GE Profile JGSP48WHWW Dimensions And Installation Information

TM
JGSP48BH/CH/WH – GE Profile
Dimensions (in inches) and Installation Information Dimensions (in inches) and Installation Information
24
31-1/4
2-7/8"
To Front
Surface Of
Countertop
20-5/8"
Door Clearance
From Front
Surface of
Countertop
27-1/2
44-3/4
Counter Cutout Dimensions (in inches)
If you are using the
If you are NOT using the
optional Filler or Backguard: optional Filler or Backguard:
23-3/16
30
Specification Revised 11/03
230124
™ 30" Slide-In Gas Range
Accessory
Backguard
30 Min .
4 Min.
From Walls
4
2"
(Grates)
30 Min .
23-3/16
36
Max. depth of
cord, plug,
receptacle box
& gas hookup
3-1/2 to prevent
36
interference
with drawer
3
15
29-15/16 Min.
30-1/16 Max.
25
30
You must use the rear filler strip kit shipped with the range or the
Shave Raised Edge To Clear
31-1/8 Wide Control Panel optional accessory backguard (JXS31, JXS32, JXS33, JXS34) when
installing these ranges.
9/16
Note: Cabinets installed adjacent to slide-in ranges must have an
adhesion spec of at least 194°F temperature rating.
Optional Kits for Slide-In Gas Ranges:
(Available at additional cost)
13 Max.
18 Min.
Lower/Side Trim Kits
JXS52BB—Lower Trim Kit (Black)
JXS53WW—Lower Trim Kit (White)
25
JXS55CC—Lower Trim Kit (Bisque)
Acceptable
Gas Line &
Electrical
Endcap Kit
Outlet Area
JXS40—Endcap kit to accommodate
7
replacement where countertop may
12
already be notched.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
