be reactivated! •... -
Page 27: General Carbon Monoxide (Co) Information
16. General Carbon Monoxide (CO) Information Carbon monoxide (CO) is a colorless, odorless, and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxygen. Possible Sources of Co Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO. - Page 28 HVAC contractors will perform CO inspections. Some contractors may charge for this service. It’s advisable to inquire about any applicable fees prior to having the service performed. Kidde will not pay for, or reimburse the owner or user of this product, for any repair or dispatch calls related to the alarm sounding.
-
Page 29: Cleaning Your Alarm
17. Cleaning Your Alarm Your Alarm Should be Cleaned at least once a Year You can clean the interior of your alarm (sensing chamber) by using compressed air or a vacuum cleaner hose and blow- ing or vacuuming through the openings around the perimeter of the alarm. The outside of the alarm can be wiped with a damp cloth. -
Page 30: Good Safety Habits
18. Good Safety Habits develop and Practice a Plan of escape Prepare and practice a home escape plan twice a year, including drills at night. Know two ways out of every room (door & window) and identify a meeting place outside the home where everyone will gather once they have exited the resi- dence. - Page 31 Smoke detection – Are More Alarms desirable? For your information, the National Fire Protection Association’s Standard 72 reads: Where required The required number of smoke alarms might not by other governing laws, codes, or standards for provide reliable early warning protection for those a specific type of occupancy, approved single and multiple-station smoke alarms shall be installed as areas separated by a door from the areas protected by...
- Page 32 FCC (Contains FCC Id: 2AC7z-eSPwrooM32Ue) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 33: Service And Warranty
Kidde warrants that the enclosed alarm will be free from defects in material and workmanship or design under normal use and service for a period of ten years from the date of purchase. The obligation of Kidde under this warranty is... - Page 34 QUeSTIonS or For More InForMATIon Call Kidde Product Support line at 1-877-542-5471 or contact us at www.kidde.com Kidde 1016 Corporate Park Drive, Mebane, NC 27302 Kidde’s General Privacy Notice can be found at: https://www.corporate.carrier.com/legal/privacy-notice/ A Carrier Company ©2022 Carrier. All Rights Reserved.
