- Page 1 Fan Ovens Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. -
Page 3: Before Using For The First Time
– Switch the empty oven ON at maximum temperature for about two hours to eliminate traces of grease and smell from the components. – Let the oven cool down, switch off the electrical supply, then clean the inside of the oven with a cloth soaked in water and neutral detergent and dry thoroughly. - Page 4 – Always use oven gloves when removing the shelves and food trays from the oven whilst hot. – Clean the oven regularly and do not allow fat or oils to build up in the oven base or trays. Remove spillages as soon as they occur.
-
Page 5: Control Panel
Please Note: This appliance incorporates a safety cooling fan which you will hear operating whenever the oven or grill are in use. The cooling fan may also operate when the oven is switched off. This fan is to reduce the external temperature of the appliance and cool the internal components. -
Page 6: General Features
– Circular element 2200 W Note: Upon first use, it is advisable to operate the oven at the maximum temperature for 60 minutes in the position to eliminate possible traces of grease on the heating elements. Repeat the operation for another 15 minutes with the grill element on as explained in the chapters TRADITIONAL GRILLING and USE OF THE GRILL. -
Page 7: How To Use The Oven
Fig. 2 with the oven temperature. Function Selector Knob (Fig. 3) Rotate the knob clockwise to set the oven for one of the following functions. Oven Light By turning the function selector knob to this setting, the oven light will illuminate in the oven cavity. -
Page 8: Hot Air Cooking
Hot Air Cooking The circular element and fan come on. The heat is dispersed by forced convection and the temperature can be regulated to between 50 °C and 225 °C via the thermostat knob. The oven does not require preheating. -
Page 9: Cooking Advice
Set the switch to position and the thermostat knob to position 150 °C. Bread becomes fragrant again if wet with a few drops of water and put into the oven for about 10 minutes at the highest temperature. Simultaneous Cooking of Different Foods With the function selector in position at the same time. -
Page 10: Electronic Programmer
The electronic programmer is a device that groups together the following functions: – 24 hour clock with illuminated display – Timer (up to 23 hours and 59 minutes) – Programme for automatic oven cooking – Programme for semi-automatic oven cooking. Description of the Buttons: Symbols... -
Page 11: Electronic Timer
Note: If the clock is reset it deletes any previously set programs. Normal Cooking without the Use of the Programmer To manually use the oven, that is, without the aid of the programmer, it is necessary to cancel the flashing AUTO by pushing the button (AUTO will be switched off and the symbol will go on - Fig. -
Page 12: Automatic Oven Cooking
3. Set the temperature and the cooking program by using the switch and thermostat knobs of the oven (see specific chapters). Now the oven is programmed and every thing will work automatically, that is the oven will turn on at the right moment to end the cooking at the established hour. -
Page 13: Semi - Automatic Cooking
Then set the temperature and the cooking program (see the relevant sections). The oven is switched on and it will switch off automatically at the end of the desired time. During cooking, the symbol remains on and by pressing the button remains until the end of the cooking. -
Page 14: Do's And Do Not's
– Do read the user instructions carefully before using the oven for first time. – Do allow the oven to heat for one and a half hours, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food. -
Page 15: Care And Maintenance
Inside of Oven The oven should always be cleaned after use when it has cooled down. The cavity should be cleaned using a mild detergent solution and warm water. Suitable proprietary chemical cleaners may be used after first consulting with the manufacturers recommendations and testing a small sample of the oven cavity. - Page 16 CAUTION: Do not store flammable material in the oven. CAUTION: Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
- Page 17 WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. – Let the oven cavity and the heating elements to cool down; – Switch off the electrical supply; – Unscrew the protective cover C (fig. 12);...
- Page 18 Assembling and Dismantling of the Side Runner Frames – Assemble the wire racks to the oven walls using the 2 screws (Fig. 13). – Slide the tray and rack into the runners (Fig. 14). The rack must be fitted so that the safety catch, which stops it sliding out, faces the inside of the oven.
-
Page 19: Oven Door
When removing and replacing the inner glass, the door should be held still by one person (fig. 15). A second person should gently remove the glass (fig. 17). To clean the inner pane of the oven door on both sides operate as follows: – Open the oven door. - Page 20 – Reassemble the seal G in the correct way (fig. 21) by hooking the no. 3 fixing hooks in the proper holes. Fig. 19 The oven door has a sealed gasket in the top part. It is normal the opened gap between the top edge of the inner glass and the sealed gasket.
-
Page 21: Advice For The Installer
• Always disconnect the appliance from the electrical supply before carrying out any maintenance operations or repairs. • The walls surrounding the oven must be made of heat-resistant material. • Taking care NOT to lift the oven by the door handle. - Page 22 60 cm. Installation requires a compartment as illustrated in figures 23 and 24. On the lover side, the oven must lay on supports standing the oven weight. Note: please consider the side opening of the door (either right of left hinged, dependent on model) when installing the oven.
- Page 23 To ensure internal ventilation, aeration channels must be provided as illustrated in the figures 25 and 26. 50 mm 30 mm Fig. 25 Fig. 26...
-
Page 24: Fixing The Oven
Fixing the Oven Introduce the oven into the furniture opening and fix it with screws (not supplied) as figure 27. It is essential that the oven rests on a surface which will support its weight, as the screw fixing is only complementary. - Page 25 – To avoid damage to the lower trim please note the following instructions. – The lower trim is designed to allow for good air circulation and the correct opening of the oven door. – To ensure the trim is not damaged due to the appliance being placed on the floor, the appliance should be suitably supported as in below illustrations.
-
Page 26: Mains Electricity Connection
Mains Electricity Connection Incorrect installation may be dangerous and the manufacturer can not be held responsible. Warning! This appliance must be earthed The manufacturer declines all responsibility for any problem caused by failure to observe this rule. THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 13A FUSE. - Page 27 Connection of the Power Supply Cable Unhook the terminal board cover by inserting a screwdriver into the two hooks “A” (fig. 30). Open the cable gland by unscrewing screw “F” (fig. 31), unscrew the terminal screws and remove the cable. The new supply cable, of suitable type and section, is connected to the terminal board following the diagram of fig.
-
Page 28: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1. - Page 29 After the first year and within five years, the parts will be supplied free of charge provided that the repair is carried out by an agent authorised by CDA and the labour will be charged at the commercial rate applicable at the time of repair.
- Page 32 Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
