Introduction Thank you for choosing this Sony FD Trinitron Colour Television. Before operating the TV, please read this manual thoroughly and retain it for future reference. • Symbols used in the manual: • Important information • Information on a feature.
Safety Information This set is to operate on a 220- 240V AC supply only. Take care not to connect too many appliances to the same power socket as this could result in fire or electric shock. Do not open the cabinet and the rear cover of the TV.
5 seconds). b) If Media Selector is switched to VCR: For Sony’s VCR double-digit programme numbers, e.g. 23, press -/- - first and then the buttons 2 and 3. 7 Selecting screen format: Press this button repeatedly to change the format of the screen.
Overview of TV Buttons Remote Control On/Off Locator: switch By pressing this button on the TV, the remote control beeps for 30 seconds to enable you to find it easily. To stop beeping, press any button on the remote control. Inserting Batteries into the Remote Control Make sure you insert the supplied batteries using the correct polarities.
Switching On the TV and Automatically Tuning The first time you switch on your TV, a sequence of menu screens appear on the TV enabling you to: 1) choose the language of the menu screen, 2) choose the country in which you wish to operate the TV, 3) adjust the picture slant, 4) asign an ID to your remote control, 5) search and store all available channels (TV Broadcast) and 6) change the order in which the channels (TV Broadcast) appear on the screen.
Page 8
Because of the earth’s magnetism, the picture might slant. The Picture Rotation menu allows you to correct the picture slant if it is necessary. If it is not necessary, press OK to select Not necessary. If it is necessary, press then press OK and correct any slant of the picture between –5 and +5 by pressing OK to store.
Page 9
After all available channels are captured and stored, the Programme Sorting menu automatically appears on the screen enabling you to change the order in which the channels appear on the screen. If you wish to keep the broadcast channels in the tuned order, go to step 9.
Introducing and Using the Menu System Your TV uses an on-screen menu system to guide you through the operations. Use the following buttons on the Remote Control to operate the menu system: Press the MENU button to switch the first level menu on. •...
• If you select “Dolby Virtual” on the “Effect” option, the “Auto Volume” option will automatically be switched to “Off” and vice versa. The “BBE High Definition Sound system” is manufactured by Sony Corporation under license from BBE Sound, Inc. It is covered by U.S. Patent No. 4,638,258 and No. 4,482,866. The word “BBE”...
Level 1 Level 2 • While watching the TV, you can press the remaining. • One minute before the TV switches itself into standby mode, the time remaining is displayed on the TV screen automatically. Even if you have selected “On” or “Off” in the “Auto Format” option, you can always modify the format of the screen by pressing repeatedly on the remote control to select one of the following formats: Smart: Imitation of wide screen effect for 4:3 broadcast.
Level 1 Level 2 If you select “AUTO”, the output signal will always be the same one that is displayed on the screen. If you have connected a decoder to the Scart Scart, please remember to change back the “AV3 Output” to “AUTO” or “TV” for correct unscrambling.
Level 1 Level 2 Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up Menu System Level 3 / Function PIP POSITION The “PIP Position”...
Level 1 Level 2 Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up...
Level 1 Level 2 Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up The following option is only available depending on the country you have selected in the “Language/Country” menu. After selecting the System option, press Then press to select the TV Broadcast system (B/G for western European countries or D/K for eastern European countries).
Level 1 Level 2 Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up...
Teletext Teletext is an information service transmitted by most TV stations. The index page of the teletext service (usually page 100) gives you information on how to use the service. To operate teletext, use the remote control buttons as indicated below. Teletext errors may occur if you use a channel (TV Broadcast) with a weak signal.
NexTView* (depending on availability of service). NexTView is an on-screen electronic programme guide, providing you with programme information for different broadcasters. When looking for information you can search by theme (sports, art, etc...) or date. If wrong characters appear when viewing NexTView, use the menu system to enter the “Language/Country”...
Page 20
“Overview” interface (fig. 2) Icons for different themes (see the “Icons’ key” section below) Date Overview Record This function only works if you have connected a VCR which supports SmartLink and Timer Programming feature. If you wish to record the selected programme, press the red button on the remote control.
This option is only available depending on the country you have selected in the “Language/Country” menu. Hi-fi “PlayStation”* Decoder ). Repeat this option for each scrambled Decoder “PlayStation” is a product of Sony Computer Entertainment, Inc. “PlayStation” is a trademark of Sony Computer Entertainment, Inc. or through a continued... Additional Information...
Connecting to external Audio Equipment: Plug in your Hi-Fi equipment to the audio output sockets D if you wish to amplify the audio output from TV. Next , using the menu system, select the “Sound Adjustment” menu and set the “TV Speakers” to “Off”. Audio level of the external speakers can be modified by pressing the volume buttons on the remote control.
Remote Control Configuration for VCR/DVD In it’s default condition this remote control will operate the basic functions of this Sony TV, Sony DVDs and most Sony VCRs. To control VCRs and DVDs of other manufacturers (and some Sony VCR models), please complete the following steps: Before you start, look up the 3 digit code for your brand of DVD or VCR from the list below.
Specifications Sony España, S.A., hereby declares that this Colour TV is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. www.compliance.sony.de TV system: Depending on your country selection: B/G/H, D/K Colour system: SECAM, NTSC 3.58, 4.43 (only...
Troubleshooting Here are some simple solutions to problems which may affect the picture and sound. Problem No picture (screen is dark) and no sound. Poor or no picture (screen is dark), but good sound. No picture or no menu information from equipment connected to the Scart connector.
Page 26
• If the remote control does not operate the VCR or DVD even when the Media Selector has been set correctly. Enter the necessary code set as explained in the “Remote Control Configuration for VCR/DVD” chapter of this instruction manual. • Replace the batteries. • Contact your nearest Sony service centre.
Page 38
AUTO AUTO AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu: AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting...
Page 39
AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu: AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting...
Page 40
AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu:...
Page 41
AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu: AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting...
Page 42
• • PROG + ( PROG - ( TELETEXT Index Programme News Sport Weather...
Page 46
• • • • • • • • 3a moho odopyfbahe Bkjizete moho a apatypata k∂m L/G/S/I kyæjyhla ha æpefhnr ahej ha tejebnsopa n nsdepete bxofeh cnlhaj Kohcyjtnpa te ce c∂c cekunrta Hactpo ka ha sbyka b toba yæ∂tbahe n nsdepete A b mehito sa sbyka.
Page 77
@£ @™ Az energiamegtakarítás érdekében ajánlatos a televíziót teljesen kikapcsolni, ha azt @¡ nem használja. @º !ª !• !¶ !§ !º !∞ !¡ !™ !¢ !£ 6 a) 8 Ez a gomb csak teletext üzemmódban működik. !º Joystick: • • !¡...
Page 78
Az eurocsatlakozóval történő csatlakoztatás választható.
Page 79
• • English Norge Français Italiano Nederlans Sverige Norge Italia Schweiz/Suisse/Svizzera...
Page 82
• • • • • 1. szint 2. szint • Ez a menü szintén lehetővé teszi a kép üzemmód módosítását az Ön által nézett program típusának megfelelően: Élő (élő televíziós közvetítéseknél, DVD és Digital Set Top Box vevőe- gységnél) Egyéni (egyéni ízléshez). Mozi (filmekhez) •...
Page 83
• Ha az “Dolby Virtual”-ban beállítja a “Effekt”-t, az “Auto hangerő” automatikusan “Ki” pozícióba kapcsol és fordítva. A BBE High Definition Sound System-et a Sony Corporation gyártja a BBE Sound, Inc. licence alapján. Az 4,638,258 és No. 4,482,866 sz. USA szabadalommal védve. A “BBE”...
Page 84
1. szint 2. szint • Ha meg kívánja tekinteni a kikapcsolásig fennmaradó időt miközben a televíziót nézi, nyomja meg a gombot. • Egy perccel a televízió készenléti üzemmódba kapcsolása előtt a fennmaradó idő megjelenik a képernyőn. 3. szint / funkció AUTOMATIKUS MÉRET...
Page 88
1. szint 2. szint Ismételje meg ezeket a lépéseket további csatornák beállításához és rögzítéséhez. Ha a későbbiekben ezt a funkciót törölni kívánja, válassza újból a “Nem”-et az “Igen” helyett. Ha a későbbiekban törölni akarja ezt a funkciót, válassza újból a “Ki”-t “Be” helyett. 3.
Page 90
Teletext • Ha eltéveszti, üssön be bármilyen három számjegyet, majd ezt követően üsse be újra a helyes oldalszámot. • Amennyiben az oldalszámláló nem áll le, ez azt jelenti, hogy a kért oldal nem áll rendelkezésre. Ebben az esetben üssön be egy másik oldalszámot PROG + ( A Teletext szolgáltatásból való...
Page 134
AUTO AUTO AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu: AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting...
Page 135
AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu: AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting...
Page 136
AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu:...
Page 137
AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting Select NexTView Select NexTView AV Preset AV Preset Manual Set Up Manual Set Up Select: Select: Enter Menu: Enter Menu: AUTO Set Up Set Up Auto Tuning Auto Tuning Programme Sorting Programme Sorting...
Page 138
• • PROG + ( PROG - ( TELETEXT Index Programme News Sport Weather...
