TECHNICAL & SERVICE MANUAL
SAP – CMR2428E
FILE NO.
FILE NO.
(Combination with indoor unit mod. SAP-K/KR128E-FTR128E)
MULTI-SPLIT SYSTEM AIR CONDITIONER
MULTI-SPLIT SYSTEM AIR CONDITIONER
Model No.
Product Code No.
Model No.
Product Code No.
SAP – CMR2428E
SAP – CMR2428E
852 070 02
Outdoor Unit
Outdoor Unit
SAP–CMR2428E
SAP–CMR2428E
SM
700311
REFERENCE NO.
0.8180.134.0
02/2001
Advertisement
Table of Contents
Related Manuals for Sanyo SAP–CMR2428E
Summary of Contents for Sanyo SAP–CMR2428E
- Page 1 TECHNICAL & SERVICE MANUAL SAP – CMR2428E FILE NO. FILE NO. (Combination with indoor unit mod. SAP-K/KR128E-FTR128E) MULTI-SPLIT SYSTEM AIR CONDITIONER MULTI-SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. Model No. Product Code No. SAP – CMR2428E SAP – CMR2428E 852 070 02 Outdoor Unit Outdoor Unit...
