HP ProLiant DL140 Generation 3 Server
Maintenance and Service Guide
Part number 413173-006
Sixth edition October 2012

Advertisement

loading

Related Manuals for HP Proliant DL140

Summary of Contents for HP Proliant DL140

  • Page 1 All manuals and user guides at all-guides.com HP ProLiant DL140 Generation 3 Server Maintenance and Service Guide Part number 413173-006 Sixth edition October 2012...
  • Page 2 © Copyright 2007, 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
  • Page 3 Illustrated parts catalog ......................... 16 Mechanical components ......................... 16 System components ..........................20 HP contact information ........................... 25 Before you contact HP ........................25 Removal and replacement procedures ....................26 Required tools ............................26 Hardware configuration warnings......................26 Server warnings and cautions........................26 Symbols on equipment..........................
  • Page 4 All manuals and user guides at all-guides.com NMI button (SW4) ..........................88 Hot-plug HDD peripherals ........................89 Hot-plug backplane board........................89 Hot-plug cable ..........................90 Status LED indicators ..........................90 Front panel LED indicators ........................91 Hot-plug HDD LED indicators ......................92 Rear panel LED indicators ........................
  • Page 5 If during the diagnosis period HP (or HP service providers or service partners) identifies that the repair can be accomplished by the use of a CSR part, HP will ship that part directly to you for replacement. There are two categories of CSR parts: •...
  • Page 6 Centre d'assistance technique HP. Dans les documents envoyés avec la pièce de rechange CSR, HP précise s'il est nécessaire de lui retourner la pièce défectueuse. Si c'est le cas, vous devez le faire dans le délai indiqué, généralement cinq (5) jours ouvrés. La pièce et sa documentation doivent être retournées dans l'emballage fourni.
  • Page 7 In caso di necessità si può richiedere l'assistenza telefonica di un addetto del centro di supporto tecnico HP. Nel materiale fornito con una parte di ricambio CSR, HP specifica se il cliente deve restituire dei componenti. Qualora sia richiesta la resa ad HP del componente difettoso, lo si deve spedire ad HP entro un determinato periodo di tempo, generalmente cinque (5) giorni lavorativi.
  • Page 8 Flexibilität beim Austausch defekter Bauteile zu ermöglichen. Wenn HP (oder ein HP Servicepartner) bei der Diagnose feststellt, dass das Produkt mithilfe eines CSR-Teils repariert werden kann, sendet Ihnen HP dieses Bauteil zum Austausch direkt zu. CSR-Teile werden in zwei Kategorien unterteilt: •...
  • Page 9 HP podrá cobrarle por el de sustitución. En el caso de todas sustituciones que lleve a cabo el cliente, HP se hará cargo de todos los gastos de envío y devolución de componentes y escogerá la empresa de transporte que se utilice para dicho servicio.
  • Page 10 Optioneel: Onderdelen waarvoor reparatie door de klant optioneel is. Ook deze onderdelen zijn ontworpen voor reparatie door de klant. Als u echter HP verzoekt deze onderdelen voor u te vervangen, kunnen daarvoor extra kosten in rekening worden gebracht, afhankelijk van het type garantieservice voor het product.
  • Page 11 CSR de reposição se a peça com defeito deve ser devolvida à HP. Nos casos em que isso for necessário, é preciso enviar a peça com defeito à HP dentro do período determinado, normalmente cinco (5) dias úteis. A peça com defeito deve ser enviada com a documentação correspondente no material de transporte fornecido.
  • Page 12 All manuals and user guides at all-guides.com Contents 12...
  • Page 13 All manuals and user guides at all-guides.com Contents 13...
  • Page 14 All manuals and user guides at all-guides.com Contents 14...
  • Page 15 All manuals and user guides at all-guides.com Contents 15...
  • Page 16 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.
  • Page 17 All manuals and user guides at all-guides.com Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés. Optional: Facultatif—Pièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également conçues pour permettre au client d'effectuer lui-même la réparation.
  • Page 18 Optional: Opcional—Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto.
  • Page 19 All manuals and user guides at all-guides.com Contents 19...
  • Page 20 All manuals and user guides at all-guides.com System components System components spare parts list Table 2 Item Description Spare part Customer self number repair System fan module 416350-001 Mandatory Processor heat sink 416348-001 Optional Processor Optional Quad-Core Intel Xeon Processors a) E5310 (1.60 GHz, 1066 MHz FSB, 80W) 453310-001 b) E5320 (1.86 GHz, 1066 MHz FSB, 80W)*...
  • Page 21 All manuals and user guides at all-guides.com System components spare parts list Table 2 Item Description Spare part Customer self number repair h) 5150 (2.66 GHz, 1333 MHz FSB, 65W)* 458689-001 i) 5160 (3.0 GHz, 1333 MHz FSB, 80W)* 458688-001 Memory Mandatory a) 512 MB DDR2-667MHz FBD...
  • Page 22 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.
  • Page 23 No: No—Algunos componentes no están diseñados para que puedan ser reparados por el usuario. Para que el usuario haga valer su garantía, HP pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes. Dichos componentes se identifican con la palabra “No”...
  • Page 24 Optional: Opcional—Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto.
  • Page 25 For HP technical support: • In North America: Call 1-800-HP-INVENT (1-800-474-6836). This service is available 24 hours a day, 7 days ○ a week. For continuous quality improvement, calls may be recorded or monitored. If you have purchased a Care Pack (service upgrade), call 1-800-633-3600. For more ○...
  • Page 26 Hardware configuration warnings Read the following sections before performing any servicing or troubleshooting procedure. WARNING: Only authorized technicians trained by HP should attempt to repair this equipment. Because of the complexity of the individual boards and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board.
  • Page 27 All manuals and user guides at all-guides.com CAUTION: The server must always be operated with the system top cover on. Proper cooling is not achieved when the system covers are removed. CAUTION: Whenever installing hardware or performing maintenance procedures requiring access to internal components, it is recommended that all server data be backed up to avoid loss.
  • Page 28 All manuals and user guides at all-guides.com These symbols, on power supplies or systems, indicate that the equipment is supplied by multiple sources of power. WARNING: To reduce the risk of injury from electric shock, remove all power cords to completely disconnect power from the system. Rack warnings WARNING: To reduce the risk of personal injury or damage to equipment, always ensure that the rack is adequately stabilized before extending a component outside the rack.
  • Page 29 All manuals and user guides at all-guides.com • Avoid touching pins, leads, or circuitry. • Always place drives with the Printed Circuit Board (PCB) assembly-side down. • Use conductive field service tools. Pre-installation procedure Perform the steps below before you open the server or before you remove or replace any component. 1.
  • Page 30 All manuals and user guides at all-guides.com Powering down the server The server does not completely power down when the power button is pressed. The button toggles between On and Standby. The standby position removes power from most electronics and the drives, but some internal circuitry remains active.
  • Page 31 All manuals and user guides at all-guides.com Opening the server The top cover is detachable. Remove this cover before you can remove or replace a server component. To remove the top cover: 1. Perform steps 1 through 3 of the pre-installation procedure. 2.
  • Page 32 The server supports three drive bays—two drive bays for 1-inch hard disk drives and one drive bay for a slim-type optical media drive. Go to the HP website at www.hp.com and refer to the options list for this server model for the latest information on supported hard drives and optical media drives.
  • Page 33 All manuals and user guides at all-guides.com System drive cable connections This section highlights the location of the system board connectors for the system drives’ data cables. IMPORTANT: Observe the cable management guidelines listed on page 30 when routing the drive cables.
  • Page 34 All manuals and user guides at all-guides.com Hot-plug SATA/SAS hard drive cables Figure 6 Hot-plug SATA/SAS HDD cable connections Item Description 9-pin HDD LED cable connector HDD 2 data cable connector HDD 1 data cable connector 15-pin HDD power cable connector Optical media drive The optical media device bay supports the installation of a slim-type CD-ROM or DVD-ROM drive.
  • Page 35 All manuals and user guides at all-guides.com Preparing the optical media device bay for installation Figure 7 3. Remove the new optical drive from its protective packaging. The optical drive option kits include mounting screws for drive installation. 4. Install the new optical drive in its carrier. Align the optical drive in the carrier.
  • Page 36 All manuals and user guides at all-guides.com Hard drives Hard drives installed in the server are labeled as Device 1 and Device 2, from left to right, when viewed from the front of the server. Figure 10 Hard drive device numbers Hard drive support The server’s HDD bays support both non-hot-plug and hot-plug SATA drives, as well as hot-plug SAS drives.
  • Page 37 All manuals and user guides at all-guides.com • If you removed a hard drive without plans of installing a new one, you must reinstall the mounting screws to the blank HDD carrier, and then reinstall the carrier in the chassis for proper cooling of the system.
  • Page 38 All manuals and user guides at all-guides.com To remove a hot-plug SATA/SAS hard drive: 1. Make sure that the drive activity and fault identification LED indicators on the HDD carrier are off. 2. Remove the hot-plug SATA/SAS hard drive from the chassis. Press the hard disk carrier button to release the ejector lever.
  • Page 39 All manuals and user guides at all-guides.com 3. Install the new non-hot-plug SATA hard drive in its carrier. If you are installing the new drive in a previously occupied drive bay, use the HDD carrier and mounting screws you removed from the old drive. If you are installing the new drive in an empty drive bay, use the HDD carrier and mounting screws you removed from that drive bay.
  • Page 40 All manuals and user guides at all-guides.com Configuring a hot-plug SATA/SAS hard drive NOTE: The procedures below assume that the user is switching from a non-hot-plug SATA hard drive system to a hot-plug SATA/SAS one. The steps listed below give an overview of the hot-plug SATA/ SAS hard drive configuration procedure.
  • Page 41 All manuals and user guides at all-guides.com Installing the hot-plug backplane board Figure 19 5. Install the PCI-X riser board. Refer to page 55 for detailed procedure. 6. Install the hot-plug SATA/SAS controller board. Refer to page 56 for detailed procedure. 7.
  • Page 42 All manuals and user guides at all-guides.com Routing the hot-plug cable from the low-profile slot Figure 20 3. Proceed to step 7 for instructions on how to connect the hot-plug cable to the backplane board. 4. Route the hot-plug cable from the standard height slot to the backplane board by first engaging the connector end of the cable to the rear connector of the hot-plug SATA/SAS controller board.
  • Page 43 All manuals and user guides at all-guides.com Reinstalling the PCI riser board assembly Figure 22 6. Route the hot-plug cable towards the backplane board. Lay the hot-plug cable in the space between the PCI retainer bracket and the power supply unit.
  • Page 44 All manuals and user guides at all-guides.com Connecting the backplane board cables Figure 24 8. Perform the post-installation procedure. 9. Install the new hot-plug SATA/SAS hard drive to the unit. Proceed to the next section for instructions. To install a hot-plug SATA/SAS hard drive: 1.
  • Page 45 All manuals and user guides at all-guides.com Installing a hot-plug SATA/SAS hard drive Figure 25 3. Set up the SATA/SAS configuration. Refer to the documentation that came with the hot-plug SATA/SAS controller board for detailed procedure. System board configuration Refer to the following sections for instructions about how to remove or replace the processor, memory modules, expansion boards, the IPMI card, and the system battery.
  • Page 46 All manuals and user guides at all-guides.com Processor socket numbers Figure 27 • Handle the processor and heat sink with care. Damage to either may prevent the system from functioning properly. • The pins beneath the processor are very fragile. Do not bend or damage them. •...
  • Page 47 All manuals and user guides at all-guides.com 3. Remove the processor air baffle. Remove the screw securing the processor air baffle to the system board. Lift the processor air baffle away from the system board. Removing the processor air baffle Figure 29 Store the processor air baffle (with its screw) for reassembly later.
  • Page 48 All manuals and user guides at all-guides.com To remove the heat sink: 1. Perform the pre-installation procedure. 2. If necessary, remove any accessory boards or cables that prevent access to the air duct. 3. Lift the air duct away from the processor sockets. Keep it for reinstallation later.
  • Page 49 All manuals and user guides at all-guides.com To remove a processor: 1. Disengage the load lever. 2. Lift up the retention plate to expose the socket body. 3. Grasp the processor by its edges and carefully lift it out of its socket. Removing the processor Figure 33 4.
  • Page 50 To install the new heat sink: CAUTION: To prevent overheating or a possible system crash, use only a heat sink specified for the HP ProLiant ML110 Generation 5 Server. 1. Remove and discard the plastic cover protecting the thermal interface material.
  • Page 51 ○ Memory installation guidelines • Use only HP supported fully buffered registered ECC DDR2 667 DRAM modules in 512 MB, 1 GB, 2 GB, or 4 GB capacities. • Install identical modules (of the same type, manufacturer, speed, timing, and organization) per the instructions below.
  • Page 52 All manuals and user guides at all-guides.com Install the first pair in the DIMM1 and DIMM3 slots. − Memory upgrade granularity is two DIMMs. Observe the following channel pair − sequence during installation: DIMM5 - DIMM7, DIMM2 - DIMM4, then DIMM6 - DIMM8. When operating in single DIMM mode, the module should be installed in the DIMM1 slot.
  • Page 53 All manuals and user guides at all-guides.com Installing a memory module Figure 39 6. Perform the post-installation procedure. Expansion board System board PCI expansion slots There are four PCI expansion slots on the system board. System board PCI expansion slots Figure 40 Item Component code...
  • Page 54 All manuals and user guides at all-guides.com System default PCI Express riser boards Figure 41 Item Description Standard height/full length PCI Express x16 riser board Low-profile PCI Express x8 riser board NOTE: Users have the option to replace either or both of the PCI Express riser boards with a PCI-X model using the PCI-X riser board option kit.
  • Page 55 All manuals and user guides at all-guides.com To install the PCI-X riser board: Installing the PCI-X riser board option allows users to install PCI-X compatible expansion boards in the ProLiant server. NOTE: For ease of reading, the PCI riser board assembly will simply be referred to as “assembly” in the succeeding sections.
  • Page 56 3. Perform the post-installation procedure. Installing a PCI expansion board Guidelines for installing PCI expansion boards The system supports up to two expansion boards at a time. Use only HP supported expansion boards that meet the following specifications: • Compliance PCI Express x8 or x16 ○...
  • Page 57 8. Perform the post-installation procedure. System battery The HP ProLiant server uses nonvolatile memory that requires a battery to retain system information when power is removed. The battery, a 3 V 200-mAh internal lithium battery, is located on the system board (BT1).
  • Page 58 System battery replacement warnings Observe the following precautions when replacing the system battery: • Replace the battery with the same type as the battery recommended by HP. Use of another battery may present a risk of fire or explosion. •...
  • Page 59 All manuals and user guides at all-guides.com Replacing the system battery Figure 49 3. Perform the post-installation procedure. System fans The server has six system fans located on the chassis’ center wall. Figure 50 System fans System fan connections identifies the system fans by their device number and shows their corresponding cable Figure 51 connections.
  • Page 60 All manuals and user guides at all-guides.com Device number Connector System fan 1 to 4 CN3 to CN6 on the front panel board System fan 5 CN9 on the system board System fan 6 CN8 on the system board NOTE: System fans 1 to 5 are for the memory modules and processors, while system fan 6 is for the PCI slots and system chipsets.
  • Page 61 All manuals and user guides at all-guides.com Installing a system fan Figure 53 5. Perform the post-installation procedure. Power supply unit Located on the rear panel of the server is a single standard autoranging 650-watts PSU with PFC (power factor correction) function. Power supply unit Figure 54 PSU replacement warnings...
  • Page 62 All manuals and user guides at all-guides.com Removing the power supply unit Figure 55 3. Install the new PSU. CAUTION: Do not over tighten the PSU’s screws to prevent them from breaking off. A maximum torque of 7 ± 1 is set for the system. Position the new PSU in the PSU section of the chassis.
  • Page 63 NOTE: For more information about the diagnostic tools described in this table, and other tools available for your server, refer to the Servers Troubleshooting Guide located inside the HP ProLiant DL140 Generation 3 Server Support CD. For the most recent version of this guide, go to www.hp.com.
  • Page 64 All manuals and user guides at all-guides.com PhoenixBIOS software PhoenixBIOS software is a ROM BIOS-based diagnostic tool that monitors system activity and performs constant hardware testing to ensure proper system operation. ROM BIOS is a set of programs permanently stored in an EEPROM chipset (U64) located on the system board. These programs micro-manage the hardware devices installed on your server.
  • Page 65 All manuals and user guides at all-guides.com The Setup Utility loads the configuration values in a battery-backed nonvolatile memory called CMOS RAM. This memory area is not part of the system RAM, which allows configuration data to be retained when power is turned off. The values take effect when the system is booted. POST uses these values to configure the hardware.
  • Page 66 All manuals and user guides at all-guides.com Navigating through the Setup Utility Use the keys listed in the legend bar on the bottom of the Setup screen to work your way through the various menu and submenu screens of the Setup Utility. Table 4 Setup Utility’s navigation keys Functions...
  • Page 67 All manuals and user guides at all-guides.com Setup Utility menus The Setup Utility provides a menu bar with the menu selections. The menu bar choices are described in the. Table 5 Setup Utility's primary menus Menu Function Main Use this menu to: View BIOS information including ROM ID, version number and build date •...
  • Page 68 All manuals and user guides at all-guides.com Setup Utility's primary menus Table 5 Menu Function Power Use this menu to: Enable or disable the modem ring power-up function. • Enable or disable the WOL (Wake-On-LAN) function of the onboard LAN controllers •...
  • Page 69 All manuals and user guides at all-guides.com To change the administrator password: 1. In the Security menu screen, select the Administrator Password Is field, and then press Enter. 2. Type the original password in the password box. 3. Type a new password, and then press Enter. 4.
  • Page 70 All manuals and user guides at all-guides.com Boot-time diagnostic screen The boot-time diagnostic screen displays basic and important information about the current server configuration and is necessary for troubleshooting and may be required when asking for technical support. This information includes: Processor specifications Serial port base I/O address •...
  • Page 71 Be sure to use a CMOS backup utility that is designed for the particular CMOS type and OS version installed in your ProLiant server. For information on a compatible CMOS backup utility, contact your local HP representative. Loading system defaults If your system fails after you make changes in the Setup menus, reboot the server, enter Setup and load the system default settings to correct the error.
  • Page 72 POST. The number of tests displayed depends on the configuration of the server. During POST you can press: • Esc to skip the HP logo and go to POST boot progress display system summary screen. • F7 to display the Boot menu. •...
  • Page 73 Verify that the keyboard cable is securely connected to the keyboard port (not the mouse port) on the rear panel of the server. If the problem persists, replace the keyboard or contact your HP Customer Support provider. 0212 Keyboard Controller Keyboard controller failed test.
  • Page 74 CMOS. You can either load the system default values or access Setup and enter your own custom values. If the error persists, check the system battery or contact your HP Customer Support provider. 0260 System timer error The timer test failed.
  • Page 75 All manuals and user guides at all-guides.com The routine derives the beep code from the test point error as follows: 1. The 8-bit error code is broken down to four 2-bit groups (Discard the most significant group if it is 00). 2.
  • Page 76 All manuals and user guides at all-guides.com POST beep codes Table 7 Code Beep Description Set ES segment register to 4 GB Auto size DRAM Initialize POST Memory Manager Clear 512 KB base RAM 1-3-4-1 RAM failure on address line xxxx 1-3-4-3 RAM failure on data bits xxxx of low byte of memory bus Enable cache before system BIOS shadow...
  • Page 77 All manuals and user guides at all-guides.com POST beep codes Table 7 Code Beep Description Initialize POST display service Display prompt ”Press F10 to enter SETUP” Disable processor cache Test RAM between 512 and 640 KB Test extended memory Test extended memory address lines Jump to user patch 1 Configure advanced cache registers Initialize multiprocessor APIC...
  • Page 78 All manuals and user guides at all-guides.com POST beep codes Table 7 Code Beep Description Test and initialize PS/2 mouse Initialize floppy controller Determine number of ATA drives (optional) Initialize hard disk controllers Initialize local bus hard disk controllers Jump to user patch 2 Build MP table for multi-processor boards Install CD-ROM for boot Clear huge ES segment register...
  • Page 79 All manuals and user guides at all-guides.com POST beep codes Table 7 Code Beep Description Initialize SMBIOS Initialize PnP option ROMs Clear parity checkers Display Multi-boot menu Clear screen (optional) Check virus and backup reminders Try to boot with INT 19 Initialize POST Error Manager (PEM) Initialize error logging Initialize error display function...
  • Page 80 To obtain the guide, refer to any of the following sources and then select the HP ProLiant Servers Troubleshooting Guide: •...
  • Page 81 All manuals and user guides at all-guides.com Connectors, switches, and LEDs Connectors and components Front panel Figure 59 Front panel Item Icon Component Hard disk drive (HDD) bays Optical media device bay Front unit identification (UID) button with LED indicator (blue) Press to illuminate the UID LED indicators on the front and rear panels.
  • Page 82 All manuals and user guides at all-guides.com Rear panel Figure 60 Rear panel Item Icon Component Ventilation holes Thumbscrew for the top cover Thumbscrews for the PCI riser board assembly Low-profile PCI Express x8/PCI-X riser board slot cover Standard height/full-length PCI Express x16/PCI-X riser board slot cover Power supply cable socket GbE LAN ports for NIC 1 and NIC 2 (RJ-45) Rear UID button with LED indicator (blue)
  • Page 83 All manuals and user guides at all-guides.com System board Figure 61 System board components Item Component code Component 10/100 Mbps LAN port for IPMI management SKT6 PS/2 mouse port SKT3 PS/2 keyboard port Serial port CN10 Video port SKT2 and SKT1 USB ports UID button with LED indicator (blue) RJ1 and RJ2...
  • Page 84 All manuals and user guides at all-guides.com Item Component code Component CPU1 Intel LGA771 processor 1 socket — Processor 2 socket air baffle — Airflow regulator for the front system fans 1 - 4 USBCN1 9-pin connector for the front USB ports CN9 and CN8 4-pin system fan connectors (for system fans 5 and 6) PWRCN1...
  • Page 85 All manuals and user guides at all-guides.com Front panel board The front panel board is linked to the system board through the front panel board connector (FPCN1). Front panel board Figure 62 Item Component Component code Front UID button LED6 Front UID LED indicator LED5 System health LED...
  • Page 86 All manuals and user guides at all-guides.com Front panel board cable connections Figure 63 Front panel board cable connections Item Connector Cable Front panel board system board connector Connects to FPCN1 on the system board Front panel board power connector Connects to the PSU.
  • Page 87 All manuals and user guides at all-guides.com 7. Arrange the drive and power cables of the available hard drives over the routed FPB cables, and then reconnect them to their corresponding connectors on the rear of the drives. 8. Connect the FPB cables to their FPB connectors. Connect the FPB power cable to the CN1 connector.
  • Page 88 All manuals and user guides at all-guides.com System configuration switch (SW2) Figure 65 System configuration switch Switch Status Function SW2-1 Boot block enabled Normal boot SW2-2 Clear CMOS settings and restore system defaults Normal CMOS settings SW2-3 — Reserved SW2-4 —...
  • Page 89 All manuals and user guides at all-guides.com Hot-plug HDD peripherals Hot-plug backplane board If you are switching from a non-hot-plug SATA hard drive system to a hot-plug SATA/SAS one, you will need to install the hot-plug backplane board (HPBB). This backplane board supports both SATA and SAS functions.
  • Page 90 All manuals and user guides at all-guides.com Hot-plug cable If you are switching from a non-hot-plug SATA hard drive system to a hot-plug SATA/SAS one, you will need to install the hot-plug cable. This cable supports both SATA and SAS functions. Go to page 41 for instructions on how to install this cable.
  • Page 91 All manuals and user guides at all-guides.com Front panel LED indicators Figure 69 Front panel LED indicators Item Indicator Status Description UID LED indicator Blue A UID button has been pressed. (recessed underneath the UID button) System health LED System health is normal. indicator Amber A pre-failure system threshold has been breached.
  • Page 92 All manuals and user guides at all-guides.com Hot-plug HDD LED indicators Figure 70 Hot-plug HDD LED indicators Item Indicator Status Description Drive activity Forced off (override drive activity output) LED indicator The drive is not a member of any RAID volumes; or the drive is •...
  • Page 93 All manuals and user guides at all-guides.com Item Indicator Status Description Drive fault identification • The drive is not in a failed state. LED indicator • The drive is not selected (unit identification). Solid blue The drive is not in a failed state. •...
  • Page 94 All manuals and user guides at all-guides.com Rear panel LED indicators Figure 71 Rear panel LED indicators Item Indicator Status Description NIC activity/link status LED Solid green An active network link exists. indicators Flashing green An ongoing network data activity exists. The server is off-line.
  • Page 95 All manuals and user guides at all-guides.com System specifications Technical specifications System unit Table 8 System unit specifications Item Description Processor socket Intel LGA771 processor socket (two) Processor support Dual-Core and Quad-Core Intel Xeon processors Core logic chipsets • Intel MCH – north bridge, core logic controller Intel ICH –...
  • Page 96 All manuals and user guides at all-guides.com System unit specifications Table 8 Item Description Memory Eight DDR2-667 DIMM slots, four DIMMs per processor for a maximum system memory capacity of 16 GB (2 GB per DIMM) Media storage Two 1-inch HDD bays supporting both non-hot-plug and hot-plug SATA drives, as •...
  • Page 97 All manuals and user guides at all-guides.com Processor Table 10 Quad-Core Intel Xeon processor specifications Processor Number Specification E5310 L5320 LV E5320 E5335 L5335 E5345 X5355 X5365 CPU speed 1.6 GHz 1.86 GHz 1.86 GHz 2.0 GHz 2.0 GHz 2.33 GHz 2.66 GHz 3.0 GHz Bus speed...
  • Page 98 All manuals and user guides at all-guides.com Table 11 Dual-Core Intel Xeon processor specifications Processor number Specification 5080 5060 5050 5160 5150 5140 5148 LV 5130 5110 CPU speed 3.73 GHz 3.2 GHz 3.0 GHz 3.0 GHz 2.66 GHz 2.33 GHz 2.33 GHz 2.0 GHz 1.6 GHz...
  • Page 99 All manuals and user guides at all-guides.com IDE CD-ROM drive Table 12 IDE CD-ROM drive specifications Item Description Dimensions Height 12.7 mm (0.5 in) Width 128 mm (5.04 in) Depth 137.2 mm (5.4 in) Weight < .34 kg (< .75 lb) Applicable disk formats CD-DA, CD-ROM (mode 1 and 2);...
  • Page 100 Non-hot-plug SATA hard drive Table 13 Non-hot-plug SATA hard drive specifications Item 80 GB 160 GB 250 GB 500 GB Model HP Serial-ATA (SATA) Hard Drive Capacity 80,026 MB 160,041 MB 250,059 MB 500,107 MB Physical dimensions Height 26.1 mm (1.028 in) 26.1 mm (1.028 in)
  • Page 101 Table 14 Hot-plug SATA hard drive specifications Item 80 GB 160 GB 250 GB 500 GB 750 GB Model HP Serial-ATA (SATA) Hard Drive Capacity 80,026 MB 160,041 MB 250,059 MB 500,107 MB 750,156 Physical dimensions 26.4 mm 26.4 mm 26.4 mm...
  • Page 102 Table 15 Hot-plug SAS hard drive specifications Item 36 GB 72 GB 146 GB 300 GB Model HP Serial Attached SCSI (SAS) Hard Drive Capacity 36,420,075,520 MB 73,407,856,856 MB 146,815,737,856 MB 300,000,000,000 Physical dimensions 25.4 mm (1.0 in) 25.4 mm (1.0 in) 25.4 mm (1.0 in)
  • Page 103 All manuals and user guides at all-guides.com Gigabit Ethernet controller Table 17 Gigabit Ethernet controller specifications Item Description Model Broadcom BCM5721 NetXtreme Network interface 10/100/1000Base-T Ethernet Media interface controller (MAC) Triple speed, IEEE 802.3 compliant System interface Single lane 4-pin PCI-X Connector RJ-45 Industry-compliant manageability features...
  • Page 104 All manuals and user guides at all-guides.com Physical specifications System physical specifications Table 19 Item Description System board platform ATX (Advanced Technology Extended) System board dimensions Length 295 mm (11.6 in.) Width 412 mm (16.2 in.) Server dimensions Height 43mm (1.70 in) Width 426 mm (16.78in) Depth...
  • Page 105 All manuals and user guides at all-guides.com Environmental specifications System environmental specifications Table 20 Item Description System inlet temperature Operating 10° to 35°C (50° to 95°F) Non-operating 30° to 60°C (-22° to 140°F) Relative humidity (non- condensing) 10 to 90% RH at 28°C (82.4°F) maximum wet bulb temperature Operating 5 to 95 % RH at 38.7°C (101.7°F) maximum wet bulb temperature Non-operating...
  • Page 106 (CSR), 5 part number, 22 replacement warnings, 58 replacing, 58 diagnostics beep codes, 74 accessing, 63 BIOS configuration HP ROMPaq Utility, 63 POST, 72 IPMI Event Log, 63 boot block switch, 88 overview, 63 boot sequence PhoenixBIOS software, 64 configuring, 67...
  • Page 107 All manuals and user guides at all-guides.com installing, 34 non-hot-plug HDD mounting screws, 36 part number, 21 SATA HDD configuration, 67 DVD-RW drive storage controller, 95 part number, 21 supported drives, 36 hardware configuration backing up data, 26 EEPROM boot-time diagnostic screen, 70 BIOS, 84 ESD damage prevention, 28 BMC, 84...
  • Page 108 LED indicators, 92 keyboard PS/2 connector, 82 contact information, 25 technical support, 25 LAN controllers HP ROMPaq Utility, 63 GbE LAN controller, 83 LAN ports I/O ports. See input/output ports 10/100 Mbps LAN port, 82 I/O subsystem, 95 configuration settings, 67...
  • Page 109 67 hot-plug backplane board, 21 multi-boot support, 67 hot-plug cable, 22 hot-plug SATA/SAS controller board, 21 HP SATA/SAS hard drive, 21 NIC indicators IDE data cable assembly, 22 activity/link status, front, 91 mass storage devices, 21 activity/link status, rear, 94...
  • Page 110 All manuals and user guides at all-guides.com installing, 56 user-configurable field, 66 PCI riser board assembly, 54 PhoenixBIOS software riser board expansion slots, 53 configuration function, 64 system board expansion slots, 53 overview, 64 PCI expansion slots POST, 72 PCI-X riser board, 53 physical specifications system board, 53 system board, 104...
  • Page 111 All manuals and user guides at all-guides.com system board power connector, 84 south bridge, 84 technical specifications, 97 spare parts processor air baffle mechanical components, 16 location, 84 storing, 28 part number, 16 system components, 20 removing, 46 transporting, 28 processor mounting plate, part number, 16 standby mode PS/2 connectors...
  • Page 112 82 technical specifications CD-ROM drive, 99 Wake-On-LAN. See WOL Gigabit Ethernet controller, 103 warnings HP SAS HDD, 102 component-level repairs, 26 HP SATA HDD, 101 improper repairs, 26 memory module, 96 personal injury, 26 NHP SATA HDD, 100...
