Swing Gate Operator Installation Manual*
fr
Manuel d'installation de l'opérateur de porte battante
nl
Installatiehandleiding draaihekaandrijving
de
Installationshandbuch für Drehtorantriebe
pl
Instrukcja instalacji operatora bramy skrzydłowej
cs
Instalační manuál pro obsluhu křídlové brány
sk
Inštalačný manuál k pohonu krídlovej brány
sl
Priročnik za namestitev upravljalnika krilnih vrat
hu
Swing kapu Üzemeltető Installation Manual
* For GB (UK, NI) specific information on national regulations and requirements
see English part of the manual.
LA250EVK / LA300EVK
Advertisement
Table of Contents
Related Manuals for Chamberlain LA250EVK
Summary of Contents for Chamberlain LA250EVK
- Page 1 LA250EVK / LA300EVK Swing Gate Operator Installation Manual* Manuel d‘installation de l‘opérateur de porte battante Installatiehandleiding draaihekaandrijving Installationshandbuch für Drehtorantriebe Instrukcja instalacji operatora bramy skrzydłowej Instalační manuál pro obsluhu křídlové brány Inštalačný manuál k pohonu krídlovej brány Priročnik za namestitev upravljalnika krilnih vrat Swing kapu Üzemeltető...
-
Page 2: Table Of Contents
TABLE OF CONTENTS NOTE:The original installation and operating instructions were compiled in English. Any other available language is a translation of the original English version. 1. SAFETY INSTRUCTIONS AND INTENDED USE......................................2 2. DELIVERY SCOPE..............................................4 3. TOOLS NEEDED.................................................4 4. OVERVIEW OF GATE OPERATOR..........................................4 5. -
Page 3: Safety Instructions And Intended Use
1. SAFETY INSTRUCTIONS AND INTENDED USE About this Manual – Original Manual These instructions are the original operating instructions according the machinery directive 2006/42 EC. The instruction manual must be read carefully to understand important product information. Pay attention to the safety and warning notices. Keep the manual in safe place for future reference and to make it available to all persons for inspection, service, maintenance and repair. - Page 4 1. SAFETY INSTRUCTIONS AND INTENDED USE During operation, the gate should not under any circumstances obstruct public path ways and roads (public area). When using tools and small parts to install or carry out repair work on a gate exercise caution and do not wear rings, watches or loose clothing. To avoid serious personal injury due to entrapments, remove any locking device fitted to the gate in order to prevent damage to the gate.
-
Page 5: Delivery Scope
2. DELIVERY SCOPE LA250EVK (2 x motor units) LA300EVK (2 x motor units) Post Mounting Gate Mounting Circlip (4x) Circlip pin (4x) Fix Post Adjustable Post Gate Mounting Circlip (2x) Bracket (2x) Bracket (2x) Bracket (2x) Bracket (2x) Bracket (2x) -
Page 6: Mechanical Installation
All crushing points must be secured by an entrapment protection according to EU: EN 12453, EN 60335-2-103; GB (UK, NI): BS EN 12453, BS EN 60335-2-103. Table 1: Table 1: LA250EVK with external hardstop, LA300EVK with internal hardstop, LA300EVK without internal hardstop,... -
Page 7: Post Bracket Installation
4.1 Installation with external gate hard stops: (gate hard stops already installed): a. For LA250EVK: pull out the tube completely and make 1 complete turn of the tube in clockwise direction see (picture 4.1.a). For LA300EVK (with internal operator hard stops removed): pull the operator trolley to the max. closed position leaving 25 mm free space from absolute end position. -
Page 8: Hardstop Installation
5. MECHANICAL INSTALLATION LA250EVK LA300EVK 4.1.a 4.1.a 25 mm min. 1 x 360° 25 mm min. Spirit level Spirit level 1115 mm 730 mm with hardstops 750 mm w/o hardstops 4.1.b 4.1.c LA250EVK LA300EVK 5.5 Hardstops Installation Hardstop 5 mm 90°... -
Page 9: Emergency Release Mechanism
5.8 Power Wiring Power wiring must be done by a certified electrician specialist. Not included with LA250EVK Congratulations! Herewith the mechanical installation of your gate ope- rator is finished. Please proceed with Programming and Basic Settings... -
Page 10: Wiring Diagram
6. WIRING DIAGRAM AC 230V IN IR 3 IR 2 IR 1 EXAMPLE 8.2K BATTERY 24V BAT EDGE IR SENSOR COMMAND E-LK SPEC SE SE GND IR2 IR1 IN3 IN2 IN1 24V external accessories Examples: outdoor receiver EXAMPLE 24VDC SYNC STBY UART LIMIT-SW... -
Page 11: Programming
7. PROGRAMMING 7.1 Display, Programming Buttons and Function Setting 2 digit LED display Programming buttons function (4 buttons): Button Function program / delete remote controls and specific functions enter programming mode, select function and save LED spot Navigate through the menu and change the value on display Function and programmed values are shown on LED display. -
Page 12: Wing Movement Direction
7. PROGRAMMING 7.3 Wing Movement Direction Before programming, move the gate manually in the middle position and re-engage release mechanism (see page 8). Press and hold the “–“ button on the control board and ensure that the motors are moving in CLOSE direction. If correct, immediately let go of the “-“ button and gate stops. -
Page 13: Stand-By Mode
7. PROGRAMMING Advanced Learning Mode (manual setting of Soft Stop position) 1. Press and hold “+ and –“ buttons for 2 seconds. 2. Automatic learning starts. LL will flash on the display during complete process. 3. Wing 2 moves in CLOSE direction until hard stop is reached, and stops. 4. -
Page 14: Programming And Erasing Of Remote Controls, Radio Accessories And Myq Devices
7. PROGRAMMING 7.6 Programming and Erasing of Remote Controls, Radio Accessories and myQ Devices Program remote control devices (transmitters and wireless wall controls): NOTE: the remote controls delivered with the operator are already factory pre- learned to the operator (top button near the LED) and do not require extra pro- gramming. -
Page 15: Advanced Settings
7. PROGRAMMING 7.7 Advanced Settings Herewith you start with Advanced Settings. 7.7.1 Overview Advanced Settings Function Function Transmitter Flashing Light IR1 photocell Pre-Flashing IR2 photocell Special contact IR3 photocell START Speed in OPEN and CLOSE Input 1 command Maintenance counter Input 2 command Password Input 3 command... -
Page 16: Partial Opening Motor 1
7. PROGRAMMING 7.7.7 Delay Motor 1 in Close Direction Open – Close – Open Delay Motor 1 in CLOSE direction function defines time delay for Motor 1 in Open – Stop – Close – Stop – Open (Default) CLOSE direction. Not available for the single motor application. Not executed during reversal or after IR beam interruption in both directions. -
Page 17: Relief Motor 1 For E-Lock
7. PROGRAMMING 7.7.10a Relief Motor 1 for E-Lock 7.7.12 Special Contact Settings Relief Motor 1 for E-Lock function enables to briefly push Motor 1 in CLOSE direc- Special Contact function defines relay activation time. tion before engaging e-lock to relieve excess pressure on e-lock. Not available if EL A 24V max 500mA relay can be connected to manage other devices, e.g. -
Page 18: Password Use
7. PROGRAMMING 7.7.15b Password Use 1. Choose “PS” function and press “P” button. 2. “00” flashes on display. 3. Use “+” and “–” buttons to enter the correct password and press “P” button to confirm. 4. If correct password is entered, the display shows the value for 2 seconds and changes to “PS”. -
Page 19: Soft-Stop Speed
7. PROGRAMMING Speed Motors 1 & 2 in CLOSE Direction 7.8 Factory Default Speed Motor 1 and 2 in CLOSE direction allows closing speed adjustment compa- Factory default function resets control board to the original factory set-ups. All set- red to the speed set during Learning phase. Password must be entered to access tings, including limit settings, will be erased. -
Page 20: Error Codes
9. ERROR CODES Error Issue Possible reason Solution code Press transmitter, but no gate AP is set to 00 Check if AP is set to 00. If yes, change to correct application setting. movement 1) IR1 is not connected, or wire is cut. 1) Check if IR1 is not connected, or wire is cut. -
Page 21: Technical Data
Input Voltage 220-240 Input frequency 50/60 Motor Voltage "Standby consumption (without accessories)" Motor Rated Power (LA250EVK = 2 x LA250-24) (LA300EVK = 2 x LA300-24) Rated Force Maximum Motor Pushing/Pulling Force 1250 1500 Cycles per hour Max. cyles per day 1.5m / 250kg... -
Page 22: Maintenance
The manual consists of these operating instructions and the declaration of conformity. The radio equipment type (TX4EVF) is in compliance with Directive 2014/53/EU and for UK with Radio Equipment Regulation SI 2017 No. 1209. The full text of the EU declaration of conformity is available at the following internet address: https://doc.chamberlain.de... - Page 23 Chamberlain GmbH Saar-Lor-Lux-Str. 19 66115 Saarbrücken Germany WEEE-Reg.Nr. DE66256568 www.liftmaster.eu info@liftmaster.eu 114A5438 2021, all rights reserved...
