JVC DLA-NP5 Instructions Manual

D-ila projector
Hide thumbs Also See for DLA-NP5:
Table of Contents

Advertisement

Quick Links

.
D-ILA
PROJECTOR
DLA-NZ9 DLA-RS4100
DLA-NZ8 DLA-RS3100
DLA-NZ7 DLA-RS2100
DLA-NP5 DLA-RS1100
.
http://manual3.jvckenwood.com/projector/mobile/global/
The Mobile User Guide can be viewed on mobile internet devices including
smartphones and tablets.
.
For Customer use :
Enter below the serial No. which is located on the side of the cabinet. Retain this information for future reference.
DLA-NZ9BK, DLA-NZ8BK, DLA-NZ7BK, DLA-NP5BK,
DLA-NZ9BE, DLA-NZ8BE, DLA-NZ7BE, DLA-NP5BE, DLA-NP5WE,
DLA-RS4100K, DLA-RS3100K, DLA-RS2100K, DLA-RS1100K,
DLA-RS4100E, DLA-RS3100E, DLA-RS2100E, DLA-RS1100E
Model No.
Serial No.
.
Not suitable for household room illumination.
INSTRUCTIONS
Mobile User Guide
B5A-3961-01

Advertisement

Table of Contents
loading

Related Manuals for JVC DLA-NP5

Summary of Contents for JVC DLA-NP5

  • Page 1 INSTRUCTIONS D-ILA PROJECTOR DLA-NZ9 DLA-RS4100 DLA-NZ8 DLA-RS3100 DLA-NZ7 DLA-RS2100 DLA-NP5 DLA-RS1100 Mobile User Guide http://manual3.jvckenwood.com/projector/mobile/global/ The Mobile User Guide can be viewed on mobile internet devices including smartphones and tablets. For Customer use : Enter below the serial No. which is located on the side of the cabinet. Retain this information for future reference.

  • Page 2: Safety Precautions

    FCC INFORMATION (U.S.A. only) WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO CAUTION: NOT EXPOSE THIS APPLIANCE TO RAIN OR Changes or modification not approved by JVC could MOISTURE. void the user’s authority to operate the equipment. NOTE: WARNING: This equipment has been tested and found to comply THIS APPARATUS MUST BE EARTHED.
  • Page 3 IMPORTANT SAFEGUARDS 150 mm (6 in) and above Electrical energy can perform many useful functions. This unit has been engineered and manufactured to 300 mm assure your personal safety. But IMPROPER USE (12 in) and 300 mm above CAN RESULT IN POTENTIAL ELECTRICAL (12 in) and above SHOCK OR FIRE HAZARD.
  • Page 4 (e.g.attaching it to the ceiling) since special replacement, please consult your dealer, or the nearest technical knowledge and skills are required for authorized JVC service center. installation. If installation is performed by an When fixing the unit to the ceiling, Please note that we do...
  • Page 5 THIS APPARATUS MUST BE EARTHED. Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVCKENWOOD Deutschland GmbH Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY...
  • Page 6 ENGLISH Information for Users on Disposal of Old Equipment and Batteries [European Union only] These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.
  • Page 7 CLASS 1 LASER PRODUCT PRODUIT LASER DE CLASSE 1 PRODUCTO LÁSER DE CLASE 1 LASERPRODUKT DER KLASSE 1 PRODOTTO LASER DI CLASSE 1 ЛАЗЕРНОЕ ИЗДЕЛИЕ КЛАССА 1 KLASSE 1 LASERPRODUCT LASER CAUTION LABEL ÉTIQUETTE DE MISE EN GARDE POUR LE LASER ETIQUETA DE PRECAUCIÓN DEL LÁSER LASERWARNSCHILD ETICHETTA DI ATTENZIONE LASER...
  • Page 8 CAUTION/PRUDENCE/PRECAUCIÓN/ACHTUNG/ATTENZIONE/ВНИМАНИЕ/VOORZICHTIG Do not stare into the projector beam at any distance from the projector. Ne regardez pas dans le faisceau du projecteur à n’importe quelle distance du projecteur. No mire directamente al haz del proyector a ninguna distancia del mismo. Blicken Sie nicht direkt in den Lichtstrahl vom Projektor, egal aus welcher Entfernung.
  • Page 9 LASER ENERGY LABEL ÉTIQUETTE D’ÉNERGIE LASER ETIQUETA ENERGÉTICA DEL LÁSER LASERENERGIE-WARNSCHILD ETICHETTA ENERGETICA LASER ЭТИКЕТКА ОТНОСИТЕЛЬНО ЛАЗЕРНОЙ ЭНЕРГИИ LASERENERGIE-ETIKET WARNING: LASER ENERGY - EXPOSURE NEAR APERTURE MAY CAUSE BURNS AVERTISSEMENT : ÉNERGIE LASER - L’EXPOSITION À PROXIMITÉ DE L’OUVERTURE PEUT ENTRAÎNER DES BRÛLURES ADVERTENCIA: ENERGÍA LÁSER - LA EXPOSICIÓN CERCA DE LA APERTURA PUEDE CAUSAR QUEMADURAS...
  • Page 10 IEC62471-5 Location information of the mark / Informations d’emplacement du repère / Información de la ubicación de la marca / Informationen zur Lage der Markierung / Informazioni sulla posizione del marchio / Информация о расположении меток / Locatie-informatie van de markering As with any bright light source, do not stare into the beam, RG2 IEC 62471-5:2015 Tout comme pour n’importe quelle source lumineuse brillante, ne regardez pas fixement le faisceau, RG2 IEC 62471-5: 2015...
  • Page 11 FCC INFORMATION (U.S.A. only) Disposal of these materials may be CAUTION: regulated in your community due to Changes or modification not approved by JVC could environmental considerations. For void the user’s authority to operate the equipment. disposal or recycling information,...
  • Page 12 IMPORTANT SAFEGUARDS Power source indicated on the label. If you are not sure of the type of power supply to your home, consult your Electrical energy can perform many useful functions. product dealer or local power company. This unit has been engineered and manufactured to This product is equipped with a three-wire plug.
  • Page 13 For electrical shock. replacement, please consult your dealer, or the nearest authorized JVC service center. Do not use optical instruments (such as magnifying glass or When fixing the unit to the ceiling, Please note that we do reflector) viewing the laser output.
  • Page 14 THIS APPARATUS MUST BE EARTHED. Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVCKENWOOD Deutschland GmbH Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY...
  • Page 15 ENGLISH Information for Users on Disposal of Old Equipment and Batteries [European Union only] These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.
  • Page 16 IEC62471-5 Location information of the mark / Informations d’emplacement du repère / Información de la ubicación de la marca / Informationen zur Lage der Markierung / Informazioni sulla posizione del marchio / Информация о расположении меток / Locatie-informatie van de markering As with any bright light source, do not stare into the beam, RG2 IEC 62471-5:2015 Tout comme pour n’importe quelle source lumineuse brillante, ne regardez pas fixement le faisceau, RG2 IEC 62471-5: 2015...

  • Page 17: Table Of Contents

    Contents Getting Started Fine-tuning the Image Quality ....... 54 Adjusting the Output Value of the Projected Image Safety Precautions ..........2 (Gamma/Tone Mapping) ........54 Accessories/Optional Accessories ......19 Fine-tuning of Gamma/Tone Mapping to Preferred Check the Accessories ........19 Settings .............
  • Page 18 DLA-NZ8. z indicates a function that is supported by DLA-NZ7. 4 indicates a function that is supported by DLA-NP5. 5 indicates a function that is supported by DLA-RS4100. 6 indicates a function that is supported by DLA-RS3100.

  • Page 19: Accessories/Optional Accessories

    Accessories/Optional Accessories Check the Accessories Lens cover ................1 piece * It is attached to the main unit at the time of shipment. Remote control ............... 1 piece AAA-size batteries (for operational check) ......2 pieces Power cord (for USA) (about. 2 m (about. 78.7 in)) ....1 piece Power cord (for UK) (about.

  • Page 20: Controls And Features

    Controls and Features Main Unit - Front A Lens C Indicator This is a projection lens. Do not look through the lens Refer to “Indicator Display on the Main Unit”P. 114. while an image is projected. D Exhaust vent B Remote Sensor (front) Warm air is discharged to cool down the internal Please aim the remote control at this area when using temperature.

  • Page 21: Main Unit - Side

    Main Unit - Side F Lamp Cover When replacing the light source lamp, remove this cover. (P. 91) Main Unit - Rear x y z 5 6 7 G Input terminals J Power input terminal For details on the terminals, refer to “Main Unit - Input Connect the supplied power cord to this terminal.
  • Page 22 G Input terminals J Power input terminal Please see “Main Unit - Input Terminals”P. 23 for Connect the supplied power cord to this terminal. more details about the terminals. K Air Inlets H Operation panel The inlets take in air to cool down the internal For more details, please refer to the “Operation temperature.

  • Page 23: Main Unit - Input Terminals

    Main Unit - Input Terminals A [3D SYNCHRO] terminal E [SERVICE] terminal By connecting a 3D Synchro Emitter (sold separately) For updating the software using a commercially to this terminal, you can view 3D movies. available USB flash drive. B [HDMI 1] input terminal F [LAN] terminal (RJ-45) The projector can be controlled by connecting it to a C [HDMI 2] input terminal...

  • Page 24: Remote Control

    Remote Control A B [STANDBY] L [PICTURE MODE] Displays the picture mode Turns off the power. (P. 34) selection menu. (P. 39) B C [ON] M [COLOR PROFILE] Turns on the power. (P. 33) Displays the color profile selection C [INPUT] menu.

  • Page 25: Loading Batteries Into The Remote Control

    Loading Batteries into the Remote Control If the remote control has to be brought closer to the unit Loading the batteries to operate, it means that the batteries are wearing out. Replace the batteries with new ones (AAA). Insert the batteries according to the t s marks. Be sure to insert the s end first.

  • Page 26: Menu

    Menu Select the icon at the top of the menu to display its corresponding setting item as shown below. A Picture Adjust B Input Signal C Installation D Display Setup E Function F Information...

  • Page 27: Installing The Projector

    Installing the Projector Precautions during Installation Please read the following carefully before installing this Using the unit unit. Please refrain from projecting in the following circumstances. Otherwise, it may cause fire or When carrying this unit malfunction. Projection with the unit stood vertically This unit is heavy in weight.

  • Page 28: Precautions During Mounting

    Take the necessary actions to prevent the main unit from falling off such as during an earthquake. Regardless of the warranty period, JVC is not liable for When this unit is to be mounted to a fixed position for any product damage caused by mounting the unit with use, install it horizontally.

  • Page 29: Adjusting The Position

    Adjusting the Position Adjusting the elevation angle of the projector The height and inclination of the unit (0 to 5 mm (0 to 0.2 in)) can be adjusted by turning the feet. Lift the unit and adjust the four feet. 4 Locations Extend Contract...

  • Page 30: Connecting The Projector

    Connecting the Projector Do not turn on the power until connection is complete. The connection procedures differ according to the device used. For details, please refer to the instruction manual of the device to be connected. This projector is used for projecting images. To output the audio of connected devices, please connect a separate audio output device, such as an amplifier or speaker.

  • Page 31: Connecting To The Lan Terminal

    Connecting via HDMI-DVI conversion cable Desktop PC, etc. This Unit To [HDMI 1] or [HDMI 2] input terminal DVI Output Terminal   HDMI-DVI Conversion Cable (Sold Separately) If noise occurs, move the desktop PC away from this unit. If the video is not displayed, try to reduce the length of the cable or lower the resolution of the video transmitting equipment.

  • Page 32: Connecting To The Trigger Terminal

    Connecting to the TRIGGER Terminal Screen This Unit To [TRIGGER] Terminal Trigger Input Terminal (Ø3.5) Trigger Cable (Sold Separately) Do not use it to supply power to other devices. Connecting to the audio terminal of another device may cause the device to malfunction or break down. Using beyond the rated value will cause the unit to malfunction.

  • Page 33: Viewing Videos

    Viewing Videos MEMO Make sure to remove the lens cover. Connect the power cord, and ensure that the “STANDBY/ON” indicator lights up in red. During standby in the “ECO Mode”, the “STANDBY/ON” indicator does not light up even when the power cord is correctly connected. In this case, cancel the standby mode by pressing any button on the remote control unit, or use the A button on the projector unit when you are turning on the power.
  • Page 34 Turn off the power Remote control: press the B [STANDBY] button Projector unit: press the A button While the “Are you sure you want to turn off?” message is displayed, press the button again. The light of the LD block/lamp goes off, and the “STANDBY/ON” indicator switches from a green light to a red blinking light.

  • Page 35: Adjusting The Projector Screen

    Adjusting the Projector Screen Adjusting the Lens According to the Projection Position Press the [LENS CONTROL] button, and use the [JKH I] keys to adjust Focus, Zoom (screen size), and Shift (screen position) Focus Pressing the [LENS CONTROL] or [OK] button each time switches the mode in the following sequence: “Focus”...

  • Page 36: Adjusting The Screen Size (Aspect)

    Adjusting the Screen Size (Aspect) The screen size of the projected image can be adjusted optimally according to the original screen size (aspect) that has been input. Press the [MENU] button to display the menu Select “Installation” " “Aspect” in the menu, then select the setting and press [OK] Installation Mode Mode 1 Lens Control...

  • Page 37: Viewing 3D Movies

    Viewing 3D Movies By using the 3D Glasses (PK-AG3) and 3D Synchro Emitter (PK-EM2), both sold separately, you can enjoy 3D video images. Installing the 3D Synchro Emitter Connect 3D Synchro Emitter to the [3D SYNCHRO] terminal on the main unit Installation Example This Unit 3D Glasses...

  • Page 38: Viewing 3D Movies

    Viewing 3D Movies Connect this unit to a 3D-compatible Format Description HDMI device, and turn on the power Auto Automatically determines and to play back the 3D video image sets the format upon receiving 3D For details on how to play back 3D video images, signal.

  • Page 39: Selecting An Image Quality According To The Video Type

    Selecting an Image Quality According to the Video Type Setting the Picture Mode Press the [MENU] button to display the menu, followed by using the ↑↓ keys to select “Content Type”. Next, press [OK] Doing so enables selection of a picture mode that suits the content for viewing. Item Description Auto...
  • Page 40 Press the [PICTURE MODE] button, use the [JK] keys to select “Picture Mode” and press [OK] You can also perform the setting by pressing the [MENU] button to display the menu followed by selecting “Picture Adjust” " “Picture Mode”. Video Type (*) Available Picture Modes Description Natural...

  • Page 41: Setting The Color Profile

    Setting the Color Profile By setting the “Color Profile” (color space information) according to the “Picture Mode”, you can fine-tune the image quality according to the movie you are viewing. * When “Picture Mode” is set to “HDR10+”, the setting is fixed at BT.2020(Normal) x y 5 6/“BT. 2020”...
  • Page 42 Normal cinema filter is a setting that prioritizes brightness and is best suited for video content or movies with an apparent peak. Wide cinema filter is a setting that prioritizes color reproduction and allows users to enjoy the wide color gamut of HDR.
  • Page 43 Picture Mode Color Profile User 1 to User 3 Auto BT.709 BT.2020(Wide) x y 5 6 BT.2020(Normal) x y 5 6 BT.2020 z 4 7 8 Video Anime. x y 5 6 Cinema Off (Wide) x y 5 6 Off (Normal) x y 5 6 Off z 4 7 8 Custom1 to Custom4 User 4 to User 6...

  • Page 44: Adjusting To Your Preferred Color (Color Management)

    Adjusting to your Preferred Color (Color Management) Based on the setting of the selected “Color Profile”, you can adjust each of the following colors according to your preference: Red, Yellow, Green, Cyan, Blue, and Magenta. Press the [MENU] button to display the menu, followed by selecting “Picture Adjust”...

  • Page 45: Viewing Hdr Content

    Viewing HDR Content When viewing HDR content, making adjustments according to the content and viewing environment allows the images to be played back in higher quality. What is HDR content? HDR (High Dynamic Range) refers to images with a significant difference in brightness between the highlight and shadow areas (dynamic range).
  • Page 46 Frame Adapt HDR (Dynamic Tone Mapping) Each HDR movie or title is designed for peak brightness that will change from scene by scene or frame by frame.The “Frame Adapt HDR” feature enables the HDR tone mapping to be adjusted in real time automatically. This feature does not require any mastering information, it will analyze each frame of the HDR image in real time to achieve the almost same mastering information as the original director’s cut.

  • Page 47: Viewing Hdr10+ Content

    Viewing HDR10+ Content Press the [MENU] button to display the menu, and set “Content Type” to “Auto” or “HDR10+” in the “Picture Adjust” menu. Enter the HDR10+ content. When “Input Signal” " “HDMI EDID Setting” " “HDR10+” is configured to “Off”, the receiving of HDR10+ is disabled. To enjoy HDR10+ content, configure to “On”.

  • Page 48: Using The "Theater Optimizer

    Using the “Theater Optimizer” Press the [MENU] button to display the menu, followed by selecting “Installation” " “Screen Setting” to display the “Screen Setting” menu. You can also display the menu by selecting “Screen Setting” from the “Theater Optimizer” menu. Select “Screen Size(Diagonal)”...
  • Page 49 Select “Screen Aspect” to configure the aspect ratio of the screen in use. Select “Screen Gain” to configure the gain of the screen in use. Set “Picture Mode” to “Frame Adapt HDR” (“Setting the Picture Mode”P. 39) Select “Picture Adjust” " “Theater Optimizer” to display the “Theater Optimizer” menu.

  • Page 50: Adjusting Tone Mapping Automatically (Per Movie Or Title)

    Adjusting Tone Mapping Automatically (Per Movie or Title) Press the [MENU] button to display the menu, and set “Content Type” to “Auto” or “HDR10” in the “Picture Adjust” menu. Configure “Picture Mode” to “HDR10” or “User 4 to User 6” in the “Picture Adjust” menu.
  • Page 51 Performing Tone Mapping Manually “HDR(PQ)” gamma is the PQ curve adopted by HDR10. Fine adjustments can be made according to the screen size and environment although the default settings for viewing with the projector have been adjusted to allow optimum viewing.
  • Page 52 For users seeking to obtain a gamma curve that is more faithful to the original PQ curve This unit has been adjusted to display the projector images on the screen in the optimal quality in the default setting based on the original PQ curve. For users who wish to obtain results more faithful to the original PQ curve, please adjust manually with reference to the values below.

  • Page 53: Collaboration With Panasonic Uhd Bd Player Dp-Ub9000

    Collaboration with Panasonic UHD BD Player DP-UB9000 Selecting one of two special projector color profiles from the HDR Display Type of the DP-UB9000 enhances dimensionality and improves gradation accuracy by tone mapping HDR video to match the JVC projector display characteristics.

  • Page 54: Fine-Tuning The Image Quality

    Fine-tuning the Image Quality Adjusting the Output Value of the Projected Image (Gamma/Tone Mapping) You can adjust the output value of the projected image with respect to the video signal input. * This item is not available when “Picture Mode” is set to “Frame Adapt HDR”/“HDR10+”. Example of gamma adjustment The overall image appear brighter with respect to the original image, making the dark areas more visible.
  • Page 55 “Gamma/Tone Mapping” Settings Gamma/Tone Mapping Description When “Color Profile” is Film 1 Image is close to the characteristics of Eastman Kodak Company set to “Film 1” movie films. x y 5 Film 2 Places more emphasis on the gradation compared to the “Film 1” setting.
  • Page 56 List of Selectable “Gamma/Tone Mapping” According to “Picture Mode” Picture Mode Gamma/Tone Mapping Film x y 5 6 Film 1 Film 2 Custom 1 to Custom 3 Cinema Natural User 1 to User 3 Cinema 1 Cinema 2 Custom 1 to Custom 3 HDR10+ HDR(Auto) Frame Adapt HDR...

  • Page 57: Fine-Tuning Of Gamma/Tone Mapping To Preferred Settings

    Fine-tuning of Gamma/Tone Mapping to Preferred Settings You can perform fine adjustments based on the selected gamma adjustment setting. Press the [GAMMA SETTINGS] button to display the Gamma/Tone Mapping menu You can also perform setting from “Picture Adjust”"Gamma/Tone Mapping in the menu. Adjust to the preferred setting Select the color to be adjusted from “Color Selection”...
  • Page 58 Selecting the Base Correction Value (Initial Value) for Adjustment Selecting one of the “Custom 1” to “Custom 3” settings in “Gamma” allows you to select the “Correction Value”. Select the base “Correction Value” for adjustment using the H I keys. The selectable correction values vary according to “Picture Mode”.

  • Page 59: Reducing The Delay And After-Image Of Fast-Moving Images (Motion Control)

    Gamma Adjustment When the gamma curve is a straight line: The brightness and contrast of the video input will be Gamma Curve the same as that of the video output. Bright Area for which the gamma curve is above the straight line (A): Video output appears brighter than the input.

  • Page 60: Clear Motion Drive

    Clear Motion Drive (C.M.D.) Optimal interpolation according to the content is made possible with the new high-definition image interpolation technique. For some scenes, interpolation may cause distortion in the image. In this case, set to “Off”. Original Image Interpolation Enabled Intermediate Frame Generation Intermediate Frame Generation Press the [C.M.D.] button, use the [JK] keys to select a...

  • Page 61: Adjustments And Settings In The Menu

    Adjustments and Settings in the Menu Pressing the [MENU] button displays the menu. Press the [JKH I] keys to select an item, followed by pressing the [OK] button to confirm the selection. List of Menu Items Picture Adjust Content Type ..............................P. 64 Picture Mode ..............................
  • Page 62 Input Signal Input Level ................................ P. 74 Color Space ..............................P. 74 3D Setting ................................. P. 37 Auto Pic.Mode Select ............................P. 75 9 SDR(2D)/ SDR(3D) ............................. P. 75 9 HDR10 ................................ P. 75 9 HLG ................................P. 75 HDMI EDID Setting ............................P. 76 9 Mode ................................
  • Page 63 Display Setup Back Color ................................ P. 85 Menu Position ..............................P. 85 Signal Display ..............................P. 85 Logo ................................. P. 86 Language ................................. P. 86 Function Trigger ................................P. 86 Off Timer ................................P. 86 ECO Mode ................................ P. 86 Network ................................

  • Page 64: Picture Adjust

    Picture Adjust Content Type Changes the available picture modes according to the type of content for viewing. Æ “Setting the Picture Mode” (P. 39) Picture Mode You can adjust the image quality according to the type of video image you are viewing. Æ...

  • Page 65: Dynamic Ctrl X Y Z 5 6 7

    Dynamic CTRL x y z 5 6 7 Expands the dynamic range of video expression through controlling the brightness of the light source based on image analysis. Æ “Reducing the Delay and After-image of Fast-moving Images (Motion Control)” (P. 59) Setting Description Does not control.

  • Page 66: Contrast

    Contrast For adjusting the white level point to avoid clipping or over saturation. Setting range: -50 (little difference in brightness) to +50 (large difference in brightness) Brightness For adjusting the black level point to avoid clipping or over saturation. Setting range: -50 (darker) to +50 (brighter) Color For adjusting the color saturation of the video image.

  • Page 67: Color Selection

    Color Profile Configures the “Color Profile” (color space information) according to the preconfigured “Picture Mode”. It is also used to fine-tune the preconfigured “Color Profile” settings. Æ “Setting the Color Profile” (P. 41) The available “Color Profile” settings vary according to “Picture Mode”. Color Management, Color Selection, Hue, Saturation, Brightness Each of the colors is adjustable according to the user’s preference.
  • Page 68 List of selectable “Color Temp.” according to “Picture Mode” Picture Mode Color Temp. Film x y 5 6 Xenon 1 x y 5 6 Xenon 2 x y 5 6 Custom 1 to Custom 2 Cinema 5500K 6500K 7500K 9300K Xenon 1 x y 5 6 Xenon 2 x y 5 6 High Bright...

  • Page 69: Correction Value

    Picture Mode Color Temp. User 4 to User 6 5500K 6500K 7500K 9300K High Bright HDR10 Custom 1 to Custom 2 * When “Picture Mode” is set to “HDR10+”, the setting is fixed at “HDR10+”. Correction Value Configures the color temperature based on which “Gain Red” / “Gain Green” / “Gain Blue” / “Offset Red” / “Offset Green” / “Offset Blue”...

  • Page 70: Hdr Processing

    HDR Processing This is a feature for configuring the content analysis method using “Tone Mapping” when “Picture Mode” is configured to “Frame Adapt HDR”. This item is not available when “Content Type” is set to “SDR”. When “Picture Mode” is configured to “HDR10+”, “HDR Processing” is fixed at “HDR10+”. “HDR10+” is used only when the Picture Mode is configured to “HDR10+”.

  • Page 71: Theater Optimizer

    Theater Optimizer This feature automatically configures the overall brightness level during tone mapping according to the screen size and state of the projector. Æ “Using the “Theater Optimizer”” (P. 48) To use, configure the details of the screen in use in “Screen Setting”, followed by pressing “Set”. This option does not appear in the menu when “Content Type”...

  • Page 72: Mapping Level

    When “Picture Mode” is set to “HDR10+” Setting Description Displays the tone map when the overall brightness is configured to the high level. High This is suited for large-sized screens. Displays the tone map when the overall brightness is configured to the medium level.

  • Page 73: Mpc/E-Shift X Y Z 5 6 7, Mpc Level 4 8

    MPC/e-shift x y z 5 6 7 MPC Level 4 8 This is a feature for adjusting the sharpness of the displayed image. It employs an original algorithm to create a natural impression that is sharper at areas in focus and softer at areas that are not in focus, enabling you to enjoy highly expressive images with a greater sense of depth.

  • Page 74: Input Signal

    Input Signal Input Level For setting the dynamic range (gradation) of the video input. If the image is not displayed properly even after selecting “Auto”, select an appropriate setting. If the dynamic range is not appropriate, the bright areas become overexposed, and the dark areas become underexposed.

  • Page 75: I 9 Sdr(2D)/ Sdr(3D)

    Auto Pic.Mode Select For configuring “Picture Mode” when the video type switches automatically while “Content Type” is configured to “Auto”. SDR(2D)/SDR(3D) For configuring the “Picture Mode” to switch to automatically during input of SDR (2D) or SDR (3D) signal. Setting Description Last Setting Switches to the “Picture Mode”...

  • Page 76: Hdmi Edid Setting

    HDMI EDID Setting Mode For changing the EDID mode of the “HDMI 1/HDMI 2” terminal. Set to “A” under normal condition. The images may not be displayed on some old devices. In this case, try “B” or “C”. Setting Description Configures the EDID mode to “A”...

  • Page 77: Installation

    Installation Installation Mode Collectively manages the setting values of “Lens Control”, “Pixel Adjust”, “Mask”, “Anamorphic”, “Screen Setting”, “Installation Style”, “Keystone” and “Aspect”. * The lens position may be shifted slightly with respect to the position that was saved. Mode Select For selecting the group to save and retrieve the setting values.

  • Page 78: Focus / Zoom / Shift

    Lens Control Focus / Zoom / Shift For adjusting the lens according to the projection position Æ “Adjusting the Lens According to the Projection Position” (P. 35) Image Pattern For setting whether to display the lens adjustment pattern. Setting Description Displays external signals, and does not display the lens adjustment pattern.

  • Page 79: Pixel Adjust

    Pixel Adjust For correcting the phase shifting between each RGB color by adjusting the pixel. Adjust For setting the adjustment feature to On or Off. Adjust Area Setting Description Whole Adjusts the entire image. Zone Enables fine adjustment of each area by dividing the screen evenly into 10 vertical and horizontal zones.
  • Page 80 Whole Adjust (Pixel) Operation Procedure For making general adjustments to slight color fringing in the horizontal/vertical directions of the video image. A Set “Adjust Area” to “Whole” B Select “Adjust Color” and “Adjust Pattern Color” C Select “Adjust (Pixel)”, and press the [OK] button The Adjustment mode is activated, and the selected adjustment pattern and Adjustment (Pixel) window are displayed.
  • Page 81 Whole Adjust (Fine) Operation Procedure For making general adjustments on the misalignment of the entire screen using “Adjust (Pixel)”, followed by making fine adjustments. A Set “Adjust Area” to “Whole” B Select “Adjust Color” and “Adjust Pattern Color” C Select Adjust (Fine), and press the [OK] button The Adjustment mode is activated, and the selected adjustment pattern and Fine window are displayed.
  • Page 82 Zone Adjust Operation Procedure For fine-tuning misalignments on a part of the screen after adjusting the overall screen misalignment using “Adjust (Pixel)” and “Adjust (Fine)”. The screen can be divided vertically and horizontally into 10 sections for partial adjustments to be made. A Set “Adjust Area”...

  • Page 83: Mask

    Mask For hiding the peripheral area of the image with a mask (black strip). Setting Description Not masked. Hides the ranges specified in “Top”, “Bottom”, “Left” and “Right” by masking (with black strips). Mask: black strip around the periphery “Top” / “Bottom” / “Left” / “Right” For specifying the ranges to hide by masking (with black strips).

  • Page 84: Screen Setting

    This item cannot be set when “Screen Adjust” is set to “Off”. For information on the screen and the corresponding correction mode, please visit our website. https://www.jvc.com/global/projector/screen MEMO You can utilize the optional optical sensor and dedicated projector calibration software to make finer adjustments.

  • Page 85: Display Setup

    Installation Style For setting to “Front”, “Ceiling Mount (F)”, “Rear”, or “Ceiling Mount (R)” according to the installation status of the projector. “Front” or “Ceiling Mount (F)” is set when projector is installed in the front with respect to the screen. “Rear”...

  • Page 86: Function

    Logo For setting the display of logo during startup to “On” or “Off”. Setting Description Not displayed. Displays the “D-ILA” logo for 5 seconds during startup. Language For setting the display language to “English”, “Deutsch”, “Español”, “Italiano”, “Français”, “Português”, “Nederlands”, “Polski”, “Norsk”, “Русский”, “繁體中文”, or “日本語”.

  • Page 87: Network

    Network For specifying the settings for external control from a PC or smartphone. Setting Description DHCP Client Obtains the IP address automatically from the DHCP server inside the connected network. For configuring the network settings manually. IP Address For configuring the IP address. Subnet Mask For configuring the subnet mask.

  • Page 88: Remote Code

    Remote Code For changing the remote control code. Setting Description Change the remote control code from “B” to “A”. Change the remote control code from “A” to “B”. You need to configure the remote control according to the settings of this unit. On the remote control unit, press the [MENU] button for three seconds or longer while pressing and hold the [BACK] button to switch the code.

  • Page 89: High Altitude Mode

    High Altitude Mode For setting the high altitude mode to “On” or “Off”. Set to “On” when using the projector at a location of low atmospheric pressure (higher than 900 m (3,000 ft) above sea level). Hide Mode x y z 5 6 7 For reducing the power consumption through suppressing the current supply for the LD block when the [HIDE] button is pressed to hide the image temporarily.

  • Page 90: Information

    Information Setting Description Input Displays the currently selected video input terminal. Source Displays the input source. (Displayed only during video signal input) Resolution Displays the image resolution. (Displayed only during PC signal input) H Frequency Displays the horizontal frequency. V Frequency Displays the vertical frequency.

  • Page 91: Replacing The Lamp 4 8

    Replacing the Lamp 4 8 The lamp is a consumable item. If the image appears dark or the lamp goes out, replace the lamp unit. When the lamp replacement time approaches, the user is notified with a message displayed on the screen and by the indicator.
  • Page 92 Tighten the screws of the new lamp MEMO unit Usable lamp life Tighten the screws with a t screwdriver. When the lamp is used with “Lamp Power” set to “Low”, the lamp life on this unit is approximately 4500 hours. This is the average usable time and not a guaranteed value.

  • Page 93: Resetting The Lamp Time 4 8

    Resetting the Lamp Time 4 8 Reset the lamp time when you have replaced the lamp. It provides an estimated timing for lamp replacement Resetting the lamp time from the menu screen Press the [MENU] button to display the menu Select “Function”"“Lamp Reset”...

  • Page 94: Maintaining The Cabinet And Remote Control

    Maintaining the Cabinet and Remote Control Gently wipe off dirt on the cabinet with a soft cloth. If it is extremely dirty, wet a cloth in water, wring dry and use it to wipe off the dirt, followed by wiping again with a dry cloth.
  • Page 95 Restore the sponge filter to the original position Place the sponge filter under the tabs Restore the cover and fasten the screws at the four corners MEMO If the sponge filter is damaged and requires replacement, or if dirt gets into the unit, consult your authorized dealer or nearby service center.
  • Page 96 If the sponge filter is damaged and needs to be replaced or if dirt has entered the unit, please consult the authorized dealer from which this unit is purchased or any nearby JVC servicing center. * Be sure to attach the filter. Using this unit without attaching the filter may cause unexpected malfunction.

  • Page 97: Troubleshooting

    Troubleshooting Before sending the unit to your authorized dealer for repair, please check the following points. The following symptoms are not malfunctions. You do not need to worry about the following symptoms if there is no abnormality on the screen. A part of the top or front surface of the unit is hot.
  • Page 98 Video image does not appear Check Action Refer to Is the correct external input selected? Select the correct external input terminal. P. 33 Is the power of the AV device or PC Turn on the power of the AV device or PC and play the P.
  • Page 99 3D video image looks unnatural Check Action Refer to Are there overlapping video images? If there are overlapping video images partially, this is due P. 38 to the crosstalk phenomenon. In this case, adjust “Crosstalk Cancel” accordingly. If there are overlapping video images partially, this is due P.
  • Page 100 Projected image is dark Check Action Refer to Is the lamp near end of the rated hours? Check the lamp time in the “Information” menu. P. 90 Prepare a new lamp unit or replace as soon as possible when the lamp is near end of the rated hours. Is the aperture closed? Increase the value of the “Aperture”...
  • Page 101 Noise is heard Check Action Refer to Is the exhaust vent blocked? Check the installation condition of the projector. P. 27 Is the unit used near a heater or air- When the surrounding temperature of the projector is high, conditioner? the fan revolution speed increases to protect the projector unit, hence a louder operating sound.

  • Page 102: When The Following Messages Appear

    When the Following Messages Appear... Message Description Action No device is connected to the input Input the video signals. terminal. No Input The input terminal is connected but there is no signal. The video signal input is not supported Input video signals that can be used. Out of Range on this unit.

  • Page 103: External Control

    External Control It is possible to control this unit by connecting it to a PC using an RS-232C cross cable (D-sub 9-pin). The projector can be controlled by connecting it to a PC through the computer network with a LAN cable for control commands to be sent to the projector.

  • Page 104: Command Format

    Command Format The command between this unit and the computer consists of “Header”, “Unit ID”, “Command”, “Data” and “End”. Header (1 byte), Unit ID (2 bytes), Command (2 bytes), Data (n bytes), End (1 byte) Header This binary code indicates the start of communication. Binary Code Type Description...

  • Page 105: Remote Control Code

    Remote Control Code Binary code is sent during communication. The following applies to the case when the remote control code is “A”. In the case of “B”, add “36” to the beginning of the code. Remote Control Button Binary Code Remote Control Button Binary Code Name...

  • Page 106: Communications Example

    Communications Example This section shows the communication examples of RS-232C. Operating command Type Command Description Connection check PC " This unit: 21 89 01 00 00 0A Connection check This unit " PC: 06 89 01 00 00 0A Power (On) PC "...

  • Page 107: Specifications

    Specifications Product Name D-ILA Projector Model Name DLA-NZ9BK, DLA-NZ9BE, DLA-NZ8BK, DLA-NZ8BE, DLA-NZ7BK, DLA-NZ7BE, DLA-RS4100K, DLA-RS4100E, DLA-RS3100K, DLA- RS3100E, DLA-RS2100K, DLA-RS2100E, DLA-NP5BK, DLA- NP5BE, DLA-NP5WE, DLA-RS1100K, DLA-RS1100E *1 Display Panel/Size D-ILA device *2, 3 0.69” 4K D-ILA (4096 x 2160 pixels) x 3 Projection Lens 2.0 x power zoom lens, motorized zoom and focus Light Source...
  • Page 108 “W” indicates that the main unit is white in color. “B” indicates that the main unit is black in color. D-ILA is the abbreviation for Direct Drive Image Light Amplifier. D-ILA devices are manufactured using extremely high-precision technology with a pixel effectiveness of 99.99%. Only 0.01% or less of the pixels are either missing or would remain permanently lit.
  • Page 109 Screen Size and Projection Distance Projection Distance (m) Screen Size 17:9 Screen 16:9 Screen 2.35:1 Screen 4:3 Screen Diagonal (Inch) Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end 1.67 3.43 1.75 3.61 1.86 3.82 2.16 4.44 1.96 4.02 2.06 4.23 2.18 4.47 2.54...
  • Page 110 Projection Distance (Inch) Screen Size 17:9 Screen 16:9 Screen 2.35:1 Screen 4:3 Screen Diagonal (Inch) Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end 65.5 135.1 69.1 142.2 73.1 150.3 85.2 174.7 77.0 158.2 81.1 166.4 85.8 175.8 100.0 204.3 88.5 181.2 93.1 190.6...
  • Page 111 y z 4 6 7 8 Projection Distance (m) Screen size 17:9 Screen 16:9 Screen 2.35:1 Screen 4:3 Screen Diagonal (Inch) Wide End Tele End Wide End Tele End Wide End Tele End Wide End Tele End 1.79 3.66 1.88 3.85 1.99 4.07...
  • Page 112 Projection Distance (Inch) Screen Size 17:9 Screen 16:9 Screen 2.35:1 Screen 4:3 Screen Diagonal (Inch) Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end 70.5 144.1 74.0 151.6 78.3 160.2 90.9 186.2 82.3 168.5 86.6 177.2 91.7 187.4 106.3 217.3 94.5 192.9 99.2 202.8...
  • Page 113 Types of Possible Input Signals Video Digital Video Signal 480p 576p 720p 50/60 Hz 1080i 50/60 Hz 1080p 24/25/30/50/60/100/120 Hz 2K (2048×1080) 24/25/30/50/60 Hz* 4K (3840×2160) 24/25/30/50/60/100/120 Hz 4K (4096×2160) 24/25/30/50/60/100/120 Hz 8K (7680×4320) 24/25/30/48/50/60 Hz x y z 5 6 7 3D Signal Frame Packing 720p 50/60 Hz...
  • Page 114 Indicator Display on the Main Unit Meaning of the front panel indicators The indicator is solid. The indicator appears blinking. Operation mode display Displays using the different colors and solid/blinking light of the indicator on the projector unit. “STANDBY/ON” lights up (red) “STANDBY/ON”...
  • Page 115 Warning display You can tell the details of a warning from the (repeated) displays of the “WARNING” and “LIGHT” indicators. The “STANDBY/ON” indicator will light up or appear blinking according to the operation mode of the projector unit. (Please refer to ““Operation mode display”P. 114”.) The Warning mode is activated once the message is displayed.
  • Page 116 Indicator Status Blinking Description Check and Countermeasure STANDBY/ Frequency WARNING LIGHT Cooling fan stopped Check that nothing is abnormally blocking the air inlets. Check that the external Internal temperature is WARNING WARNING LIGHT STANDBY/ON temperature is normal. abnormally high (Red) Mode Countermeasure: Leave the External temperature is too...
  • Page 117 Dimensions (Unit: mm) Top Surface Bottom Surface 337 (13-9/32) 500 (19-11/16) (1-5/8) (1-15/32) Front Rear Surface (2-5/32) (3-27/32) (10-15/16) (3-27/32) (8-5/32) (8-5/32)
  • Page 118 y z 6 7 Top Surface Bottom Surface 337 (13-9/32) 500 (19-11/16) (1-5/8) (1-15/32) Front Rear Surface (2-5/32) (3-27/32) (10-15/16) (3-27/32) (8-5/32) (8-5/32)
  • Page 119 Top Surface Bottom Surface 337 (13-9/32) 500 (19-11/16) (1-5/8) (1-15/32) Front Rear Surface (3-27/32) (10-15/16) (3-27/32) (3-7/8) (9-19/32) (3-7/8) (8-5/16)

  • Page 120: Software License Agreement

    Software License Agreement The software embedded in the Product (hereinafter the “Licensed Software”) provided by JVCKENWOOD Corporation (hereinafter the “Licensor”) is copyrighted to or sublicensable by the Licensor, and this Agreement provides for the terms and conditions which Users shall follow in order to use the Licensed Software. The User shall use the Licensed Software by agreeing with the terms of this Software License Agreement.
  • Page 121 Article 8 Termination In case the User falls under any of the events described in the following items, the Licensor may immediately terminate this Agreement or claim that the User compensates for the damage incurred by the Licensor due to such event: (1) when the User violated any provision of this Agreement;...

  • Page 122: Important Notice Concerning The Software

    Important Notice concerning the Software Software License Attached to the Product : The Software embedded in the Product is composed of several independent software components, and in each of such individual components (hereinafter the “Licensed Software”), a copyright of either JVCKENWOOD Corporation (hereinafter “JKC”) or a third party subsists.

  • Page 123: Index

    Index A Accessories............19 Enhance ...............73 Adjust (Pixel Adjust)..........79 External Control..........103 Adjust Area ............79 F Factory Reset ............89 Adjust Color ............79 Filter Product no............96 Adjust Pattern ............79 Focus ..............35 Adjust Pattern Color ..........79 Frame Interpolation..........60 Adjust (Fine) ............79 Function ...............
  • Page 124 License ..............89 Screen Setting ............. 84 Light Source Time Screen Size and Projection Distance....109 x y z 5 6 7 ....90 Screen Size(Diagonal) ......... 84 SDR(2D)/SDR(3D) ..........75 List of Menu Items..........61 Securing (Mounting) the Projector......28 Lock ..............78 Securing the Projector (Ceiling Mount)....
  • Page 125 1021KSH-SW-XX © 2021...

This manual is also suitable for:

Dla-rs1100Dla-nz9Dla-nz8Dla-nz7Dla-rs4100Dla-rs3100 ... Show all

Table of Contents
