In the manual, the ™ or ® marks are not specified. Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user licence agreement.
Cushions formed by corrugated board used in packaging. Owner's record The serial number and model number are located on your Sony VAIO. Record the numbers and refer to them if you call VAIO-Link. See also the printed Specifications document. TAR Office Equipment Program is an international program that promotes energy saving through the use of NERGY TAR guidelines for energy efficiency.
Read this first Safety information General ❑ Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. ❑ Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee. ❑...
Make sure that the socket outlet is easily accessible. Regulatory information Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC (radio equipment and telecommunications terminal equipment Directive). Declaration of Conformity The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade.
Page 6
Disposing of the internal memory backup battery ❑ Your Sony VAIO is equipped with an internal back-up memory battery (motherboard battery) that should not have to be replaced during the lifetime of the product. If you want to replace the battery, please contact VAIO-Link: ❑...
Page 7
Read this first Disposing of the AA batteries The bundled remote control is powered by AA batteries. ❑ Do not handle damaged or leaking batteries. ❑ Dispose of promptly and properly at end-of-life. ❑ May explode or leak if recharged, disposed of in fire, mixed with other types of battery or improperly installed.
Page 8
Giga Pocket – Take advantage of the Giga Pocket technology, allowing you to watch TV and record your favourite programmes digitally and by remote control. ❑ Sony Memory Stick PRO slot – The next generation in digital storage allows you to easily transfer images, sounds, data and text between cameras, computers, and more. ❑...
Page 9
A Guide to Troubleshooting / Using the VAIO Recovery and Documentation Disc, where you will find solutions to common problems, an explanation of the purpose and use of the VAIO disc delivered with your computer, and VAIO-Link information; ❑ Your Sony Guarantee conditions; ❑ A Safety Regulations booklet; ❑...
Page 10
The Giga Pocket manual explains how to watch and record TV and video on your PC. My Documentation also gives you: ❑ A direct link to the VAIO-Link website, Sony’s service centre. This will give you troubleshooting hints, downloads, contact details, and everything else you need for the smooth operation of your VAIO. ❑...
Welcome Ergonomic considerations Whenever possible, try and take into account the following ergonomic considerations when using your new computer, whether at home or in the office:...
Page 12
Welcome ❑ Position of the keyboard and mouse – Make sure the keyboard is directly in front of you. Keep your forearms horizontal, with your wrists in a neutral, comfortable position (1) while using the keyboard or mouse – not at an angle. Let your upper arms hang naturally at your sides. Place the mouse at the same level as the keyboard and use your whole arm to move it.
Using your VAIO Using your VAIO Once you have read and followed the information in the printed Getting Started guide and Specifications sheet, you can start using your computer safely and confidently. Read on to get the most out of using your VAIO computer. ❑...
Using your VAIO Shutting down your computer safely It is important that you shut down your computer properly so you do not lose unsaved data. To shut down your computer, proceed as follows: Turn off any peripherals connected to your computer. Click the Start button.
Using your VAIO Your VAIO as a multimedia system The unique advantage of your VAIO is the way it transforms smoothly from one home entertainment unit into the next. Much more than a computer, you can use this unit in your living room as a TV, sound system and digital photo album in one.
Page 16
Using your VAIO Computer mode If you want to work on your VAIO as a desktop computer, fold down the keyboard fully, as shown. Position yourself in front of the computer as described in Ergonomic considerations (page 10).
Page 17
Using your VAIO Audio mode When you want to listen to music on your VAIO and are not using the keyboard or the display, fold the keyboard up to cover the screen, as shown. As soon as you lift the keyboard up, the visible part of the screen shows the time and date. You can also choose an effect and a background colour (use the options in the top right-hand corner).
Page 18
Using your VAIO TV / video / photo viewing mode When you want to use the screen on your VAIO, the keyboard can be neatly stowed away so the front panel buttons can be used without covering the screen. The front panel gives you additional TV, channel, and volume control buttons and is equipped with built-in stereo speakers and indicator lights.
Page 19
Using your VAIO To view your photos in slideshow format, use VAIO Media together with the remote control. Use WinDVD for VAIO and the remote control to enjoy DVD movies on your VAIO.
Using your VAIO Using the keyboard Your VAIO has a built-in keyboard. The features are much the same a standard keyboard, with some additional functions which you may be unfamiliar with. For more information on the standard keys, please go to the Windows Help and Support Center. The VAIO-Link website (www.vaio-link.com) also contains glossary information to help you use the keyboard.
Using your VAIO Using the shortcut keys Press a shortcut key (<S> Key) on the left side of your keyboard to start your favourite software, without having to follow a path on the computer. If you so wish, you can use VAIO Action Setup to change the functions of the <S> Keys. All six buttons are reprogrammable.
Export your video capsules to MPEG2, MPEG1 and (DVI) AVI-files; ✍ Sony cannot guarantee the streaming of recorded content if it is beyond a certain level of high quality. For details on using Giga Pocket and the remote control, please see the dedicated online guide...
Using your VAIO Using the mouse Your computer is delivered with a VAIO USB optical mouse, which uses a light-emitting diode (LED) instead of a ball. Avoid using the mouse on a piece of glass or other transparent material, as this can interfere with smooth cursor movement on the screen.
Page 24
Using your VAIO Setting up the mouse for left-handed users To set your mouse up for left-handed users, proceed as follows: Go to Start, select Control Panel, then click the Printers and Other Hardware option. Click the mouse icon. The Mouse Properties dialog box appears. In the Buttons tab, select the option button next to Switch primary and secondary buttons.
Using your VAIO Using the disc drive Your computer is equipped with a DVD±RW drive, which reads data from a compatible CD or DVD and writes data to a DVD-RW, DVD+RW, DVD-R, DVD+R, CD-RW, or CD-R. To insert a disc, proceed as follows: Turn on the computer.
Page 26
Using your VAIO Place a disc in the tray with the label side facing outwards. Make sure the disc is secure in the centre of the tray. Close the tray by pushing it gently. ✍ See the printed Troubleshooting Guide if you have problems using discs.
Page 27
Using your VAIO Reading and writing CDs and DVDs To achieve optimum performance when writing data on to disc (also called ’burning’), follow these recommendations: ❑ Only use circular discs. Do not use discs with any other shape (star, heart, card, etc.), as this may damage the disc drive.
Page 28
Using your VAIO Playing DVDs To achieve optimum performance when playing DVDs, you should follow these recommendations: ❑ Close all open applications before playing a DVD movie. ❑ You can play DVDs with the software WinDVD for VAIO. ❑ Do not switch power saving modes while playing a DVD. ❑...
Using your VAIO Using the modem Your VAIO is equipped with an internal modem. As described in the printed Getting Started guide, use the single RJ-11 jack to connect the supplied modem cable to the phone line. Once you have connected the phone line and registered with an Internet Service Provider, you can take advantage of online services and the Internet, to register your computer and software online, and to contact VAIO-Link.
Using your VAIO Using power modes The colour of the power indicator light at the top of the display tells you which mode the computer is in. Power indicator Green Amber No light ✍ Please see the printed Specifications sheet for the exact location of the indicators. To set the timer for your computer to automatically enter Standby or Hibernate mode after a certain amount of time, go to Control Panel, click Performance and Maintenance and change the settings under Power Schemes.
Using your VAIO Using Standby mode If you plan to stop using your computer for a short period of time (not overnight), you can put it into Standby mode instead of turning it off completely. Putting the computer into Standby mode saves energy and allows a quick return to normal computer use.
Using your VAIO Using Hibernate mode If you are interrupted and need to leave your computer suddenly, you can put it into Hibernate mode. This power saving mode saves you the time of shutting down in the normal way. When you put your computer into Hibernate mode: ❑...
Please see your printed Specifications sheet to see which Memory Stick types are compatible with your VAIO and if there are any limitations. ❑ You can purchase Memory Sticks from the Sony Style website (www.sonystyle-europe.com), or from your local Sony dealer. ❑...
Page 34
Using your VAIO Inserting a Memory Stick To insert a Memory Stick, proceed as follows: Locate the Memory Stick slot on the left-hand side of the display. Hold the Memory Stick with the connectors pointing towards the back and push it in until it clicks. The Memory Stick is automatically detected by your system and appears in the My Computer window with its own drive.
Page 35
Using your VAIO Removing a Memory Stick To remove a Memory Stick, proceed as follows: Make sure the indicator light is not on. Push the Memory Stick in to release it, and then pull it out. ✍ Always remove the Memory Stick gently, or it may pop out unexpectedly. You are recommended to remove the Memory Stick before shutting down the computer.
Page 36
Using your VAIO Write-protecting cards Memory Sticks are designed with an erasure prevention switch to protect valuable data from accidental erasure or overwriting. Move the tab to the right or left to set or release write-protection. (On the 128 MB Memory Stick, move the tab up or down.) When the erasure prevention switch is off, data can be saved on the Memory Stick.
Using your VAIO Using PC Cards Your VAIO has a PC Card slot on the side panel that supports Type I or Type II PC Cards. PC Cards allow you to interconnect with portable external devices.
Using your VAIO Inserting a PC Card Insert the PC Card gently into the PC Card slot with the label facing towards you. The PC Card is automatically detected by your system and the Safely Remove Hardware in the taskbar. ✍...
Page 39
Using your VAIO Removing a PC Card Follow the steps below to remove the PC Card while your computer is on. If it is not removed properly, your system may crash and unsaved data may be lost. If you want to remove a PC Card when your computer is off, skip steps 1 to 5.
❑ To identify and locate the ports on your computer, please see the printed Specifications sheet. ❑ Sony computer supplies, accessories and peripherals can be purchased from your local retailer or from the Sony website: ❑ For more information about connection compatibility, go to the VAIO-Link website:...
Connecting peripheral devices Connecting a Universal Serial Bus (USB) device You can connect a USB device such as a scanner, a floppy disk drive or a printer, to your VAIO. To connect a USB device, simply plug in the USB cable of the device into one of the ports on your computer.
Page 42
Connecting peripheral devices Connecting a USB printer USB printer drivers should be automatically installed although some printers do not function properly without updated drivers. You can check the printer manufacturer’s website for the latest drivers for Windows XP before installing your printer.
Page 43
❑ The i.LINK device will need its own power supply. ❑ You are strongly advised to use only Sony i.LINK cables, as using other brands may cause problems with the i.LINK devices. ❑ The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
✍ The Sony digital video camera recorder is an example; your digital video camera recorder may need to be connected differently. If your digital video camera recorder includes a Memory Stick slot, you can use it to copy images from the camera to your computer. To do so, simply copy images on the Memory Stick, and then insert it into the Memory Stick slot of your computer.
Connecting an S/PDIF device The S/PDIF (Sony/Philips Digital Interface) port on your computer allows you to transfer audio files to optical devices. The advantage is that is does not use the conversion to and from an analog format, which could degrade the signal quality.
Connecting peripheral devices Connecting to a network Your computer comes with a built-in Ethernet interface. To connect to a network, proceed as follows: Connect your 10BASE-T/100BASE-TX Ethernet cable (not supplied) to the Ethernet port right-hand side of the computer. If there is a sticker covering the Ethernet port, this is to remind customers in Germany not to insert an ISDN cable (see caution below).
Page 47
Connecting peripheral devices Connect only 10BASE-T/100BASE-TX cables to the Ethernet port. Using other cables or a telephone cable may cause a malfunction, excessive heat or even fire in the port. If using this computer in Germany, please make sure you do not use an ISDN cable. It is physically very similar, but its higher voltage of 12V may destroy the motherboard inside the computer.
Page 48
Upgrading your VAIO computer Upgrading your VAIO Sony recommends contacting your local dealer for upgrade or maintenance of your new computer. Your local dealer has knowledge of this specialised personal computer and familiar with the safety practices and regulatory compliance required for using and modifying electronic equipment.
Upgrading your VAIO computer Upgrading memory In the future you may want to upgrade the memory installed on your VAIO by replacing / adding memory modules. However, we recommend that you do not install them yourself unless you are familiar with upgrading memory on a computer.
Page 50
Upgrading your VAIO computer Adding / replacing a memory module If you are not familiar with upgrading memory on a computer, we highly recommend that you contact your dealer. To add or change a memory module, proceed as follows: Shut down the computer, unplug it, remove any peripheral devices and wait for the computer to cool down.
Page 51
Upgrading your VAIO computer With the release button pressed, slide the cover to the right and lift away from the system unit. To remove an existing memory module, locate the memory module you want to remove. Push out on the latches, located on both sides of the module, to gently eject it from the slot.
Page 52
Upgrading your VAIO computer Hold the module by the sides and store it in a static-free bag. To insert a new memory module, remove the memory module from its anti-static package, handling it by the edges. Locate the notch on the bottom edge of the module and align the module to the open memory module slot.
Page 53
Upgrading your VAIO computer Viewing the amount of memory To view the amount of memory, proceed as follows: Turn on the computer. Click the Start button, point to All Programs, then VAIO System Information, and click VAIO System Information again. You can view the amount of installed memory here.
Getting help Getting help This section describes how to get help and support if something goes wrong with your computer. Sony offers you many support options for your computer. Sony documentation Please see the section Documentation pack delivered with your computer, as well as further sources of reference.
Page 55
Getting help e-Support What is e-Support? You have searched our user guides and website (www.vaio-link.com) but have not found an answer to your question/issue? e-Support is the ideal solution for you! Our e-Support Web Portal is an interactive website on which you can submit any technical query you may have regarding your VAIO and receive answers from our dedicated support team.
Page 56
Getting help Can I submit questions in my native language? Since you are interacting with our e-Support Team through a portal, which connects you directly to our central database, e-Support will only accept and deal with queries submitted in English. Can I submit my questions at any time? Yes, you can submit your questions 24/7, but please keep in mind that our e-Support Team can only treat your queries from Monday till Friday between 8am and 6pm.
Page 57
Precautions Precautions This section describes safety guidelines and precautions to help you protect your computer from potential damage. Please contact VAIO-Link if you need assistance. ❑ On handling the hard disk ❑ On using the power source ❑ On handling your computer ❑...
Precautions On handling the hard disk The hard disk has a high storage density and reads or writes data in a short time. However, it can be easily damaged by mechanical vibration, shock or dust. Although the hard disk has the internal safety device to prevent losing data due to mechanical vibration, shock or dust, you should be careful when handling your computer.
Precautions On using the power source ❑ See the printed Specifications sheet to check the power operation of your VAIO. ❑ Do not share the AC outlet with other high power-consuming equipment, such as a photocopier or shredder. ❑ You can purchase a power strip with a surge protector. This device prevents damage to your computer caused by sudden power surges, in an electrical storm, for example.
Precautions On handling your computer ❑ Clean the unit with a soft cloth, which is either dry or lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine, as these may damage the finish of your computer.
Precautions ❑ Do not use cut or damaged connection cables. ❑ If the computer is brought directly from a cold location to a warm one, moisture may condense inside your computer. In this case, allow at least one hour before turning on your computer. If any problems occur, unplug your computer and contact VAIO-Link.
Precautions On handling compact discs ❑ Do not touch the surface of the disc. ❑ Do not drop or bend the disc. ❑ Fingerprints and dust on the surface of a disc may cause reading errors. Always hold the disc by its edge and central hole, as shown.
Precautions On handling Memory Sticks ❑ Do not touch the Memory Stick connector with your finger or metallic objects. ❑ Use only the label supplied with the Memory Stick as a label. ❑ Do not bend, drop, or apply heavy shock to the Memory Stick. ❑...
Page 64
Microsoft Works and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the U.S. and other countries. i.LINK is a trademark of Sony used only to designate that a product contains an IEEE1394 connection. Adobe, Adobe Acrobat Elements, Adobe Photoshop Album, Adobe Reader, Adobe Premiere and Adobe Photoshop Elements are trademarks of Adobe Systems Incorporated.
