- Page 1 Si06-762 REMOVAL PROCEDURE S E R V I C E M A N U A L 5.6 kW Class Indoor Unit Inverter Floor Standing Type...
- Page 2 Service Manual Removal Procedure Indoor Unit Heat Pump FVXD56FV2C...
-
Page 3: Table Of Contents
Si06-762 Table of Contents 1. Removal of Air filter.................2 2. Removal of Suction Grille................4 3. Removal of Power Supply / Control PCB..........6 4. Removal of Piping Fixture ..............10 5. Removal of Electrical Box ..............11 6. Removal of Fan Rotor / Fan Motor............13 7. -
Page 4: Removal Of Air Filter
Removal of Air filter Si06-762 1. Removal of Air filter Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Features Fixing Screws Display Vertical Blades Air Outlet Horizontal Blades (Inside) - Page 5 Si06-762 Removal of Air filter Step Procedure Points 2. Remove the air filter. Warning : Put your fingers on the Make sure the horizontal blades right and left air inlets, are closed. Otherwise the air and open the suction filter cannot be pulled out. grille.
-
Page 6: Removal Of Suction Grille
Removal of Suction Grille Si06-762 2. Removal of Suction Grille Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the suction grille. Open the suction grille and remove the 2 screws (one each on the right and left). - Page 7 Si06-762 Removal of Suction Grille Step Procedure Points Tilt the suction grille toward yourself first and then lift it out of position. (Undo the 2 claws at the bottom of the suction grille.) (R2443) When placing the suction grille back in position, fit the claws at the bottom first.
-
Page 8: Removal Of Power Supply / Control Pcb
Removal of Power Supply / Control PCB Si06-762 3. Removal of Power Supply / Control PCB Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the power supply/ Screws control PCB. - Page 9 Si06-762 Removal of Power Supply / Control PCB Step Procedure Points Disconnect the connector for fan motor (S1). (R2448) Disconnect the connectors (S21, S35). (R2449) Disconnect the connectors (S26, S28) and the connector for heat exchanger thermistor (S32). (R2450) Disconnect the Connector connectors for swing S6 : White...
- Page 10 Removal of Power Supply / Control PCB Si06-762 Step Procedure Points Disconnect the connector for thermal Terminal Strip Board fuse. with Thermal Fuse (R2451) Disconnect the terminal strip for power supply (upper row). 3 : Transmission 1 : Power Supply 2 : Power Supply (Brown) (Blue)
- Page 11 Si06-762 Removal of Power Supply / Control PCB Step Procedure Points Release the room temperature thermistor. Room Temperature (Unlock the fixing Thermistor holder.) Fixing Holder (R2454) Pull the 3 PCB spacers Preferably use long-nose out of the power supply / pliers to easily draw out the control PCB.
-
Page 12: Removal Of Piping Fixture
Removal of Piping Fixture Si06-762 4. Removal of Piping Fixture Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Detach the piping fixture. Remove the suction grille. Remove the screw and detach the piping fixture. -
Page 13: Removal Of Electrical Box
Si06-762 Removal of Electrical Box 5. Removal of Electrical Box Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the electrical box. Remove the electrical box Earth Terminal cover. - Page 14 Removal of Electrical Box Si06-762 Step Procedure Points Remove the 2 fixing screws off the electrical Fixing Screws (2) box. (R2463) Pull out the electrical box toward yourself. (R2464) Removal Procedure...
-
Page 15: Removal Of Fan Rotor / Fan Motor
Si06-762 Removal of Fan Rotor / Fan Motor 6. Removal of Fan Rotor / Fan Motor Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Detach the fan rotor. Remove the suction grille, electrical box and piping fixture. -
Page 16: Removal Of Front Panel
Removal of Front Panel Si06-762 7. Removal of Front Panel Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Detach the front panel. The front panel is hooked by 3 claws each on the right Remove the 6 screws and left. -
Page 17: Removal Of Display Pcb
Si06-762 Removal of Display PCB 8. Removal of Display PCB Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the display PCB. Take out the display PCB from behind the front panel. - Page 18 Removal of Display PCB Si06-762 Step Procedure Points Undo the 4 claws (2 The display case has the from the braid and 2 cover, braid and display Cover from the cover), and PCB integrated. Display PCB Claws (Cover) draw out the display <View from A >...
-
Page 19: Removal Of Heat Exchanger
Si06-762 Removal of Heat Exchanger 9. Removal of Heat Exchanger Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Detach the heat Fin Guard Heat Exchanger exchanger. - Page 20 Revision History Month / Year Version Revised contents 07 / 2013 Si06-762 First edition...
- Page 21 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
