  • Page 1 AV Receiver DTR-10.5 Instruction Manual...

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.

  • Page 3: Precautions

    AC outlet voltages vary from country to country. Make sure that the voltage in your area meets the voltage requirements printed on the DTR-10.5’s rear panel (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz). Setting the [Standby/On] switch to Standby does not fully shutdown the DTR-10.5.

  • Page 4: Table Of Contents

    Before Using the DTR-10.5 ...9 Installing the Batteries ... 9 Using the Remote Controller ... 9 Types of the DTR-10.5 Option Boards ... 10 Installing the Option Boards (USA and Australian Models Only) ... 11 Index Parts and Facilities ...12 Front Panel ...
  • Page 5 Client Sub-menu ... 122 Lock/Version Setup...123 Lock Setup Sub-menu ... 123 Firmware Version Sub-menu ... 123 Using the Remote Controller Operating Integra/Onkyo Products Using the Remote Controller ...124 Operating Integra/Onkyo Products Using Connection ... 124 DVD Mode ... 124 CD Mode ... 126 MiniDisc Mode ...

  • Page 6: Features

    • 13 Digital Inputs (1 Optical on Front) (7 Optical/6 Coaxial/12 Assignable) to connect any variety of digital sources to the DTR-10.5’s powerful digital processor • 4 Digital Outputs (2 Optical/2 Coaxial/4 Assignable) to make direct digital dubs to other digital devices •...
  • Page 7 Features —Continued • THX is a trademark or registered trademark of THX Ltd. • HDMI, the HDMI logo and High Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC. • Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” “Surround EX,” and the double-D symbol are trademarks of Dolby Laboratories.

  • Page 8: Supplied Accessories

    • Do not use a power cord other than the one supplied with the DTR-10.5. The power cord supplied is designed for use with the DTR-10.5 and should not be used with any other device. • Never have the power cord disconnected from the DTR-10.5 while the other end is plugged into the...

  • Page 9: Before Using The Dtr-10.5

    (IR), or radio frequency (RF) for use with the optional RF Receiver. This is useful when, for example, the DTR-10.5 is installed in a rack or is not in line of sight of the remote controller. • To select AMP mode, press the scroll wheel. “AMP”...

  • Page 10: Types Of The Dtr-10.5 Option Boards

    Before Using the DTR-10.5 —Continued Types of the DTR-10.5 Option Boards The following option boards are available for the DTR-10.5 as of October 2004. DIGITAL IN DIGITAL IN OPTICAL COAXIAL “Net-Tune” is a trademark of Onkyo Corporation. ETHERNET Net-Tune SURR R...

  • Page 11: Installing The Option Boards (Usa And Australian Models Only)

    Turn off the power and unplug the power cord both from the DTR-10.5 and electrical outlet. Be sure to turn off the power of the DTR-10.5. Inserting or removing an option board with the DTR-10.5 turned on may cause failure.

  • Page 12: Index Parts And Facilities

    Index Parts and Facilities Here is an explanation of the controls and displays on the front panel of the DTR-10.5. The specifications for your model may differ due to regional requirements. Front Panel Standby/On Standby Rec/ Zone 3 Red )
  • Page 13 Index Parts and Facilities —Continued For further operational instructions, see the pages indicated in brackets [ ]. Standby indicator [9, 52] Lights when the DTR-10.5 is in the standby state and when a signal is received from the remote controller. Standby/On button [52] Press this button, the DTR-10.5 turns on and the...
  • Page 14 Index Parts and Facilities —Continued I Exit button [86] Press this button to return to the last menu. To exit from the setup mode, press the [Setup] button again. Select/Preset dial When the input source is FM or AM, turning this jog dial allows you to switch between your preset stations.

  • Page 15: Front Panel Display

    Index Parts and Facilities —Continued Front Panel Display Listening mode or input format indicators One of these indicators lights to show the format of the current input source. In addition, one of the listening mode indicators lights to indicate the current listening mode.

  • Page 16: Rear Panel

    TRIGGER OUT AC INLET SPEAKERS A AC OUTLET AC 120V 60Hz SWITCHED 120W 1A MAX. SPEAKERS B MODEL NO. DTR-10.5 RS 232 12 V ANTENNA HDMI TRIGGER IN 1 IR IN 12 V DC PWR SUPPLY 20mA MAX. IN 2...
  • Page 17 These connectors are for connecting to the audio input and output jacks on audio/video components. To connect a turntable, connect to the PH jacks. In addition to the PH jacks, the DTR-10.5 offers nine input and five output jacks. VIDEO/S VIDEO IN/OUT These connectors are for connecting to the video input and output jacks on video components.

  • Page 18: Remote Controller (Amp Mode)

    Remote Controller (Amp Mode) The DTR-10.5’s remote controller is a multipurpose device that can be used to control not just the DTR-10.5 but your other AV components as well. This section explains how its various operating modes can be used to control the DTR-10.5.
  • Page 19 This button is used to access the onscreen setup menus (OSD) that appear on the TV. Muting button This button is used to mute the DTR-10.5. This function can be set only with the remote controller. Main B button For the speakers used in main room B, every press of this button toggles the status between enabled and disabled.

  • Page 20: Speaker Placement

    Basic Speaker Placements for Home Theater and the Function of Respective Speakers The DTR-10.5 has many excellent features to recreate a clear three-dimensional sound image and lively sound movement. This enables you to enjoy, at home, the rich sound effects of a live theater or concert hall performance.

  • Page 21: Placing The Speakers

    Speaker Placement —Continued Placing the Speakers To fully enjoy surround sound, the configuration and placement of the speakers used are important. Be sure to read through the descriptions in the previous page and shown below. This section provides examples and descriptions that assume a typical situation. Front Left and Right Speakers, and Center Speaker •...

  • Page 22: Speaker Placement Suitable For Thx Audio

    Speaker Placement —Continued Subwoofer Using a subwoofer greatly improves the volume level and sound quality of bass sounds. The subwoofer effect depends not only on the listening position but also on the shape of the listening room. • In general, place the subwoofer in a corner of the room or at a point 1/3 the width of the room.

  • Page 23: Available Speaker Placements According To The Number Of Speakers

    According to the Number of Speakers The following speaker placements will be available according to the number of speakers connected to the DTR-10.5. For the number of speaker channel, _.1 ch represents a subwoofer. Key to abbreviations: FL : Front left speaker, FR : Front right speaker, C : Center...

  • Page 24: Connection Examples

    Speaker Placement —Continued Connection Examples The DTR-10.5 has two speaker terminal blocks for speaker system [A] and [B]. This allows you to build two 7.1 ch home theater systems, and various speaker placements and connections are also available. For example, some channels of either speaker system can be used for another room (Zone 2), or you can select one of two speaker systems for playback according to the source.
  • Page 25 Speaker Placement —Continued Main room A: 7.1 ch speaker systems and the two additional front speakers (When you want to use speaker system [A] for movies and enjoy 7.1 surround sound and the two additional front speakers for classic music.) Main room A •...
  • Page 26 Speaker Placement —Continued Main room A: 5.1 ch speaker system including the front speakers connected through the BTL or bi- amp connections Main room A • For speaker system [A], set the surround back speaker parameters to “BTL for Front ” or “Bi-Amp for Front” and all the other speaker parameters to “Main A”...

  • Page 27: Connecting Speakers

    Attaching the Speaker Labels The positive speaker terminals on the DTR-10.5 are color coded for easy identification. Attach the supplied speaker labels to the speaker cables, and then match the colors on the speaker cables to the corresponding terminals.

  • Page 28: Connecting A Subwoofer

    Connecting Auxiliary Power Amplifier (For Speaker System [A] only) These jacks are for connecting an auxiliary power amplifier. The PRE OUT terminals on the DTR-10.5 use the mode settings for speaker system [A]. You can use an auxiliary power amplifier to listen at louder volumes than you can with the DTR-10.5 alone.

  • Page 29: Using The Btl Connection

    DTR-10.5 will not be used. Connect the (+) terminal on the right speaker to the FRONT R SPEAKERS (+) terminal on the DTR-10.5 and the (–) terminal on the right speaker to the SURR BACK R SPEAKERS (+) terminal on the DTR-10.5.

  • Page 30: Connecting Antennas

    120W 1A MAX. SPEAKERS B MODEL NO. DTR-10.5 Once your DTR-10.5 is ready for use, you’ll need to tune into an FM radio station and adjust the position of the FM antenna to achieve the best possible reception. Use thumbtacks or something similar to fix the FM antenna into position.

  • Page 31: Connecting The Am Loop Antenna

    Push Insert wire Once your DTR-10.5 is ready for use, you’ll need to tune into an AM radio station and adjust the position of the AM antenna to achieve the best possible reception. Keep the antenna as far away as possible from your DTR-10.5, TV,...

  • Page 32: Connecting Av Components

    In addition to the conventional terminals, the DTR-10.5 has various terminals that are capable of next-generation digital transmission. Before connecting AV components to the DTR-10.5, make sure that your cable type matches the terminal shape and the signal type and that the cable length is appropriate for the placement of your connected components.
  • Page 33 S Video connection. The terminal shape for the component video connection cable can be BNC-type or RCA- type. For the DTR-10.5, the USA and Canadian models are equipped only with RCA-type termi- nals, and the Australian model is equipped with both RCA-type and BNC-type terminals.

  • Page 34: Connecting Monitors Such As Tv Or Projector

    Connecting Monitors such as TV or Projector • This section describes the connections for displaying the video source or the operating information of the DTR-10.5 on a monitor device such as a TV or projector. Before making a connection, check the terminal types on the monitor device and acquire the necessary cables by referring to page 33.

  • Page 35: Connecting A Dvd Player

    Integra products via connections with the DTR-10.5, you have to make analog audio signal connections. Con- nect the audio output terminals on the DVD player to the AUDIO IN terminals on the DTR-10.5 using analog audio cables (RCA/phono). • This section shows the connection example when you use the default settings of the DTR-10.5. However, you can connect a DVD player to other terminals within the same terminal section on the DTR-10.5.

  • Page 36: Connecting A Dvd Recorder Or Digital Vcr (Video 1)

    Connecting a DVD Recorder or Digital VCR (VIDEO 1) • When connecting a DVD recorder or digital VCR to the DTR-10.5, make connections for video and audio signals using digital and analog terminals. Before making connections, refer to pages 32 and 33 for correct connections.

  • Page 37: Connecting A Vcr (Video 2, Video 3)

    Connecting AV Components —Continued Connecting a VCR (VIDEO 2, VIDEO 3) • When connecting a VCR to the DTR-10.5, make connections for video and audio signals. Before making connec- tions, refer to pages 32 and 33 for correct connections. • This section shows the connection example when you use VIDEO 2 or VIDEO 3 as an input. In this case, you do not need additional configurations.
  • Page 38 Connecting AV Components —Continued Example for connecting with the VIDEO 3 as input When connecting to other Audio Outpuit audio terminals within the AUDIO OUT same terminal section, config- DIGITAL ure the audio input settings OPTICAL accordingly using the Audio Assign sub-menu (See page 94).

  • Page 39: Connecting A Dbs Tuner, Dbs Tv, Or Bs/Cs Tuner

    Connecting a DBS Tuner, DBS TV, or BS/CS Tuner • When connecting a DBS tuner, DBS TV, or BS/CS tuner to the DTR-10.5, make connections for video and audio signals using digital and analog terminals. Before making connections, refer to pages 32 and 33 for correct connec- tions.

  • Page 40: Connecting A Portable Dvd Player Or Video Camcorder

    Audio Assign sub-menu (See page 94). • When a turntable is equipped with a ground wire, connect the wire to the GND terminal on the DTR-10.5. However, some turntables may produce noise when the ground wire is connected to the DTR-10.5. In such a case, you do not have to connect the ground wire.

  • Page 41: Connecting A Recording Device Such As Md Recorder, Dat Deck, Cd Recorder Or Cassette Deck

    • Connect a cassette or DAT tape deck to TAPE1, and an MD or CD recorder to TAPE 2. • When you connect a cassette deck to the DTR-10.5, be sure to use only analog audio terminals. In the initial settings, no terminal of this unit is assigned to a REC terminal of the cassette deck.

  • Page 42: Connection Using The I.link (Audio) Terminal ( )

    The DTR-10.5 supports “i.LINK (AUDIO)” of the i.LINK transfer format. Accordingly, “i.LINK (AUDIO)” must also be supported for other devices that you want to connect to the DTR-10.5. The DTR-10.5 does not support other i.LINK transfer formats such as “MPEG-2 TS” used for BS digital broadcasts or “DV” used for DVD recorders, digital video, etc.
  • Page 43 Interconnection of i.LINK (AUDIO)-supported Devices The i.LINK connection allows for data transfer, even if the DTR-10.5 is connected to other devices via another i.LINK (AUDIO)-supported device. You can connect up to 17 devices in a daisy chain (in-line) connection arrangement using the i.LINK connection.
  • Page 44 OSD for DVD If DVD player is connected to the DTR-10.5 via i.LINK, you can output the OSD of the DTR-10.5 on a TV, even if a DVD player is directly connected to the TV. You can configure the setting to specify the display area on the TV, for example, right or left side of the screen.

  • Page 45: Connection Using Hdmi Terminals

    Intel, Silicon Image, FUJITSU, and Hewlett-Packard (Compaq Computer). How to Make a Connection through the HDMI Interface Use the HDMI cable to connect the HDMI terminals on the DTR-10.5 and on an HDMI-enabled device such as a DVD player, TV, or projector.
  • Page 46 Connecting AV Components —Continued Connection example when the source selection is performed on the DTR-10.5 DVD Player with HDMI OUTPUT HDMI Set Top Box with HDMI OUTPUT HDMI Connection example for higher video quality When connecting an AV component equipped with the HDMI input terminal, you can use the connecting layout shown below.

  • Page 47: Connecting

    Power on/ready function When the DTR-10.5 is in the standby state, if an connected component is turned on, the DTR-10.5 also turns on and the input source selected at the DTR-10.5 automatically switches to that component.

  • Page 48: Connecting Components Not Reached By The Remote Controller Signals (Ir In)

    ® Xantech RF Receivers can also be used with the remote controller to control the DTR-10.5 from a remote location. To use RF Receivers, set the Transmission Signal Format set- ting to “RF” (See page 141 for details). If Remote Controller Signal Does not Reach the DTR-10.5 Remote Sensor...

  • Page 49: Using An External Device With 12V Trigger Terminal

    Phoenix (Pluggable Connector) terminal (larger one) and one device to the 12V TRIGGER OUT E terminal (mini-jack). You can connect any external devices to the DTR-10.5 whether the connected device is located in the main, Zone 2 or Zone 3 room.

  • Page 50: Basic Operation Of Remote Controller Buttons

    Basic Operation of Remote Controller Buttons The remote controller supplied with the DTR-10.5 is a multifunctional remote controller, so you can operate not only the DTR-10.5 but also AV components connected to the apparatus and components placed in another room. The basic operations are explained here.

  • Page 51: To Operate A Connected Component (Mode Switching)

    Zone 3 Zone 2 When you perform the procedures on the DTR-10.5, press the [Zone 2] (or [Rec/Zone 3]), and turn the [Select/Preset] (or [Control/Tuning]). Before performing the following procedure, complete your macro settings (See page 137).

  • Page 52: Connecting The Power/Basic Operations

    Connecting the Power/Basic Operations • Before you plug in the DTR-10.5, confirm that all connections have been made properly. • Turning on the power may cause a momentary power surge, which might interfere with other electrical equipment on the same circuit, such as computers. If this happens, use a wall outlet on a different circuit.

  • Page 53: Turning On The Power From The Remote Controller

    Remote Controller Before you can use the remote controller, you must perform steps 1 and 2 in the “Turning on the Power” section and place the DTR-10.5 in the standby state. Press the scroll wheel. “AMP” appears on the remote controller’s display.
  • Page 54 Adjusting the Brightness of the Front Display You can adjust the brightness of the front display of the Master Volume DTR-10.5 using the [Dimmer] button on the remote controller or on the DTR-10.5 front panel. Net Audio DTR-10.5...
  • Page 55 Language Loca t ion RC-556M Using the Sleep Timer (remote controller only) With the sleep timer you can set the DTR-10.5 so that it automatically turns off after a set period. Press the scroll wheel, and then Remote press the [Sleep] button repeat-...
  • Page 56 Switching the Display While listening to or watching an input source, you can display information regarding the type of source and sig- nal being input. DTR-10.5 Press the [Display] button on the DTR-10.5. DISPLAY On the remote controller, press the...
  • Page 57 (AUDIO), and multichannel signals for audio input. You can choose the kind of signal to be played for a specific device. For Zone 2, the DTR-10.5 accepts only analog and digital signals for audio input. • “i.LINK” setting can be selected when the i.LINK terminal board [A] is installed.

  • Page 58: Using The Listening Modes

    Using the Listening Modes Types of Listening Modes Listening modes on the DTR-10.5 enable you to enjoy movie theater or concert hall quality sounds in your room. The DTR-10.5 provides the following listening modes. Before playing a source in optimal sound, be sure to complete the Speaker/Output Setup (See pages 88 - 91).
  • Page 59 This is a listening mode used for playing Super Audio CD format sources during i.LINK (AUDIO) connec- tion. Integra’s Proprietary Listening Mode (DSP) All Ch Stereo This mode is useful for playing music as BGM. Stereo sounds are provided by all speakers, so you can enjoy a powerful sound field.
  • Page 60 Using the Listening Modes —Continued Studio-Mix This mode is suitable for rock‘n’ roll and popular music. The image of powerful sounds is reproduced as sounds that make you feel as if you are sitting in a live house. TV Logic This mode is suitable for television programs broadcast from studios.

  • Page 61: Selecting The Listening Mode

    Using the Listening Modes —Continued Selecting the Listening Mode The DTR-10.5 provides various listening modes. Note: The available modes depend on the input signal you selected. Input source buttons Standby/On Standby Display Tape 1 Tape 2 Tuner Phono Net Audio...

  • Page 62: Listening To Radio Broadcasts

    Listening to Radio Broadcasts Using the Tuner One of the features of the DTR-10.5 that is most frequently used is its ability to play FM and AM broadcast radio stations. The DTR-10.5 provides a number of listening modes perfect for listening to the radio and getting the most out of your audio system.
  • Page 63 Mode Memory You can enter text names for any of the preset radio stations (See page 97). Selecting a Preset Radio Station Master Volume When using the DTR-10.5: Press [Tuner] input source button Tuner Open on the DTR-10.5. Video Audio...

  • Page 64: Enjoying Multichannel Playback

    For USA and Canadian models, multichannel playback is available when the multichannel terminal board [E] is installed. To the DTR-10.5, you can be connected up to two devices, such as a DVD player, that deal with multi- channel sounds (5.1-7.1 channels).

  • Page 65: Playing Back In Multichannel Sound

    You can also adjust the volume level with the input source button, the [Audio Selector] button, and the [Master Volume] dial on the DTR-10.5. You can also set the listening mode in advance for mul- tichannel playback (Listening Mode Preset). To do so, select “Input Setup”...

  • Page 66: Enjoying Movies And Music In The Remote Zone (Zone 2/3)

    When Connecting Only Speakers (Zone 2) • You can enjoy a different source in a remote zone while a 5.1 channel source is being played in the main room. • Adjust the volume level on the DTR-10.5. Main Room DTR-10.5 SURR BACK R...

  • Page 67: Enjoying Movies And Music In A Remote Zone

    Zone 3) • You can enjoy a different source in a remote zone while a 7.1 channel source is being played in the main room. • Adjust the volume level on the DTR-10.5 (not on the power amplifier). Main Room DTR-10.5...
  • Page 68 Mode Memory Dimmer Clear Zone 2 Select/Preset Turn on the power supply to the DTR-10.5, and then select a source for Zone 2 or Zone 3 Zone 2 Zone 3. For Zone 2, press the [Zone 2] button, and then select the source with the [Select/Preset] dial.

  • Page 69: Recording A Source

    [Standby] indicator is not blinking, and then start operations. When not using in the main room, press the [Standby/ On] button. If the DTR-10.5 is in the standby status, the power supply to Zone 2 and Zone 3 is not switched off.

  • Page 70: Recording Audio/Video While Playing

    You can record an audio source or a video on a compo- nent while playing another source on another compo- nent. For example, you can record a CD while watching a DVD. Operate this function on the DTR-10.5 in the main room. Turn on the power supply to DTR-10.5 in Main A or Main B mode.

  • Page 71: Recording The Video From One Source And The Audio From Another Source

    VIDEO IN 3 onto a video cassette tape on a VCR connected to VIDEO OUT 2. Operate this function in the main room. Turn on the power supply to the DTR-10.5 in Main A or Main B mode. Check connections and settings to the recording component.

  • Page 72: Enjoying Net Audio

    NET terminal board [B] (for Net Audio) is inserted. About Net-Tune The DTR-10.5 can be used as a Net-Tune client on a standard Ethernet network, allowing you to play music (MP3, WAV) stored on your Network Audio server through the DTR-10.5. If your network is connected to the Internet, you can also tune into Internet radio sta- tions.

  • Page 73: Networking Your Dtr-10.5

    figure these settings manually, see page 121. Networking Your DTR-10.5 To connect the DTR-10.5 to your Ethernet network, plug one end of a CAT5 Ethernet cable into the ETHERNET (Net- Tune) port, and plug the other end into a LAN port on your router or switch.

  • Page 74: Using The Remote Controller

    Enjoying Net Audio —Continued Using the Remote Controller To select Net-Tune mode, press the [Mode] button, and then roll the scroll wheel until “NET-T” appears on the display. Note: While neither the [Input] button nor [Mode] button is illuminated, the scroll wheel changes the input source and remote controller mode simultaneously (when you enter the Net-Tune mode, be sure that the LCD display shows “MSRV”...
  • Page 75 Enjoying Net Audio —Continued Number/letter buttons These buttons are used to enter numbers and letters when searching for music in your Network Audio server. Mode button This button is used with the scroll wheel to select the remote controller modes. Press this button first, and then roll the scroll wheel until “NET-T”...

  • Page 76: Enjoying Internet Radio

    [Mode] button is illuminated, roll the scroll wheel to select IRD (Internet Radio). “NET-T” appears in the bottom line. On the DTR-10.5, press the [Net Audio] button. This button switches between two alternative settings: Server and Internet Radio. Press the [Display] button on the remote controller.
  • Page 77 Press the [Enter] button. Buffering starts with the following mes- sage displayed. Enter When the buffering is complete, the DTR-10.5 starts playback of the broad- cast. Note: If you’re using a narrowband Internet connection (e.g., 56K modem, ISDN), depending on the station, Internet radio may not work satisfactorily.

  • Page 78: Playing A Music File Saved On The Network Audio Server

    Wait until the Network Audio server starts up. It may take a few second. Turn on the DTR-10.5. When you connect the DTR-10.5 to the net- work the first time, it will be connected to the first server found. While neither the [Input] button...
  • Page 79 Repeat 1 → All → Off. Repeat 1: Repeats the current track only. Repeat All: Repeats the tracks in the currently selected mode. Repeat Off: Repeat mode is disabled. You can operate the DTR-10.5 when playing and when stopped. ] but-...

  • Page 80: Configuring The Music Server

    Press the [Setup] button. This completes the configuration proce- dure and the menu disappears. Tips: When choosing settings on the DTR-10.5, after selecting the input source using the input source buttons, press the [Setup] button. Next, select the menu you want to configure by turning the [Select/Preset]...
  • Page 81 Enjoying Net Audio —Continued Music Server Memo Internet Radio Memo...

  • Page 82: Setup Menu

    When making the various settings required to configure your DTR-10.5 for optimum performance, you can use either the OSD Menu that appears on your television monitor or you can use the display on the front of the DTR-10.5. The OSD Menu is a settings menu that is displayed on your TV monitor.
  • Page 83 Setup Menu —Continued Main A Setup ===================== 0.Hardware Setup 1.Speaker/Output Setup 2.Input Setup 3.Listening Mode Setup 4.Audio Adjust 5.Preference 6.i.LINK Setup 7.Network Setup 8.Lock/Version 4.Audio Adjust ===================== 1.Tone Control 5.Preference ===================== 1.Volume Setup 2.Headphone Level Setup 3.OSD Setup 4.OSD Position 6.i.LINK Setup ===================== 1.Wakeup Setup...

  • Page 84: Osd Map (Main B)

    Setup Menu —Continued OSD Map (MAIN B) Main menu Main B Setup ===================== 0.Hardware Setup 1.Speaker Setup 2.Input Setup 3.Audio Adjust 4.Preference 0.Hardware Setup ===================== 1.TV Format Setup 1.Speaker Setup ===================== 1.Speaker Impedance 2.Speaker Crossover 3.Speaker Distance 4.Level Calibration 5.THX Audio Setup 2.Input Setup ==Input:XXXXXXXXX==== 1.Listening Mode Preset...

  • Page 85: Osd Map (Zone 2)

    Setup Menu —Continued OSD Map (ZONE 2) The Zone 2 settings shown on this page can be made when you perform either of the following settings in the “MAIN A” setup menu. • Under the “Speaker/Output Setup → Speaker Configuration” menu, when you select the surround back setting to “Powered Zone 2.”...

  • Page 86: Navigating The Setup Menu

    Setup Menu —Continued Navigating the Setup Menu You can change Setup Menu settings using the buttons on the front panel and on the remote controller. The illustrations here represent the remote controller. Main A Setup ===================== 0.Hardware Setup 1.Speaker/Output Setup 2.Input Setup 3.Listening Mode Setup 4.Audio Adjust...

  • Page 87: Hardware Setup

    AM tuner frequency. The initial setting is 9 kHz, and this only needs to be changed if you are using the DTR-10.5 in a 10 kHz region. 9 kHz: Select if 9 kHz increments are used in your area.

  • Page 88: Speaker/Output Setup

    Speaker/Output Setup The DTR-10.5 provides a wide range of variations in speaker connections and speaker settings, so you have to specify speaker settings according to conditions of each variation. For proper selection of an AV device connected at switching of the input type, you also need to allocate “audio output” and “video output” to each input type. If this allocation is incorrect, the desired component will not play a selected input source.

  • Page 89: Speaker Impedance Sub-Menu

    The selectable parameters are common to all items. Note: Before you change this setting, be sure to first lower the volume at the DTR-10.5 to the minimum level. 8 ohms (default): Select this when the impedance of the connected speaker is 8 ohms or more.

  • Page 90: Notch Filter Sub-Menu

    Speaker/Output Setup —Continued Perform the setup procedure below following the operating instructions described on page 86. 1. Select the unit of distance from “Unit.” You can select either “feet” or “meters.” The default varies depending on the region. 2. Set the distance you measured. Enter all the values for every speaker you connected.

  • Page 91: Thx Audio Setup Sub-Menu

    DTR-10.5 to input (play) sources. The setting varies depending on the connection conditions. The DTR-10.5 is equipped with analog output jacks for five lines, and digital output jacks: optical jacks (OPT) for two lines, and coaxial jacks (COAX) for two lines. If setting the analog jacks to “Zone 2 Out”...

  • Page 92: Video Output Assign Sub-Menu

    Pre Out (variable): Select this when you want to set “variable” for output to a device connected to Zone 2 or Zone 3. You should operate the DTR-10.5 to adjust the sound volume from the device in Zone 2 or Zone 3.

  • Page 93: Input Setup

    Items described here are set when you press the input source buttons. The DTR-10.5 is equipped with several types of jacks in addition to the standard audio and video jacks, and multiple jacks are provided for each type. You may freely assign input sources such as CD, PHONO, TUNER, TAPE 1, TAPE 2, and VIDEO 1-7 to these jacks.

  • Page 94: Audio Assign Sub-Menu (When Input Is Other Than Net Audio)

    Press the [Setup] button. Settings are completed and the menu screen disappears. Hint: When you perform the procedures on the DTR-10.5, after selecting the input source using the input source buttons, press the [Setup] button. Next, select the menu you want to configure by turning the [Select/Preset] dial and press the dial to confirm the selection.

  • Page 95: Music Server Sub-Menu (When Input Is Net Audio)

    Coax 1-Coax 6: Select the device connected to “DIGITAL IN COAXIAL 1-6.” Front: Select the device connected to the “Video 7 Input Digital” jack behind the front door of the DTR-10.5. AES/EBU: Select the device connected to “DIGITAL IN (BALANCED) AES/EBU.” The “AES/EBU” is available when the board [E] equipped with AES/EBU terminal is inserted.

  • Page 96: Listening Mode Preset Sub-Menu

    Input Setup —Continued Listening Mode Preset Sub-menu You can specify a listening mode you frequently use for each input source. When a picture you like and frequently watch is a Dolby Digital source, for example, you may specify “Dolby Digital,” and if a CD of classical music you are fond of is a PCM source, you can specify “Pure Audio.”...

  • Page 97: Character Edit Sub-Menu

    Input Setup —Continued D.F. Mono Here, you can specify the listening mode for playing digital signals such as Dolby Digital and AAC recorded in monaural. This option can be set for Main B and Zone 2 as well as for Main A. You can select from the listening modes listed below: (Main A/B) Pure Audio, Direct, Stereo, Mono (Default), Mono...

  • Page 98: Intellivolume Sub-Menu

    (narrowing the delay) will make the sound field sharper. 12V Trigger Assign Sub-menu When the 12V TRIGGER OUT jack on the DTR-10.5 is connected to the12V TRIGGER IN jack of a device, you can specify the room where you are going to trigger the device to turn on the power (for connection details, see page 49).

  • Page 99: Listening Mode Setup

    Listening Mode Setup This menu allows you to configure the listening mode settings including audio effect and playback options. Mono Setup Sub-menu This sub-menu allows you to configure the audio effect and playback options when you play a source in the Mono listening mode.

  • Page 100: Stereo Setup Sub-Menu

    Listening Mode Setup —Continued Re-EQ On: Adjusts the soundtrack in which the treble is overemphasized, so that the sound is optimized for home theater. Academy On: Lowers the treble level and filters the noise when the source contains emphasized treble sound and too much hiss, such as an old mono audio movie recorded onto videotape.

  • Page 101: Direct, Pure Audio Setup Sub-Menu

    Listening Mode Setup —Continued • When the impedance setting for “Front L/R A” or “Front L/R B” in the Speaker Impedance sub-menu is set to “6 ohms” or “4 ohms,” the available options will be “A” and “B.” A (Default): Outputs the source from the speakers connected to the FRONT L/R SPEAKERS A terminals.

  • Page 102: Multichannel Input Setup Sub-Menu

    This option selects the enhancement mode for playback when you play a 5.1ch analog multichannel source as a 6.1 or higher channel source through the DTR-10.5. The surround back setting you select here will be applied to all of the multichannel input signals.

  • Page 103: I.link(Ieee1394):Dvd-Audio Input Setup Sub-Menu

    Surr L/R Sp This option configures the surround speakers to use when the DTR-10.5 plays an input source such as DVD- Audio and Super Audio CD. Select the speaker terminals to which the speakers you want to use are connected.
  • Page 104 SPEAKERS B terminals. g. Surr Bk Speaker This option configures the surround back speakers to use when the DTR-10.5 plays DVD-Audio. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the “(Speaker B) Surr Back”...

  • Page 105: I.link(Ieee1394):Sacd Input Setup Sub-Menu

    Surr L/R Sp This option configures the surround speakers to use when the DTR-10.5 plays a Super Audio CD. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the “(Speaker B) Surr L/R”...

  • Page 106: Dolby Digital Setup Sub-Menu

    Surr Bk Speaker This option configures the surround back speakers to use when the DTR-10.5 plays a Super Audio CD. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the “(Speaker B) Surr Back”...
  • Page 107 Listening Mode Setup —Continued On: Adjusts the soundtrack in which the treble is overemphasized, so that the sound is optimized for home theater. f. Front Speaker This option configures the front speakers to use when playing the source in the Dolby Digital listening mode. Select the speaker terminals to which the speakers you want to use are connected.

  • Page 108: Dts Setup Sub-Menu

    This option allows you to select the enhancement mode for playback when you play a 5.1ch source as a 6.1 or higher channel source through the DTR-10.5. The surround back setting you select here will be applied to the DTS input signal “*/2.”...

  • Page 109: Aac Setup Sub-Menu

    SB Mode (5ch) Selects the enhancement mode for playback when you play a 5.1ch source as a 6.1 or higher channel source through the DTR-10.5. The surround back setting you select here will be applied to the AAC input signal “*/ 2.”...

  • Page 110: Dolby Pro Logic Iix/Dts Neo:6 (2Ch Input Only) Setup Sub-Menu

    Selects the enhancement mode for playback when you play a 2ch source as a 6.1 or higher channel source through the DTR-10.5. The surround mode setting you select here will be applied to the Analog/PCM and D.F. 2ch input signals.
  • Page 111 Logic IIx Music mode. When you play the source in the Dolby Pro Logic II mode and the center speaker is connected to the DTR-10.5, the center channel signal is output only from the center speaker (if the center speaker is not connected, the center channel signal will be equally divided into the left and right front speakers to create a virtual center sound image).

  • Page 112: Thx Setup Sub-Menu

    “SB Mode (2ch)” is applied. b.THX Mode (5ch) This option allows you to select which THX mode the DTR-10.5 will use when applying the THX effect to the signal. The THX Mode you select here will be given preference over the SB Mode (5ch).
  • Page 113 Games Mode: In this new mode for the THX Ultra2, the DTR-10.5 plays a 2 ch game source as a 7.1 or higher channel source. d. Front Speaker This option configures the front speakers to use when...

  • Page 114: Mono Movie Setup/Enhance Setup/Orchestra Setup/Unplugged Setup/Studio-Mix Setup/Tv Logic Setup Sub-Menu

    This sub-menu allows you to configure the audio effect and playback options when you play a source in the Integra original listening mode. The settings in this sub- menu can be made when the (Speaker A) Surr L/R setting is set to an option other than “Not Used” in the Speaker Configuration sub-menu.

  • Page 115: All Ch Stereo Setup/Full Mono Setup Sub-Menu

    Speaker Configuration sub-menu. a. Re-EQ/Academy This option allows you to configure whether the Re-EQ or Academy effect is applied or not in the Integra original listening mode. Use these effects when you do not want to overemphasize the treble sound.

  • Page 116: Dolby Virtual Speaker Setup Sub-Menu

    Listening Mode Setup —Continued e. Surr Bk Speaker This option configures the surround back speakers to use when playing the source. Select the speaker terminals to which the speakers you want to use are connected. This setting can be made when the “(Speaker B) Surr Back”...

  • Page 117: Dolby Headphone Setup Sub-Menu

    Listening Mode Setup —Continued A+B: Outputs the source from the speakers connected to the SURR L/R SPEAKERS A and SURR L/R SPEAKERS B terminals. e. Subwoofer This option configures the subwoofer to use when playing the source. Select the terminal to which the subwoofer you want to use is connected.

  • Page 118: Audio Adjust

    Audio Adjust Tone Control Sub-menu You can adjust bass, mid, and treble notes for each speaker set. • For any speaker set to “Not Used” in the Speaker Configuration sub-menu, no associated setting item is displayed. Front Bass Option for adjusting bass notes from front L/R speakers.

  • Page 119: Preferences

    Power On Volume You can set a constant volume level of sounds output when the DTR-10.5 is powered on. When displaying in absolute values, specify at 0.5 intervals in a range from 0 to 100. When displaying in relative values, specify at 0.5 dB intervals in a range from –...

  • Page 120: I.link Setup

    Setup This menu can be used when connecting to an Integra i.LINK (AUDIO)-ready device. Wakeup Setup a. Wakeup on i.LINK (IEEE1394) Specify connecting condition on standby of the DTR-10.5. Enable: To be left connected. Disable (Default): To be disconnected while the DTR-10.5 is on standby to save electricity.

  • Page 121: Network Setup

    If using a broadband router (DHCP function), you need not perform “7. Network Setup” because the DHCP function on the DTR-10.5 is defaulted to “Enable.” When the DHCP function for the broadband router is set to “Disable,” network setup is required. In this case, you have to be knowledgeable about the network.

  • Page 122: Client Sub-Menu

    DTR-10.5 is a client. a. Client Name Confirm the client name used on the Net-Tune system. The client name is assigned by the DTR-10.5. You cannot change the assigned name. b. Wakeup on LAN Specify the network condition on standby of the DTR-10.5.

  • Page 123: Lock/Version Setup

    Lock/Version Setup The following sub-menus allow you to lock your settings or display the software version of the DTR-10.5. Lock Setup Sub-menu a. Lock You can lock all of the setting menus to prevent settings from being changed by mistake.

  • Page 124: Operating Integra/Onkyo Products Using The Remote Controller

    Remote Controller The RC-556M remote controller is a useful tool that can operate not only the DTR-10.5, but also all the other com- ponents of your home theater. To operate any component other than the DTR-10.5 with the RC-556M remote con- troller, press the [Mode] button and use the scroll wheel to select the component to operate.
  • Page 125 Setup/Guide button This button is used to access the DVD player’s onscreen setup menus. Muting button This button is used to mute the DTR-10.5. This function can be set only with the remote controller. Play [ ] button This button is used to start DVD playback.

  • Page 126: Cd Mode

    “CD” appears on the display. button This button is used to set the volume of the DTR-10.5. Muting button This button is used to mute the DTR-10.5. This function can be set only with the remote controller. ] button is...

  • Page 127: Minidisc Mode

    This button is used to set the volume of the DTR-10.5. Muting button This button is used to mute the DTR-10.5. This function can be set only with the remote controller. Play [ ] button This button is used to start MiniDisc playback.

  • Page 128: Tape Mode

    This button is used to set the volume of the DTR-10.5. Muting button This button is used to mute the DTR-10.5. This function can be set only with the remote controller. Play [ ] button This button is used to start tape playback.

  • Page 129: Using The Remote Controller With Other Components

    134 and 135. Remote Control Codes for an Integra/Onkyo DVD player The remote control code that you use with an Integra/ Onkyo DVD player depends on whether it’s connected , as follows: 5001: Use this code if you’ve connected an and an RCA/phono analog audio connection cable to your DVD player.
  • Page 130 Aiwa 5010 Akai 5019 Apex 5015, 5016 CyberHome 5027 Denon 5017, 5020 5003 Hitachi 5009 Integra 5001, 5002 Integra Research 5001, 5002 5023 Kenwood 5017 Magnavox 5004, 5021 Marantz 5025, 5026 Mitsubishi 5005 Onkyo 5001, 5002 Panasonic 5011, 5017, 5020...
  • Page 131 Using the Remote Controller with Other Components —Continued SAT (satellite tuner) Manufacturer Control code Manufacturer Universum 4021, 4024 Aiwa Vortec 4017 Akai Wela 4025 Alba Zehnder 4020 Anitech Zenith 4032 Baird CBL (cable receiver) Bell & Howell Manufacturer Control code Blaupunkt 3001, 3002, 3021 Bush...
  • Page 132 Using the Remote Controller with Other Components —Continued Manufacturer Control code 2001, 2002, 2003, 2008, 2010, 2013, 2021, 2023, 2025, 2026, 2027 2007, 2008, 2010, 2011, Realistic 2012, 2017 2048 Roadstar 2033, 2043 Runco 2019 Saba 2040, 2048 Saisho 2028, 2041 Salora 2030 Samsung...
  • Page 133 Using the Remote Controller with Other Components —Continued Manufacturer Control code Manufacturer Loewe 1014, 1040, 1055 Pioneer Luxman 1004, 1006 Portland 1001, 1006, 1010, 1014, Price Club 1016, 1017, 1034 Prism M Electronic 1035, 1053, 1062, 1063 Profex Magnadyne 1040, 1067, 1068 Proline Magnafon 1067...
  • Page 134 On, Standby Standby CH/Disc +/– Select satellite channels Select menu items Enter Confirm selection Number buttons Enter numbers The following buttons control the DTR-10.5. Adjust the DTR-10.5 volume Muting Mute the DTR-10.5 Controlling a VCR Standby @.-'/ PQRS + 10...
  • Page 135 *Buttons marked with an asterisk can always be used to control a TV regardless of the currently selected remote controller mode. These buttons do not work with the additional TV modes. The following buttons control the DTR-10.5. Adjust the DTR-10.5 volume MUTING Mute the DTR-10.5...

  • Page 136: Learning Commands From Another Remote Controller

    [LIGHT], [Custom], [Macro], [Mode], [Input], [Zone 2], [Zone 3], and the scroll wheel but- ton. • The DTR-10.5’s remote controller can learn a total of 150 commands. However, the commands of some remote controllers may use a lot of memory, in which case, this total will be reduced.

  • Page 137: Using Macros

    DTR-10.5: 1. Press the scroll wheel, (to select AMP mode). 2. Press the [On] button (to turn on the DTR-10.5). 3. Roll the scroll wheel to select CD (to select the CD remote controller mode and the CD input source).
  • Page 138 Using the Remote Controller with Other Components —Continued Running Macros Programmed macros can be run as follows. Press the [Macro] button. Roll the scroll wheel to select the macro’s number, and then press the scroll wheel. The actions in the macro are per- formed in the order in which they were programmed.

  • Page 139: Other Settings For The Remote Controller

    Other Settings for the Remote Controller Editing Remote Controller Modes Adding New Remote Controller Modes You can add additional modes (DVD, TV, VCR, CBL, SAT) to the remote controller. This is useful if, for example, you have several DVD players or TVs. Press and hold the [Custom] but- ton for more than three seconds.
  • Page 140 Other Settings for the Remote Controller —Continued Deleting Remote Controller Modes You can delete remote controller modes that you don’t need, such as modes for components that you don’t have. The AMP mode cannot be deleted. Press and hold the [Custom] but- ton for more than three seconds.

  • Page 141: Resetting The Remote Controller

    RF receiver to pick up commands from the remote controller, which are then fed to the DTR-10.5 via its IR IN socket. For this to work, you must assign the same ID and channel to the remote controller and RF receiver.

  • Page 142: Changing The Remote Controller's Control Id

    Other Settings for the Remote Controller —Continued Changing the Remote Controller’s Control ID This section explains how to change the remote control- ler’s ID. You may need to change this if the DTR-10.5’s remote controller interferes with other Integra/Onkyo components located in the same room. Note: If you change the remote controller’s ID, be sure to...

  • Page 143: Relationship Between Input Source And Listening Mode

    Relationship Between Input Source and Listening Mode Available listening modes may differ depending on your region and the option board installed. Input Signal Format Button Type of source CD, TV, LD, VHS, MD, Vinyl, Radio, Cassette, Cable, Listening mode Satellite, etc. ✔...
  • Page 144 Relationship Between Input Source and Listening Mode —Continued Input Signal Format Multichanne (*/2) Button Type of source Listening mode Direct Direct Pure A Pure Audio Stereo Stereo Multiplex • PLII Movie • PLII Music • PLII Game • PLIIx Movie •...
  • Page 145 Relationship Between Input Source and Listening Mode —Continued Input Signal Format Multichannel Button (*/2) Type of source Listening mode ✔ Direct Direct ✔ Pure A Pure Audio ✔ Stereo Stereo Multiplex • PLII Movie • PLII Music • PLII Game ✔...

  • Page 146: Troubleshooting

    Troubleshooting If you have any trouble using your DTR-10.5, look for a solu- tion in this section. If you can’t resolve the issue yourself, con- tact the dealer from whom you purchased this unit. Power Can’t turn on the DTR-10.5? •...

  • Page 147: Video

    fluorescent lights. Relocate if neces- sary. • If the DTR-10.5 is installed in a rack or cabinet with col- ored glass doors, the remote controller may not work reli- ably when the doors are closed. •...

  • Page 148: Recording

    Zone 2/Zone 3 Zone 2/3 has turned off? • Was the Sleep function set? The Sleep function turns off Zone 2/3 as well as the DTR-10.5. To set the Sleep function for Zone 2/3 only, see page 67. There’s no sound? •...

  • Page 149: Error Messages

    five seconds, and then plug it back in again. To reset the DTR-10.5 to its factory defaults, turn it on and, while holding down the [Video 1] button, press the [Standby/ On] button.

  • Page 150: Specifications

    Specifications General Power Supply Rating USA and Canadian models: AC 120 V, 60 Hz Australian models: AC 230-240 V, 50 Hz Consumption Power USA & Canadian models: 13.8 A Australian models: 1,200 W Standby Power Consumption: 3.9 W Dimensions (W × H × D): 435 ×...
  • Page 151 Specifications —Continued Output Level and Impedance: Audio 200 mV, 470 Ω (Tape 1/2/ Video AUDIO 1-5: 1/2/3 Rec Out) 100 mV, 470 Ω (Zone 2/3 Out (fixed)) 1 V, 470 Ω (Zone 2/3 Out (variable)) 1 V, 470 Ω (Front L/R, CENTER, PRE OUT A: SURR L/R, SURR BACK or Zone 2 L/R, SUB WOOFER)
  • Page 152 Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Printed in Japan D0410-1 Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN...

Table of Contents
