Brief Operating Instructions
Nivector FTI26
Capacitance
Point level switch for powdered and fine-grained
solids
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet:
www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services
Advertisement
Table of Contents
Related Manuals for Endress+Hauser Nivector FTI26
Summary of Contents for Endress+Hauser Nivector FTI26
- Page 1 Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation: Available for all device versions via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App...
- Page 2 Nivector FTI26 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
-
Page 3: Table Of Contents
Nivector FTI26 Table of contents Table of contents About this document ............. . 4 Symbols used . -
Page 4: About This Document
About this document Nivector FTI26 About this document Symbols used 1.1.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. -
Page 5: Symbols For Graphics
• W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Standard documentation • TI01384F → Nivector FTI26, IO-Link •... -
Page 6: Registered Trademarks
Basic safety instructions Nivector FTI26 Registered trademarks is a registered trademark of the IO-Link company group. Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. -
Page 7: Operational Safety
It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. IT security Our warranty is valid only if the device is installed and used as described in the Operating Instructions. -
Page 8: Product Structure
Product description Nivector FTI26 Product structure A0035860 1 Product structure of Nivector FTI26, connection and housing covers optional Valve plug M12 plug Protection cover (for hazardous areas) Plastic housing cover with LED for valve plug, IP65 Plastic housing cover with LED, IP65/67... -
Page 9: Incoming Acceptance And Product Identification
Nivector FTI26 Incoming acceptance and product identification A0035936 2 Product structure of Nivector FTI26 IO-Link, connection and housing covers optional M12 plug Protection cover (for hazardous areas) Plastic housing cover with LED, IP65/67 Metal housing cover, IP66/68/69 Housing Process connection G 1"... -
Page 10: Product Identification
Incoming acceptance and product identification Nivector FTI26 DELIVERY NOTE A0035872 Do the data on the nameplates correspond to the order specifications on the delivery note? If one of these conditions is not satisfied, contact your Sales Center. Product identification The measuring device can be identified in the following ways: •... -
Page 11: Storage And Transport
Nivector FTI26 Installation 4.2.2 Nameplate Company logo Device name Manufacturer address Order code Order code: Serial number Ser. no.: Marking for test magnet Ext. ord. cd.: Extended order code Supply voltage Signal output I max. Process and ambient temperature 40 bar... -
Page 12: Mounting The Measuring Device
Installation Nivector FTI26 A miniature contactor, a solenoid valve or a programmable logic controller (PLC) can be connected directly to the point level switch. A0035880 3 Application examples Overfill prevention or upper level detection (MAX) Dry-running protection or lower level detection (MIN) Mounting the measuring device 5.2.1... - Page 13 Nivector FTI26 Installation G 1" ≥20 (0.8) A0036360 5 Where buildup occurs on the silo wall with internal G 1" threaded adapter G 1" ≥20 (0.8) A0036359 6 Bore hole in silo wall with lock nuts, can be ordered as an accessory G 1"...
- Page 14 Installation Nivector FTI26 < = 1 C - B A0036363 8 Installation with Tri-Clamp, which can be ordered as an accessory, and with NA Connect adapter provided by customer Distance between Tri-Clamp and NA Connect adapter Diameter of Nivector...
-
Page 15: Post-Installation Check
Nivector FTI26 Installation 0.6 Nm A0035999 View with ground terminal Can also be ordered as an accessory G 1" ≥20 (0.8) A0036433 10 Installation with protection cover, included in scope of delivery for hazardous areas or can be ordered as an accessory Post-installation check ... -
Page 16: Electrical Connection
Electrical connection Nivector FTI26 Electrical connection Connection conditions The measuring device has two modes of operation: • Maximum point level detection (MAX): e.g. for overfill prevention The device keeps the electrical switch closed as long as the sensor is not yet covered by medium. - Page 17 Nivector FTI26 Electrical connection Electrical connection Operating mode (SIO mode with factory setting) M12 plug 0.5A 0.5A L– L– L+ Symbols Description Yellow LED (ye) lit Yellow LED (ye) not lit External load Function monitoring With two-channel evaluation, functional monitoring of the sensor is also possible in addition to level monitoring provided that no other monitoring option has been configured via IO-Link.
-
Page 18: Valve Plug
Electrical connection Nivector FTI26 Valve plug Depending on the assignment of the connector or the wiring of the cable, the device works in either the MAX or MIN operating mode. Electrical connection Mode of operation Valve plug – – 0.5A 0.5A... -
Page 19: Operation Options
7.1.2 Structure of the operating menu The menu structure has been implemented according to VDMA 24574-1 and complemented by Endress+Hauser-specific menu items. Commissioning If an existing configuration is changed, measuring operation continues! The new or modified entries are only accepted once the setting has been made. -
Page 20: Function Check
Commissioning Nivector FTI26 WARNING Risk of injury and damage to property due to uncontrolled activation of processes! ‣ Make sure that downstream processes are not started unintentionally. Function check Before commissioning your measuring point, ensure that the post-installation and post- connection checks have been performed: •... - Page 21 Nivector FTI26 Commissioning Apply operating voltage to the device The green and red LEDs flash at a frequency of 1.5Hz The LEDs stop flashing after 5s After 10s the green and red LEDs flash at a frequency of 3Hz The LEDs stop flashing after 20s Remove test magnet.
- Page 22 Commissioning Nivector FTI26 8.3.4 Function test Carry out a function test while the device is in operation. ‣ Hold the test magnet against the marking on the housing for at least 2 seconds. This inverts the current switch status, and the yellow LED changes state. When the magnet is removed, the switching status valid at that time is adopted.
- Page 24 *71450817* 71450817 www.addresses.endress.com...
