- Page 1 Hoshizaki America, Inc. “A Superior Degree of Reliability” www.hoshizaki.com Self-Contained Cubelet Models C-100BAF-AD C-100BAF-ADDS SERVICE MANUAL Number: 73180 Issued: 10-6-2010...
- Page 2 Hoshizaki provides this manual primarily to assist qualified service technicians in the service and maintenance of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write, or send an e-mail message to the Hoshizaki Technical Support Department for assistance. HOSHIZAKI AMERICA, INC.
-
Page 3: Important Safety Information
Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. WARNING Indicates a hazardous situation which could result in death or serious injury. CAUTION Indicates a situation which could result in damage to the unit. -
Page 4: Table Of Contents
This manual should be read carefully before the icemaker is serviced or maintenance operations are performed. Only qualified service technicians should install, service, and maintain the icemaker. Read the warnings contained in this booklet carefully as they give important information regarding safety. Please retain this booklet for any further reference that may be necessary. - Page 5 C. Removal and Replacement of Evaporator Assembly Components ... 30 1. Upper Bearing Wear Check ... 31 2. Removal and Replacement of Extruding Head ... 32 3. Removal and Replacement of Auger ... 32 4. Removal and Replacement of Evaporator ... 33 5.
-
Page 6: Specifications
I. Specifications A. C-100BAF-AD, C-100BAF-ADDS AC SUPPLY VOLTAGE AMPERAGE MINIMUM CIRCUIT AMPACITY MAXIMUM FUSE SIZE APPROXIMATE ICE PRODUCTION PER 24 HR. lbs./day ( kg/day ) Reference without *marks SHAPE OF ICE ICE QUALITY APPROXIMATE STORAGE CAPACITY ELECTRIC & WATER CONSUMPTION ELECTRIC W (kWH/100 lbs.) -
Page 7: General Information
Gear Motor Protector (External Overload) Reset Switch Bin Control Thermostat Float-Operated Water Valve Water Reservoir Suction Temperature Safety Upper Rear Panel Lower Rear Panel Power Switch Control Box Front C-100BAF-AD Shown Drier Rear C-100BAF-AD Shown Front Panel Louver Top Panel Evaporator Assembly Gear Motor Compressor... -
Page 8: Ice Making Unit
2. Ice Making Unit Cutter (motionless) Allen Head Cap Screw Extruding Head and Upper Bearing Auger Cylinder Mechanical Seal O-Ring Housing and Lower Bearing Spline Coupling Hex Head Bolt with Washer Evaporator Flange Insulation Allen Head Cap Screw with Washer Fig. -
Page 9: Sequence Of Operation
B. Sequence of Operation This icemaker utilizes a thermostatic bin control to switch the gear motor, fan motor, and compressor on and off as needed. This icemaker utilizes a float-operated water valve in the water reservoir to allow water into the icemaker as needed. After the power switch is placed in the "ON"... -
Page 10: Technical Information
III. Technical Information A. Water Circuit and Refrigeration Circuit 1. C-100BAF Series Water Inlet Water Reservoir Overflow Hose Condenser Condenser Fan Motor Float-Operated Water Valve Water Level Evaporator Assembly Water Supply Drier Discharge Compressor Gear Motor Capillary Tube Suction Temperature Safety Suction Fig. -
Page 11: Wiring Diagram
B. Wiring Diagram 1. C-100BAF Series 2. C-100BAF Series with Optional Drain Pump HS-0248 (3W) (external) (3W) (external) (external overload 2.4~3.0A) (internal) (external overload 2.4~3.0A) (internal) -
Page 12: Sequence Wiring Diagram
3. Sequence Wiring Diagram a) Freeze Cycle Power supplied. Gear motor, fan motor, compressor relay, and compressor energize. The float-operated water valve allows water into the reservoir as needed to continue the ice making process. (3W) (external) (external overload 2.4~3.0A) (internal) C-100BAF Series... -
Page 13: B) Bin Control Thermostat Shutdown
b) Bin Control Thermostat Shutdown Ice fills storage bin to level of bin control thermostat. Bin control thermostat opens. Gear motor, fan motor, compressor relay, and compressor de-energize. (3W) (external) (external overload 2.4~3.0A) (internal) C-100BAF Series... -
Page 14: C) Low Water/Freeze-Up Safety Shutdown
c) Low Water/Freeze-Up Safety Shutdown If the water supply is interrupted or a freeze-up condition occurs, the decrease in suction line temperature causes the suction temperature safety to open and shut down the icemaker. See the table below for suction temperature safety cut-out/cut-in temperatures. Suction Temperature Safety Cut-out 23.9°F±2.7°F (-4.5°C±1.5°C) -
Page 15: D) Gear Motor Protector (External Overload) Shutdown
d) Gear Motor Protector (external overload) Shutdown If gear motor amperage exceeds 2.4~3.0 amps, the gear motor protector (external overload) operates independently to turn off the gear motor. The gear motor external overload can be manually reset by pressing the switch on the control box. (3W) (external) (external... -
Page 16: E) Optional Drain Pump Hs-0248 Safety Shutdown
e) Optional Drain Pump HS-0248 Safety Shutdown If the water level in the drain pump reservoir rises high enough to close the drain pump upper float switch, the drain pump safety interrupts power to the icemaker. When the water level lowers enough to open the drain pump upper float switch, power is restored to the icemaker. -
Page 17: Performance Data
C. Performance Data 1. C-100BAF-AD, C-100BAF-ADDS APPROXIMATE ICE PRODUCTION PER 24 HR. lbs./day kg./day APPROXIMATE ELECTRIC CONSUMPTION watts APPROXIMATE WATER CONSUMPTION PER 24 HR. gal./day /day Evaporator Outlet HEAD PRESSURE PSIG kg/cm SUCTION PRESSURE PSIG kg/cm TOTAL HEAT OF REJECTION FROM CONDENSER Note: 1. -
Page 18: Service Diagnosis
IV. Service Diagnosis 1. This unit should be diagnosed and repaired only by qualified service personnel to reduce the risk of death, electric shock, serious injury, or fire. 2. Risk of electric shock. Use extreme caution and exercise safe electrical practices. - Page 19 5) Shutdown (bin full) – Ice fills storage bin to level of BC. BC opens. GM, FM, CR, and Comp de-energize. Diagnosis: When the icemaker is running, hold ice in contact with BC bulb. If the components fail to de-energize, check BC. 6) Move the power switch to the "OFF"...
-
Page 20: Diagnostic Charts
C. Diagnostic Charts 1. No Ice Production Problem Possible Cause [1] The icemaker will not a) Power Supply start. b) Power Switch (Control Box) c) Suction Temperature Safety (Low Water/Freeze-Up Safety) d) Bin Control Thermostat Assembly (with integrated heater) e) Gear Motor Protector (External Overload) (2.4~3.0A) Remedy... - Page 21 Problem Possible Cause [1] The icemaker will not f) Gear Motor Internal start (continued). Overload (Thermal Protector) g) Optional Drain Pump HS-0248 Safety [2] Gear motor starts, a) Power Supply but compressor will not start or operates b) Compressor Relay intermittently.
-
Page 22: Low Ice Production
Problem Possible Cause [4] Gear motor and b) Refrigerant Line compressor start, but no ice is produced (continued). c) Gear Motor d) Compressor 2. Low Ice Production Problem Possible Cause [1] Low ice production. a)Bin Control Thermostat Assembly (with integrated heater) b)High-Side Pressure Too High c) Refrigerant Line... -
Page 23: Other
See "V.C.1. Upper Bearing Wear Check." 1. Bearing or gear worn 1. Replace. out/damaged. 1. Scale on inside wall 1. Use Hoshizaki "Scale of evaporator freezing Away" solution to clean cylinder. periodically. See "VI. A. Cleaning and Sanitizing Instructions." If the water is found hard by testing, install a softener. -
Page 24: Optional Drain Pump Hs-0248
Wipe down the float switch assembly with a mixture of 1 part recommended cleaner Hoshizaki "Scale Away" and 25 parts warm water. 6) Rinse the float switch assembly, then replace the reservoir cover in its original position. - Page 25 7) Make sure all hose connections are secure, then reinstall the lower rear panel and upper rear panel in their correct positions. WARNING! Make sure that there are no wires pinched between the rear covers and icemaker. 8) Resecure the vent hose to the icemaker. CAUTION! The vent hose must be attached and secured to the icemaker or water damage may occur.
-
Page 26: Removal And Replacement Of Components
V. Removal and Replacement of Components 1. This unit should be diagnosed and repaired only by qualified service personnel to reduce the risk of death, electric shock, serious injury, or fire. 2. Move the power switch to the "OFF" position and unplug the unit from the electrical outlet before servicing. -
Page 27: Brazing
5) Disconnect the gauge manifold hose from the vacuum pump and attach it to a refrigerant service cylinder. Remember to loosen the connection and purge the air from the hose. See the nameplate for the required refrigerant charge. Hoshizaki recommends only virgin refrigerant or reclaimed refrigerant which meets the requirements of ARI Standard 700 (latest edition) be used. -
Page 28: Removal And Replacement Of Compressor
2. When brazing, protect the drier by using a wet cloth to prevent the drier from overheating. Do not allow the drier to exceed 250°F (121°C). Note: Hoshizaki recommends that compressor starting components be replaced at the same time as the compressor. Due to the ability of the POE oil in the compressor to absorb moisture quickly, the compressor must not be opened more than 15 minutes for replacement or service. - Page 29 15) Evacuate the system, then charge it with refrigerant. See the nameplate for the required refrigerant charge. 16) Connect the terminals and replace the terminal cover in its correct position. 17) Replace the control box, louver, and panels in their correct positions. 18) Plug the unit back in.
-
Page 30: Removal And Replacement Of Evaporator Assembly Components
C. Removal and Replacement of Evaporator Assembly Components Thumbscrew Spout Cutter (motionless) Packing Evaporator Flange Extruding Head and Upper Bearing Fig. 6 Drain Hose Auger Connection Allen Head Cap Screw with Washer Hex Head Bolt with Washer Gear Motor Allen Head Cap Screw Evaporator Reservoir Hose... -
Page 31: Upper Bearing Wear Check
1. Upper Bearing Wear Check To ensure that the bearing inside the extruding head does not exceed the wear tolerance of .02", follow the instructions below. 1) Move the power switch to the "OFF" position, then unplug the unit from the electrical outlet. -
Page 32: Removal And Replacement Of Extruding Head
2. Removal and Replacement of Extruding Head 1) Move the power switch to the "OFF" position, then unplug the unit from the electrical outlet. 2) Close the water supply line shut-off valve. 3) Remove all ice from the storage bin. 4) While maintaining a hold on the door, remove the hinge stop pin from hinge (B). -
Page 33: Removal And Replacement Of Evaporator
8) Remove the clamp securing the drain plug, then lower the drain hose into a container. Remove the drain plug to drain the water from the reservoir and evaporator assembly. 9) After all of the water has drained, replace the drain hose, drain plug, and drain clamp in their original positions. - Page 34 9) Disconnect the drain hose and reservoir hose from the evaporator. 10) Remove the packing. 11) Remove the allen head cap screws securing the extruding head and evaporator flange. Remove the evaporator flange, then grasp the cutter and carefully lift out the cutter and extruding head.
-
Page 35: Removal And Replacement Of Mechanical Seal And Lower Housing
5. Removal and Replacement of Mechanical Seal and Lower Housing 5a. Mechanical Seal 1) Move the power switch to the "OFF" position, then unplug the unit from the electrical outlet. 2) Close the water supply line shut-off valve. 3) Remove all ice from the storage bin. 4) While maintaining a hold on the door, remove the hinge stop pin from hinge (B). -
Page 36: Removal And Replacement Of Gear Motor
22) Plug the unit back in. Move the power switch to the "ON" position. 6. Removal and Replacement of Gear Motor Note: Hoshizaki recommends that the gear motor capacitor be replaced at the same time as the gear motor. 1) Move the power switch to the "OFF" position, then unplug the unit from the electrical outlet. -
Page 37: Removal And Replacement Of Water Reservoir
the fan motor assembly into the unit. Connect the fan motor wires, then replace the removed parts in the reverse order of which they were removed. 6) Replace the louver and panels in their correct positions. 7) Plug the unit back in. Move the power switch to the "ON" position. E. -
Page 38: Cleaning And Maintenance
For safety and maximum effectiveness, use the solution immediately after dilution. Dilute 1.6 fl. oz. (47 ml or 3.2 tbs) of Hoshizaki "Scale Away" with 1 qt (1 l) of warm water. This is a minimum amount. Make more solution if necessary. - Page 39 3) While maintaining a hold on the door, remove the hinge stop pin from hinge (B). Pull out the bottom of the door slightly, then gently remove the door from hinge (A). See Fig. 10. 4) Remove the 2 screws securing the top panel, then lift it off. 5) Remove all ice from the storage bin.
-
Page 40: Sanitizing Solution
12) Allow the icemaker to sit for 10 minutes before operation. If you placed a clamp on the reservoir hose in step 11, remove it before operation and replace the spout in its correct position. 13) Plug the unit back in. Move the power switch to the "ON" position. 14) Allow the unit to make ice using the solution. -
Page 41: Sanitizing Procedure - Final
5. Sanitizing Procedure - Final 1) Remove the drain plug to drain any remaining solution. 2) After all of the solution has drained, replace the drain plug in its correct position. 3) Remove the reservoir cover. Pour the sanitizing solution into the reservoir until the solution starts to flow through the overflow hose. -
Page 42: Maintenance
B. Maintenance The maintenance schedule below is a guideline. More frequent maintenance may be required depending on water quality, the icemaker's environment, and local sanitation regulations. 1. Only qualified service technicians should attempt to service this icemaker. 2. Move the power switch to the "OFF" position and unplug the unit from the electrical outlet before servicing. - Page 43 1. Storage Bin Drain In some conditions, slime may build up inside the storage bin drain and prevent water from draining properly. To prevent this buildup, perform the following procedure once every 3 months or as often as necessary for conditions. 1) Move the power switch to the "OFF"...
-
Page 44: Preparing The Icemaker For Long Storage
C. Preparing the Icemaker for Long Storage When storing the icemaker for an extended time or in sub-freezing temperatures, follow the instructions below to prevent damage. When the icemaker is not used for two or three days under normal conditions, it is sufficient to move the power switch to the "OFF"...
