Frigidaire FEF366C Factory Parts Catalog

Electric
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FEF366CBA
FEF366C
FEF366CQA
FEF366C
FEF366CSA
FEF366C
SERVICE DATA SHEET - # 316218506
WIRING DIAGRAM - #316255173
OWNER'S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
30" f/s elec
black
30" f/s elec
bisque
30" f/s elec
white
Publication No.
5995389581
030429
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
MARKET
North America
North America
North America
ELECTRIC
RANGE
Model No.
FEF366C
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FEF366C

Summary of Contents for Frigidaire FEF366C

  • Page 1 PRODUCT NO. BASE MODEL NO. FEF366CBA FEF366C FEF366CQA FEF366C FEF366CSA FEF366C SERVICE DATA SHEET - # 316218506 WIRING DIAGRAM - #316255173 OWNER’S GUIDE - # 316257105 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917...
  • Page 2 Publication No. FEF366C 5995389581 BACKGUARD 04/03...
  • Page 3 A = FEF366C (FEF366CSA) B = FEF366C (FEF366CBA) C = FEF366C (FEF366CQA) POS. NO 20 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF366C BACKGUARD PART NO DESCRIPTION 316239900 A B C Shield,backguard ,rear wall...
  • Page 4 Publication No. FEF366C 5995389581 BODY 04/03...
  • Page 5 A = FEF366C (FEF366CSA) B = FEF366C (FEF366CBA) C = FEF366C (FEF366CQA) POS. NO 12 # 18 # 37 # 62 # 66 # 67 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF366C...
  • Page 6 Publication No. FEF366C 5995389581 TOP/DRAWER 04/03...
  • Page 7 A = FEF366C (FEF366CSA) B = FEF366C (FEF366CBA) C = FEF366C (FEF366CQA) POS. NO 15 # 15A# 15B# # = Fast-moving Parts * = Non-Illustrated Parts FEF366C TOP/DRAWER PART NO DESCRIPTION 316011503 A B C Drawer 316231500 A B C...
  • Page 8 Publication No. FEF366C 5995389581 DOOR 04/03...
  • Page 9 A = FEF366C (FEF366CSA) B = FEF366C (FEF366CBA) C = FEF366C (FEF366CQA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF366C DOOR PART NO DESCRIPTION 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil 5303935191 - B -...

  • Page 10: Wiring Schematic

    Publication No. FEF366C 5995389581 WIRING SCHEMATIC 04/03...

  • Page 11: Wiring Diagram

    FEF366C Publication No. 5995389581 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
