7. FIELD WIRING
INSTALLATION
The C-5 Module is installed in series between the Boiler
Control and the ignition module.
Refer to the wiring diagram for the required wire connections
on the boiler.
Disconnect the ignition connection pins listed below from
the boiler, cut off the female spade lugs, strip back the wire
1/4 inch, and reconnect to connector P3 of the C-5 board.
From:
Boiler Ignition
Color
Module Pin #
1
Violet/Black
Yellow/
2
Black
3
Red/Black
4
5
Yellow
6
Blue
Connect 24 VAC power to the C-5 board:
From:
Color
Boiler Power
24 Hot
Blue
24 Return
Yellow
Connect reset switch (N/O):
From:
Color
Switch
Wiper
Yellow/Red
N/O
Yellow/Red
8
To:
Name
C-5, P3
Pin #
MV
1
MV/PV
2
PV
3
GND
4
24 VAC (GND)
5
24 VAC (HOT)
6
To:
Name
C-5, P1
Pin #
24 Hot
1
24 Return
3
To:
C-5, P2 Pin #
1
2
UNCONTROLLED DOCUMENT IF PRINTED
APPROVED
8. INSTALLATION
VERIFICATION
PROCEDURE
Register
Before proceeding any further, please verify that the user
registration form has been completed and mailed.
Mechanical Installation
Verify that the mechanical installation has been completed
in accordance with the instructions.
System Module Installation
Verify electrical power wiring connections.
Verify electrical connection torque requirements.
Verify Power Test has been completed successfully.
9. POWER TEST
Check Power
Utilizing a Volt-Ohm-Meter (VOM) monitor the following
on the Boiler for proper voltage levels. See "Check Your
Power Source" on page 6.
10. REPLACEMENT PARTS
The following kits are offered for replacing components of
the C-5 module:
Kit #
Description
005641F
Kit, Test/Reset Switch
006203F
Kit, PC Board, C-5 Latching Lockout
