Summary of Contents for Canon HV30E

  • Page 1: Instruction Manual

    PUB.DIE-299 HD Camcorder English Instruction Manual Introduction Preparations Basic Functions Advanced Functions Editing Mini Digital Functions Video Cassette External Please read also the following instruction manual Connections Digital Video Software (electronic version on PDF file). Version 23 Instruction Manual • Digital Video Software Additional Information...
  • Page 2: Important Usage Instructions

    For more information about where you can drop off your waste equipment for recycling, please contact your local city office, waste authority, approved WEEE scheme or your household waste disposal service. For more information regarding return and recycling of WEEE products, please visit www.canon-europe.com/environment. (EEA: Norway, Iceland and Liechtenstein)
  • Page 3: Enjoying High-Definition Video

    Enjoying High-Definition Video Preserve your most treasured memories, be it unforgettable scenery or cherished moments spent with family and friends, with high-definition video recordings of a quality second only to actually being there. What is High-Definition Video? High-definition video (HDV) allows you to record video of unparalleled high quality on regular miniDV tapes.
  • Page 4: Table Of Contents

    Table of contents Introduction Enjoying High-Definition Video ............... 3 About this Manual ................... 7 Getting to Know the Camcorder Supplied Accessories..................9 Components Guide ..................10 Screen Displays .................... 13 Preparations Getting Started Charging the Battery Pack ................16 Inserting and Removing a Tape ..............18 Inserting and Removing a Memory Card ............
  • Page 5 System Setup (Beep, etc.) ..............42 Date/Time Setup .................42 Using the Recording Programs Recording Programs..................43 Giving a Cinematic Look to your Recordings ..........44 Flexible Recording: Changing the Aperture and Shutter Speed....44 Special Scene: Recording Programs to Match Special Conditions ....46 Adjusting the Picture: Exposure, Focus and Color Manual Exposure Adjustment and Automatic Backlight Correction ....47 Manual Focus Adjustment ................47 Focus Assist Functions..................48...
  • Page 6: Additional Information

    Print Orders....................81 Additional Information Trouble? Troubleshooting .................... 83 List of Messages ................... 87 Do’s and Don’ts Handling Precautions..................90 Maintenance/Others..................93 Cleaning the Video Heads ................93 Using the Camcorder Abroad ............... 94 General Information System Diagram ................... 95 Optional Accessories ..................
  • Page 7: About This Manual

    About this Manual Thank you for purchasing the Canon HV30. Please read this manual carefully before you use the camcorder and retain it for future reference. Should your camcorder fail to operate correctly, refer to the Troubleshooting table ( 83).
  • Page 8 About the Joystick and the Joystick Guide The mini joystick allows you to control many of the camcorder’s operations and to make selections and changes in the camcorder’s menus. Push the joystick up, down, left or right ) to select an item or change Press the joystick itself ( ) to save the settings.
  • Page 9: Getting To Know The Camcorder

    Getting to Know the Camcorder Supplied Accessories Getting to Know the Camcorder CA-570 Compact Power BP-2L13 Battery Pack WL-D87 Wireless Lithium Button Battery Adapter Controller CR2025 for Wireless (incl. power cord) Controller CTC-100/S Component STV-250N Stereo Video IFC-300PCU DIGITAL VIDEO Cable Cable USB Cable...
  • Page 10: Components Guide

    Getting to Know the Camcorder Components Guide Left side view FOCUS lever ( BLC (backlight correction) button ( FOCUS button ( 47, 48) Speaker DISP. (display) button ( 55)/ LCD backlight button (long press) ( LIGHT button ( 58)/ (print/share) button ( 76, 79) USB terminal ( CARD access indicator (...
  • Page 11 Getting to Know the Camcorder LCD screen ( Back view Dioptric adjustment lever ( Viewfinder ( Terminal cover START/STOP button ( switch ( Power indicator ( Joystick ( FUNC. button ( 21, 33) RESET button ( Serial number/Battery attachment unit DC IN terminal ( HDV/DV terminal ( 65, 74)
  • Page 12 Getting to Know the Camcorder Wireless Controller WL-D87 START/STOP button ( CARD –/+ buttons ( DATE SEARCH buttons ( START/ STOP PHOTO ZOOM button ( –/ button ( CARD PAUSE button ( SLOW button ( DATE SEARCH ZERO SET MEMORY button ( PLAY DISP.
  • Page 13: Screen Displays

    Getting to Know the Camcorder Screen Displays Recording Movies Recording program ( White balance ( Image effect ( Digital effects ( Still image quality/size (simultaneous recording) ( Microphone attenuator ( Self timer ( Recording reminder Instant AF ( 35)/Manual focus ( Recording standard (HDV or DV) ( DV recording mode ( Tape operation...
  • Page 14 Getting to Know the Camcorder Recording reminder Remaining battery charge The camcorder counts from 1 to 10 seconds when you start recording. This is helpful to avoid scenes that are too short. • When “ ” starts flashing in red, replace Tape operation the battery pack with a fully charged one.
  • Page 15 Getting to Know the Camcorder Playing Movies Tape operation Time code (hours : minutes : seconds : frames) Remaining tape Data code ( Search function display END SEARCH ( 30)/ DATE SEARCH ( Quality/size for capturing still images ( Audio level indicator ( Viewing Still Images Image number ( Current image / Total number of images...
  • Page 16: Getting Started

    Getting Started Preparations Getting Started Getting Started Connect the power cord to the compact power adapter. Plug the power cord into a power Charging the Battery Pack outlet. Connect the compact power adapter The camcorder can be powered with a to the camcorder’s DC IN terminal.
  • Page 17 Getting Started The charging time will vary depending on the NOTES surrounding temperature and the battery pack’s initial charge condition. In cold places, the The CHARGE indicator also serves as a effective usage time of the battery will rough estimate of the battery charge status. decrease.
  • Page 18: Inserting And Removing A Tape

    Getting Started Inserting and Removing a Tape IMPORTANT Use only videocassettes marked with the Do not interfere with the cassette logo. To record in HDV standard we compartment while it is opening or closing recommend using tapes specifically automatically, or attempt to close the cover designed for high definition.
  • Page 19: Preparing The Camcorder

    Getting Started IMPORTANT The Wireless Controller Make sure to initialize all memory cards Inserting the Battery before using them with this camcorder for the (Lithium Button Battery CR2025) first time ( 64). Memory cards have front and back sides that are not interchangeable.
  • Page 20: Adjusting The Lcd Screen

    Getting Started LCD Backlight Adjusting the LCD Screen You can set the brightness of the LCD screen to normal or bright. Rotating the LCD Panel Open the LCD panel 90 degrees. You can rotate the panel 90 degrees downward. 180° Hold pressed down for more DISP.
  • Page 21: Using The Menus

    Using the Menus the screen (such as the icon, Using the Menus Using the Menus small arrows, etc.). Many of the camcorder’s functions can be adjusted from the menus that open after Selecting an Option from the Setup pressing the FUNC. button ( FUNC.
  • Page 22: First Time Settings

    First Time Settings First Time Settings First Time Settings Changing the Time Zone Default value Changing the Language DATE/TIME SETUP Options T.ZONE/DST PARIS FUNC. Press FUNC. Select ( ) the icon and press Default value ) to open the setup menus. Select ( ) [DATE/TIME SETUP] DISPLAY SETUP/...
  • Page 23: Setting The Date And Time

    First Time Settings Setting the Date and Time DATE/TIME SETUP DATE/TIME 1.JAN.2008 12:00 AM FUNC. Press FUNC. Select ( ) the icon and press ) to open the setup menus. Select ( ) [DATE/TIME SETUP] and press ( Select ( ) [DATE/TIME] and press The first field of the date will be indicated with blinking up/down...
  • Page 24: Basic Functions Recording

    Recording O REVIEW THE LAST SCENE RECORDED Basic Functions Recording Recording Recording Movies Before You Begin Recording Make a test recording first to check if the camcorder operates correctly. If necessary, clean the video heads ( 93). Set the mode switch to If the joystick guide does not appear on screen, press ( ) to display it.
  • Page 25: Recording Still Images

    Recording become distorted or it may not be recorded at Recording Still Images the actual levels. This is not a malfunction. About the Power Save mode: To save power when the camcorder is powered by a battery Before using a memory card for the first pack, the camcorder will automatically shut off if time, be sure to initialize it with this left without any operations for 5 minutes...
  • Page 26: Zooming

    Recording 10x Optical Zoom IMPORTANT Move the zoom lever toward W to Observe the following precautions while the zoom out (wide-angle). Move it toward card access display ( ) appears on screen T to zoom in (telephoto). and when the CARD access indicator is on or You can also change the zoom speed flashing.
  • Page 27: Playback

    Playback Holding the lock button pressed Playback Playback down, set the switch to PLAY. Move the switch to Playing Back Movies (tape). Play back the tape on the LCD display or Locate the point where you want to close the LCD panel to use the begin the playback.
  • Page 28: Adjusting The Volume: Speaker And Headphones

    Playback During the playback of HDV recordings: Even though their icons will appear on screen, the following special playback modes are not available. - Reverse slow playback - Frame reverse - Double speed playback (forward or reverse) To protect the tape and video heads, the camcorder will enter the stop mode ( ) if left in playback pause (...
  • Page 29 Playback Press FUNC. Returning to a Pre-marked Position appears. Note that if the joystick guide appears on the screen, it will If you wish to return to a particular scene conceal the icon. Press ( ) to later, mark the point with the zero set hide the joystick guide.
  • Page 30: Locating The End Of The Last Scene

    Playback Locating the End of the Last Scene Locating Scenes by Recording Date After playing back a tape, use this You can locate the change of the date/ function to locate the end of the last time zone with the date search function. scene recorded in order to continue recording from that point.
  • Page 31: Viewing Still Images

    Playback Viewing Still Images IMPORTANT Observe the following precautions while the card access display appears on screen, and when the CARD access indicator is on or flashing. Failing to do so may result in permanent data loss. - Do not open the memory card slot cover and do not remove the memory card.
  • Page 32: Magnifying The Playback Image

    Playback O SKIP STILL IMAGES return to moving between single images. If the joystick guide does not appear Move the zoom lever toward T. on screen, press ( ) to display it. The index screen closes and the Push the joystick ( ) toward selected image is displayed.
  • Page 33: Menu Options Lists

    Menu Options Lists Advanced Functions Image effect Menu Options Lists Menu Options Lists Menu items not available appear grayed out. For details about how to select an Mode switch: item, refer to Using the Menus ( 21). IMAGE EFFECT OFF], VIVID], [ NEUTRAL], LOW SHARPENING],...
  • Page 34 Menu Options Lists When [HD STANDARD] is set to Recordings made in [ DV(NORMAL)]: [ S S.FINE/640x480], DV(NORMAL)]: [ S FINE/640x480], STILL I.REC OFF], [ S NORMAL/640x480] [M 1440x1080], [S 640x480] Quality: SUPER FINE], [ FINE], SLIDESHOW NORMAL] Still image size/quality [CANCEL], [START] PROTECT Size:...
  • Page 35: Setup Menus

    Menu Options Lists The digital zoom indicator will appear in Setup Menus light blue from 10x up to 40x and dark blue from 40x up to 200x. Camera Setup (Digital Zoom, Image Stabilizer, etc.) CAMERA SETUP The digital zoom cannot be used with the [ NIGHT] recording program.
  • Page 36: Recording/Video Input Setup (Hd Standard, Dv Recording Mode, Etc.)

    Menu Options Lists Recording/Video Input Setup (HD Standard, DV Recording Mode, etc.) REC/IN SETUP AF AST LAMP HD STANDARD AUTO], [ OFF] FOCUS PRI. HDV], [ HDV(PF25)], DV(WIDE)], [ DV(NORMAL)] Selects the video standard of the recording and in DV standard also the Mode switch: aspect ratio.
  • Page 37 Menu Options Lists DV REC MODE WIND SCREEN STD PLAY], [ LONG PLAY] Mode switch: AUTO], [ When [HD STANDARD] is set to one of the DV standards, you can change the The camcorder automatically reduces the video quality and as a result, also the background sound of wind when recording time available on the tape.
  • Page 38: Card Operations (Initialization, Erase All Images, Etc.)

    Menu Options Lists FILE NOS. ERASE ALL IMAGES [NO], [YES] RESET], [ CONTINUOUS] Select the image numbering method to be INITIALIZE used when you insert a new memory card. Images are automatically assigned consecutive image numbers from 0101 to [CANCEL], [INITIALIZE], [COMPL.INIT.] 9900, and stored in folders containing up to 100 images.
  • Page 39 Menu Options Lists This setting will be unavailable while The camcorder will retain the audio the camcorder is connected to an balance adjustment; however if you turn external device using the HDMI cable. off the camcorder, [AUDIO OUT] will be reset to [ STEREO1].
  • Page 40 Menu Options Lists This setting will be unavailable while Select the [PLAYBACK STD] and [DV the camcorder is connected to an OUTPUT] settings according to the external device using the HDMI cable. specifications you want to use for playback on a high-definition TV. Refer to DV OUTPUT the table below.
  • Page 41: Display Setup (Lcd Brightness, Language, Etc.)

    Menu Options Lists in order to allow you to focus manually Display Setup (LCD Brightness, Language, etc.) DISPLAY SETUP more easily. Using the assist functions will not affect BRIGHTNESS the recordings on the tape or memory card. AUDIO LEVEL Adjust ( ) the brightness of the LCD display with the joystick.
  • Page 42: System Setup (Beep, Etc.)

    Menu Options Lists LANGUAGE POWER SAVE [DEUTSCH], [ENGLISH], [ESPAÑOL], ON], [ OFF] [FRANÇAIS], [ITALIANO], [POLSKI], In order to save power when the ], [TÜRKÇE], [ camcorder is powered by a battery pack, ], [ ], [ it will automatically shut off if left without ], [ ], [ ], [...
  • Page 43: Using The Recording Programs

    Using the Recording Programs Recording Programs Using the Recording Programs Auto The camcorder adjusts the focus, exposure and other settings automatically, allowing you to just point and shoot. : Flexible Recording Programs ( PROGRAM AE] SHUTTER-PRIO. AE] APERTURE-PRIO. AE] The camcorder sets the You select the shutter You select the aperture aperture and shutter speed.
  • Page 44: Giving A Cinematic Look To Your Recordings

    Using the Recording Programs Mode switch: Giving a Cinematic Look to your Set the recording program to [ CINE Recordings MODE], as described in the previous section. Give your recordings a cinematic look by using the [ CINE MODE] recording MENU FUNC.
  • Page 45 Using the Recording Programs Shutter speed guidelines SHUTTER-PRIO.AE] Set the shutter speed value. The 1/6, 1/12, 1/25 camcorder automatically sets the with cinema effect appropriate aperture value. Use a high HDV(PF25)] shutter speed to record fast moving 1/6, 1/12, 1/25 subjects or a slow shutter speed to add 1/2, 1/3, 1/6, 1/12, 1/25 motion blur, emphasizing the feel of...
  • Page 46: Special Scene: Recording Programs To Match Special Conditions

    Using the Recording Programs SHUTTER-PRIO.AE] NOTES - If you use a slow shutter speed in dark places, you can obtain a brighter image, but the image Do not change the position of the mode quality may be lower, and the autofocus may switch while recording, as the brightness of the not work well.
  • Page 47: Adjusting The Picture: Exposure, Focus And Color

    Adjusting the Picture: Exposure, Focus and Color Mode switch: (except for the Adjusting the Picture: Adjusting the Picture: Exposure, Focus and Color [ FIREWORKS] recording program). Exposure, Focus and Color Manual Exposure Adjustment and Automatic Backlight Correction At times, backlit subjects may appear too If the joystick guide does not appear dark (underexposed) or subjects under on screen, press (...
  • Page 48: Focus Assist Functions

    Adjusting the Picture: Exposure, Focus and Color Fast moving subjects Adjust the zoom. In autofocus mode, keep FOCUS pressed down for more than 2 seconds. Through wet windows • appears. • Pressing again will return the FOCUS camcorder to autofocus. •...
  • Page 49: White Balance

    Adjusting the Picture: Exposure, Focus and Color TUNGSTEN] NOTES For recording under tungsten and tungsten Using the focus assist functions will not affect type (3-wavelength) fluorescent lighting. the recordings on the tape or memory card. FLUORESCENT] When you start recording, the assist functions will be canceled.
  • Page 50: Image Effects

    Adjusting the Picture: Exposure, Focus and Color NEUTRAL] NOTES Tones down the contrast and color When you select the custom white balance saturation. SET]: LOW SHARPENING] - Make the white balance adjustment in a place with sufficient light. Records subjects with softened outlines. - Set [D.ZOOM] to [ OFF] ( 35).
  • Page 51: Still Image Recording Options

    Still Image Recording Options On a 512 MB memory card Still Image Recording Still Image Recording Options Options Image Size 1920x1080 1,040 2048x1536 Selecting the Size and Quality of Still 1440x1080 1,370 Images 848x480* 1,775 2,515 5,030 640x480 2,320 3,355 6,040 Still images are recorded on the memory card using the JPEG (Joint Photographic...
  • Page 52: Capturing A Still Image While Recording Movies

    Still Image Recording Options When printing still images, use the following guidelines as a reference for selecting the print FUNC. size. Image Size Recommended Use 2048x1536 To print photos up to A4 size. Icon of the currently selected Still Image Simultaneous 1440x1080 To print photos up to L FUNC.
  • Page 53: Light Metering Mode

    Still Image Recording Options POINTS TO CHECK POINTS TO CHECK Set [TV TYPE] to [ WIDE TV] before Mode switch: (except for the Special using this function ( 38). Scene recording programs) Options Default value FUNC. EVALUATIVE] Appropriate for standard shooting conditions, including backlit scenes.
  • Page 54: Continuous Shooting And Exposure Bracketing

    Still Image Recording Options POINTS TO CHECK NOTES In the [ FIREWORKS] recording program the focus priority is automatically set to [ OFF]. Mode switch at : The focus priority cannot be turned off. Mode switch at : You can turn off the focus priority and you can also select the Continuous Shooting and Exposure AF (autofocus) mode to be used.
  • Page 55: Other Functions

    Other Functions Other Functions Other Functions FUNC. On-Screen Displays The camcorder keeps a data code Icon of the currently selected containing the date and time and other FUNC. Drive Mode camera data (shutter speed, aperture, etc.) registered at the time of recording. Desired option You can select the data to be displayed.
  • Page 56 Other Functions Selecting the Data Code Reading the Histogram Display You can select the data code to be When viewing still images you can displayed when playing back movies. display the histogram and the icons of all the functions used at the time of recording.
  • Page 57: Flash

    Other Functions Press , first halfway to PHOTO Flash activate the autofocus and then fully to record the still image. You can use the built-in flash for recording still images in dark places. The VFL-1 V O USE THE OPTIONAL IDEO LASH IGHT...
  • Page 58: Mini Video Light

    Other Functions - The brightness of the AF-assist lamp could be Self Timer an inconvenience. Consider turning it off in public places such as restaurants or theaters. POINTS TO CHECK Mini Video Light : Set the camcorder in record You can turn on the mini video light pause mode.
  • Page 59: Audio Recording Level

    Other Functions Adjust ( ) the audio level as Audio Recording Level necessary. • Push the joystick ( ) toward You can adjust the audio recording level raise the audio recording level or push for the built-in or for an external it ( ) toward to lower it.
  • Page 60 Other Functions THER MICROPHONES You can also use commercially available FUNC. microphones not compatible with the advanced accessory shoe, by connecting the external microphone to the MIC terminal. Use commercially available MENU FUNC. condenser microphones with their own power supply and a cable no longer than DISPLAY SETUP/ 3 m.
  • Page 61: Digital Effects

    Other Functions Setting Digital Effects POINTS TO CHECK FUNC. Icon of the currently selected BLK&WHT], [ SEPIA] FUNC. Digital Effect only. Mode switch: Desired digital effect.* FUNC. Options Default value * You can preview the effect on the screen D.EFFECT OFF] before pressing FUNC.
  • Page 62 Other Functions Push the joystick ( ) toward D.EFFECTS : ...in record pause mode, then press to start recording with START/STOP a fade in. : ...in playback pause mode, then press to fade in and start the playback. Push the joystick ( ) toward D.EFFECTS : ...while recording, then press...
  • Page 63: Still Image Options

    Still Image Options While reviewing the image immediately Editing Functions Still Image Options Still Image Options after recording: Push the joystick ( ) toward Select ( ) [ERASE] and press Erasing Still Images Erasing All Images IMPORTANT Protected images will not be deleted even Be careful when erasing images.
  • Page 64: Initializing The Memory Card

    Still Image Options Initialize all memory cards before using them PROTECT FUNC. with this camcorder. Press ( PROTECT]: The image selection screen appears. FUNC. ROM THE IMAGE SELECTION SCREEN Select ( ) the still image you MENU FUNC. want to protect. Press ( ) to protect the still CARD OPERATIONS...
  • Page 65: Connecting To A Tv Or Vcr

    Connecting to a TV or VCR Connecting to a TV or VCR External Connections Connecting to a TV or VCR Connection Diagrams Turn off all the devices when making the connections and refer also to the instruction manual of the connected device. Terminal COMPONENT OUT Terminal The component video terminal is for video only.
  • Page 66 Connecting to a TV or VCR High Definition TV Sets (HDTV) Terminal on the Connected Terminal on the Camcorder Connecting Cable Device Output connection (Signal Flow ) to an HDTV with component video input terminals. Pr/Cr Pb/Cb Blue CTC-100/S Component Cable (Supplied) Green AUDIO...
  • Page 67 Connecting to a TV or VCR Standard Definition TV Sets Terminal on the Terminal on the Connecting Cable Camcorder Connected Device Output connection (Signal Flow ) to a TV with a DV (IEEE1394) terminal. Input connection (Signal Flow ) from a TV or other digital video source with a DV (IEEE1394) output.
  • Page 68: Playback On A Tv Screen

    Connecting to a TV or VCR Playback on a TV Screen NOTES The quality of the playback picture will Turn off all the devices before starting the connections. vary depending on the connected TV and Sound from the built-in speaker will be muted the type of connection used.
  • Page 69: Recording To A Vcr Or Digital Video Recorder

    Connecting to a TV or VCR - There will be no video or audio output from POINTS TO CHECK the HDMI OUT terminal while there is a video input connection to the HDV/DV terminal or the terminal. - To output audio dubbed later on a tape Change the following settings as through the HDMI OUT terminal, set [AUDIO OUT] to [...
  • Page 70: Analog Line-In Recording

    Connecting to a TV or VCR Recording - Proper operation cannot be guaranteed for all digital devices equipped with a DV terminal. If the operation does not work, use the AV/ This camcorder: Load the recorded terminal. cassette. You cannot record to an external device using Connected device: Load a blank the HDMI connection –connection type –.
  • Page 71: Digital Video Dubbing

    Connecting to a TV or VCR Set [PLAYBACK STD] to [ AUTO] 38) before making the connections. Connecting Connect the camcorder to the video input source using the digital connection –connection type 65)– shown in the previous section Connection When the scene you wish to record Diagrams.
  • Page 72: Analog/Digital Conversion

    Connecting to a TV or VCR Recording starts. During recording: If you try to record from software that contains copyright control While recording, press signals for protection of software, pause the recording. “COPYRIGHT PROTECTED DUBBING In record pause, press again to RESTRICTED”...
  • Page 73 Connecting to a TV or VCR IMPORTANT Depending on the signal sent from the connected device, the conversion from analog to digital signals might not work properly (e.g., signals that include copyright protective signals or anomalous signals such as ghost signals). Usually, leave [AV DV] set to the default setting [...
  • Page 74: Connecting To A Computer

    Connecting to a Computer Connecting to a Computer Connecting to a Computer PC Connection Diagrams USB Terminal Open the LCD panel cover to access. HDV/DV Terminal • Check the type and orientation of the terminal and make sure you connect the DV cable properly.
  • Page 75: Transferring Video Recordings

    Connecting to a Computer Connecting Transferring Video Recordings Start the computer. You can transfer recordings to a computer Set the camcorder to using the HDV/DV terminal. mode. Connect the camcorder to the computer using the digital connection –connection type Equipment and System Requirements 74)–...
  • Page 76: Transferring Still Images - Direct Transfer

    Connecting to a Computer Transferring Still Images – Direct IMPORTANT Transfer When the CARD access indicator is on or flashing do not perform the following actions. With the supplied USB cable and the Doing so may result in permanent data loss. Digital Video Software, you can transfer - Do not open the memory card slot cover and still images to a computer simply by...
  • Page 77: Transfer Orders

    Connecting to a Computer Select ( ) a transfer option and SELECT & TRANSFER] press Allows you to select the still image you Select ( ) the image you want to want to transfer to the computer. transfer and press WALLPAPER] •...
  • Page 78: Connecting To A Printer

    Press ( 81). : The image selection screen Canon printers: SELPHY printers of the CP, appears. DS and ES series and inkjet printers marked with the PictBridge logo. ROM THE IMAGE SELECTION SCREEN...
  • Page 79: Selecting The Print Settings

    Image Optimize options vary depending on your printer function to achieve higher quality prints. model. Select [ON], [OFF] or [DEFAULT]. Canon inkjet printers and SELPHY DS printers: Trimming settings ( You can also select [VIVID], [NR] and Paper settings [VIVID+NR].
  • Page 80 Printing Multiple Images on the Same Sheet When using Canon printers, you can print the same still image multiple times on the same sheet of paper. Use the following table as a guideline for the recommended PAGE LAYOUT] settings depending on the [ PAPER SIZE] setting.
  • Page 81: Trimming Settings

    Connecting to a Printer Move ( ) the trimming - Images recorded with the camcorder but edited on a computer. frame. - Images whose file names were changed. After setting the trimming frame, - Images not recorded with this camcorder. press to return to the print FUNC.
  • Page 82 Connecting to a Printer Select ( PRINT] and press FUNC. • The print setting menu appears. • The error message “SET PRINT ORDER” appears if you connect a printer with direct print function and PRINT ORDER FUNC. select [ PRINT] without having set any print orders beforehand.
  • Page 83: Additional Information Trouble

    Trouble? Additional Information Troubleshooting Trouble? If you have a problem with your camcorder, refer to this checklist. Consult your dealer or a Canon Service Center if the problem persists. Power Source Problem Solution • Camcorder will not turn on. Battery pack is exhausted. Replace or charge the battery pack.
  • Page 84 Trouble? Problem Solution Video noise appears on screen. When using the camcorder in a room where a plasma TV is – located, keep a distance between the camcorder and the plasma TV. Video noise appears on the TV When using the camcorder in a room where a TV is located, –...
  • Page 85 Trouble? Playback Problem Solution During playback there is video Video heads are dirty. Clean the video heads. noise. Pressing the playback button Load a cassette. does not start playback. Set the camcorder to Tape reached the end (“ END” appears on the screen). Rewind the tape.
  • Page 86 Trouble? Memory Card Operation Problem Solution Memory card cannot be Memory card was not facing the correct direction. Turn the inserted. memory card over and reinsert it. Cannot record on the memory Memory card is full. Erase still images to free some space or card.
  • Page 87: List Of Messages

    Trouble? List of Messages Some error messages will disappear after being displayed for about 4 seconds. Message Explanation/Solution SET THE TIME ZONE, You have not set the time zone, date and time. This message DATE AND TIME appears each time you turn the power on until you set the time zone, date and time.
  • Page 88 Direct Print Related Messages NOTES About Canon inkjet printers and SELPHY DS Printers: If the printer’s error indicator flashes or an error message appears on the printer’s operation panel, refer to the printer’s instruction manual. Message Explanation/Solution PAPER ERROR There is a problem with the paper.
  • Page 89 Trouble? Message Explanation/Solution PRINT ORDER No still image on the memory card has been marked with a print order. READJUST TRIMMING You changed the print style after you set the trimming settings. PRINTER ERROR Cancel printing. Turn the printer off and then on again. Check the printer status.
  • Page 90: Do's And Don'ts

    Do’s and Don’ts Handling Precautions Do’s and Don’ts Battery Pack DANGER! Camcorder Treat the battery pack with care. • Keep it away from fire (or it might Do not carry the camcorder by the LCD explode). panel. Be careful when closing the LCD •...
  • Page 91 Canon Inc. makes no Return cassettes to the case and store warranties for corrupted or lost data. them upright. Rewind tapes from time to Do not turn off the camcorder, time if they are stored for a long time.
  • Page 92 Do’s and Don’ts Do not attach any labels or stickers on Built-in Rechargeable Lithium Battery the memory card. When you erase image files or initialize The camcorder has a built-in the memory card, only the file allocation rechargeable lithium battery to keep the table is altered and the data itself is not date/time and other settings.
  • Page 93: Maintenance/Others

    30 °C. the Canon DVM-CL Digital Video Head Cleaning Cassette or a commercially available dry cleaning cassette. Do not use wet type cleaning cassettes Condensation as this may damage the camcorder.
  • Page 94: Using The Camcorder Abroad

    When a cold room is heated rapidly supply between 100 and 240 V AC, 50/60 Hz. Consult the Canon Service Center for information on plug adapters for overseas use. Playback on a TV Screen You can only play back your recordings on TVs compatible with the PAL system.
  • Page 95: General Information

    General Information System Diagram General Information (Availability differs from area to area) WS-20 Wrist Strap BP-2L13, BP-2L14, CB-2LWE SS-600/SS-650 NB-2LH, BP-2L24H Battery Charger Shoulder Strap Battery Pack MiniDV Video cassette BP-2L13, BP-2L14, NB-2LH, BP-2L24H Battery Pack WL-D87 Wireless Controller CA-570 Compact Power Adapter WD-H43 Wide-converter...
  • Page 96: Optional Accessories

    This product is designed to achieve excellent performance when used with genuine Canon accessories. Canon shall not be liable for any damage to this product and/or accidents such as fire, etc., caused by the malfunction of non-genuine Canon accessories (e.g., a leakage and/or explosion of a battery pack).
  • Page 97 General Information FS-43U II Filter Set Neutral density and MC protector filters help you to control difficult lighting conditions. VFL-1 Video Flash Light This video flash light allows you to record still images and movies even at night or in dark places.
  • Page 98 SC-2000 Soft Carrying Case A handy camcorder bag with padded compartments and plenty of space for accessories. This mark identifies genuine Canon video accessories. When you use Canon video equipment, we recommend Canon-brand accessories or products bearing the same mark.
  • Page 99: Specifications

    More than 100 lx Image Stabilization Optical You can play back with this camcorder tapes recorded in HDV standard with a Canon XL H1, XH G1 or XH A1 (both, 50i and 25F mode). Video shot with the [ HDV(PF25)] standard will be recorded on the tape as 50i.
  • Page 100 General Information File Format Design rule for Camera File system (DCF), Exif 2.2 compliant, DPOF compliant Image Compression Method JPEG (compression: Super Fine, Fine, Normal) This camcorder has been tested with miniSD cards up to 2 GB. Performance cannot be guaranteed for all miniSD cards.
  • Page 101: Index

    General Information Index Data code ..... . . 55 16:9 aspect ratio ....36 Date and time .
  • Page 102 General Information Reviewing - Movies (Record review) . . .24 Reviewing - Still images ... .37 Language ..... . . 22 LCD backlight .
  • Page 103 General Information White balance ....49 Wide angle ..... . 26 Wide TV (16:9) .
