30" ELECTRIC DROP-IN RANGE INSTALLATION INSTRUCTIONS
INSTALLATION AND SERVICE MUST BE PERFORMED BY
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Shave Raised
Edge To Clear
30" (76.2 cm)
Wide Cooktop Rim
1-½ " Max.
(3.8 cm Max.)
Locate
Cabinet Doors
1" Min. from
C
Cut-Out
Opening
*Note:
29" (73.7 cm)
Wide Opening
For Overlapping
Cooktop And
Built-In Look
Do not pinch the power supply cord between the range and
the wall.
Do not seal the range to the side cabinets.
**NOTE: 24" (61 cm) minimum clearance between the
cooktop and the bottom of the cabinet when the bottom of
wood or metal cabinet is protected by not less than 1/4" (0.64
cm) flame retardant millboard covered with not less than No.
28 MSG sheet metal, 0.015" (0.4 mm) stainless steel, 0.024"
(0.6 mm) aluminum, or 0.020" (0.5 mm) copper.
30" (76.2 cm) minimum clearance when the cabinet is
unprotected.
(45.7 cm)
FRONT
OF
CABINET
Recycled paper
A QUALIFIED INSTALLER.
30"
(76.2 cm Min.)
30" Min.**
(76.2 cm Min.)
18" Min.
(45.7 cm Min.)
A
30"
(76.2 cm)
Exact
Approx. 1-7/8"
B
(4.8 cm)
Grounded Junction Box
in adjoining cabinet
22 7/8"
(58.1 cm)
1 1/8"
B
Ref.
NOTE: Two sets of holes are provided
under anti-tip bracket. Bracket is attached
in the upper hole position at the factory.
24" Min.
(61 cm Min.)
A. MINIMUM
CUTOUT WIDTH
29" (73.7 cm)
Figure 1
Printed in Canada
1
Smoothtop Models
B. CUTOUT DEPTH
C. HEIGHT OF
(According to front
CUTOUT
of cabinet)
21 ¾" (55.2 cm)
29" (73.7 cm)
20" (50.1 cm)
P/N 318201601 (0003) Rev. A
English - pages 1-4
Español - páginas 5-8
29-3/8"
(74.6 cm)
