All manuals and user guides at all-guides.com Operating instructions DISHWASHER Contents Installation, 2-3 Positioning and levelling Connecting the water and electricity supplies Advice regarding the first wash cycle Technical data Description of the appliance, 4 Overall view Control panel Loading the racks, 5 Lower rack Cutlery basket Upper rack...
All manuals and user guides at all-guides.com Installation Positioning and levelling see the Assembly instruction sheet see Assistance see adjacent information Connecting the water and electricity supplies New Acqua Stop see figure...
All manuals and user guides at all-guides.com Advice regarding the first wash cycle chapter entitled Rinse aid and refined salt see chapter entitled Rinse aid and refined salt see figure Technical data width 60 cm Dimensions height 85 cm depth 60 cm Capacity 14 standard place-settings Water supply...
All manuals and user guides at all-guides.com Description of the appliance Overall view Upper rack Upper sprayer arm Tip-up compartments Rack height adjuster Lower rack Lower sprayer arm Cutlery basket Washing filter Salt dispenser Detergent and rinse aid dispensers Data plate Control Panel Control panel Half load button and...
All manuals and user guides at all-guides.com Loading the racks After loading the appliance, check that the sprayer arms can rotate freely. Lower rack Loading examples. The height of the upper rack should ideally be adjusted WHEN THE RACK IS EMPTY. Never lift or lower the rack on one side only.
All manuals and user guides at all-guides.com Start-up and use Starting the dishwasher Measuring out the detergent see below see Loading the racks see Table of wash cycles see adjacent information washing fixed light AUTO WASH CYCLES Compartment A: Compartment B: Table of wash cycles...
All manuals and user guides at all-guides.com Wash options* The OPTIONS may only be set, modified or reset after the wash cycle has been selected and before the Start/ Pause button has been pressed. see Table of wash cycles Remember to load the upper rack only, and to reduce the amount of detergent accordingly.
All manuals and user guides at all-guides.com Wash cycles If the crockery is only lightly soiled or if it has been rinsed with water before being placed in the dishwasher, reduce the amount of detergent used accordingly. The number and type of wash cycles and options may vary depending on the dishwasher model. Detergent Wash Wash cycle...
All manuals and user guides at all-guides.com Rinse aid and refined salt Only use products which have been specifically designed for dishwashers. Do not use table salt or industrial salt, or washing up liquid. Follow the instructions given on the packaging. ON/OFF we recommend that you add salt, especially if you live in an area where the water is hard or...
All manuals and user guides at all-guides.com Care and maintenance Clean the water inlet filter at the tap outlet regularly. - Turn off the water tap. - Unscrew the end of the water inlet hose, remove the filter and clean it carefully under running water. - Replace the filter and screw the water hose back into position.
All manuals and user guides at all-guides.com Precautions and advice Saving energy and respecting the environment General safety see Wash cycles Table of wash cycles see Start-up and use see Start-up and use Disposal...
All manuals and user guides at all-guides.com Troubleshooting Malfunction: Possible causes / Solutions: The dishwasher does not start. • T h e p l u g h a s n o t b e e n i n s e rt e d i n t o t h e e l e c t ri c a l s o c k e t p ro p e rly, o r t h e re i s n o p o w e r i n t h e h o u s e .
The type of malfunction. The appliance model (Mod.). The serial number (S/N). This information can be found on the appliance data plate (see Description of the appliance). ARISTON GENUINE ACCESSORIES PRIORITY SERVICE & SPARE PARTS If you are not completely satisfi ed...
Page 14
All manuals and user guides at all-guides.com...
Page 15
All manuals and user guides at all-guides.com...
Page 16
All manuals and user guides at all-guides.com 195078519.00 05/2009 - Xerox Fabriano...
