Page 1
Display for 5-in-1 Weather Sensor model 06057 Package Contents 1. Display with Tabletop Stand 2. Power Adapter 3. Instruction Manual This product requires an AcuRite 5-in-1 Weather Sensor (sold separately) to be operational. PRODUCT MUST BE REGISTERED IMPORTANT TO RECEIVE WARRANTY SERVICE PRODUCT REGISTRATION Register online to receive 1 year warranty protection www.AcuRite.com...
Page 3
1. Current Outdoor Temperature 14. RAINFALL Button Arrow icon indicates direction Press to change the RAINFALL data temperature is trending. being displayed (Month, Year, All-Time). 15. Date Stamp for Previous Rainfall 2. Outdoor Sensor Signal Strength Data (#16) 3. Sensor Low Battery Indicator 16.
Back of Display BACK OF DISPLAY 6. A-B-C Switch ID code that must match 5-in-1 1. Integrated Hang Hole sensor’s A-B-C switch to ensure For easy wall mounting. units synchronize. 2. Plug-in for Power Adapter 7. Power Adapter 3. Battery Compartment 8.
Display Setup AcuRite recommends high quality alkaline batteries for the best product performance. Heavy duty or rechargeable batteries are not recommended. Plug Power Adapter into Set the A-B-C Switch Electrical Outlet The A-B-C switch is located inside the battery compartment. It can be set to A, B or C.
Set the Time, Date & Units Press the “SET” button, located on the front of the display, to enter SET MODE. Once in set mode, the preference you are currently setting will blink on the display. To adjust the currently selected (flashing) item, press and release the “ “ or “ “...
Page 7
Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of the display is critical to the accuracy and performance of this product. Display Placement Place the display in a dry area free of dirt and dust. To ensure accurate temperature measurement, place out of direct sunlight and away from heat sources or vents.
Weather Forecast AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast of weather conditions for the next 12 to 24 hours by collecting data from the sensor in your backyard. It generates a forecast with pinpoint accuracy - personalized for your exact location.
Page 9
Rainfall Tracking This weather station features enhanced tracking of historical rainfall data. Rain accumulation data is recorded for today, over all-time, by year, by month, and by rainfall event. Press the “RAINFALL” button to review rainfall records. The icon is shown on the display while historical data is being viewed.
Troubleshooting Problem Possible Solution • Relocate the display and/or the 5-in-1 sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet (90 cm) away from electronics that may interfere with the wireless communication (such as TVs, microwaves, computers, etc).
Page 11
RECORD / RESET button, located in the battery compartment of the display. Date and time will need to be entered after a reset. If your AcuRite product does not operate properly after trying the troubleshooting steps, visit www.AcuRite.com or call (877) 221-1252 for assistance.
Care & Maintenance Display Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. Calibration The indoor / outdoor temperature and humidity readings, and barometric pressure can be calibrated on the display to improve accuracy.
Specifications DISPLAY’S BUILT-IN 32ºF to 122ºF; 0ºC to 50ºC TEMPERATURE RANGE DISPLAY’S BUILT-IN 1% to 99% HUMIDITY RANGE 0 to 99 mph; 0 to 159 kph WIND SPEED WIND DIRECTION 16 points INDICATORS 0.01 inches (0.25 mm) and up RAINFALL 330ft / 100m depending on home construction materials WIRELESS RANGE...
Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 AcuRite Visit us at www.
