OPERATING INSTRUCTIONS
Dishwasher DSD644GXXL
EN

Advertisement

Table of Contents
loading

Related Manuals for Asko DSD644GXXL

Summary of Contents for Asko DSD644GXXL

  • Page 1 OPERATING INSTRUCTIONS Dishwasher DSD644GXXL...

  • Page 2: Table Of Contents

    Open the door and press the main power switch. "Welcome to your new ASKO. This is a first time set up." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results. See page 4.

  • Page 3: Safety Instructions

    Safety instructions Activate child lock (Kid Safe™) NOTE! You can activate the child lock (button lock) to prevent children from Read the operating instructions and keep starting the dishwasher. See the chapter Settings. them in a safe place! Installation Number of standard place settings: 14 See the chapter Installation.

  • Page 4: Before Washing For The First Time

    Open the door and press the main power switch. soft water (water with low mineral content). Hard water leaves a white "Welcome to your new ASKO. This is a first time set up." is shown coating on dishes and the dishwasher.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher Greener dishwashing Water hardness 0/1/2/3/4/5/6/7/8/9 Do not rinse under running water Adjusting the water softener. Select a setting depending on the Simply scrape off large food particles before loading the dishwasher. hardness of the water supply. It is important that this setting is correct! Do not forget to put salt in the salt compartment after you have set Choose a green detergent the water softener to 1 - 9.
  • Page 6 Fragile dishes The dishwasher's baskets Some cookware is not dishwasher safe. This can be for several reasons. The dishwasher is equipped with a top cutlery tray, an upper basket Some materials cannot withstand strong heat, others can be damaged and a lower basket with a cutlery basket. by dishwashing detergent.
  • Page 7 glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right. Foldable tines Lower the foldable tines (plate supports) when washing pots. Release the foldable tines by pressing the catch inwards before adjusting their position.
  • Page 8 Fold-down section for small items The cutlery basket has a fold-down section in the middle for small items, or small shafts, such as electric whisk attachments. Cutlery basket with lid (only certain models) The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see below).

  • Page 9: Using The Dishwasher

    Using the dishwasher Add detergent NOTE! Use only dishwasher detergent! Washing up liquid must not be used Press to open as the foam that forms prevents the dishwasher from operating effectively. Dishwasher tablets Halve the tablet if it is difficult to close the dispenser lid. There is a risk that the detergent will not be released properly if the lid is tight and will not open correctly.
  • Page 10 Open the door and press the main power switch. Starting the dishwasher START STOP 2:00 Speed mode Select the programme Select a programme mode Select any options Hygiene wash The main power switch This programme is ideal to use where demands on hygiene are extra high, e.g.
  • Page 11 Speed mode Red - Do not load The programme time is shortened, but the dishwasher uses more You should not load more dishes (risk of poorer dishwashing result). energy. Flashing red indicates a problem. See also the chapter Troubleshooting. Night mode Green - Unload Lower noise level during the dishwashing programme.

  • Page 13: Settings

    Settings Open the dishwasher's Settings menu To open the dishwasher's Settings menu, press the Navigation button until Settings menu is shown on the display and confirm your selection with the mode selector To exit the dishwasher's Settings menu, select Exit and confirm your selection with the mode selector Navigation buttons for choosing setting Mode selector to confirm current setting START...
  • Page 14 Settings Options Super rinse On/Off Super rinse adds two extra rinses. Activated in the following programmes: Normal wash ECO wash Daily wash Plastic wash Lower half wash Upper half wash High temperature On/Off Activate the setting High temperature to improve the dishwashing results.

  • Page 15: Care And Cleaning

    Care and cleaning Fine filter Top up rinse aid Debris that collects on the fine filter is automatically rinsed away during When the rinse aid needs topping up, the above symbol lights on the each wash. Clean the fine filter when necessary. display.
  • Page 16 Unblocking the drainage pump If the dishwasher still contains water after the programme has finished, something may be blocking the drainage pump. Such items are easily removed. 1. Turn off the machine using the main power switch and unplug it from the wall socket.

  • Page 17: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling water 1 Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 18 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings blocked. Clean the spray arms. See the chapter Care and cleaning.
  • Page 19 Problem Possible causes Action Water remains in the dishwasher. The filters are blocked. Clean the coarse and fine filters. The filters are not fitted correctly. Check that the filter handle is locked in the stop position. The handle should point straight out from the dishwasher.

  • Page 20: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 ASKO Model designation: DSD644GXXL Number of standard place settings: Energy efficiency class: A+++ Annual energy consumption(AE 236 kWh per year Energy consumption of the standard cleaning cycle(E 0.83 kWh...

  • Page 21: Installation

    Installation [mm] 1294** 1238 30-94 *Remove locking nuts for an installed height of 820-821 mm. Door length Cover door with slide function fitted, which means the cover door slides upwards when the dishwasher is opened. Nominal dimensions. Actual measurements may vary. It is important that you read through and follow the instructions and directions below.

  • Page 22: Service

    If you have encountered a problem that you cannot resolve, See the separate installation instructions for necessary information. please contact your nearest dealer, see www.asko.com. This dishwasher is suitable for installing in a raised recess (to attain When making contact, provide the details on the serial number plate.

  • Page 23: Information For Test Institute

    Information for test institute Request test institute information via e-mail dishwashers@appliance-development.com. The request should include the details on the serial number plate. Include the article number (1) and the serial number (2). ART. NO. SERIAL NO.

  • Page 24: Quick Guide

    Top up salt and rinse aid to achieve good washing and drying results. (See page 4.) Top up rinse aid Top up salt Select a programme, programme mode and any options (See page 10.) Press Start/Stop, close the door START STOP ASKO APPLIANCES SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
