BQ76952 3-Series to 16-Series High Accuracy Battery Monitor and Protector for

1 Features

Battery monitoring capability for 3-series to 16-
series cells
Integrated charge pump for high-side NFET
protection with optional autonomous recovery
Extensive protection suite including voltage,
temperature, current, and internal diagnostics
Two independent ADCs
– Support for simultaneous current and voltage
sampling
– High-accuracy coulomb counter with input
offset error < 1 µV (typical)
– High accuracy cell voltage measurement < 10
mV (typical)
Wide-range current applications (±200-mV
measurement range across sense resistor)
Integrated secondary chemical fuse drive
protection
Autonomous or host-controlled cell balancing
Multiple power modes (typical battery pack
operating range conditions)
– NORMAL mode: 286 µA
– Multiple SLEEP mode options: 24 µA to 41 µA
– Multiple DEEPSLEEP mode options: 9 µA to 10
µA
– SHUTDOWN mode: 1 µA
High-voltage tolerance of 85 V on cell connect and
select additional pins
Tolerant of random cell attach sequence on
production line
Support for temperature sensing using internal
sensor and up to nine external thermistors
Integrated one-time-programmable (OTP) memory
programmable by customers on production line
Communication options include 400-kHz I
and HDQ one-wire interface
Dual-programmable LDOs for external system
usage
48-pin TQFP package (PFB)
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
Copyright © 2021 Texas Instruments Incorporated
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Li-Ion, Li-Polymer, and LiFePO
2
C, SPI,
Product Folder Links:
SLUSE13A – JANUARY 2020 – REVISED MAY 2021
SLUSE13A – JANUARY 2020 – REVISED MAY 2021
Battery Packs
4

2 Applications

Battery backup unit (BBU)
E-bike, e-scooter, and LEV
Cordless power tools and garden tools
Non-military drones
Other industrial battery pack (≥10S)

3 Description

The Texas Instruments BQ76952 device is a
highly integrated, high-accuracy battery monitor
and protector for 3-series to 16-series Li-ion, Li-
polymer, and LiFePO
4
includes a high-accuracy monitoring system, a
highly configurable protection subsystem, and support
for autonomous or host controlled cell balancing.
Integration includes high-side charge-pump NFET
drivers, dual programmable LDOs for external system
use, and a host communication peripheral supporting
2
400-kHz I
C, SPI, and HDQ one-wire standards.
The BQ76952 device is available in a 48-pin TQFP
package.
Device Information
(1)
PART NUMBER
PACKAGE
BQ76952xx
PFB (48-pin)
(1)
See the
Device Comparison Table
device family. For all available devices, see the orderable
addendum at the end of the data sheet.
+
VC15
+
VC14
+
+
VC13
VC12
+
+
VC11
VC10
+
+
VC9
+
VC8
+
VC7
+
VC6
+
VC5
VC4
+
+
+
+
Simplified Schematic
BQ76952
BQ76952
BQ76952
battery packs. The device
BODY SIZE (NOM)
7 mm × 7 mm
for information on the
PACK+
CHG
DSG
CAN
5V
COMM TO
TRANSCEIVER
SYSTEM
COMM
REGIN
REG1
REG2
VDD
3.3V
RST_SHUT
DDSG
MCU
DCHG
DFETOFF
CFETOFF
HDQ
SDA
SCL
ALERT
GND
PACK-
