New Holland T7.175 Service Manual
  1. Manuals
  2. Brands
  3. New Holland Manuals
  4. Tractor
  5. T7.175
  6. Service manual

New Holland T7.175 Service Manual

Hide thumbs Also See for T7.175:

Advertisement

Quick Links

SERVICE MANUAL
T7.175 / T7.190 / T7.195 / T7.205
Tractor
Part number 47770506A
English
February 2017
© 2017 CNH Industrial Latin America LTDA. All Rights Reserved.

Advertisement

loading

Related Manuals for New Holland T7.175

Summary of Contents for New Holland T7.175

  • Page 1 SERVICE MANUAL T7.175 / T7.190 / T7.195 / T7.205 Tractor Part number 47770506A English February 2017 © 2017 CNH Industrial Latin America LTDA. All Rights Reserved.
  • Page 2 SERVICE MANUAL T7.175 With cab, 18X6, TIER 3 [HCCZ7175CECW21177 - ] T7.190 With cab, 18X6, TIER 3 [HCCZ7190CECW21177 - ] T7.195 With cab, 18X6, TIER 3 [HCCZ7195CECW21177 - ] T7.205 With cab, 18X6, TIER 3 [HCCZ7205CECW21177 - ] 47770506A 15/02/2017...
  • Page 3 Link Product / Engine Product Market Product Engine T7.175 Com cabine, 18x6, TIER 3 Latin America F4DE9684J*J106 [HCCZ7175CECW21177 - ] T7.190 Com cabine, 18x6, TIER 3 Latin America F4DE9684V*J101 [HCCZ7190CECW21177 - ] T7.195 Com cabine, 18x6, TIER 3 Latin America...
  • Page 4 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.103] Crankshaft and flywheel.
  • Page 5 Power Take-Off (PTO) ..............31 [31.104] Rear electro-hydraulic control ............31.1 [31.114] Two-speed rear Power Take-Off (PTO) .
  • Page 6 [41.200] Hydraulic control components............41.3 [41.206] Pump .
  • Page 7 47770506A 15/02/2017 Find manuals at https://best-manuals.com...
  • Page 8 INTRODUCTION 47770506A 15/02/2017 Find manuals at https://best-manuals.com...

  • Page 9: Table Of Contents

    Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Foreword - How to use and navigate through this manual .

  • Page 10: Foreword - Important Notice Regarding Equipment Servicing

    Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your NEW HOLLAND Sales and Service Networks. 47770506A 15/02/2017...

  • Page 11: Foreword - How To Use And Navigate Through This Manual

    INTRODUCTION Foreword - How to use and navigate through this manual This manual has been produced by a new technical information system. This new system is designed to deliver technical information electronically through web delivery (eTIM), DVD, and paper manuals. A coding system called SAP has been developed to link the technical information to other Product Support functions, e.g., Warranty.
  • Page 12 INTRODUCTION Manual content This manual is divided into Sections. Each Section is then divided into Chapters. Contents pages are included at the beginning of the manual, then inside every Section and inside every Chapter. An alphabetical Index is included at the end of each Chapter.
  • Page 13 INTRODUCTION 61 - Metering system 62 - Pressing - Bale formation 63 - Chemical applicators 64 - Chopping 66 - Threshing 68 - Tying/Wrapping/Twisting 69 - Bale wagons 70 - Ejection 71 - Lubrication system X X X X X 72 - Separation 73 - Residue handling 74 - Cleaning...
  • Page 14 INTRODUCTION Chapters Each Chapter is identified by a number e.g. Engine - Engine and crankcase - 10.001. The first number is identical to the Section number i.e. Chapter 10.001 is inside Section 10, Engine. The second number is representative of the Chapter contained within the Section.
  • Page 15 INTRODUCTION Information units and information search Each chapter is composed of information units. Each information unit has the SAP code shown in parentheses. This indicates the function and type of information in that information unit. Each information unit has a page reference within that Chapter.

  • Page 16: Safety Rules - Ecology And The Environment

    Improper disposal of batteries can contaminate the soil, groundwater, and waterways. NEW HOLLAND strongly recommends that you return all used batteries to a NEW HOLLAND dealer, who will dispose of the used batteries or recycle the used batteries properly. In some countries, this is a legal requirement.

  • Page 17: Safety Rules

    INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual and on machine safety signs, you will find the signal words DANGER, WARNING, and CAU- TION followed by special instructions.

  • Page 18: Basic Instructions - Shop And Assembly

    Only use CNH Original Parts or NEW HOLLAND Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or NEW HOLLAND Original Parts can offer this guarantee.
  • Page 19 W0111A Special tools The special tools that NEW HOLLAND suggests and illustrate in this manual have been specifically researched and designed for use with NEW HOLLAND machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting operation.

  • Page 20: Torque - Minimum Tightening Torques For Normal Assembly

    INTRODUCTION Torque - Minimum tightening torques for normal assembly METRIC NON-FLANGED HARDWARE NOM. LOCKNUT LOCKNUT SIZE CL.8 CL.10 CLASS 8.8 BOLT and CLASS 10.9 BOLT and W/CL8.8 W/CL10.9 CLASS 8 NUT CLASS 10 NUT BOLT BOLT PLATED PLATED UNPLATED UNPLATED W/ZnCr W/ZnCr 2.2 N·m (19 lb...
  • Page 21 INTRODUCTION METRIC FLANGED HARDWARE NOM. CLASS 8.8 BOLT and CLASS 10.9 BOLT and LOCKNUT LOCKNUT SIZE CLASS 8 NUT CLASS 10 NUT CL.8 CL.10 W/CL8.8 W/CL10.9 BOLT BOLT PLATED PLATED UNPLATED UNPLATED W/ZnCr W/ZnCr 2.4 N·m (21 lb 3.2 N·m (28 lb 3.5 N·m (31 lb 4.6 N·m (41 lb 2.2 N·m (19 lb...
  • Page 22 INTRODUCTION 1. Manufacturer's Identification 2. Property Class 3. Clock Marking of Property Class and Manufacturer's Identification (Optional), i.e. marks 60° apart indicate Class 10 properties, and marks 120° apart indicate Class 8. INCH NON-FLANGED HARDWARE LOCKNUT LOCKNUT NOMINAL SAE GRADE 5 BOLT SAE GRADE 8 BOLT GrB W/ Gr5 GrC W/ Gr8...
  • Page 23 INTRODUCTION INCH FLANGED HARDWARE NOM- LOCKNUT LOCKNUT SAE GRADE 5 BOLT and SAE GRADE 8 BOLT and INAL GrF W/ Gr5 GrG W/ Gr8 SIZE BOLT BOLT UNPLATED PLATED UNPLATED PLATED or PLATED W/ZnCr or PLATED W/ZnCr SILVER GOLD SILVER GOLD 12 N·m (106 lb 13 N·m (115 lb...
  • Page 24 INTRODUCTION Inch Lock Nuts, All Metal (Three optional methods) 20090268 Grade Identification Grade Corner Marking Method (1) Flats Marking Method (2) Clock Marking Method (3) Grade A No Notches No Mark No Marks Grade B One Circumferential Notch Letter B Three Marks Grade C Two Circumferential Notches...

  • Page 25: Torque - Standard Torque Data For Hydraulics

    INTRODUCTION Torque - Standard torque data for hydraulics Installation of adjustable fittings in straight thread O-ring bosses 1. Lubricate the O-ring by coating it with a light oil or petroleum. Install the O-ring in the groove adjacent to the metal backup washer which is assembled at the extreme end of the groove (4).
  • Page 26 INTRODUCTION Pipe thread fitting torque Thread size Torque (maximum) 1/8-27 13 N·m (10 lb ft) Before installing and tightening pipe fittings, clean the 1/4-18 16 N·m (12 lb ft) threads with a clean solvent or Loctite cleaner and apply 3/8-18 22 N·m (16 lb ft) sealant L ®...

  • Page 27: Consumables

    Coolant água PAG-E13 Air-conditioning compressor oil As required Óleo de baixa viscosidade SP10 Viscosidade ISO100 NEW HOLLAND AMBRA GR-9 Grease and bearing housings As required NLGI2, Li-Ca MULTI-PURPOSE GREASE Main fuel reservoir 209 L (55 US gal) Diesel oil or Biodiesel B (B5) -...
  • Page 28 A list of the oils and lubricants recommended for your ma- chine is available on a decal fixed to the left-hand side of the engine water radiator. Contact your NEW HOLLAND dealer to get a new decal if it is damaged or illegible.
  • Page 29 Torque - Standard torque data for hydraulics Sealant Loctite® 565™ PST Torque - Standard torque data for hydraulics Loctite® 545™ Torque - Standard torque data for hydraulics NEW HOLLAND AMBRA Consumables MASTERGOLD™ HSP ENGINE OIL SAE 10W-30 NEW HOLLAND AMBRA Consumables MASTERGOLD™...
  • Page 30 SERVICE MANUAL Engine T7.175 With cab, 18X6, TIER 3 [HCCZ7175CECW21177 - ] T7.190 With cab, 18X6, TIER 3 [HCCZ7190CECW21177 - ] T7.195 With cab, 18X6, TIER 3 [HCCZ7195CECW21177 - ] T7.205 With cab, 18X6, TIER 3 [HCCZ7205CECW21177 - ] 47770506A 15/02/2017...
  • Page 31 Contents Engine - 10 [10.001] Engine and crankcase ............. . . 10.1 [10.103] Crankshaft and flywheel.
  • Page 32 CONSUMABLES INDEX Consumable Reference PAGE NEW HOLLAND AMBRA Engine cooling system - Filling 10.6 / 5 AGRIFLU NEW HOLLAND AMBRA Engine coolant replace 10.6 / 6 ACTIFULL™ OT EXTENDED LIFE COOLANT 47770506A 15/02/2017...
  • Page 33 47770506A 15/02/2017...
  • Page 34 Engine - 10 Engine and crankcase - 001 T7.175 With cab, 18X6, TIER 3 [HCCZ7175CECW21177 - ] T7.190 With cab, 18X6, TIER 3 [HCCZ7190CECW21177 - ] T7.195 With cab, 18X6, TIER 3 [HCCZ7195CECW21177 - ] T7.205 With cab, 18X6, TIER 3 [HCCZ7205CECW21177 - ] 47770506A 15/02/2017 10.1 [10.001] / 1...
  • Page 35 Contents Engine - 10 Engine and crankcase - 001 SERVICE Engine Connect ................. . 3 Remove .
  • Page 36 Engine - Engine and crankcase Engine - Connect CAUTION Heavy object! The component is heavy. Use care not to drop the component when installing, removing, or handling. Failure to comply could result in minor or moderate injury. C0095A 1. Line up the front support and engine assembly with the transmission.
  • Page 37 Engine - Engine and crankcase 4. Connect the supply hose of the hydraulic brake master cylinder. BAIS06CCM085AVA 5. Connect the transmission oil cooler pipes (1) and (2). BAIS06CCM032AVA 6. Install the transmission shaft flange, if installed. Tighten the M24 nut (if installed) to 294 N·m (217 lb ft). Tighten the M12 bolt (if installed) to 80 N·m (59 lb ft) .
  • Page 38 Engine - Engine and crankcase 9. Connect the supply hose of the hydraulic brake valve. BAIS06CCM086AVA 10. Connect the fuel supply and return lines. BAIS06CCM137AVA 11. Connect the oil supply hoses of the steering cylinder (1) and (2). BVE0218A 12. Connect the high-pressure hose (1) and the low-pres- sure hose (2) of the air conditioning.
  • Page 39 Engine - Engine and crankcase 13. Connect the cab heater hose. BAIS06CCM064AVA 14. Connect the cab heater hose to the radiator. BAIS06CCM083AVA 15. Connect the positive battery cable (2) and the nega- tive cable (ground) (1). 16. Connect the engine wire harness connectors. BVE0403A 17.
  • Page 40 Engine - Engine and crankcase 18. When installed, install the radar (2). Connect the radar electrical connector (1). BAIS06CCM080AVB 19. Install the side shield on both sides of the engine. 20. Connect the battery ground lead. 21. Fill the engine cooling system. For more information see Engine coolant replace (10.400).
  • Page 41 Engine - Engine and crankcase Engine - Remove DANGER Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity. Always support units or parts with suitable slings or hooks. Make sure the work area is clear of all bystanders. Failure to comply will result in death or serious injury.
  • Page 42 Engine - Engine and crankcase 5. Disconnect the cab heater coolant hose. BAIS06CCM083AVA 6. Remove the electrical wiring from the air filter frame (1). Remove the filter-drier from the air filter frame (2). BAIS06CCM129AVA 7. Disconnect the high-pressure hose (1) and the low- pressure hose (2) of the air conditioning.
  • Page 43 Engine - Engine and crankcase 9. Disconnect the differential lock supply hose (1) and re- move the support (2). BAIS06CCM037AVA 10. Disconnect the steering cylinder supply hoses (1) and (2). NOTE: Note the position of the steering cylinder oil feed hoses.
  • Page 44 Engine - Engine and crankcase 13. Disconnect the fuel supply and return lines. BAIS06CCM137AVA 14. Remove the attachment drive chain. BAIS06CCM131AVA 15. Remove the air-conditioning compressor assembly, the condenser filter-drier, and the tubing from the en- gine. Do not disconnect the tubing. See Air-condi- tioning compressor - Remove (50.200).
  • Page 45 Engine - Engine and crankcase 18. Remove the front fixing bolts of the air filter mounting frame. BAIS06CCM135AVA 19. Remove the engine wiring clamp fixing bolts and repo- sition the engine wiring on top of the engine. BVE0304A 20. Remove the rear fixing bolts of the air filter mounting frame.
  • Page 46 Engine - Engine and crankcase 22. Remove the positive (1) and negative (2) cables from the starter motor and the electrical connector. (3). BAIS06CCM134AVA 23. Install lift supports on the engine. BVE0310A 24. Use a suitable chain to secure the engine to a hoist. 25.
  • Page 47 Engine - Engine and crankcase Engine - Install DANGER Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity. Always support units or parts with suitable slings or hooks. Make sure the work area is clear of all bystanders. Failure to comply will result in death or serious injury.
  • Page 48 Engine - Engine and crankcase 4. Remove the engine lift supports. BVE0310A 5. Connect the positive (1) and negative (2) cables to the starter motor and the electrical connector (3). BAIS06CCM134AVA 6. Install the air filter mounting frame with a suitable chain and hoist.
  • Page 49 Engine - Engine and crankcase 8. Position the engine wiring. Install the wiring clamp fix- ing bolts. BVE0304A 9. Install the front fixing bolts of the air filter mounting frame. BAIS06CCM135AVA 10. Connect the turbo air filter outlet hose. BAIS06CCM163AVA 11.
  • Page 50 Engine - Engine and crankcase 12. Install the air-conditioning compressor assembly, the condenser filter-drier, and the tubing on the engine. Do not disconnect the tubing. See Air-conditioning compressor - Install (50.200). 13. Install the attachment drive chain. BAIS06CCM131AVA 14. Connect the fuel supply and return lines. BAIS06CCM137AVA 15.
  • Page 51 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...

This manual is also suitable for:

T7.190T7.195T7.205
