TABLE OF CONTENTS
1 Specifications ----------------------------------------------------- 3
2 Schematic Diagram ---------------------------------------------- 3
3 Wiring Connection ----------------------------------------------- 4
4 Trouble Shooting Chart ---------------------------------------- 5
5 Disassembly and Assembly Instruction ------------------ 7
Model No.
Destination : SD2, KUWAIT, NIGERIA, UAE, GENERAL,
PAGE
5.1. Disassembly of Upper and Lower Body --------------7
5.2. Disassembly of Motor Case Set------------------------ 8
5.3. Disassembly of Cord Reel Unit -------------------------9
5.4. Disassembly of Rail Base Unit--------------------------9
5.5. Disassembly of Fan Motor Unit----------------------- 10
© 2012 Panasonic Manufacturing Malaysia Berhad
(6100-K). Unauthorized copying and distribution is a
violation of law.
Vacuum Cleaner
MC-CG525R747-KW
MC-CG525R747-NG
MC-CG525R147-AE
MC-CG525R149-AE
MC-CG525R149-JO
MC-CG525R149-LB
MC-CG525R149-QA
MC-CG525R149-LY
MC-CG525R149-EG
MC-CG525R149-PK
MC-CG525R149-OM
MC-CG525R747-SA
JORDAN, MIDDLE EAST, PGF, EGYPT,
LIBYA, QATAR, LEBANON, OMAN AND
AFRICA GENERAL
PMMA120406CE
PAGE
Advertisement
Table of Contents
Related Manuals for Panasonic MC-CG525R747-KW
Summary of Contents for Panasonic MC-CG525R747-KW
-
Page 1: Table Of Contents
4 Trouble Shooting Chart ---------------------------------------- 5 5.4. Disassembly of Rail Base Unit--------------------------9 5 Disassembly and Assembly Instruction ------------------ 7 5.5. Disassembly of Fan Motor Unit----------------------- 10 © 2012 Panasonic Manufacturing Malaysia Berhad (6100-K). Unauthorized copying and distribution is a violation of law. - Page 2 6 Exploded View and Replacement Parts List ----------- 11 6.1. Exploded View -------------------------------------------- 11 6.2. Attachment Exploded View ---------------------------- 12 6.3. Packing Instruction--------------------------------------- 13 6.4. Replacement Parts List --------------------------------- 14...
-
Page 3: Specifications
1 Specifications Model MC-CG525 Power Source 220V~240V~50/60Hz Input Power (Max) 1700W Input Power (IEC) 1400W - 1650W Power Control SLIDE Dust Capacity 3.0L Automatic Cord Rewind Vac Gauge Exhaust Filter ANTI-BACTERIA Extension Wands METAL TELESCOPIC WAND Blower Operation Floor Nozzle 2-STEP Dust Bag CLOTH BAG... -
Page 4: Wiring Connection
3 Wiring Connection... -
Page 5: Trouble Shooting Chart
4 Trouble Shooting Chart... -
Page 7: Disassembly Of Upper And Lower Body
5 Disassembly and Assembly Instruction 5.1. Disassembly of Upper and Step 4 Release 2 catches using Philip Screwdriver. Step 5 Remove Body Cover. Lower Body Step 1 Open Dust Cover & remove Dust Bag. Step 2 Release Dust Cover from Hanger. Step 6 Take out Filter (sponge) Step 3 Remove 2 screws from the Front Side. -
Page 8: Disassembly Of Motor Case Set
5.2. Disassembly of Motor Case Set Step 8 Remove 4 screws from Upper Body . Step 1 Pull out the Swicth On/Off. Step 9 Take out Upper Body from Lower Body. Step 2 Remove Volume Ass’y from Motor Case Set. Step 3 Pull up Motor Case Set from Lower Body. -
Page 9: Disassembly Of Cord Reel Unit
5.3. Disassembly of Cord Reel Unit 5.4. Disassembly of Rail Base Unit Step 1 Pull up the Cord Reel Unit. Step 1 Remove the Cord Reel Unit from the Rail Base Unit by insert a slotted screwdriver into the shaft of the Cord Reel Unit and turning it 90... -
Page 10: Disassembly Of Fan Motor Unit
Disassembly of Fan Step 4 Remove Motor Support Rubbers. 5.5. Motor Unit Step 1 Pull up Motor Set. Step 2 Remove Silicon Cloth. Step 3 Disconnect Wire Terminals. -
Page 11: Exploded View And Replacement Parts List
6 Exploded View and Replacement Parts List 6.1. Exploded View Plug C3 Plug E2... -
Page 12: Attachment Exploded View
6.2. Attachment Exploded View... -
Page 13: Packing Instruction
6.3. Packing Instruction METAL WAND TELESCOPIC HOSE UNIT FLOOR NOOZLE ASS'Y CURVED WAND CREVICE NOZZLE CONNECTION WAND DUSTING BRUSH UNIT NOZZLE HOLDER COMPLETE SET... -
Page 14: Replacement Parts List
6.4. Replacement Parts List Safety Ref. Part No. Part Name & Description Remarks XTN4+10FFJ SCREW XTN4+12BFJ PAN TAP SCREW XTN4+16BFJ PAN TAP SCREW YMV02ADN000 UPPER BODY YMV08EDP000 SWITCH PEDAL SPRING YMV30KDN000-P FILTER ANTI BACTERIAL YMV01DDN000 BUCKLE YMV46HBW000 BAG CLAMPER SPRING YMV92LDN0R0 DUST COVER UNIT YMV0NA81000...
