INSTALLATION GUIDE
Bolt
Metal Nut
Install the Toilet Seat
Remove the existing toilet seat and mounting hardware.
If necessary, clean the toilet surface.
Use a finger to lift each hinge cover.
Align the two bolts with the toilet seat mounting holes.
Thread a nut onto each of the bolts as shown.
Verify that the seat is properly positioned.
Using a flat-blade screwdriver and an adjustable wrench, tighten the nuts.
Do not overtighten.
Close the hinge covers.
X product numbers are for Thailand (i.e. K-12345X)
Kohler.com
Hinge Cover
Seat
Toilet Seat
Mounting Holes
K-4195, K-4636, K-4639,
Nut
TOILET SEAT
K-4713, K-4732
1035808-X2-B
Advertisement
Related Manuals for Kohler K-4195
Summary of Contents for Kohler K-4195
- Page 1 TOILET SEAT K-4195, K-4636, K-4639, K-4713, K-4732 INSTALLATION GUIDE Bolt Hinge Cover Seat Metal Nut Toilet Seat Mounting Holes Install the Toilet Seat Remove the existing toilet seat and mounting hardware. If necessary, clean the toilet surface. Use a finger to lift each hinge cover. Align the two bolts with the toilet seat mounting holes. Thread a nut onto each of the bolts as shown. Verify that the seat is properly positioned. Using a flat-blade screwdriver and an adjustable wrench, tighten the nuts. Do not overtighten. Close the hinge covers. X product numbers are for Thailand (i.e. K-12345X) Kohler.com 1035808-X2-B...
- Page 2 Operating the Toilet Seat Your Kohler toilet seat is designed to close slowly when the seat is dropped. Always close the seat cover after use to extend the life time of the seat. The toilet seat also has an easy-to-clean, quick-release hinge that allows the toilet seat to be quickly removed for complete cleaning. The hinge covers are easily lifted using a fingertip. If room is tight, push the toilet seat back to ease the hinge cover operation. Once the hinge covers are lifted, pull the toilet seat forward leaving the mounting hardware in place. After cleaning, simply push the toilet seat back into place on the mounting hardware and close the hinge covers. Care and Cleaning The toilet seat may be completely removed for a complete cleaning, refer to the “Operation” section. Clean the outside surface of your toilet seat with mild soap, such as liquid dish soap and warm water. Wipe the entire surface completely dry with a clean soft cloth. Do not use any abrasive cleaners, as they will scratch and dull the surface. Avoid any detergents, disinfectants, or cleaning products in aerosol cans. Avoid contact with abrasive chemicals and cosmetics,...
- Page 3 คู ่ ม ื อ การติ ด ตั ้ ง ฝารองนั ่ ง สุ ข ภั ณ ฑ์ K-4195, K-4636, K-4639, K-4713, K-4732 วิ ธ ี ก ารติ ด ตั ้ ง ฝารองนั ่ ง สุ ข ภั ณ ฑ์ ถอดฝารองนั ่ ง สุ ข ภั ณ ฑ์ แ ละอุ ป กรณ์ ย ึ ด ชุ ด เก่ า ออกจากสุ ข ภั ณ ฑ์...
- Page 4 กั ด ผิ ว และเครื ่ อ งสำ า อางค์ บ างชนิ ด เช่ น นำ ้ า ยาล้ า งเล็ บ หรื อ นำ ้ า ยาโกนหนวด เพราะอาจทำ า ให้ พ ื ้ น ผิ ว ฝารองนั ่ ง สุ ข ภั ณ ฑ์ เ สี ย หายได้ ฝ่ า ยลู ก ค้ า สั ม พั น ธ์ 0-2204-6222 Call Center : +(66) 2204-6222 callcenterthailand@kohler.com Kohler.com 1035808-X2-B...
