Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should be made, you could be required to stop operation of the equipment. Canon U.S.A. Inc. One Canon Plaza, Lake Success, NY 11042, U.S.A. Tel No. (516)328-5600 CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Page 3
IMPORTANT SAFETY INSTRUCTIONS In these safety instructions the word “product” refers to the Canon HDV Camcorder HV10 A and all its accessories. Read Instructions — All the safety and operating instructions should be read before the product is operated. Retain Instructions — The safety and operating instructions should be retained for future reference.
Page 4
The Adapter can be used with a power supply between 100 and 240 V AC. For areas where 120 V AC power is not used, you will need a special plug adapter. Contact your nearest Canon Service Center for further information.
Enjoying High-Definition Video Preserve your most treasured memories, be it unforgettable scenic beauty or cherished moments spent with family and friends, with high definition video recordings of a quality second only to actually being there. What is High-Definition Video? High-definition video (HDV) allows you to record video of unparalleled high quality on regular miniDV tapes.
Table of contents Introduction Enjoying High-Definition Video ... 5 About this Manual ... 9 Getting to Know the Camcorder Supplied Accessories... 11 Components Guide ... 12 Screen Displays ... 15 Preparations Getting Started Charging the Battery Pack ... 18 Inserting and Removing a Tape ... 19 Inserting and Removing a Memory Card ...
Page 7
FUNC. Menu Options ...37 Recording Programs Using the Recording Programs ...40 Flexible Recording: Changing the Aperture and Shutter Speed ...41 Special Scene: Recording Programs to Match Special Conditions ...42 Adjusting the Picture: Exposure, Focus and Color Manual Exposure Adjustment...43 Light Metering Mode...43 Automatic Focus Modes ...44 Manual Focus Adjustment ...44 Focus Assist Functions...45...
Page 8
List of Messages ... 76 Do’s and Don’ts Handling Precautions... 79 Maintenance/Others... 82 Cleaning the Video Heads ... 82 Using the Camcorder Abroad ... 83 General Information System Diagram ... 84 Optional Accessories ... 85 Product Codes ... 87 Specifications ... 88...
About this Manual Thank you for purchasing the Canon HV10. Please read this manual carefully before you use the camcorder and retain it for future reference. Should your camcorder fail to operate correctly, refer to the Troubleshooting table ( Conventions Used in the Manual IMPORTANT: Precautions related to the camcorder operation.
Page 10
About the Operating Modes The camcorder’s operating mode is determined by the positions of the power switch and the switch. In the manual, mode shown and indicates that the function is not available. When no operating mode icons are given, the function is available in all operating modes.
The serial number of this product can be found at the battery attachment unit of the camcorder. Write down the number and other information here and retain this book as a permanent record of your purchase to aid identification in case of theft.
Screen Displays Recording Movies Recording Still Images Getting to Know the Camcorder Recording program ( White balance ( Image effect ( Digital effects ( Still image quality/size (simultaneous recording) ( Self timer ( Recording reminder Instant AF ( 31)/Manual focus (...
Page 16
Getting to Know the Camcorder Recording reminder The camcorder counts from 1 to 10 seconds when you start recording. This is helpful to avoid scenes that are too short. Tape operation Record, Record pause, Stop, Eject, Fast forward, Rewind, Playback,...
Page 17
Playing Movies Viewing Still Images Getting to Know the Camcorder Tape operation Time code (hours : minutes : seconds : frames) Remaining tape Data code ( Search function display END SEARCH ( 28)/ DATE SEARCH ( Quality/size for capturing still images (...
Getting Started Preparations Getting Started Getting Started Charging the Battery Pack The camcorder can be powered with a battery pack or directly using the compact power adapter. Charge the battery pack before use. Remove the battery terminal cover before attaching the battery BATT.
86 °F). Outside the temperature range of 0 °C to 40 °C (32 °F to 104 °F), the charging will not start. Do not connect to the camcorder’s DC IN terminal or to the compact power adapter any electrical equipment that is not expressly recommended for use with this camcorder.
Be careful not to get your fingers caught in the cassette compartment cover. NOTES If the camcorder is connected to a power source, cassettes can be inserted/removed even if the POWER switch is set to Inserting and Removing a Memory Card Use only commercially available miniSD cards.
Place the lithium button battery with the + side facing up. Insert the battery holder. Using the Wireless Controller Point the controller at the camcorder’s remote sensor when you press the buttons. NOTES The wireless controller may not work properly when the remote sensor is situated under strong light sources or direct sunlight.
( 36). Using the Menus Using the Menus Many of the camcorder’s functions can be adjusted from the menus that open after pressing the MENU button ( the FUNC. button ( For details about the available menu options and settings, refer to Menu Options Lists - MENU/FUNC.
Select ( ) the desired option and press to save the setting. MENU Press MENU You can press to close the menu at any time. Selecting a FUNC. Menu Option FUNC. Press Select ( ) the icon of the function you want change from the left side column and press Select (...
MENU Press start the clock. IMPORTANT When you do not use the camcorder for about 3 months, the built-in rechargeable lithium battery may discharge completely and the date and time setting may be lost. In such case, recharge the battery ( zone, date and time again.
This is not a malfunction. About the Power Save mode: To save power when the camcorder is powered by a battery pack, the camcorder will automatically shut off if left without any operations for 5 minutes 37).
Do not use tripods with fastening screws longer than 5.5 mm (0.2 inch). Doing so may damage the camcorder. Recording Still Images Before using a memory card for the first time, be sure to initialize it with this camcorder ( 56).
You can also use the T and W buttons on the wireless controller. The zoom speed with the wireless controller will be the same as with the camcorder (when one of the fixed zoom speed levels is selected) or fixed at [SPEED 3] (when [VARIABLE] is selected).
- Frame reverse - Double speed playback (forward or reverse) To protect the tape and video heads, the camcorder will enter the stop mode ( playback pause ( ) mode for 4 minutes 30 seconds. To resume the playback press...
Stop the playback before using this function. END SEARCH Press • “END SEARCH” appears. • The camcorder rewinds/fast forwards the tape, plays back the last few seconds of the recording and stops the tape. • To cancel the search press again.
- Do not change the position of the switch or the operating mode. The following may not be displayed correctly. - Images not recorded with this camcorder. - Images edited on or uploaded from a computer. - Images whose file names have been changed.
If a trailing afterimage appears, set the slow shutter to [ OFF]. (camcorder shake warning) appears, we recommend stabilizing the camcorder, for example, by mounting it on a tripod. D.ZOOM OFF], [ 40X], [ Determines the operation of the digital zoom.
AUTO], [ OFF] FOCUS PRI. ON], [ OFF] The camcorder records the still image only after the focus has been adjusted. Set it to [ OFF] if you wish to record a still image as soon as you press PHOTO .
Page 33
When playing back in this camcorder tapes recorded in LP mode with other devices or vice versa, you may notice some problems in the playback picture or the sound may stop briefly.
In order to display the picture in full and in the correct aspect ratio, select the setting according to the type of television to which you will connect the camcorder. [NORMAL TV]: TV sets with 4:3 aspect ratio. [WIDE TV]: TV sets with 16:9 aspect ratio.
Page 35
Playback the Recording (1080i) (480i) You can select the video specifications to use to connect the camcorder to a high- definition TV using the video component connection. 480i]: To use the 480i specification (standard definition TV). 1080i/480i]: To use the full 1080i high...
TV or monitor. You can also use controller. When the date and time are displayed on the camcorder’s screen they will also appear on a connected TV regardless of the [TV SCREEN] setting. Turn off the date and time by repeatedly pressing 6SEC.DATE...
System Setup (Beep, etc.) SYSTEM SETUP WL.REMOTE ON], [ Allows the camcorder to be operated with the wireless controller. BEEP HIGH VOLUME], LOW VOLUME], [ OFF] A beep will accompany some operations like turning on the camcorder, the self- timer countdown, etc.
Page 39
Still image capturing Recordings made in [ HDV]: LW S.FINE/1920x1080], LW FINE/1920x1080], LW NORMAL/1920x1080] Recordings made in [ DV(WIDE)]: SW S.FINE/848x480], SW FINE/848x480], SW NORMAL/848x480] Recordings made in [ DV(NORMAL)]: S S.FINE/640x480], S FINE/640x480], S NORMAL/640x480] IMAGE ERASE [CANCEL], [ERASE] Erase a still image.
Recording Programs Recording Programs Using the Recording Programs The camcorder adjusts the focus, exposure and other settings automatically, allowing you to just point and shoot. : Flexible Recording Programs ( PROGRAM AE] The camcorder sets the aperture and shutter speed.
APERTURE-PRIO.AE] Set the aperture value. The camcorder automatically sets the appropriate shutter speed. Use low aperture values (larger lens opening) to softly blur the background...
- The subject may become overexposed on cloudy days or in shaded places. Check the image on the screen. FIREWORKS] - To avoid camcorder shake, we recommend using a tripod. Make sure to use a tripod especially in slows down.
Mode switch: Options EVALUATIVE] Appropriate for standard shooting conditions, including backlit scenes. The camcorder divides the picture into several areas and the light is measured in all of them to achieve the optimal exposure for the subject. CENT.WEIGHT.AVERAGE] Averages the light metered from the entire screen, giving more weight to the subject in the center.
FOCUS Press “MF” appears. Adjust ( ) the focus as required until the image appears focused. FOCUS Pressing camcorder to autofocus. NOTES The camcorder will automatically return to autofocus when you set the mode switch to again will return the...
• Pressing again will return the camcorder to autofocus. • Operating the zoom or the ) will return the camcorder to manual focus adjustment. Focus Assist Functions The focus assist function will magnify the center of the picture and emphasize the...
When the adjustment is completed stops flashing and stays on. The camcorder retains the custom setting even if you turn off the camcorder. FUNC. Press to save the setting and close the menu.
NEUTRAL] Tones down the contrast and color saturation. LOW SHARPENING] Records subjects with softened outlines. SOFT SKIN DETAIL] Softens the details in the skin tone area for a more complimentary appearance. CUSTOM] Allows you to adjust the brightness, contrast, sharpness, and color depth of the image.
Still Image Recording Options 2048x1536/FINE FUNC. Icon of the currently selected FUNC. Image Quality/Size Desired image size* Press FUNC. Desired image quality* * The number displayed on the right corner indicates the approximate number of images that can be recorded with the current quality/ size setting.
AEB] (Auto Exposure Bracketing) The camcorder records a still image in three different exposures (dark, normal, light in 1/2 EV steps), allowing you to choose the shot you like the best.
Other Functions Other Functions On-Screen Displays The camcorder keeps a data code containing the date and time and other camera data (shutter speed, exposure, etc.) registered at the time of recording. You can select the data to be displayed.
Selecting the Data Code You can select the data code to be displayed when playing back movies. Options DATE], [ TIME] Displays the date or time when the scene or still image was recorded. DATE & TIME] Displays both the date and time of the recording.
LAMP] to [ OFF] so the assist lamp does not light up. - The camcorder may not be able to focus even if the AF-assist lamp is on. - The brightness of the AF-assist lamp could be an inconvenience. Consider turning it off in public places such as restaurants or theaters.
Press , first halfway to activate the autofocus and then fully to record the still image. The camcorder will record the still image after a 10-second countdown (2 seconds when using the wireless controller). The countdown appears on the screen.
Page 54
NOTES When you are not using the digital effect, select [ D.EFFECT OFF]. The camcorder retains the setting last used even if you turn off the digital effects or change the recording program. PHOTO...
Editing Functions Still Image Options Still Image Options Erasing Still Images IMPORTANT Be careful when erasing images. Erased images cannot be recovered. NOTES Protected images cannot be erased. Erasing a Single Image FUNC. FUNC. IMAGE ERASE FUNC. ERASE Erasing a Single Image Just After Recording You can erase the last recorded still image while reviewing it within the time...
Repeat this step to protect additional images. appears on protected images. Press to cancel the protection. **After closing the menu the camcorder returns to the index screen. Initializing the Memory Card Initialize new memory cards when you use them for the first time. You may also have to initialize a card if you get the “CARD...
Turn off all the devices when making the connections and refer also to the instruction manual of the connected device. Open the terminal cover to access. High Definition TV Sets (HDTV) Terminal on the Camcorder Output connection (Signal Flow CTC-100 Component Cable STV-250N Stereo Video Cable (Supplied) Connecting to a TV or VCR...
Page 58
Connecting to a TV or VCR High Definition TV Sets (HDTV) Terminal on the Camcorder Output connection (Signal Flow Input connection (Signal Flow (IEEE1394) output. (Commercially available) Standard Definition TV Sets Terminal on the Camcorder Output connection (Signal Flow Input connection (Signal Flow (IEEE1394) output.
- [DV OUTPUT] to select the standard of the output video when using connection type Connecting to a TV or VCR Connecting Connect the camcorder to the TV following one of the connection diagrams shown in the previous section Connection Diagrams 57).
Recording to a VCR or Digital Video Recorder You can copy your recordings by connecting the camcorder to a VCR or a digital video device. When recording to a digital video recorder using the HDV/DV terminal, you can copy recordings with virtually no generation loss in video and sound quality.
57)–: - If the picture does not appear, disconnect the DV cable and restore the connection after a short while or turn the camcorder off and then on again. - Proper operation cannot be guaranteed for all digital devices equipped with a DV terminal. If the operation does not work, use the AV IN/ OUT terminal.
If the picture does not appear, disconnect the DV cable and restore the connection after a short while or turn the camcorder off and then on again. Do not connect any devices to the camcorder’s USB terminal while an external device is connected to the HDV/DV terminal.
(for example from a VCR) to digital signals (DV standard only) and output them to a digital recording device. Connecting Connect the camcorder to the video input source using an analog connection –connection type – shown in the previous section Connection Diagrams.
Connecting to a Computer Connecting to a Computer Connecting to a Computer PC Connection Diagrams Terminal on the Camcorder Output connection (Signal Flow USB port. Output connection (Signal Flow DV capture board. USB Terminal Open the rear terminal cover to access.
If the computer freezes while the camcorder is connected to it, disconnect the DV cable and turn off the camcorder and the computer. After a short while, turn them on again, set the camcorder to connection.
- Do not open the memory card slot cover and do not remove the memory card. - Do not disconnect the USB cable. - Do not turn off the camcorder or the computer. - Do not change the position of the switch or the operating mode.
ALL IMAGES], [ NEW IMAGES], TRANSFER ORDERS]: • The images are transferred and displayed on the computer. • The camcorder returns to the transfer menu once the transfer is complete. • To cancel the transfer, press SELECT & TRANSFER] F YOU SELECT...
71). Canon printers: SELPHY CP and SELPHY DS printers and PIXMA printers marked with the PictBridge logo. Connecting the Camcorder to the Printer Insert the memory card containing the still images you want to print.
The print effect can be used with printers compatible with the Image Optimize function to achieve higher quality prints. Select [ON], [OFF] or [DEFAULT]. Canon PIXMA/SELPHY DS printers: You can also select [VIVID], [NR] and [VIVID+NR]. Number of Copies] Select 1-99 copies.
O CANCEL THE PRINTING Press while printing. A confirmation dialog appears. Select [OK] and press With Canon’s PictBridge compatible printers, the printing will stop immediately (even if not completed) and the paper will be fed through. RINTING ERRORS If an error occurs during the printing process, an error message appears ( - Canon’s PictBridge compatible printers:...
The trimming setting applies only to one image. The trimming setting is canceled in the following cases: - When you turn off the camcorder. - When you disconnect the USB cable. - When you expand the trimming frame beyond its maximum size.
Page 72
To cancel the print order set ( ) the number of copies to 0. **After closing the menu the camcorder returns to the index screen. Erasing All Print Orders MENU MENU CARD OPERATIONS PRINT ORD.ALL ERASE...
Additional Information Trouble? Troubleshooting If you have a problem with your camcorder, refer to this checklist. Consult your dealer or a Canon Service Center if the problem persists. Power Source Problem • Camcorder will not turn on. • The camcorder switches off by itself.
Page 74
Trouble? Problem Video noise appears on screen. When using the camcorder in a room where a plasma TV is Video noise appears on the TV screen. The tape stops during record pause or playback pause. Recording Problem Image will not appear on the screen.
Page 75
Video heads are dirty. Clean the video heads. Set [AV DV] to [OFF]. Check again that the camcorder is properly connected to the TV. When connecting the camcorder to an HDTV using the CTC-100 Component Cable, make sure to select the correct specification for the [COMP.OUT] setting.
TAPE END Tape reached the end. Rewind the tape or replace the cassette. Solution Disconnect the USB cable and turn off the camcorder and the printer. After a short while, turn them on again, set the camcorder to mode and restore the connection.
Page 77
The digital device connected with the DV cable is incompatible with SUPPORTED the camcorder. PLAYBACK STD LOCKED Current camcorder settings do not match the HDV/DV standard of INCOMPATIBLE VIDEO the video input signal. Change the [PLAYBACK STD] setting to INPUT match the video input signal.
Page 78
Trouble? Direct Print Related Messages NOTES About Canon PIXMA/SELPHY DS Printers: If the printer’s error indicator flashes or an error message appears on the printer’s operation panel, refer to the printer’s instruction manual. Message PAPER ERROR There is a problem with the paper. The paper is not correctly loaded or the paper size is wrong.
Do’s and Don’ts Handling Precautions Camcorder Do not carry the camcorder by the LCD panel. Be careful when closing the LCD panel. Do not leave the camcorder in places subject to high temperatures (like the inside of a car under direct sunlight), or high humidity.
Page 80
Image data may be corrupted or lost due to memory card defects or exposure to static electricity. Canon Inc. makes no warranties for corrupted or lost data. Do not turn off the camcorder, disconnect the power source or remove the memory card while the CARD access indicator is flashing.
Page 81
3 months. To recharge the built-in lithium battery: Connect the compact power adapter to the camcorder and leave it connected for 24 hours with the power switch set to...
(Canon Digital Videocassette HDVM-E63PR, etc.) and cleaning the video heads frequently with the Canon DVM-CL Digital Video Head Cleaning Cassette or a commercially available dry cleaning cassette. Do not use wet type cleaning cassettes as this may damage the camcorder.
General Information General Information System Diagram (Availability differs from area to area) WS-20 Wrist Strap SS600/SS650 Shoulder Strap MiniDV Video cassette WL-D87 Wireless Controller WD-H37C Wide Converter TL-H37 Tele Converter FS-H37U Filter Set SC-2000 Soft Carrying Case CG-300 Battery Charger STV-250N Stereo Video Cable DTC-100 D Terminal Cable CTC-100 Component Cable...
This product is designed to achieve excellent performance when used with genuine Canon accessories. Canon shall not be liable for any damage to this product and/or accidents such as fire, etc., caused by the malfunction of non-genuine Canon accessories (e.g., a leakage and/or explosion of a battery pack).
Page 86
Pass the ends through the strap mount and adjust the length of the strap. WS-20 Wrist Strap Use this for extra additional protection for active shooting. SC-2000 Soft Carrying Case A handy camcorder bag with padded compartments and plenty of space for accessories.
This mark identifies genuine Canon video accessories. When you use Canon video equipment, we recommend Canon-brand accessories or products bearing the same mark. Product Codes Provided Accessories CA-570 Compact Power Adapter BP-310 Battery Pack WL-D87 Wireless Controller STV-250N Stereo Video Cable...
General Information Specifications HV10 System Video Recording System Audio Recording System Television System Image Sensor Compatible Tapes Tape Speed Maximum Recording Time (60 min. tape) LCD Screen Viewfinder Microphone Lens Lens Configuration Filter Diameter AF system Minimum Focusing Distance White Balance...
Page 89
* This camcorder has been tested with miniSD cards up to 1 GB. Performance cannot be guaranteed for all miniSD cards. ** This camcorder supports Exif 2.2 (also called “Exif Print”). Exif Print is a standard for enhancing the communication between camcorders and printers. By connecting to an Exif Print-compliant printer, the camcorder’s image data at the time of shooting is used and optimized, yielding extremely high quality prints.
9 Point AiAF ..... 44 Abroad, using the camcorder ..83 AEB - Auto exposure bracketing ..49 AF-assist lamp .
Page 91
Memory card ....20, 80 MENU ..... . . 22, 31 Mini video light .
Page 92
FOR THE UNITED STATES The warranty set forward below is given by Canon U.S.A., Inc. with respect to equipment purchased in the United States. The limited warranty is only effective upon presentation of your Bill of Sale or other proof of purchase.
Page 93
Video Heads which will be exchanged for a period of 3 months from the date of purchase. Labour: For a period of one year from the date of original purchase, labour will be provided free of charge by our Canon Service Facilities in Canada.
