  • Page 1 LAGAN...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Energy efficiency Daily use Environmental concerns Using the accessories IKEA guarantee Additional functions Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.

  • Page 5: Safety Instructions

    ENGLISH WARNING: Keep children and pets away from the appliance • when it operates or when it cools down. Accessible parts become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance •...
  • Page 6 ENGLISH • Follow the installation instructions supplied with the appliance. Mounting screws 2x25 mm • Always take care when moving the appliance as it is heavy. Always use safety Electrical connection gloves and enclosed footwear. • Do not pull the appliance by the handle. Warning! Risk of fire and electric •...
  • Page 7 ENGLISH • This appliance is for cooking purposes only. It must not be used for other Warning! Risk of injury, burns purposes, for example room heating. and electric shock or explosion. • Always cook with the oven door closed. • If the appliance is installed behind a •...

  • Page 8: Installation

    ENGLISH are not intended to be used in other • Disconnect the appliance from the mains applications and are not suitable for supply. household room illumination. • Cut off the mains electrical cable close to • Use only lamps with the same the appliance and dispose of it.

  • Page 9: Product Description

    ENGLISH Product description General overview Control panel Knob for the heating functions Control knob Temperature indicator Air vents for the cooling fan Grill Lamp Rating plate Shelf positions Accessories • Baking tray x 1 For cakes and biscuits. • Wire shelf x 1 For cookware, cake tins, roasts.

  • Page 10: Daily Use

    ENGLISH Screw back the screw into the hole after 2. Open the door. removing the child lock. Close the oven door without pulling the child lock. Warning! Be careful not to To remove the child lock, open the oven door scratch the control panel.

  • Page 11: Using The Accessories

    ENGLISH When you use this function the lamp automatically turns off. Using the accessories Baking tray: Warning! Refer to Safety chapters. Push the baking tray between the guide bars of the shelf support. Inserting the accessories Wire shelf: Push the shelf between the guide bars of the shelf support .
  • Page 12 ENGLISH To prevent too much smoke in the oven Initially, monitor the performance when you during roasting, add some water into the cook. Find the best settings (heat setting, deep pan. To prevent the smoke cooking time, etc.) for your cookware, condensation, add water each time after it recipes and quantities when you use this dries up.
  • Page 13 ENGLISH ECO Cooking For best results follow suggestions listed in the table below. Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Sweet rolls, 12 baking tray or dripping 35 - 40 pieces Rolls, 9 pieces baking tray or dripping 35 - 40 Pizza, frozen, wire shelf...
  • Page 14 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Muffins, 12 baking tray or dripping 30 - 40 pieces Savory pastry, 16 baking tray or dripping 35 - 45 pieces Short crust bis‐ baking tray or dripping 40 - 50 cuits, 20 pieces Tartlets, 8 pieces baking tray or dripping 20 - 30...
  • Page 15 ENGLISH Accessories Size Picture Flan base tin, dark, non-re‐ 28 cm diameter flective Information for test institutes Tests according to IEC 60350-1. Food Function Accesso‐ Shelf Temper‐ Time (min) Comments ries posi‐ ature tion (°C) Small cake Convention‐ Baking 20 - 30 Put 20 small cakes al (Top and tray...

  • Page 16: Care And Cleaning

    ENGLISH Food Function Accesso‐ Shelf Temper‐ Time (min) Comments ries posi‐ ature tion (°C) Beef bur‐ Grilling Wire shelf max. 20 - 30 Put the wire shelf and drip‐ on the third level 6 pieces, ping pan and the dripping 0.6 kg pan on the second level of the oven.
  • Page 17 ENGLISH Open the door fully Lift and turn the First lift carefully and and hold the two levers on the two then remove the door hinges. hinges with a glass panel. screwdriver. Pull the door trim to the front to remove it Clean the glass panel with water and soap.

  • Page 18: Troubleshooting

    ENGLISH 3. Turn the lamp glass cover Warning! Danger of counterclockwise to remove it. electrocution! Disconnect the fuse 4. Clean the glass cover. before you replace the lamp. 5. Replace the oven light bulb with a 25 W, The lamp and the lamp glass 230 V (50 Hz), 300 °C heat resistant oven cover can be hot.

  • Page 19: Technical Data

    Number of functions Energy efficiency Product Information Sheet according to UK Ecodesign and Energy Labelling Regulations Supplier's name IKEA Model identification LAGAN 505.178.78 Energy Efficiency Index 94.9 Energy efficiency class Energy consumption with a standard load, convention‐ 0.75 kWh/cycle al mode...

  • Page 20: Environmental Concerns

    For any additional questions not related to After Sales of your appliances, like clarifications on installation of the IKEA Read about our guarantee terms on appliance in the dedicated IKEA kitchen www.ikea.com...
  • Page 21 ENGLISH national phone numbers below/on the next page/on the last page. For quicker service, always refer to the IKEA article name and number (8-digit code) found on the rating plate of your appliance. SAVE THE SALES RECEIPT.
  • Page 22 Hétköznap 8.00 és 17.00 óra között 0900 - 235 45 32 ma-vr: 8.00 - 21.00 Nederland Geen extra kosten. (0900-BEL IKEA) zat: 9.00 - 21.00 Luxembourg 0031 - 50 316 8772 Alleen lokaal tarief. zon / pub. vakantie: 10.00 - 18.00...
  • Page 24 21552 © Inter IKEA Systems B.V. 2021 AA-2295863-1...
