MODEL G0950
48" PAN & BOX BRAKE
OWNER'S MANUAL
(For models manufactured since 08/21)
COPYRIGHT © OCTOBER, 2021 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#KS22042 PRINTED IN CHINA
V1.10.21

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G0950

Summary of Contents for Grizzly G0950

  • Page 1 (For models manufactured since 08/21) COPYRIGHT © OCTOBER, 2021 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #KS22042 PRINTED IN CHINA V1.10.21...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........................2 Contact Info ..........................2 Manual Accuracy ........................2 Identification ..........................3 Controls & Components ......................4 Machine Data Sheet ........................5 SECTION 1: SAFETY ........................6 Safety Instructions for Machinery ....................6 Additional Safety for Pan & Box Brakes ..................8 SECTION 2: SETUP .........................

  • Page 4: Introduction

    ID label (see below). This information is required for us to provide proper tech support, and it helps us determine if updated documentation is available for your machine. Manufacture Date Serial Number Model G0950 (Mfd. Since 08/21)

  • Page 5: Identification

    Clamping Finger Clamping (1 of 16) Leaf Bending Block Bending Handles Setback Wheel (1 of 2) Clamping Handles Counterweight Bending Leaf To reduce your risk of serious injury, read this entire manual BEFORE using machine. Model G0950 (Mfd. Since 08/21)

  • Page 6: Controls & Components

    Crushing hazard! Always Fingers can be individually removed or repo- keep hands clear when sitioned to allow clearance for workpiece. using this machine. D. Bending Block: Pivots with bending leaf to produce bend in workpiece. Model G0950 (Mfd. Since 08/21)

  • Page 7: Machine Data Sheet

    MACHINE DATA SHEET Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0950 48" PAN AND BOX BRAKE Product Dimensions: Weight................................313 lbs. Width (side-to-side) x Depth (front-to-back) x Height..............78-1/2 x 18 x 31 in.

  • Page 8: Section 1: Safety

    Never operate under the influence of drugs or injury or blindness from flying particles. Everyday alcohol, when tired, or when distracted. eyeglasses are NOT approved safety glasses. Model G0950 (Mfd. Since 08/21)
  • Page 9 Make sure they are properly installed, you experience difficulties performing the intend- undamaged, and working correctly BEFORE ed operation, stop using the machine! Contact our operating machine. Technical Support at (570) 546-9663. Model G0950 (Mfd. Since 08/21)

  • Page 10: Additional Safety For Pan & Box Brakes

    If normal safety pre- respect. Failure to do so could result in cautions are overlooked or ignored, seri- serious personal injury, damage to equip- ous personal injury may occur. ment, or poor work results. Model G0950 (Mfd. Since 08/21)

  • Page 11: Section 2: Setup

    To reduce this risk, you are completely satisfied with the machine and get help from other people have resolved any issues between Grizzly or the and use a forklift (or other shipping agent. You MUST have the original pack- lifting equipment) rated for aging to file a freight claim.

  • Page 12: Inventory

    NOTICE Avoid harsh solvents like acetone or brake parts cleaner that may damage painted sur- faces. Always test on a small, inconspicu- ous location first. Figure 5. Loose inventory. -10- Model G0950 (Mfd. Since 08/21)

  • Page 13: Cleaning Fingers

    When done, make sure the fingers are properly aligned (refer to Aligning Fingers on Page 14). -11- Model G0950 (Mfd. Since 08/21)

  • Page 14: Lifting & Placing

    2x4 to secure clamping leaf. Flat Washer Use forklift to raise machine, then place onto workbench. Machine Base Fasten machine to workbench following Workbench instructions in Bench Mounting. Figure 11. "Direct Mount" setup. -12- Model G0950 (Mfd. Since 08/21)

  • Page 15: Section 3: Operations

    Read books/magazines or get formal training before beginning any proj- ects. Regardless of the content in this sec- tion, Grizzly Industrial will not be held liable for accidents caused by lack of training. -13- Model G0950 (Mfd. Since 08/21)

  • Page 16: Spacing Fingers

    Figure 12. Example of finger spacing. Align finger parallel with clamping surface Align remaining fingers and tighten cap and bending block, and then tighten cap screws. screw. -14- Model G0950 (Mfd. Since 08/21)

  • Page 17: Adjusting Setback

    22 gauge. G0950 material gauge capacities are listed on the Machine Data Sheet on Page 5.) Tip: If you find it hard to turn setback wheels with your fingers, insert a hex wrench into the holes on edges of wheels to gain leverage.

  • Page 18: Adjusting Clamping Pressure

    If necessary, repeat Steps 1–4 until proper clamping pressure is achieved. Note: Proper clamping pressure is achieved when the clamping handle "snaps" (or locks) into position against handle stop (see Figure 16). -16- Model G0950 (Mfd. Since 08/21)

  • Page 19: Basic Bending

    Always wear leather gloves To perform basic bending operations: when handling sheet metal, and always chamfer and Determine setback required for bend and deburr the edges. adjust machine if needed (refer to Adjusting Setback on Page 15). -17- Model G0950 (Mfd. Since 08/21)

  • Page 20: Bending Allowance

    12-gauge steel. — For less weight leverage, extend narrow end of counterweight beyond bottom of Items Needed: counterweight collar until desired weight is Additional Person ..........1 achieved. Hex Wrench 8mm ..........1 -18- Model G0950 (Mfd. Since 08/21)

  • Page 21: Section 4: Accessories

    T-9 12 Oz. Spray ® To reduce this risk, only install accessories H3788—G96 Gun Treatment 12 Oz. Spray ® recommended for this machine by Grizzly. H3789—G96 Gun Treatment 4.5 Oz. Spray ® NOTICE Refer to our website or latest catalog for additional recommended accessories.

  • Page 22: Section 5: Maintenance

    Lubrication Clamping Leaf Pivots For optimum performance from this machine, this maintenance schedule must be strictly followed. Oil Type ..Grizzly T26685 or ISO 32 Equivalent Oil Amount ...........1–2 Drops Ongoing Lubrication Frequency ..Daily, or As Needed To minimize your risk of injury and maintain proper...

  • Page 23: Section 6: Service

    1. Machine capacities exceeded. 1. Use sheet metal gauge/thickness size within machine moves while capacities (Page 5). bending. 2. Clamping pressure not correctly adjusted. 2. Correctly adjust clamping pressure for workpiece thickness (Page 16). -21- Model G0950 (Mfd. Since 08/21)

  • Page 24: Aligning Bending Block

    (1 of 5) Figure 23. Location of hex bolts for aligning bending block. Align bending block flush with top of bending leaf, and then tighten hex bolts. -22- Model G0950 (Mfd. Since 08/21)

  • Page 25: Section 7: Parts

    FLAT WASHER 16MM P0950016 ECCENTRIC SHAFT P0950034 HEX WRENCH 6MM P0950017 ECCENTRIC BUSHING P0950035 HEX WRENCH 8MM P0950018 BENDING LEAF PIVOT SHAFT BUY PARTS ONLINE AT GRIZZLY.COM! -23- Model G0950 (Mfd. Since 08/21) Scan QR code to visit our Parts Store.

  • Page 26: Labels & Cosmetics

    For replacements, contact (800) 523-4777 or www.grizzly.com. We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability. BUY PARTS ONLINE AT GRIZZLY.COM! -24- Model G0950 (Mfd.

  • Page 27: Warranty & Returns

    WARRANTY & RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
