INTRODUCTION
This service manual describes the latest service informa-
tion for the IC-UR8050 UHF REPEATER.
To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1130002390 S.IC
µPD4049UBG
8810008660Screw PH B0 M3x6 NI-ZU IC-UR8050 Top cover
Addresses are provided on the inside back cover for your
convenience.
IC-UR8050 MAIN UNIT 5 pieces
10 pieces
DANGER
NEVER connect the repeater to an AC outlet or to a DC
power supply that uses more than 16 V. This will ruin the
repeater.
DO NOT expose the repeater to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the repeater.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the repeater's
front end.
REPAIR NOTES
1. Make sure a problem is internal before disassembling the
repeater.
2. DO NOT open the repeater until the repeater is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insu-
lated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
repeater is defective.
6. DO NOT transmit power into a signal generator or a
sweep generator.
7. ALWAYS connect a 40 dB to 50 dB attenuator between
the repeater and a deviation meter or spectrum analyzer
when using such test equipment.
8. READ the instructions of test equipment thoroughly
before connecting equipment to the repeater.
