- Page 1 Si241306 REMOVAL PROCEDURE S E R V I C E M A N U A L 3/4/5 HP Class Indoor Unit Non-Inverter Floor Standing Type...
- Page 2 Service Manual Removal Procedure Indoor Unit Applicable Models Cooling Only FV125LAVE Heat Pump FVY71LAVE FVY100LAVE FVY125LAVE...
-
Page 3: Table Of Contents
Si241306 Table of Contents 1. Procedure to Remove Suction Grille and Air Filter .........2 2. Procedure to Remove Electric Parts and Remote Controller....4 3. Procedure to Remove Fan Rotor and Fan Motor........6 4. Procedure to Remove Swing Motor ............7 5. Procedure to Remove Heat Exchanger ..........8 Removal Procedure... -
Page 4: Procedure To Remove Suction Grille And Air Filter
Procedure to Remove Suction Grille and Air Filter Si241306 1. Procedure to Remove Suction Grille and Air Filter Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Removing air filter Pull tabs of suction... - Page 5 Si241306 Procedure to Remove Suction Grille and Air Filter Step Procedure Points Removing suction grille Remove 2 fixing screws located at both left and Screws right sides of suction grille. Open widely and lift suction grille to remove Suction grille stopper Removal Procedure...
-
Page 6: Procedure To Remove Electric Parts And Remote Controller
Procedure to Remove Electric Parts and Remote Controller Si241306 2. Procedure to Remove Electric Parts and Remote Controller Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points To remove switch box cover, dismount screw... - Page 7 Si241306 Procedure to Remove Electric Parts and Remote Controller Step Procedure Points Remove 2 screws to dismount front panel. Remove 4 screws to dismount remote controller. Remote controller Remote controller fixing plate Remote controller cord Remote controller cover Hooks Removal Procedure...
-
Page 8: Procedure To Remove Fan Rotor And Fan Motor
Procedure to Remove Fan Rotor and Fan Motor Si241306 3. Procedure to Remove Fan Rotor and Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Removing fan rotor Turn bell mouth in CW... -
Page 9: Procedure To Remove Swing Motor
Si241306 Procedure to Remove Swing Motor 4. Procedure to Remove Swing Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Disconnect harness for swing motor and 1 for limit switch at connector section. -
Page 10: Procedure To Remove Heat Exchanger
Procedure to Remove Heat Exchanger Si241306 5. Procedure to Remove Heat Exchanger Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Removing switch box Disconnect connector for swing motor and 1 for limit switch. - Page 11 Revision History Month / Year Version Revised contents 01 / 2013 Si241306 First edition...
- Page 12 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
