Cleaning Spray Arms - Bosch SGV2ITX22E User Manual

Pull the micro sieve downwards.
3.
Press the locking pieces together
4.
and remove the coarse sieve
remove upwards .
1
Clean the sieve elements under
5.
running water.
Carefully clean the dirt edge
between the coarse and fine sieve.
Assemble the screening system.
6.
Check whether the locking lugs of
the coarse sieve are engaged.
Insert the sieve system into the
7.
device and turn the coarse sieve
clockwise.
Check that the arrow marks are
opposite each other.

Cleaning spray arms

Limescale and impurities in the wash
water can block the nozzles and
bearings of the spray arms. Clean the
spray arms regularly.
Unscrew the upper spray arm and
1.
pull it downwards
.
2
Pull the lower spray arm upwards.
2.
Check the nozzles of the spray arms
3.
for blockages under running water
and remove any foreign objects.
Install the lower spray arm.
4.
a The spray arm audibly clicks into place.
Fit and screw on the upper spray
5.
arm.
Cleaning and maintenance NL
1
2
37
