VEHICULAR SWING GATE OPERATOR
LA400PKGUL
LA400DC
for single swing gate applications
LA400DCS
for dual swing gate applications
• THIS PRODUCT IS TO BE INSTALLED AND
SERVICED BY A TRAINED GATE SYSTEMS
TECHNICIAN ONLY.
• This model is for use on vehicular passage
gates ONLY and not intended for use on
pedestrian passage gates.
• This model is intended for use in Class I, II,
and III vehicular swing gate applications.
• Visit LiftMaster.com to locate a professional
installing dealer in your area.
• This gate operator is compatible with myQ
and Security+ 2.0
LiftMaster
300 Windsor Drive
Oak Brook, IL 60523
RESIDENTIAL DC
INSTALLATION MANUAL
Single Arm Package
Primary 24 VDC Actuator Arm
Secondary 24 VDC Actuator Arm
®
accessories.
OPERATOR REQUIRES A
OPERATOR REQUIRES A
LIFTMASTER EXTERNAL
LIFTMASTER EXTERNAL
MONITORED ENTRAPMENT
MONITORED ENTRAPMENT
PROTECTION DEVICE BE
PROTECTION DEVICE BE
INSTALLED IN ALL
INSTALLED IN ALL
ENTRAPMENT ZONES
ENTRAPMENT ZONES
Access installation and technical support
guides or register this product
LA400PKGULTECH
®
Take a photo of the camera
1.
icon including the points ( ).
Send it in by texting the
2.
photo to 71403.

Advertisement

Table of Contents
loading

Related Manuals for Chamberlain LA400UL

Summary of Contents for Chamberlain LA400UL

  • Page 1 RESIDENTIAL DC VEHICULAR SWING GATE OPERATOR INSTALLATION MANUAL LA400PKGUL Single Arm Package LA400DC Primary 24 VDC Actuator Arm for single swing gate applications LA400DCS Secondary 24 VDC Actuator Arm for dual swing gate applications OPERATOR REQUIRES A OPERATOR REQUIRES A LIFTMASTER EXTERNAL LIFTMASTER EXTERNAL MONITORED ENTRAPMENT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY OPERATION Safety Symbol and Signal Word Review ...........2 Control Board Overview ................28 Usage Class ....................3 Manual Release ..................29 UL325 Entrapment Protection Requirements ...........3 Reset Button ...................29 Safety Installation Information ..............4 Party Mode .....................29 Gate Construction Information ..............5 Operator Alarm ..................30 INTRODUCTION Remote Control ..................30...

  • Page 3: Usage Class

    SAFETY Usage Class Class I - Residential Vehicular Gate Operator A vehicular gate operator (or system) intended for use in garages or parking areas associated with a residence of one-to four single families. Class II - Commercial/General Access Vehicular Gate A vehicular gate operator (or system) intended for use in a commercial location or building such as a multi-family housing unit (five or more single family units), hotel, garages, retail store, or other buildings...

  • Page 4: Safety Installation Information

    SAFETY Safety Installation Information 1. Vehicular gate systems provide convenience and security. Gate systems 9. The Stop and/or Reset (if provided separately) must be located in the are comprised of many component parts. The gate operator is only one line-of-sight of the gate. Activation of the reset control shall not cause component.

  • Page 5: Gate Construction Information

    SAFETY Gate Construction Information Vehicular gates should be installed in accordance with ASTM F2200: Standard Specification for Automated Vehicular Gate Construction. For a copy, contact ASTM directly at 610-832-9585 or www.astm.org. General Requirements Vehicular Horizontal Swing Gate Gates shall be constructed in accordance with the provisions The following provisions shall apply to Class I, Class II and Class III given for the appropriate gate type listed, refer to ASTM F2200 vehicular horizontal swing gates:...

  • Page 6: Introduction

    INTRODUCTION Carton Inventory NOT SHOWN: Documentation packet and hardware bag Hardware Inventory NOTE: Hardware quantities shown below are for LA412DC. Quantities are doubled for LA412DCS. Flat Washer 5/16" (1) Hex Nut 5/16"-18 (1) Key (2) Keylock Cap Flat Washer 3/8" (3) Lock Washer 5/16"...

  • Page 7: Operator Specifications

    INTRODUCTION Operator Specifications Usage Classification Class I, II, & III Main AC Supply 120 Vac, .5 Amps (6.5 Amps including Accessory Outlets) System Operating Voltage 24 Vdc Battery Run / Direct Plug-in Transformer Charge Accessory Power 24 Vdc, 500mA max. for ON + SW (switched) Solar Power Max 24 Vdc at 60 watts max.

  • Page 8: Site Preparation

    INTRODUCTION Site Preparation Check the national and local building codes BEFORE installation. Trench Additional Accessories Trench and install conduit. Before trenching, contact underground utility The vehicle loops allow the gate to stay open when vehicles are locating companies. Conduit must be UL approved for low and high obstructing the gate path.

  • Page 9: Installation

    INSTALLATION To AVOID damaging gas, power or other underground utility lines, ALWAYS wear protective gloves and eye protection when changing contact underground utility locating companies BEFORE digging more the battery or working around the battery compartment. than 18 inches (46 cm) deep. Installation Tips Do's Weld a horizontal bar across entire gate on any installation for...

  • Page 10: Step 1 Attach Brackets To Operator

    INSTALLATION Step 1 Attach Brackets to Operator 1. Insert the key into the lock on the release lever and turn it 180° counterclockwise. 2. Turn the release lever 180° counterclockwise. The operator is now in manual mode. 3. Assemble gate post bracket by placing pull-to-open bracket on top of post bracket. 4.

  • Page 11: Step 2 Determine Mounting Location

    INSTALLATION Step 2 Determine Mounting Location Measuring and Marking for the Gate Bracket Before proceeding, begin with the gate in the fully closed position. There are two methods for determining the proper location of the post brackets. Either method will work depending on preference: Paper template (Located on the back page of this manual.

  • Page 12: Step 3 Position The Operator

    INSTALLATION Step 3 Position the Operator NOTE: The post bracket assembly can be mounted several places on the gate post. 1. Open the gate to desired open position (no greater than 100°) and hold operator against gate. 2. Place the operator arm against gate post at the desired position. Temporarily secure gate post bracket with clamp.

  • Page 13: Step 4 Secure The Brackets

    INSTALLATION Step 4 Secure the Brackets Post Bracket The gate operator (arm) must be level. 1. Mark holes for the post bracket. Remove the clamp and the operator, set aside. 2. Drill adequate holes in the gate post. 3. Secure the post bracket to the gate post using hardware. Gate Bracket The gate operator (arm) must be level.

  • Page 14: Step 5 Install The Control Box

    INSTALLATION Step 5 Install the Control Box Standard Control Box The control box MUST be mounted within 5 feet (1.52 m) of the gate operator. Mount the control box as high as possible for best radio reception. Make sure the control box is level. 1.
  • Page 15 INSTALLATION Large Metal Control Box (XLSOLARCONTUL) The control box MUST be mounted within 5 feet (1.52 m) of the gate operator. Mount the control box as high as possible for best radio reception. Make sure the control box is level. Wall or Column Mount 1.

  • Page 16: Step 6 Earth Ground Rod

    INSTALLATION To reduce the risk of SEVERE INJURY or DEATH: ANY maintenance to the operator or in the area near the operator ALL electrical connections MUST be made by a qualified individual. MUST NOT be performed until disconnecting the electrical power (AC DO NOT install ANY wiring or attempt to run the operator without or solar and battery) and locking-out the power via the operator power consulting the wiring diagram.

  • Page 17: Step 8 Dual Gate Setup

    INSTALLATION Step 8 Dual Gate Setup There are two options for dual gate communication: wired or wireless. Follow the directions according to your application. Do not use wired and wireless communication simultaneously. Wired dual gate applications will have a longer battery standby time than wireless applications. Wireless dual gates will require the installation of two control boxes, one for each operator arm.
  • Page 18 INSTALLATION Wired Setup Install a second operator arm: Install a second operator arm by following installation steps 1-4. Install the extension cable and junction box: Before digging, contact local underground utility locating companies. 1. Trench across driveway to bury the extension cable. Use PVC conduit to prevent damage to cables.
  • Page 19 INSTALLATION Wire the secondary operator arm to the control board: 1. Choose a knockout in the bottom of the control box. 2. Insert the extension cable through the watertight connector. 3. Insert the extension cable and watertight connector into the knockout.

  • Page 20: Step 9 Install Entrapment Protection

    INSTALLATION To prevent SERIOUS INJURY or DEATH from a moving gate: ALL gate operator systems REQUIRE two independent entrapment Locate entrapment protection devices to protect in BOTH the open and protection systems for each entrapment zone. close gate cycles. Entrapment protection devices MUST be installed to protect anyone Locate entrapment protection devices to protect between moving gate who may come near a moving gate.
  • Page 21 INSTALLATION Wire Entrapment Protection Devices There are three options for wiring the entrapment protection devices depending on the specific device and how the device will function. Refer to the specific entrapment protection device manual for more information. These entrapment protection device inputs are for monitored devices, which include pulsed photoelectric sensors, resistive edge sensors, and pulsed edge sensors.

  • Page 22: Step 10 Power Wiring

    INSTALLATION Step 10 Power Wiring SOLAR APPLICATIONS: For solar applications refer to Solar Panels OPERATOR POWER SOURCE section in the Appendix. Follow the directions according to your DIRECT PLUG-IN TRANSFORMER (120 VAC) application. Wire Gauge 14 350 feet (107 m) NOTE: All power wiring should be on a dedicated circuit, calculated using NEC guidelines.

  • Page 23: Step 11 Finish Installation

    INSTALLATION Step 11 Finish Installation 1. Turn the release lever clockwise 180° back to the engaged position. This engages the motor. The illustration shows the release lever in the engaged position. 2. Turn the key clockwise 180°. This locks the release lever. The operator is now engaged.
  • Page 24 ADJUSTMENT Initial Limits and Force Adjustments For dual gate applications the limits will have to be set for each operator. The gate MUST be attached to the operator before setting the limits and force. If a mistake is made while programming the limits press the reset button to start over.

  • Page 25: Obstruction Test

    ADJUSTMENT Fine Tune the Force Once the initial limits have been set, the REVERSAL FORCE DIAL on the control board is used for fine tuning the force where wind or environmental changes may affect the gate travel. The REVERSAL FORCE DIAL is set to minimum at the factory.

  • Page 26: Programming

    PROGRAMMING Remote Controls (Not Provided) ® A total of 50 Security+ 2.0 remote controls or KPW250 keypads and 2 keyless entries (1 PIN for each keyless entry) can be programmed to the operator. When programming a third keyless entry to the operator, the first keyless entry will be erased to allow the third keyless entry to be programmed.

  • Page 27: Liftmaster Internet Gateway (Not Provided)

    PROGRAMMING LiftMaster Internet Gateway (not Constant Pressure Override (CPO) provided) Constant Pressure Override is for use with KPW5 and KPW250 keypads (not provided). The KPW5/KPW250 wireless commercial keypads are To program the operator to the LiftMaster Internet Gateway: security keypads and can only be programmed to ONE gate operator (see Using the learn button on the opertaor's control the KPW5/KPW250 manual for complete programming instructions).

  • Page 28: Operation

    OPERATION Control Board Overview 1 SET OPEN Button: The SET OPEN button sets the OPEN limit. See Adjust Limits section. 2 SET CLOSE Button: The SET CLOSE button sets the CLOSE limit. See Adjust Limits section. 3 MOVE GATE Buttons: The MOVE GATE buttons will either open or close the gate when the operator is in Limit setting mode. See Adjust Limits section. 4 BATT FAIL: When AC power is OFF and battery voltage is critically low the gate will latch at a limit until AC power is restored or batteries voltage increases.

  • Page 29: Manual Release

    OPERATION Manual Release In case of a power failure, the operator can be disengaged from the gate. With an operator, the release action may sometimes feel stiff/jerky, which is normal and has no effect on function. NOTE: It is normal for the operator to run slow right after a disconnect or complete loss of AC/ battery power (the operator will need to run a complete open and close cycle).

  • Page 30: Operator Alarm

    OPERATION Operator Alarm If a contact sensor detects an obstruction twice consecutively the alarm will sound (up to 5 minutes) and the operator will need to be reset. When the inherent force of the operator (RPM/current sensor) detects the following (twice consecutively) the alarm will sound (up to 5 minutes) and the operator will need to be reset.

  • Page 31: Accessory Wiring

    ACCESSORY WIRING All control wiring used to connect external devices to Class 2 circuits of the operator must be (QPTZ) Power-Limited Circuit Cables, Type CL2, CL2P, CL2R, or CL2X or other cable with equivalent or better electrical, mechanical, and flammability ratings. External control devices EXIT (2 Terminals) This input is a soft open command (maintained switch does not override...

  • Page 32: Maglock

    ACCESSORY WIRING Maglock LOCK (2 Terminals, N.C. and COM) Relay contact output, Normally - closed (N.C.) output for maglocks. Relay activates prior to motor activation and during motor run. Relay is off when motor is off. Miscellaneous wiring Single button control (SBC) (2 Terminals) Gate command sequence - Open, Stop, Close, Stop,...

  • Page 33: Maintenance

    MAINTENANCE IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of SEVERE INJURY or DEATH: READ AND FOLLOW ALL INSTRUCTIONS. Test the gate operator monthly. The gate MUST reverse on contact with an object or reverse when an object activates the noncontact ANY maintenance to the operator or in the area near the operator sensors.

  • Page 34: Troubleshooting

    TROUBLESHOOTING To protect against fire and electrocution: For continued protection against fire: DISCONNECT power (AC or solar and battery) BEFORE installing or Replace ONLY with fuse of same type and rating. servicing operator. Diagnostic Codes NOTE: When cycling or disconnecting power (ac/dc) to the control board, it is recommended that you unplug the J15 plug. To View the Codes The codes will show on the diagnostic display.

  • Page 35: Diagnostic Codes Table

    TROUBLESHOOTING Diagnostic Codes Table Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear. External Entrapment Inherent Entrapment LiftMaster System Installed System Informational Protection...
  • Page 36 TROUBLESHOOTING Code Meaning Solution Saved IF an obstruction occurred, no action required. If an obstruction did NOT Wireless edge triggered occur, check inputs and wiring. CLOSE EYE/INTERRUPT triggered, causing reversal, preventing close, or resetting TTC CLOSE EDGE triggered, causing reversal, NO IF an obstruction occurred, no action required.

  • Page 37: Control Board Leds

    TROUBLESHOOTING Control Board LEDs STATUS LEDS INPUT LEDS INPUT OFF state SBC INPUT Input inactive POWER AC charger or Solar power Input active available BLINK Input active on other operator BATT Not charging FIRE DEPT INPUT Input inactive CHARGING Three stage battery charging Input active TIMER The timer is disabled...

  • Page 38: Troubleshooting Chart

    TROUBLESHOOTING Troubleshooting Chart SYMPTOM POSSIBLE CAUSES SOLUTIONS Operator does not a. No power to control board a. Check AC and battery power run and diagnostic b. Open fuse b. Check fuses display not on. c. If on battery power only, low or dead c.
  • Page 39 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES SOLUTIONS Gate opens, but a. Open control active a. Check all Open inputs for an active input will not close with b. Vehicle loop detector active b. Check all vehicle detector inputs for an active detector transmitter or c.
  • Page 40 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES SOLUTIONS Expansion board a. Defective main board to expansionboard a. Check main board to expansion board wiring. If required, replace wire function not wiring cable. controlling gate. b. Incorrect input wiring to expansion board b. Check wiring to all inputs on expansion board. c.

  • Page 41: Appendix

    APPENDIX Bracket Types Pull-to-Open Push-to-Open...

  • Page 42: Step 10 Solar Panels

    APPENDIX Step 10 Solar Panels SOLAR PANELS ARE NOT PROVIDED. SEE ACCESSORIES. Solar Application Requirements 33AH Battery Requirements: 7AH Battery Requirements: Large Metal Control Box for Solar Applications (Model Standard Control Box for Solar Applications (Model LA400CONTUL) XLSOLARCONTUL) A minimum of two 10W solar panels in series (Model SP10W12V) A minimum of two 10W solar panels in series (Model SP10W12V) A maximum of six 10W solar panels (Model SP10W12V).
  • Page 43 APPENDIX Solar usage guide Typical System Standby Battery Current Consumption (mA) System voltage Main board with no radios programmed 2.7 mA ® One or more LiftMaster remote controls programmed +1 mA ® device or wireless dual gate programmed +2.4 mA Expansion board +11.1 mA Per loop detector LOOPDETLM (up to 3 loop detectors can be plugged in to the expansion board)
  • Page 44 APPENDIX Position The location of the panel(s) is critical to the success of the installation. In general, the panel(s) should be mounted using the provided angle bracket facing due south. The solar panel(s) should be mounted in an area clear of all obstructions and shade from buildings and trees. If the panel(s) is not casting a shadow, the battery is not being charged.
  • Page 45 APPENDIX Wire the Batteries Solar panel applications require the Solar Harness Kit model K94-37236 (see Accessories). Wire the solar panels...

  • Page 46: Limit Setup With A Remote Control

    APPENDIX Limit Setup with a Remote Control To set the limits using a remote control, first you will need a 3-button remote control that has been programmed for OPEN, CLOSE, and STOP. Refer to the Programming section. Initial Limits and Force Adjustment Adjust the limits For dual gate applications the limits will have to be set for each If the limits have already been set the operator will exit the limit setting...

  • Page 47: Repair Parts

    REPAIR PARTS STANDARD CONTROL BOX ITEM PART NUMBER DESCRIPTION K74-39307-2 Standard Plastic Control Box Only K94-36408-2 Reset Switch with Product ID K94-36411 Piezo Alarm K75-36635 Control Board Bracket K1D8388-1CC Control Board K76-36296-1 Outlet APOW3 Transformer K74-30762 Batteries (2) NOT SHOWN K94-36274-1 7AH Battery Harness K77-36541...

  • Page 48: Wiring Diagram

    WIRING DIAGRAM Standard Control Box To protect against fire and electrocution: DISCONNECT power (AC or solar and battery) BEFORE installing or servicing operator. For continued protection against fire: Replace ONLY with fuse of same type and rating.

  • Page 49: Accessories

    ACCESSORIES Entrapment Protection Remote controls LiftMaster monitored through beam LiftMaster offers a variety of LiftMaster remote controls to satisfy your photoelectric sensor application needs. Single-button to 4-button, visor or key chain. The following Models LMTBUL and LMTBU remote controls are compatible with operators manufactured by LiftMaster after 1993.
  • Page 50 ACCESSORIES Miscellaneous LiftMaster Cloud™ connected access protocol - high capacity Remote antenna extension kit Model CAPXL The remote antenna extension kit allows the antenna to be remotely installed. Model 86LM Solar panel kit Commercial access control receiver This kit is to replace or add a solar panel to the operator Access control receiver for up to 1,000 devices application.

  • Page 51: Warranty

    WARRANTY LiftMaster Two Year Limited Warranty LiftMaster warrants to the first purchaser of this product, for the structure in which this product is originally installed, that it is free from defect in materials and/or workmanship for a period of TWO years from the date of purchase. The proper operation of this product is dependent on your compliance with the instructions regarding installation, operation, maintenance and testing.

  • Page 52: Template For Post Bracket Mounting

    TEMPLATE FOR POST BRACKET MOUNTING 300 Windsor Drive Oak Brook, IL 60523 LiftMaster.com © 2018, The Chamberlain Group, Inc. - All Rights Reserved 01-39384B...
