TCL LED40D3260FD-MT10B-LA Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ED40D3260FD-MT10B-LA

Advertisement

Table of Contents
loading

Related Manuals for TCL LED40D3260FD-MT10B-LA

Summary of Contents for TCL LED40D3260FD-MT10B-LA

  • Page 1 ED40D3260FD-MT10B-LA...
  • Page 2 SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
  • Page 3 SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
  • Page 4 SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
  • Page 5 SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
  • Page 6 EM BUSINESS CENTER FTV PRODUCT PLANNING DEPT. SPECIFICATION RELEASE Version: V0.1 Issued Date: 2011.06.02 Model: L40D3260/MT10B-LA/SS4 PICTURE Panel Size (inch) Category LCD TV(LED BACK LIGHT) Aspect Ratio 16:9 Color Temperature Warm / Standard / Cold SIGNAL FORMAT CAPABILITY Y,Pb/Cb,Pr/Cr:up to 720p,1080i,1080p @50Hz/60Hz Backlight Adjustable Component Video Format Scaler Mode...
  • Page 7 Power supply USB1 USB2 Audio Amp. Panel Head phone DDR3 T90517 DDR3 LVDS MT5310 DEMO IP/GPIO FLASH Flash HDMI RECEIVER 64Mbit CVBS DECODER 3D COMB FILTER MPEG4 DECODER Serial TS in SCALER Audio TMDS YPbPr 4052 HDMI1 IF+/- HDMI 1.3 HDMI2 SWITCH 3 IN 1...
  • Page 8 Factory Alignment Specification of normal SIACP TCL WW R&D FPD CENTER Factory Alignment Specification of normal SIACP For MT10-LA Version 1.0 PREPARED BY : DATE : 2011-4-22 APPROVED BY : DATE : Page 1 of 12...

  • Page 9: Table Of Contents

    Factory Alignment Specification of normal SIACP Table of Contents Feature Specification ............................4 INFO..................................5 1.Electrical Assembly Alignment ........................5 1.1 Preconditions – DC/DC Check........................5 1.2 SW download ..............................5 1.3 Panel ID check and modify ........................... 6 1.4 Functional Test .............................. 6 1.5 DDC &...
  • Page 10 Factory Alignment Specification of normal SIACP Disclosure The information contained in this document is proprietary to TCL SZ FPD lab and shall not be disclosed by the recipient to third persons without the written permission of the team leader or GM of R&D.

  • Page 11: Feature Specification

    Factory Alignment Specification of normal SIACP Feature Specification These chassises are designed for South America LCD TV. The main chip is from Mediatec (MT5310 series) and supports below inputs and outputs: class item Status MT10B-LA MT10L-LA Cable&Antenna Cable&Antenna ( PAL- M/N, NTSC-M) Antenna Antenna (SBTVD-T)

  • Page 12: Info

    Factory Alignment Specification of normal SIACP INFO All tests and measurements mentioned hereafter have to be carried out at a normal mains voltage (220 ~ 240 VAC) All voltages have to be measured with respect to ground, unless otherwise stated All final tests have to be done on a complete set including LCD panel in a room with temperature of 25+/-7°C The White Balance (color temperature) has to be performed into subdued lighted room after at...

  • Page 13: Panel Id Check And Modify

    Factory Alignment Specification of normal SIACP upgrade FLASH SW from USB”. Remenber to do “Reset all” after upgrade the SW. 1.3 Project ID check and modify There is different ID stored in the NVM depended on different Panels. Modify it with Hyper terminal if the initial ID or a wrong ID make the set can not display clearly.

  • Page 14: Hdcp Test

    Factory Alignment Specification of normal SIACP 1.6 HDCP Test For HDCP compliancy, it’s needed to check whether the HDCP key has been well set. 2.Final Assembly Alignment 2.1 FactoryMenu Follow the below steps to pop-up the Factory Menu in case of “FactoryKey” is disable : - press RemoteControl key “MENU”...

  • Page 15: High Pot. And Insulating Resistance Tests

    Factory Alignment Specification of normal SIACP Each panel has it’s own colour coordinates, Please refer to the following table. L32V6200/L32E5200 L42E5200F/L42V6200F C32E320/L32P60 C42E320F/L42P60F Normal 0.275 0.310 0.275 0.290 0.280 0.290 0.280 0.290 Cool 0.265 0.285 0.265 0.290 0.270 0.280 0.270 0.280 Warm 0.305...
  • Page 16 Factory Alignment Specification of normal SIACP Item Sub-item Value/Sub-item Note Burning Off/On Select panel On with left/right Mode key, Press “EXIT” key to enter the burning mode; Press “Menu” key on keyboard to exit the burning mode ADC Need not to do ADC when alignment White Balance Item Sub-item...
  • Page 17 Factory Alignment Specification of normal SIACP Reset ALL Item Sub-item Value Note Reset Clear NVM values and set to default value Power Mode Item Sub-item Value Note Power Boot/Standby/ Boot: Enter power on mode Mode Last Status Standby: Enter standby mode Last Status: power on according to last status USB Clone Mode...

  • Page 18: Appendix "How To Download Flash Sw

    Factory Alignment Specification of normal SIACP Appendix “How to download FLASH SW” Prepare MTK SW tool for update. 1. Connect the PC to the serial connector on board using a special serial device (USB or COMx). 2. Provide the a correct voltage to the board 3.

  • Page 19: Appendix "Modify Panel Id With Rc

    Factory Alignment Specification of normal SIACP try again. Upgrade without loader(The TV set should be able to display normally): 1. Save the new software file(*.pkg) in the root directory of USB, and modify it’s name as a software number, such as “V8-0MT1006-LF1V017.pkg”. 2.
  • Page 20 Back Light circuit 3V3SB R142 HI = > POWER_OFF L118 LO = > POWER_ON 600R R140 PAN_ON/OFF +24V MAIN_POWER R141 ADIN3_SRV Q102 R143 MAIN_POWER BT3904 GND_P1 ON/OFF_PWR DIMMING PANEL_DIM ON/OFF_PWR PANEL_DIM PAN_ON/OFF DVDD3V3 P100 PAN_ON/OFF STB_POWER R131 GND_P2 NC/3K3 3V3SB STB_POWER D110 R132...
  • Page 21 TU200 TU201 DEMOD BD CONNECTOR for ATSC Z226 Z227 P201 P200 DEMO_DATA7 DEMO_DATA6 DEMO_DATA5 TUNER_SCL D_IF_AGC DEMO_DATA4 DEMO_DATA3 TUNER_SDA T1_VCC DEMO_DATA2 DEMO_DATA1 DEMO_DATA0 DEMOD_FAT- DEMO_POWERDOWN DEMO_VALID DEMO_CLK DEMOD_FAT+ DEMO_SYNC AVDD3V3 DEMOD_RESET FAT- R_AGC FAT+ OSCL0 OSDA0 T_SCL T_SDA T_VCC TUNER_VCC DEMOD_RST R215 DEMOD_RESET...
  • Page 22 P300 P301 P302 RX3B2P RX2+ RX2B2P RX1B2P RX2+ GND1 RX2+ GND1 GND1 RX3B2N RX2- RX1B2N RX2B2N RX2- RX3B1P RX1+ RX2- RX2B1P RX1+ RX1B1P RX1+ GND2 GND2 RX3B1N RX1- GND2 RX2B1N RX1- RX1B1N RX1- RX3B0P RX0+ RX2B0P RX1B0P RX0+ GND3 RX0+ GND3 RX3B0N GND3...
  • Page 23 close to YPbPr connector close to MT5310 3V3SB YPBPR1 IN C450 Z430 R478 1500P SOY1 MNT-HOLE2 USB PORT 0 MNT-HOLE1 3V3SB UART OUT C449 R439 U0RXD Y_IN_1 L413 R482 0.01U R480 R479 GND-1 Y1_IN P404 Y1_IN 100R R473 USB_DP0 PR_IN_1 DPOS-1 GREEN USB_DM0...
  • Page 24 MT10L_RF_AGC A_RF_AGC AVDD3V3 R512 AVDD33_DAC R515 R521 OSCL0 SCL0 C559 C564 strapping opctrl5 opctrl4 AOSDATA1 0.1U R533 0.047U OSDA0 SDA0 A_IF_AGC MT10L_IF_AGC ICE mode+27M+serial boot ROM boot+27M C516 R520 C560 ICE mode+54M+serial boot C515 0.047U ROM boot+54M VMID_AADC FLASH CI_TS IN AUDIO STRAPPING C513...
  • Page 25 CI_VCC R600 CI_DV33 NC/0R CI_VCC AVDD1V2 CI_AV12 C624 U601 L606 VCCK CI_DV10 NC/0.1U NC/60R L600 NC/600R L603 NC/600R ILIM CI_DV33 C610 C640 R618 C625 C626 NC/0.1U NC/0.1U CI_GPIO9 NC/100R C613 C639 C603 NC/0.1U NC/0.1U FAULT C642 C641 NC/0.1U NC/0.1U NC/0.1U NC/TPS2550 NC/10U NC/0.1U...
  • Page 26 3V3SB RESET circuit R781 RESET_24V NC/4K7 R745 2.9V(12V) R751 BT3906 Q705 Serial Flash C726 Z722 BT3904 R750 BT3906 Q703 OPCTRL0 Q704 DVDD3V3 2.1V(9V) R743 ORESET# 2.7V R799 POOE#_F PDD6_F C728 VCC_FLASH HOLD#_F 0.1U L700 U700 VCC_FLASH 600R POOE# HOLD DVDD3V3 C715 VCC_FLASH PDD6...
  • Page 27 DIGITAL TAS5707 AMP R864 R990 NC/0R NC/0R R892 MAIN_POWER R989 AMP_VCC NC/0R NC/0R R893 DVDD3V3 NC/0R L804 VALUE L810 C809 C851 C805 0.1U AVSS C879 2200P L811 220R R878 AMCLK AOMCLK C862 1U L816 220R R879 R845 ABCLK AOBCLK C854 470R C850 0.047U...
  • Page 28 LVDS OUT L912 LVDS POWER EXC24C P902 C922 NC/10P TX_AO0N LVDSTX_AO0N C923 NC/10P LVDSTX_AO0P TX_AO0P LVDSTX_AO0P LVDSTX_AO0N L915 L901 NC/200R LVDSTX_AO1P EXC24C LVDSTX_AO1N C920 NC/10P LVDSTX_AO1N TX_AO1N L916 VBR_EXT LVDSTX_AO2P LVDSTX_AO2N PANEL_DIM C921 NC/10P LVDSTX_AO1P NC/200R TX_AO1P Z918 LVDSVCC LVDSTX_AOCKP LVDSTX_AOCKN L902 LVDS OUT...
  • Page 33 1 Have no anything, No backlight/No Video/No Audio etc... Can not Power On +3V3_STB(P100 Check AC input and Pin7) is OK? P100 ON/OFF PIN1,2,4=24V is POWER (P100 Check PSU OK?(+24V) PIN 10)is >2V? Remote Power On Check IR net is CHECK STB LEVER Check IR net IF CHANGE(R156) ?
  • Page 34 2 Only Backlight, No Video Reset the TV set LVDS 1 Check the Q900 and Q901 is Working. Power(P902 PIN 2 Check the LVDS cable connect normally. 1) is 12V ? The P902 Check LVDS PIN13,31 clock is Check the U500 working normally. cable.
  • Page 35 3 Picture is normal, but speaker no Audio Have picture, no audio I2S signal is right? And R876\R877\R878\R879 R876\R877\R878\R879 should have sign at anytime be have sign at anytime Check the U700...
  • Page 36 DC-DC CONVERTER CIRCUIT 1 CHECK if the 12V 1.CHECK if the 24V OUTPUT from U100(L114) INPUT at U100 PIN2? CHECK if the 12V CHECK if the 1.1V INPUT at U107 OUTPUT at U107 (L100) PIN2 CHECK if the 5V CHECK if the 12V OUTPUT at U1 PIN2,4 INPUT at U1 PIN3...
  • Page 37 DC-DC CONVERTER CIRCUIT 2 1.CHECK if the 24V CHECK if the 5V OUTPUT INPUT at U106 from U106+Q100 OUT,L102 PIN1+Q100 PIN 5? CHECK if the 5V CHECK if the DVDD 3V3 INPUT at U104 OUTPUT at U104 PIN2 PIN3 CHECK if the CHECK if the 5V DDRV(1V5) OUTPUT INPUT at U111 PIN3...
  • Page 38 LVDS signal output is OK, but Panel is back Check the P100 PSU or LVDS cable and PIN12, if is H(3.3V). PANEL issue Check if L118,C163 Failure from Q102 and around Q102 ADIN3_SRV to L118 is right U500 issue...
  • Page 39 Key and IR Check if the P900 PIN2 have P100 PIN1 is 3.3V Check IR BOARD and RC the RC waveform Check if the IR net(L920,L926) and cable is Failure point right U500 issue Check if the P901 PIN2 value is variational When you press P901 PIN1 is 3.3V Keyboard issue...
  • Page 40 FOR R C T8-40F32RC-SK1 74-120110-50QSW PLASTIC BAG T8-40F32RC-SK1 76-KP2102-0AA RAW CARTON SKD 1000MM 648MM 7MM A3B 00 0 T8-40F32RC-SK1 76-L40P21-0AF RAW CARTON-BOX TCL LED40P21 FC 1021MM 3 H4-40D339Z-AGSA0AA T8-40F32FC-SK1 ASS'Y-SKD PACKING(F CAB.) FOR F C T8-40F32FC-SK1 74-120110-50QSW PLASTIC BAG T8-40F32FC-SK1...
  • Page 41 H4-40D339Z-AGSA0AA 70-STDD33-EEM1C TV PRI ADDENDUM SHEET D3300+19D3270 STAN H4-40D339Z-AGSA0AA 67-M93181-RG01ACK RAW SUPPORT --- -- 00 00 00 R=Y H4-40D339Z-AGSA0AA 62-919190-0UN6R PRI SUPPORT AC BLK -- 00 00 00 R=N H4-40D339Z-AGSA0AA 46-LL035L-12X01G WIRE POWER SULLPY WIRE FOR MAIN BOARD 35 H4-40D339Z-AGSA0AA 46-FM080L-04P01G KEY WIRE 800MM 4 A2008 A1250/1255 2.0 H4-40D339Z-AGSA0AA...
  • Page 42 08-PE461C2-PW300AA 64-Z30080-114G Screws FOR QW3 08-PE461C2-PW300AA 64-Z30080-114G Screws FOR QW1 08-PE461C2-PW300AA 64-Z30100-112G MACHINE SCREW FOR BD1 08-PE461C2-PW300AA 66-20516X-1B0 RAW HOLDER FUSE -- 01 00 R=Y FOR F1 08-PE461C2-PW300AA 67-H88490-6A0 RAW HEATSINK FOR ALL 06 00 R=Y 08-PE461C2-PW300AA 67-H88490-7A0 RAW HEATSINK FOR ALL 07 00 R=Y 08-PE461C2-PW300AA 67-H88490-8A0 RAW HEATSINK FOR ALL 08 00 R=Y...
  • Page 43 08-PE461C2-PW3AIAA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C206 08-PE461C2-PW3AIAA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C219 08-PE461C2-PW3AIAA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C204 08-PE461C2-PW300AA 08-PE461C2-PW3STAA ASS'Y - POWER BD（SMT PARTS） 08-PE461C2-PW3STAA 19-CD0479-JTX SMD.RES 4.7 OHM 1/4W +/-5%...
  • Page 44 08-PE461C2-PW3STAA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=YC305 08-PE461C2-PW3STAA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=YC304 08-PE461C2-PW3STAA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=YC407 08-PE461C2-PW3STAA 28-BB0103-KBX CAP.CER,SMD 10NF 50.0V 0805 - +/-10% R=C217 08-PE461C2-PW3STAA 28-BB0104-KBX CAP.CER,SMD 100N0F 50V DCV 0805 - C303 08-PE461C2-PW3STAA 28-BB0104-ZFX...
  • Page 45 08-PE461C2-PW3STAA 19-BC0220-JTX SMD.RES 0805,1/8W,±5%,22Ω R317 08-PE461C2-PW3STAA 19-BC0222-FTX SMD. RES 2.2K OHM 1/8W +/-1% R430 08-PE461C2-PW3STAA 19-BC0222-FTX SMD. RES 2.2K OHM 1/8W +/-1% R442 08-PE461C2-PW3STAA 19-BC0223-FTX SMD. RES 22K OHM 1/8W +/-1% R437 08-PE461C2-PW3STAA 19-BC0303-FTX SMD.RES 0805,1/8W,±1%,30KΩ R433 08-PE461C2-PW3STAA 19-BC0330-JTX SMD.RES 0805,1/8W,±5%,33Ω R418 08-PE461C2-PW3STAA 19-BC0330-JTX...
  • Page 46 08-MT10B14-MA300AA 46-40338W-12XG CONN PHD 12 2.0MM FEMALE R P100 08-MT10B14-MA300AA 46-40338W-40XG CONN PHD 40 2.0MM FEMALE R P902 08-MT10B14-MA300AA 47-EAR031-XX0 SOCKET TWO CANNEL AUDIO R NO MSJ-1537-AP455 08-MT10B14-MA300AA 47-EAR031-XX0 SOCKET TWO CANNEL AUDIO R NO MSJ-1537-AP400 08-MT10B14-MA300AA 47-EAR032-XX0 AV SOCKET R NO MSJ-1637-Y-AG-PBT(B22 P499 08-MT10B14-MA300AA 47-EAR032-XX0...
  • Page 47 08-MT10B14-MA3STAA 28-AC0224-KBX SMD.CAP 220NF 16V +/-10% C900 08-MT10B14-MA3STAA 28-AC0105-ZFX SMD. CAP 1 UF 16VDC +80%/-20% C132 08-MT10B14-MA3STAA 28-AC0105-ZFX SMD. CAP 1 UF 16VDC +80%/-20% C103 08-MT10B14-MA3STAA 28-AC0105-ZFX SMD. CAP 1 UF 16VDC +80%/-20% C834 08-MT10B14-MA3STAA 28-AC0105-ZFX SMD. CAP 1 UF 16VDC +80%/-20% C513 08-MT10B14-MA3STAA 28-AC0105-ZFX...
  • Page 48 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L901 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L902 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L908 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L909 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L904 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L903 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L906 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R L905 08-MT10B14-MA3STAA 23-D04330-JBX NETWORK RES.33R...
  • Page 49 08-MT10B14-MA3STAA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% RC860 08-MT10B14-MA3STAA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% RC861 08-MT10B14-MA3STAA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% RC837 08-MT10B14-MA3STAA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% RC853 08-MT10B14-MA3STAA 28-AB0103-KBX CAP.CER,SMD 10NF 50.0V 0603 - +/-10% R=C125 08-MT10B14-MA3STAA 28-AB0104-ZFX CAP.CER,SMD 100N0F 50V DCV 0603 -...
  • Page 50 08-MT10B14-MA3STAA 28-RF0107-MAL1 SMD.CAP 100UF 6.3V C319 08-MT10B14-MA3STAA 28-RE0227-MAH1 CAP.ELE,SMD 220UF 35V 8*10 - C199 08-MT10B14-MA3STAA 28-RE0227-MAH1 CAP.ELE,SMD 220UF 35V 8*10 - C198 08-MT10B14-MA3STAA 28-RE0226-MAX CAP.ELE,SMD 22UF 35V 6.3*5.4 - C823 08-MT10B14-MA3STAA 28-RC0477-MAH CAP.ELE,SMD 470U0F 16V DCV SMD - C100 08-MT10B14-MA3STAA 28-RC0477-MAH CAP.ELE,SMD 470U0F 16V DCV SMD - C101...
  • Page 51 08-MT10B14-MA3STAA 33-KLN601-NTX CHIP BEAD 600 OHM +/-25% L818 08-MT10B14-MA3STAA 33-KLN601-NTX CHIP BEAD 600 OHM +/-25% L921 08-MT10B14-MA3STAA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L817 08-MT10B14-MA3STAA 33-KLN121-NAX FB-SMD 120OHM 25% -A -OHM 1608（0603） L209 08-MT10B14-MA3STAA 33-KLN121-NAX FB-SMD 120OHM 25% -A -OHM 1608（0603） L210 08-MT10B14-MA3STAA 33-KLL189-KTX SMD.
  • Page 52 08-MT10B14-MA3STAA 28-HB0221-JCX CAP.CER,SMD 220P0F 50V DCV 0402 - C828 08-MT10B14-MA3STAA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C305 08-MT10B14-MA3STAA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C868 08-MT10B14-MA3STAA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C306 08-MT10B14-MA3STAA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C867 08-MT10B14-MA3STAA 28-HB0181-JCX...
  • Page 53 08-MT10B14-MA3STAA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C530 08-MT10B14-MA3STAA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C937 08-MT10B14-MA3STAA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C938 08-MT10B14-MA3STAA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C539 08-MT10B14-MA3STAA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C704 08-MT10B14-MA3STAA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 -...
  • Page 54 08-MT10B14-MA3STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R836 08-MT10B14-MA3STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R811 08-MT10B14-MA3STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R834 08-MT10B14-MA3STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R914 08-MT10B14-MA3STAA 19-AB0471-JTX SMD. RES 470 OHM 1/10W +/-5% R813 08-MT10B14-MA3STAA 19-AB0471-JTX...
  • Page 55 08-MT10B14-MA3STAA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOTQ900 08-MT10B14-MA3STAA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOTQ817 08-MT10B14-MA3STAA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOTQ812 08-MT10B14-MA3STAA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOTQ807 08-MT10B14-MA3STAA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOTQ806 08-MT10B14-MA3STAA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOTQ814...
  • Page 56 08-MT10B14-MA3STAA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 L416 08-MT10B14-MA3STAA 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 R318 08-MT10B14-MA3STAA 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 R202 08-MT10B14-MA3STAA 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 R203 08-MT10B14-MA3STAA 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 R461 08-MT10B14-MA3STAA 19-AB0101-JTX...
  • Page 57 08-MT10B14-MA3STAA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R336 08-MT10B14-MA3STAA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R358 08-MT10B14-MA3STAA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R880 08-MT10B14-MA3STAA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R481 08-MT10B14-MA3STAA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R154 08-MT10B14-MA3STAA 19-GA0101-JTX...
  • Page 58 08-MT10B14-MA3STAA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R338 08-MT10B14-MA3STAA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R921 08-MT10B14-MA3STAA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R747 08-MT10B14-MA3STAA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R513 08-MT10B14-MA3STAA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R346 08-MT10B14-MA3STAA 19-GA0229-FTX...
  • Page 59 08-MT10B14-MA3STAA 19-AB0511-JTX R-SMD 510R0OHM 5% 1/10W 0603 - R819 08-MT10B14-MA3STAA 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 R307 08-MT10B14-MA3STAA 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 R993 08-MT10B14-MA3STAA 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 R823 08-MT10B14-MA3STAA 19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 R301 08-MT10B14-MA3STAA 19-AB0473-JTX...
  • Page 60 08-MT10B14-MA3STAA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R214 08-MT10B14-MA3STAA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R298 08-MT10B14-MA3STAA 12-04822A-0BX MOSFET-SMD N 30V 8A 1.8V 0.018OHM 2W AOQ100 08-MT10B14-MA3STAA 19-AB0181-JTX SMD. RES 180 OHM 1/10W 0603 R132 08-MT10B14-MA3STAA 19-AB0122-JTX SMD. RES 1.2K OHM 1/10 J 0603 R130 08-MT10B14-MA3STAA 09-0SS34B-STX...
  • Page 61 08-40D3302-FC200AA 67-L71622-2N0 LOGO 08-40D3302-FC200AA 89-604790-JZ3 PROTECTING LABEL FC第一次贴前壳 08-40D3302-FC200AA 89-604830-JZ0 PROTECTING LABEL 50mm FC第一次贴前壳 08-40D3302-FC200AA 89-MY3003-JZ5 SUNDRIES-FILM SELF ADHESIVE FILM FC第二次贴前壳 08-40D3302-FC200AA 89-MY3003-JZB SUNDRIES-FILM SELF ADHESIVE FILM FC第二次贴前壳 H4-40D339Z-AGSA0AA 08-40AF29Z-DM200AA ASS'Y - DEMO BD 08-40AF29Z-DM200AA 46-40500W-18XG CONN PHD 18 2.0MM MALE BLACK ST P901 08-40AF29Z-DM200AA 46-40500W-14XG...
  • Page 62 08-40AF29Z-DM2STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R642 08-40AF29Z-DM2STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R646 08-40AF29Z-DM2STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R655 08-40AF29Z-DM2STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R643 08-40AF29Z-DM2STAA 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 R656 08-40AF29Z-DM2STAA 19-AB0103-JTX...
  • Page 63 08-32S129R-KE2STAA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 08-32S129R-KE2STAA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 08-32S129R-KE2STAA 19-AB0102-FTX RES SMD 1K OHM 1/10W +/-1% 0603 08-32S129R-KE2STAA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 08-32S129R-KE2STAA 46-GHSS02-04SG CONN SMT 4 1.25MM FEMALE WHITE R 08-32S129R-KE200AA 40-32S12B-KEC2XG PCB KEY PCB 183 X133.5MM 13PC DOUBLESIDE...
