Russound CA-LCD Instruction Manual

7) IR confirmation LED: This LED will flash to confirm the reception of an IR
signal from a remote control through the IR receiver.
8) IR receiver: The IR receiver is used to receive commends from an IR
remote control. Remote controls used for the source equipment will pass
through to the main controller and on to the source equipment. The cen-
ter frequency for the IR receiver is 40KHz. It will receive IR signals from
38KHz to 42KHz. To control the functions of the CA-LCD keypad, use the
CA Remote control. The CA remote control will operate the lamp, source
selection, volume up / down and room on / off.
Figure 5
ROOM
ON OFF
1 2
LISTEN TO
SOURCE
3 4
VOLUME
CA LCD RC
CAUTION
These service instructions are for use by qualified personnel only. To reduce
the risk of electric shock do not perform any servicing other than that con-
tained in the operating instructions unless you are qualified to do so.
IMPORTANT SAFETY INSTRUCTIONS
Do not install near any heat source such as radiators, heat registers, stoves
or other apparatus (including amplifier) that produce heat. Only use attach-
ments/accessories specified by the manufacturer. Keep these instructions.
Follow all instructions.
VOLUME
SOURCE
STORE POWER
REMOTE SENSOR
LIMITED WARRANTY
The Russound CA-LCD is fully guaranteed for Two (2) years from the date of purchase against all
defects in materials and workmanship. During this period Russound will replace any defective parts
and correct any defect in workmanship without charge for either parts or labor. For this warranty to
apply, the unit must be installed and used according to its written instructions. If service is necessary,
it must be performed by Russound. The unit must be returned to Russound at the owner's expense
and with prior written permission. Accidental damage and shipping damage are not considered
defects under the terms of the warranty. Russound assumes no responsibility for defects resulting
from abuse or servicing performed by an agency or person not specifically authorized in writing by
Russound. Damage to or destruction of components due to improper use voids the warranty. In these
cases the repair will be made at the owner's expense. To return for repairs, the unit must be shipped
to Russound at the owner's expense, along with a note explaining the nature of the service required.
Be sure to pack in a corrugated container with at least 3 inches of resilient material to protect the
unit from damage in transit.
5 Forbes Rd. Newmarket, NH 03857, USA
☎ 603.659.5170 • Fax 603.659.5388
e-mail: tech@russound.com
CA-System Digital
Display Keypad
CA-LCD
Instruction Manual
Come visit us at:
Russound
Conforms to CA-LCD
UL 6500
Tested to Comply
Certified to
with FCC Standards
CAN/CSA
E65-94
FOR HOME OR OFFICE USE
