- Page 1 User Manual SA100 Wireless Amplifier www.rakoso.com...
- Page 2 Contents SA100 x1 Power supply x1 RCA cable x2 ·...
-
Page 3: Interface And Functions
Interface and Functions 1. WiFi ANT: Antenna for WiFi connection 2. Reset: Short press once: switch input mode; Long press: Switch on/off; Short press twice: Re-pair Wifi or Bluetooth in Wifi or Bluetooth mode; Short press three times: Restore to factory settings *When device is off, just short press the power button to active the device 3. -
Page 4: How It Works
2.Place：Fix the amplifier at a safe and proper location. An integrated mounting bracket allows mounting to a wall or surface, but we suggest making sure you complete all installation steps before permanently mounting. 3.Connect：Speaker Wiring Diagrams (SA100 can handle speakers from 4-8ohms impedance) Speaker wire Diagram... -
Page 5: Download The App
Download the App Download the 4Stream application from the App Store for iOS and Google Play for Android. First time usage & BLE WiFi setup 1.Hold the RESET button then plug in the power cable. 2.The LED light will start flashing, release the button and wait till the LED flash slowly. 3.Make sure your mobile has connected to your home network using 2.4G and your GPS and Bluetooth is on. -
Page 6: Connection Via Lan
There is another way to setup Wifi if the above method has failed: 1.Hold the RESET button then plug in the power cable. 2.The LED light will start flashing, release the button and wait till the LED flash slowly. 3.Goto your mobile WiFi settings and search for SoundSystem_xxxx WiFi and connect. *If you cannot find SoundSystem connection, long press the RESET button for 5 secs and then refresh your mobile’s WiFi listing. - Page 7 4Stream Mobile Application: Playback After setup your device to your network, you will find it in the Device List in 4Stream APP . You can swipe to the left to select a music source, and play the music you select. In the playback screen you can play/pause the music, switch to the prev/next song and change the volume, you can also add the music to the favorite list or playback list.remo You also have the ability to combine zones so that each...
-
Page 8: Device Settings
Streaming from Mobile Phone/NAS/Online Music Services You can select local music from My Music tag, you can select songs form your mobile phone, if you have a NAS connected to the same network you will also find it here. In the middle is a list of online music services, at the bottom you will find Bluetooth, Line in, Optical in which are for you to switch to different source input mode. -
Page 9: Firmware Update
Firmware update SA100 will notify you in your app when there is a new firmware version available. It’s recommended to update firmware whenever available as this might not only correct bugs or improve security, but could also add new features or services. - Page 10 The information contained in this guide is believed to be accurate and reliable. RAKOSO assumes no responsibili- ty for any errors contained in this guide. RAKOSO reserves the rights to make changes in the specifications and/or design of the above mentioned product without prior notice. The diagrams contained in this guide may also not fully represent the product that you are using and they are for illustration purposed.
