- Page 1 XC4300 INSTALLATION/OWNERS MANUAL AM/FM/Cassette Receiver...
-
Page 2: Installation
XC4300 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. (consult a qualified technician for instructions) • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 3: Wiring Diagram
Using an incorrect fuse could damage radio. The XC4300 uses one 10 amp AGC fuse (Battery), one 1 amp AGC fuse (Ignition) and one 1 amp AGC fuse (Remote turn-on) located... -
Page 4: Operation
XC4300 OPERATION Control Locations Mute Local/Distance Volume Preset 6/CD Random Audio Preset 5/CD Repeat Eject Preset 4/CD Intro Band Preset 3 Rewind Preset 2/Disc Up Fast Forward Preset 1/Disc Down Power Display CDC Mode Tape Mode Auto Store/Preset Scan Tune/Track Up... -
Page 5: General Operation
XC4300 OPERATION General Operation Faceplate Removal Press RELEASE and pull away from the right side to remove. To re-install, insert left side of faceplate first then push right side to secure. Power On/Off Press POWER to turn the unit on/off. - Page 6 XC4300 OPERATION General Operation Reset Press and hold for more than 2 seconds to RESET the unit upon initial installation or if abnormal operation occurs. The RESET button is located behind the faceplate. Audio Press AUDIO to select between Volume (default), Bass, Treble, Balance &...
-
Page 7: Tuner Operation
XC4300 OPERATION Tuner Operation Press TUNE << or >> momentarily to seek the next strong Seek Tuning station. Press TUNE << or >> for more than 2 seconds, then release. Manual Tuning "AUTO" will disappear from the display. Press TUNE << or >>... -
Page 8: Cassette Player Operation
XC4300 OPERATION Cassette Player Operation Insert a standard audio cassette into the cassette slot. Insert Cassette The cassette will automatically begin playback. The TAPE indicator will illuminate during playback. Press the EJECT button all the way in to stop and eject the Eject cassette. -
Page 9: Limited One-Year Warranty
You may also have other rights which vary from service, you must prepay the initial shipping state to state. charges. DUAL will pay the return shipping charges if the product is returned to an address Namsung America Inc. warrants this product to within the USA. -
Page 10: Specifications
XC4300 OPERATION Specifications Cassette Player >50dB Signal-to-noise: 60Hz-10kHz, ±3dB Frequency response: 0.26% JIS Wow & flutter: >40dB Channel separation @ 1kHz: FM Tuner 87.5MHz-107.9MHz Tuning range: 12dBf FM mono sensitivity: 20dBf 50dB quieting sensitivity (stereo): 32dB Stereo separation @ 1kHz: 30Hz-13kHz, ±3dB... -
Page 11: Troubleshooting
XC4300 OPERATION Troubleshooting Problem Cause Action Yellow wire not connected or incorrect voltage Check connections for proper voltage Unit will not turn on Red wire not connected or incorrect voltage (11~16VDC) (no power) Black wire not connected Check connection to ground... - Page 12 Namsung America Inc. 21318 64th Ave. South Kent, WA 98032 Toll Free: 1-866-626-7863 ©2003 Namsung America, Inc. EVOK0903-V01...
