Briggs & Stratton Snapper Pro S800X Series Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

This manual is available in Spanish. For a copy, contact your Snapper Pro dealer or www.snapperpro.com.
Este manual está disponible en Español. Para obtener una copia, póngase en contacto con
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
5375 NORTH MAIN STREET
MUNNSVILLE, NY 13409
800 933 6175
Tractor
Model Number
5900654
5900658
Mower Deck
5900656
5900875
su distribuidor Snapper Pro o www.snapperpro.com.
Operator's Manual
S800X Series
Zero-Turn Riding Mower
Description
S800XB32
S800X28KAV
S800X/61, 61" Mower Deck
S800X72, 72" Mower Deck
5101740
Rev: L

Advertisement

Table of Contents
loading

Related Manuals for Briggs & Stratton Snapper Pro S800X Series

Summary of Contents for Briggs & Stratton Snapper Pro S800X Series

  • Page 1 Operator’s Manual S800X Series Zero-Turn Riding Mower Tractor Model Number Description 5900654 S800XB32 5900658 S800X28KAV Mower Deck 5900656 S800X/61, 61” Mower Deck 5900875 S800X72, 72” Mower Deck This manual is available in Spanish. For a copy, contact your Snapper Pro dealer or www.snapperpro.com. Este manual está...
  • Page 2 Thank you for purchasing this quality-built Snapper Product Identification Numbers Pro product. We’re pleased that you’ve placed your confidence in the Snapper Pro brand. When operated PRODUCT REFERENCE DATA and maintained according to the instructions in this Unit Model Number Unit SERIAL Number manual, your Snapper Pro product will provide many years of dependable service.

  • Page 3: Table Of Contents

    Table of Contents Gearbox Maintenance .............43 Operator Safety ............ 2 Fuse Locations ..............44 Safety Rules and Information ...........2 Battery Maintenance ............44 Safety Decals ..............11 Battery Service ..............45 Safety Interlock System ..........12 Fault Diagnosis Lamps ...........47 Safety Icons ..............13 Storage ................48 Features &...

  • Page 4: Operator Safety

    Operator Safety Operating Safety Congratulations on purchasing a superior-quality piece of lawn and garden equipment. Our products are designed and manufactured to meet or exceed all industry standards for safety. Do not operate this machine unless you have been trained. Reading and understanding this operator’s manual is a way to train yourself.
  • Page 5 Operator Safety Slope Operation Operation on slopes can be dangerous. Using the unit on a slope that is too steep where you do not have adequate wheel traction (and control) can cause sliding, loss of steering, control, and possible rollover. You should not operate on a slope greater than a 5.4 foot rise over a 20 foot length (15 degrees).
  • Page 6 Operator Safety Roll Bar Use Keep the roll bar in the raised position and fasten the seat belt. There is no roll over protection when the roll bar is down! Do not jump off if the mower tips (it is safer to be secured by the seat belt with the roll bar raised.) Lower the roll bar only when necessary (such as to temporarily clear a low overhanging obstacle) and...
  • Page 7 Operator Safety Fuel and Maintenance Always disengage all drives, shutoff the engine, and remove the key before doing any cleaning, refueling, or servicing. Gasoline and its vapors are extremely flammable. Do not smoke while operating or refueling. Do not add fuel while engine is hot or running.
  • Page 8 Operator Safety Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects. The triangle in text signifies important cautions or warnings which must be followed.
  • Page 9 Operator Safety 23. Use care when approaching blind corners, shrubs, 5. Use extra care with grass catchers or other trees or other objects that may obscure vision. attachments. These can change the stability of 24. To reduce fire hazard, keep unit free of grass, the unit.
  • Page 10 Operator Safety EMISSIONS where there is an open flame, such as in a water heater. Allow unit to cool before storing. 1. Engine exhaust from this product contains 5. Shut off fuel while storing or transporting. Do not chemicals known, in certain quantities, to cause store fuel near flames or drain indoors.
  • Page 11 Operator Safety leaks. Make sure all hydraulic fluid connections To maintain operator roll over protection and roll bar are tight and all hydraulic hoses and lines are in effectiveness: good condition before applying pressure to the • If a ROLL BAR becomes damaged for any reason, system.
  • Page 12 Operator Safety WARNING INSPECT BUCKLE & LATCH Failure to properly inspect and maintain the seat belt can cause serious injury or death. INSPECTION AND MAINTENANCE OF THE ROLL BAR SEAT BELT • The seat belt like the ROLL BAR, needs to be periodically inspected to verify that the integrity has not been compromised through normal machine use, misuse, age degradation,...

  • Page 13: Safety Decals

    Operator Safety Safety Decals Before operating your unit, read the safety decals. The cautions and warnings are for your safety. To avoid a personal injury or damage to the unit, understand and follow all safety decals. 15° Max. WARNING DANGER Amputation and thrown objects hazard If any safety decals become worn or damaged, and cannot Keep hands and feet...

  • Page 14: Safety Interlock System

    Operator Safety WARNING Safety Interlock System If the unit does not pass a safety test, do NOT operate it. See your authorized dealer. Under no circumstance should you attempt to defeat the purpose of the safety This unit is equipped with safety interlock switches. These interlock system.

  • Page 15: Safety Icons

    Operator Safety Safety Icons Features and Controls Identification Numbers North American Models When contacting your authorized dealer for replacement parts, service, or information you MUST have these numbers. Record your model / serial number and engine serial numbers on the space provided on the inside front cover for easy access.

  • Page 16: Control Functions - Tractor

    Features and Controls Features and Controls A. S/N: 2014648787 & Below B. S/N: 2014648788 & Above Tractor See Instrument Control Panel Control Functions The information below briefly describes the function of individual controls. Starting, stopping, driving, and mowing require the combined use of several controls applied in specific sequences. To learn what combination and sequence of controls to use for various tasks see the OPERATION section.

  • Page 17: Control Functions - Instrument Control Panel

    Features and Controls Retractable Seat Belt Mower Deck Lift Actuator Switch The seat belt is used to secure the operator to the seat. Pulling back on the switch will lower the mower deck. The seat belt should ALWAYS be worn when the Roll Bar Pushing forward on the switch will raise the deck.

  • Page 18: Operation

    Features & Controls Operation WARNING General Operating Safety Operating on steep slopes can be Before first time operation: dangerous. • Be sure to read all information in the Safety and Operation sections before attempting to operate this unit. • Never operate on slopes greater than 15°. •...

  • Page 19: Checks Before Starting

    Operation Checks Before Starting • Check that crankcase is filled to full mark on the engine oil dipstick (A, Figure 1). See the engine Operator’s Manual for instructions and oil recommendations. • Fill the fuel tank (B) with fresh fuel. Refer to engine manual for fuel recommendations.

  • Page 20: Check Tire Pressures

    Operation Check Tire Pressures Tire pressure should be checked periodically, and maintained at the levels shown in the chart. Note that these pressures may differ slightly from the “Max Inflation” stamped on the side-wall of the tires. The pressures shown provide proper traction, improve cut quality, and extend tire life.

  • Page 21: Starting The Engine

    Operation Starting the Engine Safety Interlock and Mower Deck Positioning Instructions WARNING This unit is equipped with an safety interlock system to help keep the operator safe while running the unit. Please Read the Operator’s Manual before read and understand the SAFETY INTERLOCK SYSTEM and attempting to operate the machine.

  • Page 22: Zero-Turn Driving Practice

    Operation Zero-Turn Driving Practice The lever controls of the Zero Turn rider are responsive, Smooth Travel and learning to gain a smooth and efficient control of the The lever controls of the rider’s forward, reverse, and turning movements will take Zero Turn rider are some practice.
  • Page 23 Operation Practice Turning Around a Corner Practice Turning In Place While traveling forward allow one handle to gradually return To turn in place, “Zero Turn,” gradually move one ground back toward neutral. Repeat several times. speed control lever forward from neutral and one lever back from neutral simultaneously.

  • Page 24: Mowing

    Operation Mowing Before mowing, set the cutting height as described in the Operation section. 1. Engage the parking brake. Make sure the PTO switch is disengaged and the ground speed control levers are in the NEUTRAL position. 2. Start the engine (see Starting the Engine). 3.

  • Page 25: Mowing Methods

    Operation When and How Often to Mow The time of day and condition of the grass greatly affect the results you’ll get when mowing. For the best results, follow these guidelines: 1. Mow when the grass is between three and five inches high.

  • Page 26: Pushing The Rider By Hand

    Operation Proper Mulching Engine Speed & Ground Speed for Broadcasting Mulching consists of a mower deck which cuts and recuts Use full engine throttle matched with a slow ground speed clippings into tiny particles and which then blows them so that clippings will be finely cut. Ground speed while down INTO the lawn.

  • Page 27: Raise And Lower The Roll Bar

    Operation Raise and Lower the Roll Bar WARNING Avoid serious injury or death from roll over. • Keep the roll bar in the raised position and use seat belt. • There is no roll over protection when the roll bar is down.

  • Page 28: Attachment Removal And Installation Procedure

    Operation Attachment Removal and Installation Procedure Positioning the Mower Deck for Service 1. Park the machine on a smooth, level surface such as a concrete floor. Engage the parking brake, disengage the PTO, and turn off the ignition key. 2. Turn the ignition key to the RUN position and push the mower deck lift actuator switch forward (away from the operator’s position) to extend the actuator until you hear a ratcheting noise.
  • Page 29 Operation Installing the Attachment 1. Remove the pins with lanyards (B, Figure 13) from the rear holes of the attachment latches (D). 2. Drive the tractor into the mower deck. 3. Push the deck attachment lever (E) forward and down. Make sure the attachment latches latch into place.

  • Page 30: Regular Maintenance

    Maintenance Regular Maintenance Maintenance Schedule The following schedule should be followed for normal care of your rider and mower. You will need to keep a record of your operating time. Determining operating time is easily accomplished by observing the elapsed time recorded by the hour meter. Safety Items Before Every 5...

  • Page 31: Checking/Adding Fuel

    Maintenance Checking / Adding Fuel WARNING To add fuel: Fuel and its vapors are extremely 1. Remove the fuel cap. flammable and explosive. 2. Fill the tank to about 1-1/2” (3,81 cm) from the bottom Fire or explosion can cause severe burns of the filler neck.

  • Page 32: Inspect Muffler And Spark Arrester

    Maintenance Inspect Muffler and Spark Arrester WARNING Inspect the muffler for cracks, corrosion, or other damage. Replacement parts must be the same and installed in the Remove the spark arrester, if equipped, and inspect same position as the original parts or fire could result. for damage or carbon blockage.
  • Page 33 Maintenance Figure 24. Attachment Lift Arms & Actuator Figure 21. Control Handle Pivots & Seat Plate Pivot Figure 25. Deck Lift Rods Figure 22. Idler Arms A. PTO Clutch Drive Belt Idler Arm B. Hydraulic Pump Drive Belt Idler Arm Figure 23.

  • Page 34: Servicing The Mower Blades

    Maintenance Servicing The Mower Blades Removing the Mower Blade CAUTION Avoid injury! Mower blades are sharp. Always wear gloves when handling mower blades or working near blades. 1. To remove the mower blade, use a 1” wrench on the flats of the spindle shaft and remove the mower blade Figure 26.
  • Page 35 Maintenance Sharpening the Mower Blade CAUTION Avoid injury! Mower blades are sharp. • Always wear gloves when handling mower blades or working near blades. • Always wear safety eye protection when grinding. Figure 29. Sharpening the Mower Blade A. Mower Blade Bevel 1.

  • Page 36: Check Hydraulic Oil Level

    Maintenance Check Hydraulic Oil Level 1. Before removing the reservoir cap, make sure the area around the reservoir and fill neck of the reservoir is free of dust, dirt or other debris. 2. Unscrew the reservoir cap (B, Figure 32). 3.

  • Page 37: Ground Speed Control Lever Adjustment

    Maintenance Ground Speed Control Lever Adjustment The control levers can be adjusted in three ways. The alignment of the control levers, the placement of the levers (how close the ends are to one another) and the height of the levers can be adjusted. To Adjust the Handle Alignment Loosen the ground speed control lever mount bolts (D, Figure 34) and pivot the lever(s) (C) to align with each other.

  • Page 38: Neutral Adjustment

    Maintenance Neutral Adjustment If the tractor “creeps” while the ground speed control levers are locked in NEUTRAL, then it may be necessary to adjust the linkage rod. 1. Park the machine on a hard, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, and turn off the engine.

  • Page 39: Return-To-Neutral Adjustment

    Maintenance Return-to-Neutral Adjustment Checking the Adjustment: To determine if it is necessary to adjust the neutral return, perform the following steps. 1. Disengage the PTO, engage the parking brake and turn off the engine. 2. Move the ground speed control levers into the operating position, pull the levers rearward and release.

  • Page 40: Deck Lift Rod Timing Adjustment

    Maintenance Deck Lift Rod Timing Adjustment 1. Park the machine on a flat, level surface. Disengage the PTO, engage the parking brake, turn off the engine, and remove the ignition key. Drive tires must be inflated to 10 psi (0,69 bar); tractor caster tires to 25 psi (1,72 bar); mower deck caster tires to 25 psi (1,72 bar).

  • Page 41: Deck Leveling Adjustment

    Maintenance Deck Leveling Adjustment NOTE: Before adjusting the deck level, the deck lift rod timing must be checked and/or adjusted. Coarse Adjustment Procedure When adjusting the deck level, the coarse adjustment procedure should be used to make the majority of the adjustment and the fine adjustment procedure should be used to complete the adjustment.

  • Page 42: Pto Clutch Belt Replacement

    Maintenance Fine Adjustment Procedure 1. Loosen the jam nut (A, Figure 45) and turn the fine adjustment bolt (B) to adjust the deck height until the front measurement equals 4” (10,2 cm) and the back measurement equals 4” (10,2 cm) •...

  • Page 43: Hydraulic Pump Drive Belt Replacement

    Maintenance Hydraulic Pump Drive Belt Replacement 1. Park the tractor on a smooth, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, turn off the engine, and remove the ignition key. 2. Raise the hood to gain access to the hydraulic pump drive belts (A, Figure 47).

  • Page 44: Check The Mower Belt Idler Tensioning Spring Length (72" Models Only)

    Maintenance Figures 48). Carefully rotate the breaker bar COUNTER- NOTICE To avoid damaging belts, do NOT pry belts over pulleys. CLOCKWISE, which will relieve the tension on the belt exerted from the idler arm. 4. Slide the drive belt over the edge of the right side stationary idler pulley (B).

  • Page 45: Gearbox Maintenance

    Maintenance Gearbox Maintenance Check the Gearbox Oil Level 1. Park the machine on a flat, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, turn off the engine. 2. Raise the mower deck to the service position. (See Positioning the Mower Deck for Service.) 3.

  • Page 46: Fuse Locations

    Regular Maintenance Fuse Locations The fuse blocks are located on the side of the instrument control panel installed in the right hand fuel tank. Refer to Figure 51 for the location and amperage of the fuses used in this machine. A.

  • Page 47: Battery Service

    Regular Maintenance cell once per hour. The battery is fully charged when the Battery Service cells are gassing freely at low charging rate and less than WARNING 0.003 change in specific gravity occurs over a three hour period. Keep open flames and sparks away from the battery; the Jump Starting With Auxiliary (Booster) Battery gasses coming from it are highly explosive.
  • Page 48 Regular Maintenance or frame. Then remove the other end of the same cable from WARNING the booster battery. 11. Remove the other cable by disconnecting at the For your personal safety, use extreme caution when discharged battery first and then disconnect the opposite jump starting.

  • Page 49: Fault Diagnosis Lamps

    Regular Maintenance Fault Diagnosis Lamps This unit is equipped with a attachment module that features three fault diagnosis lamps labelled A, L and C. Checking the attachement module can help you in quickly identify certain problems with the machine. 1. Park the machine on a flat, level surface such as a concrete floor.

  • Page 50: Storage

    Regular Maintenance Storage WARNING Temporary Storage (30 Days Or Less) Fuel and its vapors are extremely Remember, the fuel tank will still contain some gasoline, so flammable and explosive. never store the unit indoors or in any other area where fuel Fire or explosion can cause severe burns vapor could travel to any ignition source.

  • Page 51: Troubleshooting

    Troubleshooting Troubleshooting WARNING Troubleshooting Chart Remove the ignition key prior to While normal care and regular maintenance will extend performing maintenance on the unit. the life of your equipment, prolonged or constant use may eventually require that service be performed to allow it to •...

  • Page 52: Troubleshooting The Mower

    Troubleshooting Troubleshooting the Rider continued PROBLEM CAUSE REMEDY Engine runs, but rider will not drive. 1. Hydraulic release valve(s) in “open” 1. Turn hydraulic release valve(s) CLOCKWISE to position. close. 2. Belt is broken. 2. See Drive Belt Replacement. 3. Drive belt slips. 3.

  • Page 53: Troubleshooting Common Cutting Problems

    Troubleshooting Troubleshooting Common Cutting Problems PROBLEM CAUSE REMEDY Streaking 1. Sharpen your blades. 1. Blades are not sharp. 2. Replace your blades. 2. Blades are worn down too far. 3. Always mow at FULL throttle. 3. Engine speed is too slow. 4.

  • Page 54: Specifications

    Specifications Specifications CHASSIS NOTE: Specifications are correct at time of printing and are Fuel Tank Capacity: 12 gallons (45,2 L) total subject to change without notice. Drive Tires Tire Size: 24 X 12 - 12 Inflation Pressure: 10 psi (0,69 bar) ENGINE Front Caster Tires Tire Size: 11 x 4.00 - 5...

  • Page 55: Slope Identification Guide

    ALIGN THIS EDGE WITH A VERTICAL SURFACE (TREE, POLE, FENCE POST, BUILDING, ETC)
  • Page 56 Notes...
  • Page 57 BRIGGS & STRATTON PRODUCTS WARRANTY POLICY September 2012 LIMITED WARRANTY Briggs & Stratton warrants that, during the warranty period specified below, it will repair or replace, free of charge, any part that is defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser. This warranty is effective for and is subject to the time periods and conditions stated below.
  • Page 58 Operator’s Manual S800X Series Zero-Turn Riding Mower...
