EARTH AUGER
SET UP ANd OPERATING INSTRUcTIONS
1.
You do not put hydraulic oil in the Auger's oil assembly prior to its first use.
Before each use, check the oil level. Never run the Auger with low or no hydraulic oil.
Running the Auger with low or no hydraulic oil will permanently damage the unit.
2.
You do not put engine oil in the Engine's crankcase prior to its first use.
Before each use, check the oil level. Never run the Engine with low or no engine oil.
Running the Engine with low or no oil will permanently damage the unit.
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAl.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
9 HP ROBIN
Model
cAUTION
Your warranty is voided if:
3491 Mission Oaks Blvd., Camarillo, CA 93011
ENGINE
®
94143
. All rights reserved. No portion of this
®
.
®
Manual Revised 07k

Advertisement

Table of Contents
loading

Related Manuals for Central Hydraulics 94143

Summary of Contents for Central Hydraulics 94143

  • Page 1 EARTH AUGER 9 HP ROBIN ENGINE ® Model 94143 SET UP ANd OPERATING INSTRUcTIONS cAUTION Your warranty is voided if: You do not put hydraulic oil in the Auger’s oil assembly prior to its first use. Before each use, check the oil level. Never run the Auger with low or no hydraulic oil.

  • Page 2: Specifications

    Keep bystanders away while operating a power tool. Distractions can cause you to lose control. Protect others in the work area from debris such as chips and sparks. Provide barriers or shields as needed. REV 09b SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 2...

  • Page 3: Personal Safety

    If damaged, have the tool serviced before using. Many accidents are caused by poorly main- tained tools. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 3...

  • Page 4: Specific Safety Rules And Precautions

    Whenever possible, use a carbon monoxide detector (not included) to detect excessive car- bon monoxide fumes in the work area and in the surrounding area. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 4...
  • Page 5 Do not smoke, or allow sparks, flames, or other sources of ignition around the Auger. Keep grounded conductive objects, such as tools, away from exposed, live electrical parts and connections to avoid sparking or arcing. These events could ignite fumes or vapors. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 5...

  • Page 6: Mechanical Precautions

    Safety Chains are attached to the towing vehicle with the same length for each side. Do not allow the Safety Chains to drag on the ground. Never ride or transport cargo on the Auger. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 6...

  • Page 7: Miscellaneous Precautions

    20 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 7...
  • Page 8 This will allow you to operate the Auger on uneven surfaces. (See Figure B.) Loosen the Hex Head Bolt (67) to rotate the Handle Assembly (69). Once the Handle Assembly angle has been adjusted, firmly retighten the Hex Head Bolt. (See Figure B.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 8...
  • Page 9 Locate the BLUE Ground (–) Wire in the Wiring Harness. Then secure the BLUE Ground Wire, using a bolt located on the Engine’s (15) Mount. (See Figure d.) REV 07l SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 9...
  • Page 10 Coupler in place, using one Hitch Pin (57). (See Figure E.) Insert one Hitch Pin (57) into the Motor Pivot Bracket (58). This Hitch Pin will be used when moving and towing the Auger. (See Figure E.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 10...
  • Page 11 Hitch Pins (57). Both Hitch Pins are required on Bits with two mounting holes. (See Figure F.) Check to make sure all Hitch Pins (57) used extend completely through the mounting holes and out the far side of the connection. (See Figure F.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 11...
  • Page 12 Prior to first using the Auger, the Hydraulic Oil Tank (33) of the unit MUST be filled with a high quality 10 weight hydraulic oil. (See Figure G, next page.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 12...
  • Page 13 Engine Kill Switch to its “OFF” position while maintaining a firm grip on the Handle Assembly. (See Figure H.) Start the Engine (15) and run at slow idle. (See Engine manufacturer’s manual for complete instructions.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 13...
  • Page 14 (See Engine manufacturer’s manual for complete instructions.) Bit (65) Bit (65) FIGURE I Use the Handle Assembly (69) to position the Bit (65) bit to the center of the hole to be dug. (See Figure I.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 14...
  • Page 15 Serious injury or death can occur if the towing precautions and in- structions on pages 7, 15, and 16 of this manual are not followed: Remove the Bit (65) from the machine. (See Figure F.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 15...
  • Page 16 Ball Hitch. (See Figure K.) Temporarily remove the “R” Pin and Safety Pin from the Hitch Coupler (22). Then, pull up on the Trigger and lift up on the Handle. (See Figure K.) SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 16...
  • Page 17 Auger could jackknife, causing severe damage to the Auger and towing vehicle. When towing the Auger over long distances, stop and check the tightness of all connections frequently to ensure safe operation. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 17...

  • Page 18: Inspection, Maintenance, And Cleaning

    4 gallons.) Then, replace the Oil Plug. (See Figure G, page 13.) After every 50 hours of use, drain the old hydraulic oil and refill the Hydraulic Oil Tank (33) with 10 weight hydraulic oil. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 18...
  • Page 19 Always dispose of old engine oil and old hydraulic oil in accordance with local, state, and federal regulations. cAUTION! All maintenance, service, or repairs not mentioned in this manual must only be performed by a qualified service technician. SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 19...

  • Page 20: Please Read The Following Carefully

    Hex Head Bolt (M10 x 25) Nameplate Engine Kill Switch Hydraulic Oil Tank Handle Assembly Reservoir Pivot Nut (3/4” x 10) Oil Filter Frame Assembly Connector Oil Plug (3/4”-14UNC) Wiring Harness SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 20...

  • Page 21: Assembly Drawing

    ASSEMBlY dRAWING SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 21...

  • Page 22: Limited 90-Day Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 94143 For technical questions, please call 1-800-444-3353 PAGE 22...
