Troy-Bilt TB60AF Operator's Manual

Operator's Manual
20 Volt Lithium-Ion
Battery-Powered Trimmer
TB60AF
TOOLS REQUIRED:
• #2 Phillips screwdriver
• 3/8" Socket
Use 20V Lithium-Ion Battery TB20V or TB20V50 (TB20V not included)
Use 20V Lithium-Ion Battery Charger TBCHGR
TABLE OF CONTENTS
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Starting and Stopping Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Maintenance and Repair Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
All information, illustrations and specifications in this manual are based on the latest product information
available at the time of printing. We reserve the right to make changes at any time without notice.
Copyright© 2011 MTD SOUTHWEST INC, All Rights Reserved.
SAVE THESE INSTRUCTIONS
SERVICE INFORMATION
DO NOT RETURN THIS UNIT TO THE RETAILER. PROOF OF PURCHASE WILL BE REQUIRED FOR
WARRANTY SERVICE.
For assistance regarding the assembly, controls, operation or maintenance of the unit, please call the
Customer Support Department: 1-800-828-5500 (U.S.) or 1-800-668-1238 (Canada).
Additional information about the unit can be found on our website: www.troybilt.com (U.S.) or
www.troybilt.ca (Canada).
Please call the Customer Support Department for replacement parts. When servicing, use only identical
replacement parts.
769-07272 P00
All manuals and user guides at all-guides.com
SAFETY INFORMATION
• SAFETY ALERT SYMBOLS •
Safety alert symbols are used to draw your attention to possible dangers. These symbols, and their
explanations, deserve your careful attention and understanding. The safety warnings do not by
themselves eliminate any danger. The instructions or warnings they give are not substitutes for
proper accident prevention measures. These safety instructions are not meant to cover every
possible condition that may occur. If questions arise, please call the Customer Support
Department at 1-800-828-5500 (U.S.) or 1-800-668-1238 (Canada).
SYMBOL MEANING
DANGER:
Signals an EXTREME hazard.
Failure to obey a safety DANGER signal WILL result in serious injury or death to yourself or
to others.
WARNING:
Signals a SERIOUS hazard.
Failure to obey a safety WARNING signal CAN result in serious injury to yourself or to others.
CAUTION:
Signals a MODERATE hazard.
Failure to obey a safety CAUTION signal MAY result in property damage or injury to
yourself or to others.
IMPORTANT! Signals special mechanical information.
NOTE: Signals additional important general information.
• IMPORTANT SAFETY INSTRUCTIONS •
CALIFORNIA PROPOSITION 65
WARNING:
Battery posts, terminals and certain finished components contain
lead, lead compounds and chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Wash hands after handling.
WARNING:
When using an electric unit, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to persons, including
the following.
READ ALL INSTRUCTIONS BEFORE OPERATING
BASIC SAFETY PRECAUTIONS
• DO NOT rely exclusively upon the safety devices built into the unit.
• DO NOT allow the unit to be used as a toy.
• Please read the entire operator's manual carefully before attempting to assemble, operate or
maintain the unit.
• Follow all safety instructions. Failure to do so can result in property damage or serious injury to
yourself and/or others.
• Be thoroughly familiar with the controls and the proper use of the unit. Know how to stop the unit
and disengage the controls quickly.
• Stay alert! Do not operate the unit when tired, ill or under the influence of alcohol, drugs or medication.
• Never allow children to operate the unit. Never allow adults to operate the unit without proper instruction.
• Make sure that all guards and safety attachments are properly installed before operating the unit.
• Keep these instructions. Refer to them often and use them to instruct other users. If loaning
someone this unit, also loan them these instructions.
• Keep bystanders, especially children and pets, at least 50 feet (15 m) away. If anyone enters the
work area, stop the unit!
• Keep the work area clean. Cluttered areas invite injuries. Do not start the operation until the work
area is clear and free from obstructions and there is secure footing.
• Always wear appropriate eye and ear protection when operating this unit. Wear safety goggles, or
safety glasses with side shields, that are marked as meeting ANSI Z87.1-1989 standards. Failure
to do so could result in serious eye injury caused by thrown or falling objects. If the operation is
dusty, wear a face mask or dust mask.
• Dress appropriately. Wear non-slip protective gloves and boots. Do not wear loose clothing,
jewelry, short pants, sandals or go barefoot. Secure hair above shoulder level to prevent
entanglement in moving parts.
• Only use the unit in daylight or good artificial light.
• Only use the unit for its intended purpose. Only use the unit as described in this manual.
TRIMMER SAFETY PRECAUTIONS
• Inspect the work area before using the unit. Remove any hard and/or sharp objects, such as metal,
glass, wire, etc. If thrown, such objects could cause property damage or injury to the operator or
bystanders.
• Only use original equipment manufacturer replacement cutting blades. Never use metal-reinforced
line, wire or rope. These can break off and become dangerous projectiles.
• Keep the unit clean of vegetation and other materials that may become lodged between the
cutting head and shield. Keep vent openings clean and clear of debris.
• The cutting head shield must always be in place while operating the unit. Do not operate the unit
without the proper cutting blades installed.
• Extra caution is required when using the unit for edging purposes. There is an increased risk of
injury or property damage caused by thrown objects when the cutting head shield is not held
horizontal to the ground.
GENERAL SAFETY PRECAUTIONS
• DO NOT over reach.
• DO NOT operate the unit on unstable surfaces, such as in trees or on ladders, slopes or rooftops.
Be very careful when using the unit on stairs.
• DO NOT handle the unit with wet hands.
• DO NOT expose the unit to rain. Do not use the unit in damp or wet locations or conditions.
• DO NOT operate the unit on wet surfaces.
• DO NOT use the unit in the presence of flammable liquids or gases.
• DO NOT operate a unit that is damaged, improperly adjusted or not completely and securely
assembled. Be sure that the unit stops when the trigger is released. Do not use the unit if the switch
does not turn the unit on and off properly or if the switch lock does not work.
• DO NOT attempt operations beyond the operator's capacity or experience.
• DO NOT operate the unit with one hand! Serious injury to the operator, helpers or bystanders may result
from one-handed operation. This unit is intended for two-handed use. Grip the unit firmly with both
hands when the motor is running. Keep the left hand on the D-handle and the right hand on the shaft
grip. Use a firm grip with thumbs and fingers encircling the handles. Do not let go!
• DO NOT force the unit. It will do a better, safer job when used at the intended rate.
• Adjust the D-handle to provide the best grip.
• Keep proper footing and balance at all times.
• Keep hair, loose clothing, fingers and all other body parts away from moving parts. Do not try to touch or
stop moving parts when they rotate.
• To reduce the risk of electric shock, avoid body contact with grounded conductors, such as metal pipes
or wire fences.
• Always stop the motor when operation is delayed, before setting down the unit or when walking from
one location to another. Make sure the unit comes to a complete stop.
• To avoid accidental starting, never carry the unit with fingers on the switch trigger. Always carry the unit by the
handles with the battery removed.
• Always make sure the lock-off button is in the locked or OFF position before installing or removing the battery.
• If the unit strikes or becomes entangled with a foreign object, stop the motor immediately, remove
the battery and check for damage. Do not restart or operate the unit before repairing damage.
09/11
