- Page 1 AM/FM Home 4:30 PM Now Playing Shared Sources Favorites Alarm Sleep Timer HOME MENU MDK-C5 Multiline Display Keypad Russound User and Installation Manual...
-
Page 2: Product Information Safety
Use the right power source. Don’t connect the product directly to electrical line voltage. Use only the power If you have any questions, call Russound at 1.800.638.8055 adapter provided with the product, described in the or 603.659.5170. -
Page 3: Table Of Contents
Playlist, Channel, Station, Artist, Song Title, Genre, Warranty ..................14 and more from the RNET audio sources. The MDK-C5 is designed to control an MCA-C5 controller amplifier multiroom audio system as well as future C-series controllers. It controls Russound RNET sources, including the SMS3 Smart Media Server, iBridge™... -
Page 4: Keypad Front View
OK - Press to select highlighted item Menu Navigation - Navigate through from the menu, or access source list menus, press (slow) or press and hold from Now Playing (fast) to move up/down a menu list MDK-C5 Keypad (front) Russound MDK-C5 User and Installation Manual... -
Page 5: Using The System
If you change the selection (song, channel, playlist) on that source, the change will also happen in the other "Shared" room. AM/FM 4:30 PM Home Now Playing Shared Sources Favorites Alarm Sleep Timer Russound MDK-C5 User and Installation Manual... - Page 6 Turn off active alarm - Press the power button on the Alarm keypad or SRC-C5 remote. Shared Sleep Timer Snooze - Press the play/pause button on the keypad or Party Mode the pause button on the SRC-C5 remote control. Do Not Disturb Settings Russound MDK-C5 User and Installation Manual...
- Page 7 "Clock." Choose "Clock Format," and select 12 hour (AM/PM) or 24 hour (1200) format. AM/FM Set Time 10:25 AM : 45 PM use + & - for Numbers use | & | for Cursor press OK to Save Russound MDK-C5 User and Installation Manual...
-
Page 8: Keypad Rear View
IR receiver OS Update Jumper - Selects Programming Port - Insert cable here for "Run" or "Program" mode firmware updates. Requires Advanced Programming Cable P/N 2500-521065. MDK-C5 Keypad (rear) Russound MDK-C5 User and Installation Manual... -
Page 9: Color Plate Conversion
Reverse the order for installation, taking the following If installed, remove the MDK-C5 keypad from the precautions: wall. Gently pull the Trim Plate off the mounting a. Make sure the button key mat is positioned properly plate. -
Page 10: External Ir Connection
AM/FM Front IR 11:30 AM The MDK-C5 keypad has an External IR Receiver In terminal for connecting an external IR Receiver such as the Russound 858, SaphIR 862 Eye, or SaphIR 860 Phantom. Use 2 twisted pair wire with one pair connecting GND (GROUND) and IR (SIGNAL) and the other pair connecting ST (STATUS) and V+ (+12VDC). -
Page 11: Keypad Installation
KEYpAD INSTALLATION Keypad Installation For best viewing and usage, the MDK-C5 should be mounted at thermostat height, or about 58"-60" (1.5m) from the floor. To install a double-gang keypad, you will need a UL/CSA approved plastic 32ci double-gang wall box. Attach the box to the wall with appropriate fasteners. -
Page 12: Controller / Keypad Connection
CONTROLLER / KEYpAD CONNECTION Controller / Keypad Connection The MDK-C5 keypad is designed for use with the C-Series If more keypads are desired for a zone, use an optional controllers, and connects to a keypad port near the top SA-ZX3 keypad splitter with a Russound 1201A (12VDC1A) left on the rear of the controller. -
Page 13: Technical Specifications
Controls: Eleven backlit hard buttons Wall surface dimensions: 4.5"W x 4.5"H (11.43 x 11.43 cm) Inside box dimensions: 3.5"W x 1.5"D x 2.75"H (8.9 x 3.8 x 6.9 cm) Weight: 1 lbs. (0.45 kg) Russound MDK-C5 User and Installation Manual... -
Page 14: Warranty
To return for repairs, the correct any defect in workmanship without charge for either unit must be shipped to Russound at the owner’s expense, parts or labor. along with a note explaining the nature of service required. - Page 15 NOTES Russound MDK-C5 User and Installation Manual...
